Trustech PW15R User manual

TRUSTECH Patio Heater
Model No. PW15R
User Manual
[e-mail]

Before Use
Thank you for choosing TRUSTECH patio heater!
Please read all instructions carefully to familiarize yourself with your new heater
before using. And save these instructions for further reference. For any further
assistance or information call Customer Services on T: [phone] or visit W:
https://trustech.afterservice.vip or E: [e-mail]
Now, start enjoying your warm winter!
Specifications
Rated Voltage
120V/60Hz
Power Consumption
1500W
Unit Size
25.4 inch(W)*3.3 inch (D)*6.1 inch (H)
Unit Weight
5.7 lb

Warnings
1．Do not use any other programmer, timer, separate remote control system
or any other device that will automatically turn on the heater except the remote
controller equipped with the product. Do not turn on the heater when the device is
covered or positioned incorrectly to avoid the risk of fire.
2．It’s dangerous to install the heater close to curtains or any other
combustible materials.
3．Do not use the heater near showers, bathtubs or swimming pools.
4．Do not place the heater directly under the socket.
5．If the power cord is damaged, it must be replaced by the manufacturer, its
service agent or a similarly qualified person to avoid a hazard.
6．In order to avoid overheating, do not cover the heater.
7．This appliance can be used by children from aged 8 years and above and
persons with reduced physical, sensory or mental capabilities, or lacking experience
and knowledge, if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and with supervision.
8．Keep the appliance and its cord out of reach of children under 8 years old.

9．Warning: This heater is not equipped with a device to control the room
temperature. Do not allow persons with mobility impairments (such as infants,
disabled persons or elderly people with mobility impairments) to use the heater in
a small room to avoid dangers caused by excessive temperature, unless continuous
supervision is provided.
10．Please be careful not to use this heater near combustible materials that
move due to wind or other environmental influences, such as curtains, tents, flags,
plastic foils, etc., to avoid the risk of burning.
11．Caution: Some parts of this product become very hot during use and may
cause burns. When there are children and vulnerable people, special attention must
be paid.
When using this heater, you should follow basic safety precautions to reduce the
risk of fire, electric shock and personal injury, including the following:
1．Read all instructions before using this appliance.
2．Caution: Risk of electric shock. Do not open or try to repair the heater by
yourself.
3．This heater becomes hot during use. To avoid burns, do not let bare skin
touch hot surfaces. If possible, use handles when moving this heater.
4．Keep combustible materials, such as furniture, pillows, bedding, paper,
clothes, and curtains at least 3 feet away from the front of the heater and keep
them away from the sides, top, and rear of the heater. Do not place towels or other

objects on the heater.
5．When the heater is used by or near a child or disabled person, or when the
heater is running and unattended, extreme care must be taken.
6．Do not operate the heater after the wire is damaged or the heater is
malfunctioning, dropped, or damaged in any way. Please return the heater to an
authorized service facility for inspection, electrical or mechanical adjustment, or
repair.
7．This heater is not suitable for bathrooms, laundry areas and similar indoor
locations. Never place the heater where it may fall into a bathtub or other water
container. To protect against electrical hazards, do not immerse the heater in water
or other liquids.
8．Do not touch the control panel with a wet hand.
9．Do not place the cord under carpets. Do not cover the cord with rugs, or
similar coverings. Please place the cord away from the traffic area and at the place
where it will not be tripped over.
10．Do not insert or put any other objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
11．To prevent a possible fire, do not block the air intake or exhaust in any
manner. Do not use it on soft surfaces, like a bed, where openings may become
blocked.
12．There are heating, arcing or spark parts inside the heater. Do not use it in
areas where gasoline, paint, explosive and/or flammable liquids are used or stored.

Keep the heater away from heated surfaces and open flames.
13．Avoid using extension cords, which may overheat and cause fire. However,
if an extension cord has to be used, the minimum length of the extension cord
should be 59 inch.
14．To disconnect the heater, turn the control to OFF.
15．Always turn off the heater before moving or cleaning it, and whenever the
heater is not in use.
16．Only for intended household use as described in this manual. Any other
use not recommended by the manufacturer may cause fire, electric shock, or
personal injury. The use of attachments not recommended or sold by unauthorized
dealers may cause hazards.
17．Warning: To reduce the risk of fire or electric shock, do not use the heater
with any solid-state speed control device.
18．Do not attempt to repair or adjust any electrical or mechanical functions
on the heater. Doing so will void your warranty. There is not any user-serviceable
part inside of it. If the heater needs to be examined or repaired, please contact the
qualified personnel for help.
19．Connect the heater to properly grounded outlets only.
20．This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lacking experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.

