1. INTRODUCTION
≡1 Introduction
The TTE-Switch A664 Lab v2.0 supports laboratory testing efforts of TTEthernet.
TTEthernet is a fault-tolerant real-time communication protocol for safety-related systems that makes it
possible to conveniently configure the deterministic processing of critical Ethernet traffic (time-triggered,
ARINC 664 P7 [2]) and non-critical, standard Ethernet traffic (IEEE 802.3 [6]) in one physical infrastructure.
Switching function
The TTE-Switch A664 Lab v2.0 is a high-performance deterministic Ethernet switch that makes it possible
to implement critical network-centric applications and process packets on all its 24 ports with full-line
speeds, operating in full-duplex mode:
• 6 x triple-speed 10/100/1000 Mbit/s ports, and
• 18 x 10/100 Mbit/s ports
One additional port is available for traffic mirroring. The TTE-Switch A664 Lab v2.0 has built-in mecha-
nisms for traffic policing and fault isolation.
Virtual links and protocol support
The TTE-Switch A664 Lab v2.0 allows configuring up to 4096 virtual links (VLs). Virtual links can be
configured with 8 priorities and a bandwidth allocation gap (BAG) of 0.01 ms to 1310.71 ms. The net-
work configuration is stored in the non-volatile memory of the switch (256 Mbit). It is optionally possible
to configure IEEE 802.1Q VLANs. Profiled IP/UDP, redundancy management, and traffic shaping are
implemented in hardware.
Data loading and diagnosis
The built-in management module runs on a separate CPU and allows for data loading and the querying
of the network status via SNMP. Data loading is done according to ARINC 615A-3/TFTP and ARINC 665-
loadable software parts.
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 6Document Number:
D-A664Lab-G-05-001
2. OVERVIEW
≡2 Overview of the TTE-Switch A664 Lab v2.0
Figure 1: The TTE-Switch A664 Lab v2.0
2.1 Identification
Figure 2: Product identification label
2.2 External interfaces
1. 4 x Status LEDs (POWER/STATUS/SYNC/DEF. CONF)
2. 1 x DB-25S configuration interface for diagnosis and maintenance and access to switch discretes
3. 1 x 10/100/1000 Mbit/s MIRROR port for mirroring
4. 2 x 10/100/1000 Mbit/s Ethernet ports (PORT1 and PORT2) that can be used either via SFP or RJ45
5. 4 x 10/100/1000 Mbit/s Ethernet ports via RJ45
6. 18 x 10/100 Mbit/s Ethernet ports via RJ45
7. 1 x Ethernet Link/Activity LED per port
8. 1 x JTAG connector for factory testing and programming
9. 1 x RS-232 serial interface that can be used for debugging
10. 1 x IEC 60320-1 C13 type power connector. The switch has an electrical fuse that protects the
external power rail so that a failing switch does not cause the system power supply rail to fail.
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 7Document Number:
D-A664Lab-G-05-001
2. OVERVIEW
Figure 3: Front view of the TTE-Switch A664 Lab v2.0
Figure 4: Rear view of the TTE-Switch A664 Lab v2.0
2.3 Functional features
• Full line speed switching capability
• The switch supports partitioning between three traffic classes on each port:
a) Rate-constrained traffic (full compliance with ARINC 664 part 7 [2]),
b) Time-triggered traffic (SAE AS 6802 [7]), and
c) Best-effort traffic (IEEE 802.3-2005 [6])
• 32 MB of memory
• 256 Mbit Flash memory for storing switch configurations
• Application CPU for management functions
• Configuration data programmable via ARINC 615A [1]/TFTP
• Built-in self-tests (BISTs) for health monitoring
• Monitoring faulty/healthy switch state through SNMP
• Pin programming support
• External adapter with 12 dip switches for pin programming (including parity) and mode selection.
Supported network standards
• The switch forwards best-effort traffic in compliance with IEEE 802.3-2005 [6] (switching). The switch
has a maximum internal non-blocking port-to-port latency of 2 µs for 1 Gbit/s ports, 20 µs for 100 Mbit/s
ports, and 200 µs for 10 Mbit/s ports. This is for a frame size of 1518 bytes, sent as best-effort (BE)
traffic. The switch allows limiting best-effort traffic for each ingress and egress port.
