Trutone V3 VS-XO User manual

V
3
DRIVE-1 TONE VOL
CLIPPING
A – B - C
BASS
VS
-
XO
Sample Settings
Scream-ish
CLEAN MIX
Single Channels:
DRIVE-1 TONE VOL
CLIPPING
A – B - C
BASS
Open Mid Crunch
CLEAN MIX
DRIVE-1 TONE VOL
CLIPPING
A – B - C
BASS
Big & Fat
CLEAN MIX
DRIVE-1 TONE VOL
CLIPPING
A – B - C
BASS
Clean Boost
CLEAN MIX
DRIVE-2 TONE VOL
Rhythmic Breakup
BASS
DRIVE-2 TONE VOL
Sparkling Heat
BASS
With Clean Mix at minimum, no
other controls function except VOL.
DRIVE-2 TONE VOL
Sublime Solo
BASS
DRIVE-1 TONE VOL
CLIPPING
A – B - C
BASS
CLEAN MIX
DRIVE-2 TONE VOL
Hot Open Road
BASS
DRIVE-1 TONE VOL
CLIPPING
A – B - C
BASS
CLEAN MIX
Combined Channels:
FCC Notice: This e uipment has
been tested and found to comply
with the limits for a Class B digital
device, pursuant to part 15 of the
FCC Rules. These limits are
designed to provide reasonable
protection against harmful
interference in a residential
installation. This e uipment
generates, uses and can radiate
radio fre uency energy and, if not
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
If this e uipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the e uipment off and on,
the user is encouraged to try to
correct the interference by one or
more of the following measures:
— Reorient or relocate the receiving
antenna.
— Increase the separation between
the e uipment and receiver.
— Connect the e uipment into an
outlet on a circuit different from that
to which the receiver is connected.
— Consult the dealer or an
experienced radio/TV technician for
help.
Changes or modifications not
expressly approved by Truetone
could void the user's authority to
operate the e uipment.

ruetone.com
rue Bypass or Buffered Bypass:
By removing the 4 screws and the bottom cover, you can see 2 slide switches. Use these to
choose true bypass or our Pure Tone buffered bypass for each channel.
Signal Routing:
The VS-XO is truly 2 pedals in 1 housing. For basic setup, use the Drive-1 input and the
Drive-2 output. You may also change the order of effects by plugging your guitar or bass into
the Drive-2 input, use a short cable from the Drive-2 output to the Drive-1 input, and then go
out from the Drive-1 output. For anything other than the basic setup, just think of the VS-XO
as 2 pedals.
Battery:
If you have a battery installed, make sure to unplug both Input and Output when not using, so
you don’t drain the battery. Then again, why are you using a battery? Get a 1 SPOT!
Switch pop?
For the first 45 seconds after applying power to the pedal, the sound of foot-switch pop is
normal, due to the time it takes for power supply filter capacitors to charge fully. After that,
unlike ordinary true-bypass switches, switch pop goes away.
What is the Clipping switch?
Clipping chooses between three different clipping diode voices:
A) No diodes… low gain, organic.
B) Two LEDs… medium gain, bright.
C) Three signal diodes… higher gain, smooth asymmetrical clipping.
NOTE: These sounds are most noticeable when Clean Mix is fully clockwise.
What is the 3-way Bass switch?
This chooses 3 bass levels:
A) Bass cut.
B) Slight bass boost.
C) More bass boost.
What does the Clean Mix knob do?
This is a single knob mixer that allows you to mix your clean (un-effected) signal back in as
you turn it counter clockwise. At the minimum setting, it is 100% clean and all other knobs
and switches will not function, except for the Volume knob which can provide a clean boost.
he one knob on Drive-2 works different than on Drive-1… what’s it doing?
The Drive-2 Tone knob affects both treble and gain at the same time. As you turn it up, treble
increases dramatically, while gain increases slightly.
Support:
If you ever have any uestions or problems with your VS-XO, just go to the Truetone website
and contact our customer service. We’re here to help you!
Instructions
2015
