True CS800 User manual

Assembly Instructions
15 INCH LCD with TOUCHSCREEN
DISPLAY ASSEMBLY INSTRUCTIONS
Display Assembly Instructions cover the
three TRUE Fitness series of products below.
Treadmills Page 1
Bikes and Ellipticals: Page 6
Changing units between English & Metric: Page 10
TV Tuner Programming: Page 11
NTSC / ATSC Tuner Version

Assembly Instructions
1
Important TV Signal Requirement –NTSC / ATSC TUNER (PS850 Touchscreen does not have TV tuner option)
Please note for optimal TV image results, sufficient signal strength must be received by the 15 Inch LCD
with Touch Screen display. It is the responsibility of the customers’ facility to provide the minimum signal
strength values listed below to each individual exercise machine.
dBmV dBm dBuV dBmV dBm dBuV
0 -48.8 60 -10 -58.8 50
15.5 -33.3 75.5 15.5 -33.3 75.5
NTSC / ATSC TUNER - 75 ohm
MAXIMUM --->
TUNER ---->
SIGNAL FORMAT --->
MEASUREMENT UNIT --->
MINIMUM --->
NTSC (analog)
ATSC (digital)
Basic Guidelines for Setting Up Your Exercise Equipment
After removing the exercise equipment from the packaging, place unit on a clean, level surface. Make sure
the electrical cord easily reaches a grounded three-pronged outlet and has enough slack to allow the deck
to incline without tightening the cord. Do not allow the exercise equipment to rest on the power cord.
Important Electrical Requirements
Your TRUE exercise equipment may require a dedicated and grounded outlet circuit. This means nothing
else can be plugged into the same circuit. Please reference your exercise equipments assembly
instructions and owners manual for specific information on your model.
Danger: Do not use an extension cord or ungrounded outlet.
The ground helps prevent electrical damage to your exercise equipment and enhances your safety by
helping to prevent shock. Check with a qualified electrician or serviceman if you are in doubt as to whether
the exercise equipment is properly grounded. Do not modify the plug provided with the exercise equipment
if it will not fit the outlet. Have a proper outlet installed by a qualified electrician.
TOOL REQUIREMENTS (not included): ●7/16 Open End Wrench (two) ●#2 Phillips Screwdriver
CAUTION: It is recommended that two people attach display to treadmill.
NOTE: Remove Display components from packaging.
NOTE: Use the DISPLAY CONNECTION DIAGRAM and cable views in the steps below to identify exactly
where each cable is to be connected. Cables will be labeled near their connector with identifying names
such as those listed below in BOLD TEXT and in the instructions below.
Should you need technical assistance in assembly of your TRUE Fitness product, you can contact TRUE Fitness Technical
Support at 1-800-883-8783
____________________________________________________________________________________
TREADMILLS
15 INCH LCD with TOUCHSCREEN DISPLAY TREADMILL HARDWARE KIT
ITEM
DESCRIPTION
QTY
WHERE USED
a
15 inch LCD Display
1
Treadmill Display
b
Screw M5 w/ lock washer
4
Display Attachment
c
Auxiliary Power Supply
1
In Frame for Display Power
d
8 inch Wire Ties
4
Secure Power Supply
e
4 inch Wire Ties
2
Cable Management
f
Owner’s Manual CD
1
g
Warranty Card (on CD)
1

Assembly Instructions
2
TREADMILLS
NOTE: Treadmill Wiring Schematic is available on page 5.
1. Using 8 inch Wire Ties (d), install Auxiliary Power Supply per Treadmill Frame Assembly
Instructions shipped with treadmill. NOTE: 220V treadmills come equipped with the Auxiliary
Power Supply already installed.
2. Place a piece of cardboard or towel on top of Fan Housing (Console Rack for LC1100 model)
for protection.
3. Gently place display on protected Fan Housing, or Console Rack, while still continuing to hold
display.
4. Firmly hold display. Using the DISPLAY CONNECTION DIAGRAM-TREADMILL, connect the
following 9Console Rack cables to their mating cable (indicated by CABLE), or connector on the
Display (indicated by BOARD).
1 CNTRL Control Cable –BOARD
10-pin connector is polarized. Insert properly.
2 LEFTContact Heart Rate Cable - CABLE
3-Pin connectors are polarized. Insert properly.
3 RIGHTContact Heart Rate Cable - CABLE
3-Pin connectors are polarized. Insert properly.
4 SAFECable (Safety key)–black wires-BOARD
2-pin connector is polarized. Insert properly.
5 KEYSCable (Center Pod Keypad) - CABLE
6-pin connector is polarized. Insert properly.
6 GNDDisplay Ground –Console Rack
See Fig 1 on next page of GND screw location.
Position Ground lug pointing up so that it does
not interfere with the Display attachment.
7 AUXPSCable - CABLE
(DC Power Supply to display)
2-pin connector is polarized. Insert properly.