• The switch forwards VLAN-tagged frames according to IEEE 802.1Q [4] (VLAN core capabilities).
NOTE The switch does not implement port-based VLANs (edge switch). This means that the switch cannot
add VLAN tags to frames coming in on a specific port. The switch does not implement content-based
VLANs (e.g., based on IP addresses or TCP/UDP ports).
The switch supports static VLAN routing according to a configuration table. VLAN frames will be
accepted and routed only to the configured switch ports. VLANs are processed with a higher priority
than BE frames without a VLAN tag. The switch routes VLAN frames according to the priority specified
in the VLAN field. Frames with the same VLAN priority are processed on the basis of the incoming
switch port number. VLAN frames with the same priority are handled in a similar way as RC frames
with the same priority. Frames from Port 1 have priority over frames from Port 2. The switch can
store VLAN frames in a separated buffer space. Depending on the respective configuration, BE and
VLAN frames cannot share the same buffer space. Frames that contain a VLAN tag that is not in
the list of the configured VLAN IDs are routed according to a default VLAN route. A default VLAN
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 8Document Number:
D-A664Lab-G-05-001
2. OVERVIEW
route specifies to which ports such frames can be routed. If no port is configured, these frames are
dropped.
TTEthernet implementation
• 8 sub-schedules
• 8 clock synchronization masters
• 4096 virtual links
• Store-and-forward switch architecture
ARINC 664 p7 implementation
• Policing, filtering, switching engine for band-width control and traffic prioritizing
• Integrity checking and error checking of frames
• 4096 virtual links with up to 8 priorities, with restrictions of their associated ports
• 4096 BAGs
• BAGs freely configurable from 0.01 to 1310 ms
• BAG configuration granularity 100 µs
• Jitter and BAG resolution of 8 ns
• The switch supports ICMP (ping), SNMP v1 and A615A-3.
• Configuration data programmable via ARINC 615A/TFTP
Physical specifications
• 19-inch rack housing, 1 height unit (1U)
Power supply
• 110-230 V, 50/60 Hz
• 0.8 A max. current
Environmental operating ranges
• Operating temperature: 0 ○C to +70 ○C
Standards compliance
•IEEE 802.3™-2005 (switching, flow control) [6].
•IEEE 802.1Q™-2011 [4]
•IEEE 1588-2008: The switch supports the IEEE 1588 end-to-end transparent clock mode. The clock
of the switch is not synchronized to the IEEE 1588 Master Clock [5].
•ARINC Specification 664P7-1: The switch is fully compliant with ARINC 664 part 7 (deterministic
Ethernet networking) [2].
•SAE AS 6802: The switch supports the SAE AS 6802 network synchronization and start-up mecha-
nism (fault-tolerant TTEthernet clock synchronization protocol) [7].
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 9Document Number:
D-A664Lab-G-05-001
3. FUNCTIONAL DESCRIPTION
≡3 Functional description
This section describes the functionality of the TTE-Switch A664 Lab v2.0.
3.1 Block diagram
Figure 5: Block diagram of the TTE-Switch A664 Lab v2.0
3.1.1 Primary components
Base Board:
• 25 Ethernet transceivers (18 x 10/100 Mbit/s ports, 6 x 10/100/1000 Mbit/s ports, and 1 x 10/100/1000 Mbit/s
port for mirroring only).
TTE Switch Module 2:
• ASIC as switch engine.
• Reduced-latency DRAM with a storage capacity of 288 Mbit and running at 320 MHz.
• Application CPU that controls BISTs, error logging and management functions.
• Three 256 Mbit Flash memory ICs for storing the configuration(s) (CPU Flash).
• JTAG chain that offers access to the CPU and reduced-latency DRAM for debugging, production
testing and programming the flash memories.
• A 64 kbit FRAM used for error logging.
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 10 Document Number:
D-A664Lab-G-05-001
3. FUNCTIONAL DESCRIPTION
3.2 Interfaces
This section describes the front-panel and back-panel interfaces of the TTE-Switch A664 Lab v2.0.
3.2.1 Status LEDs
In operation, the front-panel LEDs of the TTE-Switch A664 Lab v2.0 indicate the following status informa-
tion. An empty field in the table means the respective LED is not relevant for the given status:
POWER STATUS SYNC DEF. CONF Description
When the power supply of the switch is turned on, the
POWER LED is solid green.
