Trustech KPT-91H User manual

PTC HEATER USER MANUAL
MODEL: KPT-91H
Thank you for choosing Trustech PTC heater!
This user manual will provide you with valuable information necessary for the proper care and maintenance
of your new product. Please take a few moments to thoroughly read it and start enjoying your warm winter!
Always here to help you
For any questions or help, please email us: [email protected]m
< [phone] > Working hours 9:00 to 17:00 Monday to Friday

Content
SPECIFICATION.............................................................................................................................................1
CONTROL PANEL DIAGRAM.......................................................................................................................1
OPERATION & FUNTIONALITY................................................................................................................... 3
MAINTENANCE & STORAGE.......................................................................................................................5
MARRANTY & WARNINGS..........................................................................................................................6
CONTACT US................................................................................................................................................ 8
Please take a few minute to read this manual carefully.
Proper maintenance and operation of this machine can provide better service.

1
SPECIFICATION
Voltage Rating
120 V(60Hz)
Power Consumption
1500W
Unit Size
5.31 in. (W)×9.25 in. (D)×24.21 in. (H)
Unit Weight
5.74 lbs
CONTROL PANEL DIAGRAM
Control panel
①
③
② ④
⑤ ⑦
⑥
1. Electronic display：Indicate the set temperature.
2. Temp up button: To increase the desired temperature.
3. Mode button：To select High , Low and Eco modes.
4. Oscillating button: Turn on/off oscillating function.
5. Temp down button: To decrease the desired temperature.
6. ON/OFF button: Powers on and off the heater.
7. Timer button：To engage timer mode and to set hour value for the timer.

2
Remote control
PREPARATION
Power button: Used for power-on or power-off
Mode button: Used for mode selection
Oscillation button: Turning on/off for oscillation
Timer button: Used for setting timer and adjust time value of timing
Temp up button: To rise set temperature
Temp down button: To decline set temperature

3
OPERATION & FUNTIONALITY
Operating instructions
Place the heater on a firm, level surface and plug into a 120V 60Hz power outlet and turn on
the power switch in the rear of the unit. Only operate heater in upright position.
1、Power on and select working mode
Turn the heater on by pressing the ON/OFF button on the control
panel or by pressing the Power button on the provided remote
control.
Note: After the heater is turned off, the heating element will stop
working immediately but the fan will prolong working for 30 seconds
to emit plenty of heat inside.
or
Select a heating Mode
Press the MODE button to toggle between High , Low or
Eco modes.
2、Setting Desired Temperature
or or
or
Adjust the desired temperature by pressing the Up/Down arrows
on the control panel or remote to control temperature.
The temperature of the heater is optionable between 59℉to 86
℉. Once you have selected the temperature you want, the heater
will remain on until the room temperature increases to the
temperature set and will keep on and off to maintain the desired
room temperature.
or
Turn on/off rotation by pressing oscillating button on the control
panel or on the supplied remote control.
3、Setting the Timer

4
After powering on the heater, press the Timer button on the
heater’s control panel or the remote and set the desire time.
Preparing remote
Before using remote control at the first time, please pull out the insulating film as the following steps.
Safety features
Tip-Over Safety Feature
This heater is equipped with a tip-over safety feature. Once the heater is tipped over, an internal switch will
automatically shut the heater off. Once the heater is restored an upright position, the heater will reset. To
start the heater again, turn on the heater using the supplied remote control or the control panel on the
heater.
Overheat Safety Feature
This heater is equipped with a overheat safety feature. When the heaters internal components reach a
certain temperature that could cause overheat and possible fire, the heater will automatically shut off.
WARNING:It is normal that feeling warm with the power cord when touching it. However, loose fitting
between the socket and plug may cause the plug to overheat. If this happens, try inserting the plug into
another socket. And please contact a qualified electrician to check the original socket for damage.
PULL
Remote control
Insulating film
Battery cover

5
MAINTENANCE & STORAGE
Maintenance
1. Turn off the power switch in the rear of the unit when you are not using it.
2. Unplug the unit and let it cool completely before storage.
3. Clean your heater with a soft, damp cloth. You may use a mild detergent if necessary. After cleaning,
dry the unit with a soft cloth. CAUTION: DO NOT let liquid enter the heater.
4. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes to clean the
heater. This may cause damage or deterioration to the surface of the heater.
5. DO NOT immerse the heater in water.
6. Wait until the unit is completely dry before use after cleaning.
Storage
Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-up, use the original
packaging to repack the unit.
Basic Troubleshooting
If the heater will not operate, please check the following before seeking repair advice:
1. Check if the power cord is plugged into an electrical outlet, if not, plug it in.
2. Check if electricity to the main power switch (in the back of the device) is working.
NOTE: In order for the heater to work properly, the desired temperature on the heater must be set a few
degrees higher than room temperature. If it does not seem to be heating, increase the required temperature
of the heater to engage the heating element.