Assembly Instructions
3
8 COAXCable (Coaxial Video) - CABLE
1. Torque to 1.8 ft-lb +/- .3 ft-lb (2.5 N-m +/-0.5 N-m)
2. Slide rubber boot COMPLETELY over COAX
connection so that no metal is visible.
IMPORTANT: See Important TV Signal
Requirement on Page 1. (Not present on
PS850 model)
9 FANCable–red and black wire - CABLE
(DC Fan Power from Display)
STANDARD on CS500, CS550, CS800 models
Not available on LC1100 model
NOTE: 2-pin connector is polarized. Insert properly.
5. After cable connections are made, gently recess all excess cabling back into Console Rack neck
(where cabling exits). See Fig. 1 below.
6. Place Display onto Console Rack neck mounting flange so that flange sits in display recess.
7. Attach using four M5 screws w/ split lock washer (b).
8. Remove two small screws on right side of Fan Housing. See Fig 2 below.
9. Lift up on Cord Retainer to remove. Set Cord Retainer and screws aside.
10.Place iPod ® cable into recess on top right side of Fan Housing.
Note: iPod ® Cable is not removable from Display Front. Any attempt to remove cord could
damage cord or display front lower panel.
11.Replace Cord Retainer into Fan Housing.
12.Replace two small screws into Fan Housing.
Fig 1 Fig 2: Fan –CS Products Only
iPod® Cable
Small Screw
Cord Retainer
Secure
6 GND
here
Excess cables
nested here

Assembly Instructions
4
DISPLAY CONNECTION DIAGRAM - TREADMILL
TREADMILL OPERATION
1. Read and understand all instructions and warnings prior to use.
2. Plug in Power cord in appropriate wall outlet. (See your Assembly Instructions for outlet requirements)
3. Install Safety Key. (Reference TreadmillAssembly Instructions for proper safety key installation)
4. Flip treadmill Power switch to ON (1 on toggle switch). Allow a little over a minute for display to fully
light up.
5. Follow the on screen prompts to configure Treadmill Model Set Up and Calibration.
6. Consult Owner’s Manual for specific operation instructions.
2 LEFT
3 RIGHT
6 GND
1 CNTRL
5 KEYS
7 AUXPS
8 COAX
(NOT REQUIRED
FOR PS850 MODEL.
PS850 TOUCH
SCREEN DOES NOT
HAVE TV TUNER
OPTION)
9 FAN
STANDARD ON CS
MODELS
N/A ON LC1100
4 SAFE

Assembly Instructions
5
WIRING SCHEMATIC –TREADMILL
MODELS: CS500, CS550, CS800, ES900

Assembly Instructions
6
WIRING SCHEMATIC –TREADMILL
MODELS: PS850, LC900, LC1100

Assembly Instructions
7
BIKES and ELLIPTICALS
15 INCH LCD with TOUCHSCREEN DISPLAY HARDWARE KIT
ITEM
DESCRIPTION
QTY
WHERE USED
a
15 inch LCD Display
1
Treadmill Display
b
Screw M5 w/ lock washer
4
Display Attachment
c
Auxiliary Power Supply
1
In Frame for Display Power
d
8 inch Wire Ties
4
Secure Power Supply
e
4 inch Wire Ties
2
Cable Management
f
Fan*
1
Frame
g
Fan Grill –Plastic*
1
Console Lower Housing
h
Screw, Lock Washer, Nut*
2 each
Fan Mounting
i
Owner’s Manual CD
1
j
Warranty Card (on CD)
1
*NOTE: Optional item. Available only on Commercial Series (CS) products.
BIKES / ELLIPITICALS
1. Using 8 inch Wire Ties (d), install Auxiliary Power Supply per specific Bike or Elliptical Frame
Assembly Instructions shipped with bike or elliptical.
2. Install Fan and Fan Grill: Reference Bike or Elliptical Frame Assembly Instructions for installation.
Optional: Supplied with CS products only.
3. Firmly hold display. Using the DISPLAY CONNECTION DIAGRAM-BIKE and ELLIPTICAL, connect
the following Console Rack cables to their mating cable (indicated by CABLE), or connector on the
Display (indicated by BOARD).
1 CNTRL Control Cable –BOARD
NOTE difference in Bike and Elliptical connectors.
BIKE: 12-pin connector.
DO NOT connect green wire for this product.
ELLIPTICAL: 6-pin connector.
Connectors are polarized. Insert properly.
2 LEFTContact Heart Rate Cable - CABLE
3-Pin connectors are polarized. Insert properly.
3 RIGHTContact Heart Rate Cable - CABLE
3-Pin connectors are polarized. Insert properly.
↑BIKE
↓ELLIPTICAL
DO NOT CONNECT ON
BIKE MODELS