When the bootloader starts or when the parity check fails, the
STATUS LED is solid red.
When the firmware activation fails, the STATUS LED (con-
trolled by the bootloader) flashes red.
When no valid configuration is found, the STATUS LED
flashes orange.
When the firmware is running in Normal mode, the STATUS
LED is solid green.
During start-up (initializing PHYs, running PBISTs, etc) or
when the firmware is running in SHOP mode, the STATUS
LED is solid orange.
When the firmware is running without an active TTEthernet
synchronization in Normal mode, the STATUS LED is solid
green and the SYNC LED is off.
When the firmware is running without an active TTEthernet
synchronization in SHOP mode, the STATUS LED is solid
orange and the SYNC LED is off.
When the firmware is running with an active TTEthernet syn-
chronization in Normal mode, the STATUS LED and the
SYNC LED are solid green.
When the firmware is running with an active TTEthernet syn-
chronization in SHOP mode, the STATUS LED is solid or-
ange and the SYNC LED is solid green.
When the switch has successfully started up and loaded the
default configuration in Normal mode, the STATUS and DEF.
CONF LEDs are solid green.
When the switch has successfully started up and loaded the
default configuration in SHOP mode, the STATUS LED is
solid orange and the DEF. CONF LED is solid green.
When the switch has successfully loaded the backup config-
uration in Normal mode, the STATUS is solid green and the
DEF. CONF LED is off.
When the switch has successfully loaded the backup config-
uration in SHOP mode, the STATUS LED is solid orange and
the DEF. CONF LED is off.
Table 1: Front panel status LEDs of the TTE-Switch A664 Lab v2.0
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 11 Document Number:
D-A664Lab-G-05-001
3. FUNCTIONAL DESCRIPTION
3.2.2 CONFIG interface and configuration plug
Connector type: 25-pin D-sub female connector (DB-25S)
(a) The DB-25S CONFIG interface (b) The DB-25P configuration plug
Figure 6: The CONFIG interface of the TTE-Switch A664 Lab v2.0
The DB-25P configuration plug (see Figure 6b on this page) makes it possible to select configurations and
operating modes of the switch.
Pin Pin Type Description Dip Switch No. Signal Name
1 Output Reset push button – RESET
2 Output Configuration selection 0 dip switch 1 CON_SEL_0
3 Output Configuration selection 1 dip switch 2 CON_SEL_1
4 Output Configuration selection 2 dip switch 3 CON_SEL_2
5 Output Configuration selection 3 dip switch 4 CON_SEL_3
6 Output Configuration selection 4 dip switch 5 CON_SEL_4
7 Output Configuration selection 5 dip switch 6 CON_SEL_5
8 Output Reserved for future use 9 RFU
9 Output Dip switch 7 Shop-Mode
10 NC Not connected – NC
11 Output Dip switch 8 Write_Prot
12 NC Not connected – NC
13 NC Not connected – NC
14 NC Not connected – NC
15 NC Not connected – NC
16 NC Not connected – NC
17 NC Not connected – NC
18 Output Dip switch 10 WD_Disable
19 Output Dip switch 11 Grnd-Mode
20 Output Maintenance dip switch 12 RFU
21 NC Not connected – NC
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 12 Document Number:
D-A664Lab-G-05-001
3. FUNCTIONAL DESCRIPTION
Pin Pin Type Description Dip Switch No. Signal Name
22 NC Not connected – NC
23 Ground Dip switch ground – GND
24 Ground Dip switch ground – GND
25 Ground Dip switch ground – GND
Table 2: Pin assignment of the Configuration Plug
3.2.2.1 Pin programming scheme
The programming pins Con_Sel_0 (LSB) to Con_Sel_4 (MSB) are used to represent the configuration
index, whereas Con_Sel_5 is used as the parity bit (even parity). See also Figure 6b on the previous page
and Table 2on this page. Depending on the selected programming pin combination, a switch configuration
is loaded from one of 16 possible positions.
• If the dip switch is set to position ON, the pin is connected to Ground on the connector.
• If the dip switch is set to position OFF, the pin is not connected at all on the connector.
Table 3on the current page lists the valid programming pin combinations that are possible for the default
configuration (Con_Sel_0 = OFF).
NOTE To select a programming pin combination for the actual/backup configuration, set Con_Sel_0 to ON.
