True TS-28 User manual

FEATURES/BENEFITS
Toll Free Number • 1-800-325-6152
True Website: www.truemfg.com Parts Department • 1-800-424-TRUE
TS-28-2-G-2-PT
TS-53-4-G-4-PT
Deep TS Series
•Oversized and balanced, environmentally
friendly (134A), refrigeration system, fac-
tory sealed and pre-lubricated for long life
- holds 33°F to 38°F.
•The utility of the “TS” series pass-thru is in its
ability to be a server station for cold dishes.
Designed to become a central station, rear-
loaded from the kitchen prep area to be
front-accessed by servers.
•Shelving - (3) chrome shelves per section
at no charge (includes four knob style shelf
supports per shelf (shipped separately). (4)
alternative interior options available.
• Pilasters and tray slides - are to be field
installed for TS series deep reach-in’s.
(pilasters and tray slides ship separate)
•Door locks standard.
•Energy efficient, “Low-E”, thermal glass
on glass door models.
•Lifetime guaranteed recessed door han-
dles on solid rear doors.
•300 series stainless steel interior and
exterior front & sides, with matching alumi-
num back (stainless steel rear doors on pass-
thru models).
•Solar, digital thermometer standard for
easy visibility.
•Positive seal self-closing doors with fac-
tory tested (over 1,000,000 times) lifetime
guaranteed door hinges and torsion type
closure system.
•Extruded, aluminum door frames on glass
doors.
•Fluorescent interior lighting; integrated
door light (IDL) standard on glass & combi-
nation door models.
•Incandescent interior lighting standard on
solid door models.
•Foamed-in-place polyurethane high density
cell insulation (CFC free).
•4” diameter swivel castors standard equip-
ment. 6” legs available.
•Self-contained system.
Bottom Mounted Units Have...
•A “no-stoop”, lower shelf.
•Allows for top storage.
•Compressor performs in the coolest, most
grease-free area of kitchen for ease of com-
pressor load.
•Compressor can be serviced easily, and
accessed by a single repairman.
TS-28
(glass door models feature optional shelving)
†Depth does not include 13/8” for door handle (glass doors only).
* Height does not include 5” for castors or 6” for optional legs.
300 Series Stainless Steel, Deep Reach-In Refrigerators
Model Glass Doors Solid Doors Cu. Ft. Chrome Shelves HP Amps Crated Weight
Cabinet Dimensions
L D H*
SOLID DOORS
TS-28 N/A 1 front 28 3 1/37.5 350 29 x 321 / 2x 783 / 8
TS-53 N/A 2 front 53 6 1/211.8 525 511 / 4x 321 / 2x 783 / 8
SOLID HALF DOORS
TS-28-2 N/A 2 front 28 3 1/37.5 250 29 x 321 / 2x 783 / 8
TS-53-4 N/A 4 front 53 6 1/211.8 500 511 / 4x 321 / 2x 783 / 8
All dimensions rounded up to the nearest 1/8”.
300 Series Stainless Steel, Deep Pass-Thru Refrigerators
Model Glass Doors Solid Doors Cu. Ft. Chrome Shelves HP Amps Crated Weight
Cabinet Dimensions
L D† H*
SOLID FRONT DOORS/SOLID REAR DOORS
TS-28-PT N/A 1 front/1 back 28 3 1/29.9 390 29 x 351 / 8x 783 / 8
TS-53-PT N/A 2 front/2 back 53 6 1/211.8 545 511 / 4x 351 / 8x 783 / 8
SOLID FRONT HALF DOORS/SOLID REAR DOORS
TS-28-2-PT N/A 2 front/1 back 28 3 1/29.9 415 29 x 351 / 8x 783 / 8
TS-53-4-PT N/A 4 front/2 back 53 6 1/211.8 575 511 / 4x 351 / 8x 783 / 8
GLASS FRONT DOORS/SOLID REAR DOORS
TS-28G-PT 1 front 1 back 28 3 1/210.1 425 29 x 351 / 4x 783 / 8
TS-53G-PT 2 front 2 back 53 6 1/211.8 620 511 / 4x 351 / 4x 783 / 8
GLASS FRONT HALF DOORS/SOLID REAR DOORS
TS-28-2-G-2-PT 2 front 2 back 28 3 1/210.1 430 29 x 351 / 4x 783 / 8
TS-53-4-G-4-PT 4 front 4 back 53 6 1/211.8 610 511 / 4x 351 / 4x 783 / 8
All dimensions rounded up to the nearest 1/8”.
Remote cabinets available 14% off list (condensing units
supplied by others; system comes standard with
404A expansion valve and requires R404A refrigerant).
Consult factory technical service dept. for BTU information.
* Height does not include 5” for castors or 6” for optional legs.
