Argos Sainsbury's 952/4226 User manual

Electric Table Top Patio Heater
Assembly Instructions - Please keep for future reference 952/4226
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800.
Please visit the website www.argos.co.uk for more information.
Made in China for Habitat.Argos Limited 489-499
Avebury Boulevard, Milton Keynes, MK9 2NW.
Argos (N.I.) Ltd, Forestside Shopping Centre, Upper Galwally, Belfast,
United Kingdom, BT8 6FX. Argos Distributors (Ireland) Limited,
Unit 7, Ashbourne Retail Park, Ballybin Road, Ashbourne,
County Meath, Ireland
Important - Please read this instructions fully before starting assembly
Issue 1 - 10/09/21
Please retain for future reference
Dimensions
Width - 45 cm
Depth - 45 cm
Height - 93 cm

2
1 Heating head Assembly
2 Post
3 Base
4 Remote control
5 Power cord
6 Cable connector
7 3.5x12 Phillips screw x 2
(pre-assembled on the tube)
8 6x14 Phillips screw x 2
9 Crimping plate
Please check you have all the panels listed below
Parts Description
1
2
3
9
5
6
7
8
4

3
WARNING: In order to avoid overheating, do not cover the heater.
Do not cover
■ Thiselectricalappliancecomplieswithtechnicalsafetyandelectromagnetic
compatibility standards.
■ Nevertouchyourheaterwheninoperation(riskofburns).
■ Nevertouchtheheaterwithwethands.
■ Donottouchtheheaterwhileitisoperating.Waitatleast15minutesafteritis
switchedo󰀨beforetouching.
■ Neverplaceanythingontheheaterssafetyguard(e.g.Towel)asthismay
causeoverheatingorare.
■ Neveruseyourappliancetodrywashing.
■Althoughtheheatingelementhasstoppedglowing,itmaystillbehotand
potentiallydangerous.Checkthattheselectionindicator(5)isinpositiono󰀨
before taking any action.
■Switcho󰀨yourappliance:
- After use
- In the event of malfunction
- Before cleaning it.
■Neveroperateyourapplianceifithasfallenover.
■Neverdismantleyourappliance.Anincorrectlyrepairedappliancemaybe
dangerous to the user. If you encounter any problems seek professional advice
fromasuitablequaliedprofessional.
Warning Symbols
Warnings

4
■Thewarrantywillbevoidintheeventofdamagearisingfromimproperuse.
■Donotusethisheaterintheimmediatesurroundingofabath,ashowerora
swimming pool.
■ Thismovableapplianceisdesignedforuseingardens,andcanbeused
indoor and outdoor. The warranty will not apply to appliances used for
professional usage. Although the heater may be used outdoors, the main plug
must only be connected to the supply indoors.
■ Theheaterisprovidedwithananti-tiltswitchwillswitcho󰀨theheaterifitis
overturned, and will switch it on again automatically when it is restored to its
upright position.
■ Thisheatershouldbeoperatedonatableorothersuitableraised,atand
level surface.
■ Thiselectricalappliancecomplieswithtechnicalsafetyandelectromagnetic
compatibility standards.
■ Donotcoverheater.
■ Thisheaterisnotequippedwithadevicetocontroltheroomtemperature.
Do not use this heater in small rooms when they are occupied by persons
not capable of leaving the room on their own, unless constant supervision is
provided.(IEC 60335-2-30)
■ Thisheatermustnotbeusedonornearcombustiblematerials,suchas
wooden decking or fencing.
WARNING! CONTAINS COIN OR BUTTON BATTERY.
Hazardous if swallowed, a coin or button battery can cause serious
internal chemical burns if swallowed.
WARNING! Dispose of used batteries immediately. Keep new and
used batteries away from children. If you think batteries might have
been swallowed or placed inside any part of the body, seek immediate
medical attention. ALWAYS KEEP BUTTON CELL BATTERIES OUT OF
REACH OF CHILDREN
Warnings

