TC Electronic JUNE-60 V2 CHORUS User manual

TC Electronic
JUNE-60 V2 CHORUS
Authentic Recreation of the Juno-60
Synthesizer Chorus with 2-Button Interface
and BBD Circuitry
Quick Start Guide
Controls and Connectors
(1) Input/Output jacks – Connect a ¼" TS cable from your
guitar to the INPUT jack.
Mono setup: Set slider to MONO and connect a ¼"
TS cable from the OUTPUT jack to your amplier.
Stereo setup: Set slider to STEREO and connect a
¼" TRS split cable from the OUTPUT jack to a pair
of ampliers.
Note: Input impedance has two options designed to optimize
performance for guitar or keyboard. Access the internal INPUT
LEVEL slide switch (SW6) to choose the optimal option for
your setup
(2) 9 V DC – Connect a standard 9 V power supply
(not included).
(3) Footswitch – Turns the eect on and o. The LED will
light when the pedal is engaged. The pedal operates in
true bypass when disengaged.
(4) Mode – Press button I or II to select between 2 chorus
preset settings. Press buttons I and II simultaneously to
activate a 3rd chorus preset setting.
Note: Preset I and II LFO speeds can be changed independently
via the internal LFO SPEED DIP switch (SW5).
SLOW = Original JUNO settings (recommended for keyboards)
FAST = Original JUNE 60 settings (recommended for guitar)
Settings III III (I+II)
SLOW 0.5 Hz 0.83 Hz
10 Hz
FAST 1.3 Hz 2.2 Hz
(5) Mono/Stereo switch – Select between MONO and
STEREO mode.
Internal Option Switches
(6) INPUT LEVEL – Select between input impedance for
GUITAR or KEYBOARD.
(1) LFO SPEED – Select FAST or SLOW for preset I and/or II.
Battery Replacement
Storage
(3)
(1)
(4)
(5)
(2)
(2)
(1)
V 1.0

Specication
Connectors
Input (mono) ¼" TS, unbalanced
Impedance 500 kΩ (guitar) /
12 kΩ (keyboard)
Output (mono/stereo) ¼"TS or TRS, unbalanced
Impedance 100 Ω
Power input Standard 9 V DC,
center negative, >100
mA
(not included)
Battery option Internal 9 V battery
connector
Physical
Dimensions (H x W x D) 56 x 86 x 137 mm
(2.2 x 3.4 x 5.4")
Weight 0.5 kg (1.1 lbs)
