True TA1RPT-1S-1S User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TA1RPT-1S-1S
TA1RPT-1S-1S
Model Doors
Capacity
(Cu. Ft.)
(liters)
Cabinet Dimensions
(inches)
(mm)
LDH
*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TA1RPT-1S-1S 2 31
878
29
737
371/4
947
781/4
1988
1/2115/60/1 10.4 5-15P 9
2.74
370
168
* Height does not include 5" (127 mm) for castors and 1" (26 mm) for system mechanical components.
8/07
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility costs
and exceptional food safety.
Oversized, factory balanced,
refrigeration system holds 33°F
to 38°F (.5°C to 3.3°C) for the
best in food preservation.
300 series stainless steel exterior
front, sides, back and bottom.
The very finest stainless with
higher tensile strength for
fewer dents and scratches.
NSF approved, white aluminum
interior sides and back liner. 300
series stainless steel door liner
and floor with coved corners.
Adjustable, heavy duty PVC
coated shelves.
Positive seal self-closing doors
with 120° stay open feature.
Lifetime guaranteed door
hinges.
Lifetime guaranteed recessed
door handles.
Entire cabinet structure and
solid doors are foamed-in-place
using high density, CFC free,
polyurethane insulation.
TA Series:
Pass Thru Reach-In Solid Door Refrigerator
R
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TA1RPT-1S-1S TFQY50E TFQY89S TFQY89P TFQY893
TA1RPT-1S-1S
DESIGN
• True’s solid door pass-thru reach-in’s are
designed with enduring quality that protects
your long term investment.
• Designed using the highest quality materials
and components to provide the user with colder
product temperatures, lower utility costs and
exceptional food safety.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary
tube system using environmentally friendly (CFC
free) 134A refrigerant.
• Extra large evaporator coil balanced with higher
horsepower compressor and large condenser
maintains cabinet temperatures of 33°F to 38°F
(.5°C to 3.3°C) for the best in food preservation.
• Sealed, cast iron, self-lubricating evaporator
fan motor(s) and larger fan blades give True
reach-in’s a more efficient low velocity, high
volume airflow design. This unique design
ensures faster temperature recovery and
shorter run times in the busiest of foodservice
environments.
• Top mounted refrigeration system with
evaporator positioned out of food zone to
maximize capacity.
• Hot gas condensate for energy efficiency.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors, front,
sides, rear and bottom.
• Interior - NSF approved white aluminum side
walls and back liner. 300 series stainless steel
floor with coved corners.
• Insulation - entire cabinet structure and solid
doors are foamed-in-place using high density,
CFC free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 4" (102 mm) diameter
stem castors - locks provided on front set.
DOORS
• Front and rear doors are 300 series stainless
steel exterior and door liners. Doors open
within cabinet dimension.
• Door locks standard.
• Lifetime guaranteed recessed door handles.
Each door fitted with 12" (305 mm) long
recessed handle that is foamed-in-place with
a sheet metal interlock to ensure permanent
attachment.
• Positive seal self-closing doors with 120° stay
open feature. Lifetime guaranteed door hinges.
• Magnetic door gaskets of one piece
construction, removable without tools for ease
of cleaning.
SHELVING
• Three (3) adjustable, heavy duty PVC coated
wire shelves 25" x 2813/16" (635 mm x
732 mm). Four (4) shelf supports included
per shelf. Shelves adjustable on 6" (153 mm)
increments.
• Four (4) different interior kits available (see Kit
Options). Pilasters and tray slides require field
installation.
LIGHTING
• Incandescent interior lighting - lights activated
by rocker switch mounted above doors, safety
shielded.
MODEL FEATURES
• Exterior digital temperature display, available
with either °F or °C.
• Evaporator epoxy coated to eliminate the
potential of corrosion.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1 phase
- 15 amp dedicated outlet. Cord and plug set
included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/flanged legs.
❒ 6" (153 mm) stainless steel legs.
❒ Stainless steel rail skirt for use with legs
(field installed).
❒ Metal door handles (factory installed).
❒ Additional shelves.
❒ Electronic temperature control (factory installed).
❒ Correctional facilities options.
❒ Curb mountable units.
❒ Remote cabinets (condensing unit supplied by others;
system comes standard with 404A expansion valve
and requires R404A refrigerant). Consult factory
technical service department for BTU information.
KIT OPTIONS
Upcharge applies. Lead times may apply.
❒Kit #1: Nine (9) sets of #1 type tray slides and pilasters
(field installed), bottom support of one (1) 18
" L x
26
" D (458 mm x 661 mm) pan or two (2) 14 " L x 18 " D
(356 mm x 458 mm) pans.
❒Kit #2: One (1) set half-section #2 steel rod tray slides
and pilasters (field installed), rim support of one (1)
18
" L x 26 " D (458 mm x 661 mm) pan.
❒Kit #3: Six (6) sets of universal type tray slides and
pilasters (field installed), bottom support of one (1)
18
" L x 26 " D (458 mm x 661 mm) pan, two (2) 14 " L
x 18
" D (356 mm x 458 mm) pans or two (2) 12 " L x
20
" D (305 mm x 508 mm) pans.
❒Kit #4: Three (3) chrome shelves 25
" L x 27
3
/ 4 " D
(635 mm x 705 mm). Four (4) shelf supports included
per shelf (field installed); adjustable on 6
" (153 mm)
increments. Optional wall mounted shelf support
pilasters (field installed) with four (4) shelf clips per
shelf available; adjustable on
1
/ 2 " (13 mm) increments
(must indicate at time of cabinet order).
❒Additional kit option components available
individually.
115/60/1
NEMA-5-15R
TR Series:
Pass Thru Reach-In
Solid Door Refrigerator
ELEVATION
783/16"
(1986 mm)
843/16"
(2139 mm)
5"
(127 mm)
1"
(26 mm)
PLAN VIEW
29"
(737 mm)
2623/32"
(679 mm)
9011/16"
(2304 mm)
371/4"
(947 mm)
77"
(1956 mm)
13/16"
(31 mm)
4"
(102 mm)