5
Beforeusingtheapplianceatthersttime,ensurethatyourmainsvoltage
corresponds to voltage indicated on the appliance. It is a class I appliance and
must be earthed.
CAUTION: Before tting or removing the appliance, ensure that the
heater's power line supplying the heater is disconnected. Check that the
power line is connected to a 30A di󰀨erential circuit breaker.
■Thisapplianceisdesignedforuseingardens,andanyroominyourhouse,
including those where there is a risk of splashing. The installation and use of
your appliance must comply with the applicable standards in your country.
■Whenitisswitchon,anelectricalheatingappliancereachesveryhigh
temperature liable to cause burns. Make sure that all other users are aware of
the risks.
■Children,theelderlyandtheinrmmaynotalwaysbeawareofthedanger
involved in using electrical appliances. Never allow this appliance to be used
without supervision.
■Theappliancemustbepositionedsothattheplugisaccessible.
■Donotuseifthecordisdamaged.
■Theheatermustnotbelocatedimmediatelybelowasocket-outlet
■Donotusethisheaterwithaprogrammer,timeroranyotherdevicethat
switchestheheateronautomatically,sinceareriskexistsiftheheateris
covered or positioned incorrectly.
■Donotplacetheapplianceclosetocurtainsandothercombustiblematerials.
Before using
Safety

6
■Batteriesshouldbeinstalledbyanadult.
■Nevermixoldandnewbatteries(replaceallbatteriesatthesametime).
■Nevermixalkaline,standard(CarbonZinc)orrechargeablebatteries.
■Donotrechargenon-rechargeablebatteries.
■Rechargeablebatteriesmustberemovedbeforerecharging,andcharged
under adult supervision.
■Removebatteriesfromproductbeforeextendedstorageorifexhausted.
■Donotshortcircuitthesupplyterminals.
■Batteriesmayexplodeorleakifmisused.
■Donotdisposeofbatteriesinare.
Battery safety

7
WARNING! Before installing your appliance, you must disconnect the
electrical supply at the circuit breaker.
Step 1
Step 2
Assembly
Thread the power cord
(5) through the post (3)
and connect the cable
connectors (6).
Remove the screws (7)
pre-assembled on the
post. Position the head
assembly (1) onto the
post and re-secure the
screws in place. 7
1
5
3
6

8
Assembly
Step 3
Step 4
Feed the power cord
through the middle hole
of the base(3), and then
twist the assembly with
the post clockwise into
the base.
Put the power cord(5)
into the groove at the
bottom of the base,
and then secure the
crimping plate (9) in
place using 2 x screws
(8) as illustrated.
3
8 (6x14)
5

9
Turn on the product through the main switch to enter standby mode, touch the on/
o󰀨buttonandthentouchthedisplaytocontrolthegear.
■OnlyCR2025buttonbatterycanbesued.
■Openthebatteryholderasperbelowimage.
■ChangethebuttonbatterywithanothernewCR2025buttonbattery.Please
pay attention to make the positive electrode to be the upper side.
■Pushthebatteryholderbackintotheremote.
Operation
Battery change instruction
1
2

10
- Power rate:1500w
- Cable length: 1.6m
- Standby Mode : Blinking red lamp
- Touch 1: 600W Green light (normal power)
- Touch 2: 900W Green light (intermediate power)
- Touch 3: 1500W Green light (full power)
- Touch4:OFF
The product complies with the applicable UK directives
and an evaluation method of conformity for these
directives was done.
The product complies with the applicable European
directives and an evaluation method of conformity for
these directives was done.
WEEE symbol. Waste electrical products should not be
disposed of with household waste. Please recycle where
facilities exist. Check with your local authority or local
store for recycling advice.
Read the instruction manual before operating this machine.
The product complies with the RoHS directives and an evaluation
method of conformity for these directives was done.
The product complies with IP34 standard.
Specication

11
Your appliance dose not requires any particular maintenance. However, in the
event of a malfunction, please consult a suitably qualied electrician.
Maintenance