Assembly Instructions
8
4 GNDDisplay Ground –Console Rack
See pictures on next page of GND screw locations.
Position Ground lug pointing up so that it does
not interfere with the Display attachment.
5 AUXPSCable –CABLE
(DC Power Supply to display)
2-pin connector is polarized. Insert properly.
6 COAXCable (Coaxial Video) - CABLE
1. Torque to 1.8 ft-lb +/- .3 ft-lb (2.5 N-m +/-0.5 N-m)
2. Slide rubber boot COMPLETELY over COAX
connection so that no metal is visible.
IMPORTANT: See Important TV Signal Requirement on page 1.
7 FANCable: red and black wire - CABLE
(DC Fan Power from Display)
STANDARD on CS800 Upright and Recumbent
Bikes and CS800 Ellipticals. N/A on LC models.
NOTE: 2-pin connector is polarized. Insert properly.
4. Place Display onto Console Rack neck mounting flange so that flange sits in display recess.
5. Attach using four M5 screws w/ split lock washer (b).
6. After cable connections are made, gently recess all excess cabling into Console Rack neck (where
cabling exits).
a. For CS800 Elliptical: (see Fig 4a below).
i. These instructions will allow for an organized routing of cables,
prevent them from touching the rotating underside of Fan, and
prevent pinching cables when console housing is attached.
ii. Route red and black wires from Fan down into LEFT GAP.
Route under Fan and up through RIGHT GAP toward connection
to Fan display cable.
iii. Route COAX cable from display down into LEFT GAP.
iv. Slide all other cables into RIGHT GAP.
v. Gather cables below as shown and wire tie as shown in Fig 4a.
Be sure cables does not touch rotating underside of Fan.
FAN
FAN
WIRES
COAX
CABLE
Fig 4a
RIGHT
GAP
WIRE TIE
LEFT
GAP

Assembly Instructions
9
7. Follow Bike or Elliptical Frame Assembly Instructions for additional console housing attachments.
WARNING: Do not allow wires to be pinched when installing console housing.
Note: iPod ® Cable is not removable from Display Front. Any attempt to remove cord could
damage cord or display front lower panel.
_____________________________________________________________________________________________________________
Ground Screw Locations for Bikes
CS800 Upright & Recumbent, LC900 Upright Bike LC900 Recumbent Bike
_____________________________________________________________________________________________________________
Ground Screw Locations for Ellipticals
LC900 Elliptical CS800 Elliptical
Secure 4 GND here
Secure 4 GND here
Secure 4 GND here
Secure 4 GND here
Excess cables
nested here.
See Step 6 for
details.
Excess cables
nested here

Assembly Instructions
10
DISPLAY CONNECTION DIAGRAM –BIKE and ELLIPTICAL
BIKE and ELLIPTICAL OPERATION
1. Read and understand all instructions and warnings prior to use.
2. Plug in Power cord in appropriate wall outlet. (See your Assembly Instructions for outlet
requirements)
3. Allow display to fully light up. Allow a little over a minute for display to fully light up.
4. Follow the on screen prompts to configure Model Set Up.
5. Consult Owner’s Manual for specific operation instructions.
4 GND
2 LEFT
3 RIGHT
1 CNTRL
- BIKE
7 FAN
(OPTIONAL)
5 AUXPS
6 COAX
1 CNTRL
- ELLIPTICAL

Assembly Instructions
11
Instructions for changing units between English & Metric
Treadmill / Bike / Elliptical
1. The HOME screen will appear as shown below on left.
2. Press and hold the upper left corner of HOME screen for about 5 seconds until the logo
on HOME screen begins to flash on and off. Stop pressing left corner.
3. Then press and hold, for about 5 seconds, the MANUAL WORKOUT key in the bottom right corner of
the HOME screen. The MAINTENANCE screen will appear at this point.
4. Press the CONFIGURATION key on the MAINTENANCE screen.
5. Press and highlight “Model” (it maybe highlighted already). See image below on right.
6. Press and highlight “Model number” (it maybe highlighted already) Example: Model Number = CS800.
This example will be used for the remainder of instructions.
7. You will see two arrows and a SAVE key appear. See image below on right.
8. Press the up or down arrow to change “CS800” to “CS800X”. NOTE: The “X” designates a metric units
configured model.
9. Once you have selected the “X” version of your model, press the SAVE key.
10.Units on screen will then change from ENGLISH to METRIC.
11.Press the RETURN key to exit CONFIGURATION screen.
12.Press the EXIT key to return to the HOME screen.
13.NOTE: This same procedure can be used to change units from Metric to English.
WILL FLASH
STEP 2:
PRESS AND
HOLD HERE
STEP 3:
PRESS AND
HOLD HERE
STEP 5 & 6:
PRESS HERE
HOME SCREEN
CONFIGURATION SCREEN
STEP 7:
ARROWS
AND SAVE
KEY