Position Con_Sel_0 Con_Sel_1 Con_Sel_2 Con_Sel_3 Con_Sel_4 Con_Sel_5
0 OFF ON ON ON ON ON
1 OFF OFF ON ON ON OFF
2 OFF ON OFF ON ON OFF
3 OFF OFF OFF ON ON ON
4 OFF ON ON OFF ON OFF
5 OFF OFF ON OFF ON ON
6 OFF ON OFF OFF ON ON
7 OFF OFF OFF OFF ON OFF
8 OFF ON ON ON OFF OFF
9 OFF OFF ON ON OFF ON
10 OFF ON OFF ON OFF ON
11 OFF OFF OFF ON OFF OFF
12 OFF ON ON OFF OFF ON
13 OFF OFF ON OFF OFF OFF
14 OFF ON OFF OFF OFF OFF
15 OFF OFF OFF OFF OFF ON
Table 3: Valid programming pin combinations for the default configuration
NOTE Selecting a new programming pin combination at startup is only possible if the Grnd-Mode dip switch is
set to ON, i.e. if unrestricted mode is active.
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 13 Document Number:
D-A664Lab-G-05-001
3. FUNCTIONAL DESCRIPTION
3.2.3 MIRROR port
The TTE-Switch A664 Lab v2.0 has a 10/100/1000 Mbit/s mirror port that can be used to forward selected
traffic to a dedicated monitoring end system (e.g. a PC running Wireshark).
For monitoring, an end system must be configured in the network description, or the mirror port must be
configured via the RS-232 interface. Configuring the mirror port via the RS-232 interface is only possible
in SHOP mode.
NOTE For CLI commands to enable hardware mirroring, see Section 7.5.3 on page 33.
3.2.4 Ethernet ports
Figure 7: The Ethernet ports of the TTE-Switch A664 Lab v2.0
The switch has 24 Ethernet ports, numbered PORT1 to PORT24. Ethernet ports PORT1 and PORT2
are special as they can be used either via SFP or RJ45. For each of these two ports, only one of the
connectors can be used at a time as both the SFP and RJ45 interface connect to the same physical layer.
The ports are configured as follows:
Port Description
1 … 2 General-purpose SFP and RJ45 Ethernet ports:
fiber medium – 100Base-FX/1000Base-X
copper medium – 10Base-T/100Base-TX/1000Base-T
3 … 6 General-purpose RJ45 Ethernet ports:
copper medium – 10Base-T/100Base-TX/1000Base-T
7 … 24 General-purpose RJ45 Ethernet ports:
copper medium – 10Base-T/100Base-TX
Table 4: Ethernet ports of the TTE-Switch A664 Lab v2.0
NOTE Hot-plugging of SFP modules (i.e. inserting a module during run-time) is not supported by the switch
and requires a reset to configure the module properly.
There are two LEDs per port integrated in the connector, a green Link LED and a yellow Activity LED.
Port LED Description
The Link LED is solid green when a link is established with the connected end system.
The Activity LED flashes yellow when communication activity is detected (frame transmission
or frame reception).
Table 5: RJ45 port LED status
3.2.5 JTAG interface
The JTAG connector is used for factory testing and firmware programming.
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 14 Document Number:
D-A664Lab-G-05-001
3. FUNCTIONAL DESCRIPTION
3.2.6 RS-232 interface
The RS-232 interface is used for debugging in SHOP mode (see Section 5.6 on page 22). The control
interface complies with the RS-232 standard and enables connection to one of the COM ports of a PC
using a serial 1:1 adapter cable (DB-9 connector to DB-9 socket). The settings are 19200 baud, 8 data
bits, one stop bit, no handshake, no parity.
Pin No. Signal Name Signal Type
1 NC Not connected
2 RS232_TXD_D-SUB Transmit data output from the TTE-Switch A664 Lab v2.0
3 RS232_RXD_D-SUB Receive data input from the TTE-Switch A664 Lab v2.0
4 NC Not connected
5 GND Ground
6 NC Not connected
7 NC Not connected
8 NC Not connected
9 NC Not connected
Table 6: Pin assignment of the RS-232 interface
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 15 Document Number:
D-A664Lab-G-05-001
3. FUNCTIONAL DESCRIPTION
3.3 Technical data of the TTE-Switch A664 Lab v2.0
3.3.1 Cooling
The TTE-Switch A664 Lab v2.0 is constructed for passive cooling only and can withstand an operational
ambient temperature ranging from 0 ○C to +70 ○C without air flow.
