True TGW-3 User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the next whole millimeter (inches rounded up to the next 1/8").
ROUGH-IN DATA
Field’s End Road, Goldthorpe, Nr. Rotherham, South Yorkshire S63 9EU,
England • www.truemfg.com • Tel [phone] • FAX [phone]
• Free Phone [phone] • Free Phone to U.S. 0 800 894 928
Model:
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
APPROVALS:
Printed in U.S.A.
TRUE EUROPE
AVAILABLE AT:
TGW-3
TGW-3
† Depth does not include 26 mm (1") for bumpers. ▲Plug type varies by country.
*Height does not include 127 mm (5") for castors.
Gastronorm Worktop:
Solid Door Refrigerator
12/05
Model Doors
Capacity
(liters)
(Cu. Ft.)
Shelves
Cabinet Dimensions
(mm)
(inches)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total m)
(total ft.)
Crated
Weight
(kg)
(lbs.)
TGW-3 3 456
16.1
9 1880
74
712
28
839
33
1/3230-240/50/1 3.0 ▲2.74
9
N/A
Radius
Countertop
Reversing
Air Flow
Air Flow
Keeps Your
Condenser
Clean!
Clean!
Reverse Condensing Fan Motor
ADVANCED TECHNOLOGY
ADVANCED TECHNOLOGY
True’s worktop’s are designed
with enduring quality and value
that protects your long term
investment.
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility
costs, exceptional food safety
and the best value in today’s
food service marketplace.
Oversized, environmentally
friendly (134A) force-air
refrigeration system holds .5°C
to 3.3°C (33°F to 38°F).
300 series stainless steel
exterior.
Radius countertop. Cabinet
top and backsplash - one piece
formed construction.
300 series stainless steel interior.
LED temperature display.
Front breathing.
Foamed-in-place, high density
polyurethane insulation (CFC
free).
3 sets of 1/1 gastronorm rails
with stainless steel shelves per
section.

STANDARD FEATURES
Model:
TRUE EUROPE
Field’s End Road, Goldthorpe, Nr. Rotherham, South Yorkshire S63 9EU, England • 01709 888 080 • FAX [phone] • Free Phone [phone] • Free Phone to U.S. 0 800 894 928 • www.truemfg.com
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TGW-3
TGW-3
DESIGN
• True’s commitment to using the
highest quality materials and
oversized refrigeration systems
provides the user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
134A refrigerant.
• Oversized, factory balanced
refrigeration system with guided
airflow to provide uniform product
temperature.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains
cabinet temperatures of .5°C to 3.3°C
(33°F to 38°F) for the best in food
preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motors and larger
fan blades give True worktop units
a more efficient low velocity, high
volume airflow design. This unique
design insures faster temperature
recovery and shorter run times in the
busiest of food service environments.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel.
• Interior - 300 series stainless steel.
• Countertop - heavy 16 gauge
stainless radius front. Cabinet
top and backsplash - one piece
formed construction. Bacteria and
food particles can not be trapped
underneath as with other two-piece
worktop units.
• Insulation - entire cabinet structure
and solid doors are foamed-in-
place using high density, CFC free,
polyurethane insulation.
• 102 mm (4") diameter stem castors -
locks provided on front set. 866 mm
(341/16") work surface height.
DOORS
• Stainless steel.
• Positive seal self-closing doors with
90° stay open feature. Doors swing
within cabinet dimensions.
• Each door fitted with 305 mm (12")
long recessed handle that is foamed-
in-place with a sheet metal interlock
to insure permanent attachment.
• Magnetic door gaskets of one piece
construction, removable without
tools for ease of cleaning.
SHELVING
• Three (3) sets of 1/1 gastronorm rails
per section.
• Three (3) stainless steel shelves
324 mm L x 534 mm D (123/4" x 21")
per section.
MODEL FEATURES
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
• Self-contained condensate pan. No
need for external drain.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for final connection to a
230-240/50/1 phase dedicated outlet.
Cord and plug set included.
• Plug type varies by country.
OPTIONAL FEATURES/ACCESSORIES
❒64 mm (21/2") diameter castors.
❒153 mm (6") standard legs (requires
leg mounting plates).
❒153 mm (6") seismic/flanged legs
(requires leg mounting plates).
Gastronorm Worktop:
Solid Door Refrigerator
26 mm
(1")
324 mm
(123/4")
229 mm
(9")
ELEVATION
127 mm
(5")
1097 mm
(435/32")
385 mm
(155/32")
RIGHT VIEW
1879 mm
(7315/16")
67 mm
(25/8")
712 mm
(28")
964 mm
(3715/16")
610 mm
(24")
1122 mm
(445/32")
61 mm
(23/8")
101 mm
(315/16")
864 mm
(34")
23 mm
(7/8")
737 mm
(29")
837 mm
(3215/16")