Assembly Instructions
12
TV TUNER PROGRAMMING
Analog (NTSC) and Digital (ATSC) Tuner
(Not applicable for Model PS850 Touchscreen without TV Tuner)
INITIAL STEPS
1. If you have not already reviewed and completed the necessary requirements for:
a) Treadmill Operation on Page 4 or
b) Bike and Elliptical Operation on Page 9
please complete these steps at this time if you have not already.
2. Connect video signal source into COAX connector on bottom of exercise equipment.
3. Check that equipment power cord is plugged into wall outlet and where applicable the power switch is
set to ON (1 on toggle switch).
4. Allow display to fully light up. Allow a little over a minute for display to fully light up.
ENTERING TV TUNER SETUP
5. The HOME screen will appear as shown below:
6. Press and hold the upper left corner of HOME screen for about 5 seconds until the logo
on HOME screen begins to flash on and off. Stop pressing left corner. See HOME screen image below.
7. Then press and hold, for about 5 seconds, the MANUAL WORKOUT key in the bottom right corner of
the HOME screen.
The MAINTENANCE screen will appear at this point.
8. The MAINTENANCE screen will appear
as shown here.
Press the UTILITIES key on the MAINTENANCE
screen.
STEP 6:
PRESS AND
HOLD HERE
STEP 7:
PRESS AND
HOLD HERE
WILL FLASH

Assembly Instructions
13
9. The UTILITIES screen will appear as shown.
Press the TV TUNER SETUP key on the
UTILITIES screen.
10. TV TUNER SETUP screen will appear as below.
11.Determine if the video signal source is Analog or Digital and if it is supplied by Cable or Antenna.
Once you have determined this then select the appropriate section below. Verify that you have the
settings below selected on the display. If you have different settings from those listed, then simply
press the TV MODE or TV TYPE keys to scroll through the settings to arrive at the desired setting.
a) For Analog TV (NTSC) by Air
(antenna is source) programming:
i) TV Mode = ATV Air
ii) TV Type = NTSC
b) For Analog TV (NTSC) by Cable
(cable is source) programming:
i) TV Mode =ATV Cable
ii) TV Type =ATV STD (most common setting)
NOTE: Depending on your cable provider
the ATV STD setting may result in zero
channels found. It may be necessary to
adjust your TV Type setting to
TV Type = ATV HRC or TV Type = ATV IRC.

Assembly Instructions
14
c) For Digital TV (ATSC) by Air
(antenna is source) programming:
i) TV Mode = DTV Air
ii) TV Type = ATSC
d) For Digital TV (ATSC) by Cable
(cable is source) programming:
i) TV Mode = DTV Cable
ii) TV Type = QAM STD (most common setting)
NOTE: Depending on your cable provider
the QAM STD setting may result in zero
channels found. It may be necessary to
adjust your TV Type setting to
TV Type = QAM HRC or TV Type = QAM IRC.
ENTERING AUTO SCAN PROCEDURE –Analog or Digital Tuner
12. Press START SCAN
The automatic search screen will scan through channels and list the number of TV channels that are
found. The display will show “Searching…..Please Wait. Press Exit (or STOP SCAN) button to cancel.”
13.Once the scan procedure has been completed press the CONTROL MENU key.
14.You can scroll through the recently found channels by pressing the CHANNEL + OR –key.
15.If the scanner selected a channel that you do not want then select that channel by using the CHANNEL
+ OR –key, and then press the DELETE key to remove it from the selection list.
16.This completes the AUTO SCAN PROCEDURE.
17.To exit perform the following steps:
a) From the TV TUNER SETUP screen press the RETURN key.
b) From the UTILITIES screen press the EXIT key.
c) From the MAINTENANCE screen press the EXIT key to return to the HOME screen.
START
SCAN Key
CONTROL
MENU Key

Assembly Instructions
15
Closed Captioning Setup- Digital Tuner
18. Once the scan procedure has been completed press the CONTROL MENU key.
19. Press the MENU key that is inside the Digital TV Only box.
20. Press the Right navigation key until the CAPTION tab is highlighted
21.Press the OK key that is inside the Digital TV Only box.
22. Press the Down navigation key until DIGITAL CC is highlighted
a) Press the OK key that is inside the Digital TV Only box.
CONTROL
MENU Key
Menu Key
Right
Navigation
Key
OK Key
OK Key

Assembly Instructions
16
23. Press the Down navigation key until SERVICE ONE is highlighted
b) Press the OK key that is inside the Digital TV Only box.
24. Press the RETURN key
NOTE: CC only works in the muted state; if the power cycled the equipment wakes in an unmuted
state.
truefitness.com / 800-426-6570 / 1-636-272-7100
2010 TRUE FITNESS TECHNOLOGY, INC.
Specifications subject to change
061311
OK Key
RETURN
Key