NOTE When the switch is used in environmental conditions with temperatures exceeding +45 ○C , it is mandatory
to mount the switch in a suitable rack to avoid the risk of burns or other personal injury.
3.3.2 Size
The dimensions of the TTE-Switch A664 Lab v2.0 are according to 1U of IEC 60297 [3]. Size (in mm):
351 x 482.6 x 43.8
Figure 8: Dimensions of the TTE-Switch A664 Lab v2.0
3.3.3 Weight
The TTE-Switch A664 Lab v2.0 has a maximum weight of 5 kg.
3.3.4 Electrical characteristics
Power Supply:
The switch supports the following input voltage:
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 16 Document Number:
D-A664Lab-G-05-001
3. FUNCTIONAL DESCRIPTION
• Voltage: 85 VAC - 264 VAC
• Frequency: 47 Hz - 63 Hz
Power Consumption:
The switch consumes a maximum of 45 W.
Grounding:
• For ESD protection, Signal Ground (GND) is connected with 5 x 1 nF and 2 x 10 MΩ to CHASSISGND.
• Signal Ground (GND) is AC/DC-coupled with CHASSISGND, which is connected to the housing and
the metal-plated connectors (Ethernet RJ45, SFP Cages, D-SUB DE-9, D-SUB DE-25), which can
be accessed from outside.
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 17 Document Number:
D-A664Lab-G-05-001
4. GETTING STARTED
≡4 Getting started
This section describes the sequence of steps to get started with the TTE-Switch A664 Lab v2.0.
1. Make sure the switch is connected to a power outlet and switched off.
2. Connect an RS-232 connector to the RS-232 serial interface on the back panel of the switch (see
also Appendix B).
The settings for serial communication are: 19200 baud, 8 data bits, 1 stop bit, no parity, no handshake.
3. Connect the DB-25P configuration plug to the DB-25S CONFIG interface on the front panel of the
switch.
4. On the DB-25P configuration plug, use the following dip switch positions to load the default configu-
ration of Position 0:
Dip Switch Position
Con_Sel_0 OFF
Con_Sel_1 ON
Con_Sel_2 ON
Con_Sel_3 ON
Con_Sel_4 ON
Con_Sel_5 ON
Shop-Mode OFF
Maintenance OFF
Grnd-Mode ON
5. Turn on the power switch.
• On start-up, all status LEDs are briefly turned on, which changes during the switch start-up
sequence (see Table 1on page 11).
• When the switch has successfully finished start-up, the POWER LED and the STATUS LED are
solid green. As the switch default configuration was selected for start-up, the DEF. CONF LED
is solid green as well.
• See Appendix Bfor the serial terminal output during start-up.
In the Operational state the switch provides information via SNMP. In SHOP mode, it is possible to
retrieve more detailed information via serial terminal.
6. Connect a host PC directly to one of the 24 front-panel ports using a standard Cat5 or Cat5e patch
cable.
• Set the IP address of the host PC to the same subnet as the switch, for example to 10.10.10.20.
• Set the subnet mask of the host PC to 255.255.255.0.
• Set the transmission speed to 100 Mbps Full Duplex and make sure auto-negotiation is acti-
vated.
7. To verify that the switch is operational, open the CLI window, type ping 10.10.10.10 and press
Enter . If no data packet was lost, the ping was successful.
Pinging 10.10.10.10 with 32 bytes of data:
Reply from 10. 10. 10. 10: bytes =32 time =12 ms TTL =128
Reply from 10. 10. 10. 10: bytes =32 time =9 ms TTL =128
Reply from 10. 10. 10. 10: bytes =32 time =7 ms TTL =128
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 18 Document Number:
D-A664Lab-G-05-001
4. GETTING STARTED
Reply from 10. 10. 10. 10: bytes =32 time =7 ms TTL =128
Ping statistics for 10.10.10.10:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss ),
Approximate round trip times in milli -seconds :
Minimum = 7ms, Maximum = 12ms , Average = 8ms
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information 19 Document Number:
D-A664Lab-G-05-001
Table of contents