6
MARRANTY & WARNINGS
Warranty
TRUSTECH warrants this product against defects in materials and/or workmanship under normal use for a
period of ONE (1) YEAR from the date of purchase by the original purchaser (“Warranty Period”). If a
defect arises and a valid claim is received within the Warranty Period, at its option, TRUSTECH will either 1)
repair the defect at no charge, using new or refurbished replacement parts, or 2) replace the product with a
new product that is at least functionally equivalent to the original product, or provide a store credit in the
amount of the purchase price of the original product. A replacement product or part, including a user-
installable part installed in accordance with instructions provided by TRUSTECH, assumes the remaining
warranty of the original product. When a product or part is exchanged, any replacement item becomes your
property and the replaced item becomes TRUSTECH’s property. When a store credit is given, the original
product must be returned to TRUSTECH and becomes TRUSTECH’s property. To obtain warranty service, e-
mail TRUSTECH Limited Warranty Service at [e-mail]. Please be prepared to describe
the product that needs service and the nature of the problem.
This warranty does not apply to:
a. damage caused by failure to follow instructions relating to product’use or the installation of
components;
b. damage caused by accident, abuse, misuse, fire, floods, earthquake or other external causes;
c. damage caused by service performed by anyone who is not a representative of TRUSTECH;
d. accessories used in conjunction with a covered product
e. a product or part that has been modified to alter functionality or capability;
f. items intended to be periodically replaced by the purchaser during the normal life of the product
including, without limitation, batteries or light bulbs;
g. any product sold ‘as is’including, without limitation, floor demonstration models and refurbished items;
or
h. a product that is used commercially or for a commercial purpose.
Warnings
Read ALL instructions before using this unit.
CAUTION: Risk of Electric Shock. DO NOT open or try to repair the heater yourself.
This heater may get hot when in use. To avoid burns, DO NOT touch the heater with bare skin. DO NOT
move the heater when using.
Keep combustible materials, such as furniture, pillows, bedding, paper, clothes, and curtains at least 3 ft
from the front of the heater and keep them away from the sides, top, and rear. DO NOT place towels or
other objects on the heater.
Extreme caution is necessary when any heater is used by or near children or the disabled, or when the
heater is left operating and unattended.
DO NOT operate the heater with a damaged cord or after the heater malfunctions, has been dropped or
damaged in any manner. Return heater to authorized service facility for examination, electrical or
mechanical adjustment, or repair.
This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. NEVER
locate heater where it may fall into a bathtub or other water container. To protect against electrical

7
hazards, DO NOT immerse in water or other liquids.
DO NOT touch the control panel or plug with a wet hand.
DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or similar coverings.
Arrange cord away from traffic area and where it will not be tripped over.
DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the heater.
To prevent a possible fire, DO NOT block the air intakes or exhaust in any manner. DO NOT use on soft
surfaces, like a bed, where openings may become blocked.
A heater has hot and arcing or sparking parts inside. DO NOT use in areas where gasoline, paint,
explosive and/or flammable liquids are used or stored. Keep unit away from heated surfaces and open
flames.
Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or
relocatable power tap (outlet/power strip).
To avoid fire or shock hazard, plug the unit directly into a 120 V AC electrical outlet.
To disconnect heater, turn controls to OFF, then remove plug from outlet. Pull firmly on the plug, DO
NOT unplug by pulling on the cord.
Always unplug the unit before moving or cleaning, or whenever the heater is not in use.
Use only for intended household use as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons. The use of attachments not
recommended or sold by unauthorized dealers may cause hazards.
Always use on a dry, level surface. Use on floor only.
DO NOT use outdoors.
WARNING: To reduce the risk of fire or electric shock, DO NOT use this unit with any solid-state speed
control device.
DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will void
your warranty. The inside of the unit contains no user serviceable parts. Qualified personnel should
perform all servicing only.
Save these instructions.

8
CONTACT US
Thank you for choosing TRUSTECH product.
For any questions of your product or honor your warranty, please write to
[e-mail]. Our customer service time will response ASAP within 12
hours!