21．Children should be supervised to ensure that they do not play with the
appliance.
22．When install the heater, please don’t cover the marketing information.
23．Save the user manual for future reference.
Operating Instructions
1．This appliance must be supplied with the proper voltage and frequency
(AC120V/60Hz), and connected to an individual, properly grounded branch circuit,
protected by a circuit breaker following wiring rules. Power cord of this appliance
must be fastened with the chain and installation of this appliance can only be
carried out by qualified personnel to avoid a hazard.
2．Only operate the heater when it is in the upright position. Our electric patio
heater is equipped with 3-level heat setting. The rocker switch on the right of the
heater is used to turn on/off the heater, the “-”position is on and the“0”
position is off. To increase the heating temperature of the heater, press again.
This will cause the bottom and top heating elements to glow and radiate heat, and
increase the working power.

ON/OFF Rocker Switch
After turning on the rocker switch,
press once, the display window shows P0, and the heater is in standby state;
press twice, the display window shows P1, and the heater is operating at the
power of 500W;
press three times, the display window shows P2, and the heater is operating at
the power of 1000W;
press four times, the display window shows P3, and the heater is operating at
the power of 1500W;
press , you can select the heater timing function, timing range : 1-24 hours.
Definitions of the buttons on the remote control
The function of the heater can be controlled by the buttons on the remote control
and the LED screen. You can also control certain functions of the heater through the
buttons on the front of the heater.

Remote Control
1. On / Off
Turn the heater on or off or set it to standby mode.
2. First gear
After turn on the heater, press this button to choose low heat.
3. Second gear
After turn on the heater, press this button to choose moderate heat.
4. Third gear
After turn on the heater, press this button to choose high heat.
5. Timer Off
Turn off the heater at the current time and enter standby mode.

Maintenance and Storage
Turn off the appliance before maintenance and let it cool down.
To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth.
You may use a mild detergent if necessary. After cleaning, dry the heater with a soft
cloth. Do not use alcohol, gasoline, abrasive powders, furniture polish, or rough
brushes to clean the heater. This may cause damage or deterioration to the surface
of the heater. Although this heater is outdoor approved (balconies and patios), do
not immerse the heater in water for your safety. Wait until the appliance is
completely dry before use.
If the heater will not be used for a long time, please store it in a cool and dry
place. To prevent dust and dirt build-up, use the original packaging to repack the
heater.
Troubleshooting
If the heater does not work, please check the following items before repairing:
1．Check whether the main fuse is energized.
2．Make sure the power switch is turned on. If it is not, select a setting to turn
on the device.

Disposal
Used products with batteries should be taken to a recycling station and
not be disposed of with household waste. Hand it over to the applicable collection
station for the recycling of electrical and electronic equipment. The separate
collection and recycling of the product will help to conserve natural resources and
ensure that it is recycled in a manner that protects human health and the
environment. Disposal must be carried out in accordance with local environmental
regulations for waste disposal. For more details about where you can drop off the
appliance for recycling, please contact your local city office, your household waste
disposal service or the seller from whom you purchased the product.
Limited Warranty
TRUSTECH warrants this product against defects in materials and/or
workmanship under normal use for a period of 1 YEAR (“warranty period”) from the
date of purchase by the original purchaser.
If a defect arises and a valid claim is received within the warranty period, at its
option, TRUSTECH can either 1) repair the defect free of charge, use new or
refurbished replacement parts, or 2) replace the product with a new product that is
at least functionally equivalent to the original product, or 3) provide a store credit at
the amount of the purchase price of the original product.

A replacement product or part, including a user-installable part installed in
accordance with instructions provided by TRUSTECH, assumes the remaining
warranty of the original product. When a product or part is exchanged, any
replacement item becomes your property and the replaced item becomes
TRUSTECH’s property. When a store credit is given, the original product must be
returned to TRUSTECH and becomes TRUSTECH’s property.
To obtain warranty service, e-mail TRUSTECH Limited Warranty Service at
[e-mail]. Please be prepared to describe the product that
needs services and the nature of the problems.
This warranty does not apply to the following situations:
1．Damage caused by failure to follow instructions relating to product use or
component installation.
2．Damage caused by accident, abuse, misuse, fire, floods, earthquake or other
external causes.
3．Damage caused by services performed by anyone not represented by
TRUSTECH.
4．The product or its part has been modified to alter its function or capability.
5．Items that the purchaser should replace regularly during the normal use
period of the product, including but not limited to batteries or light bulbs.
6．Any product sold "as is", including but not limited to floor display models
and refurbished products or products used for commercial or commercial purposes.

Contact Us
If you encounter questions about this heater including but not limited to using,
maintenance, safety or errors/troubles, please call Customer Services on T: +1（855）
620 5858 or contact us via E-mail service: [e-mail] or scan
the following QR code to communicate with us directly.
