ttec ArtPower Series User manual

3
Table of Contents
Thank You...................................................................................................................................
Overview......................................................................................................................................
Operation....................................................................................................................................
Switching On and Off...............................................................................................................
How to charge the ArtPower....................................................................................................
Charging your device with the ArtPower................................................................................
Checking the remaining power capacity of the ArtPower...................................................
Important safety instructions...................................................................................................
Maintenance ..............................................................................................................................
4
5
6
7
8
10
11
12
16

4
Thank you
Thank you for purchasing the ArtPower Portable Charger. For optimum performance and
safety, please read these instructions carefully before operating the product.
Please keep your user manual for future reference.
Specifications
• Capacity: 8.000mAh
• Battery Type: Li-Polymer
• Input: 1 x Micro USB Port, 1 x Type-C Port
• Output: 1 x USB Output
• Input: DC5V 2A(maximum)
• Output: DC5V 2.1A(maximum)
• Charging Time: 5 hours
• Dimensions: 137 x 68 x 13.6mm
• Weight: 170 gram

5
Overview
Contents of the package:
• 1 x ArtPower Portable Charger
• 1 x Micro USB Cable
• 1 x User Manual
The ArtPower Portable Charger includes the parts as shown in the following diagram:
LED Power Indicator
Power On/Off
Button
Micro USB Input
Type-C Input USB Output

6
• iPhone/iPod/iPad
• Samsung, LG, Sony, HTC, Nokia, Huawei, Motorola, BlackBerry, etc...
• Smart watches
• Digital cameras
• Portable Bluetooth devices such as earphones, car kits, and speakers
• Portable game consoles
Operation
iPad PSPiPhone MP3/MP4Phone

7
Switching On and Off
Switching the AlumiSlim On and Off
1. Switching the ArtPower on:
Press the power button once. The LED power indicator will illuminate, showing that the device
is on.
2. Switching the ArtPower off:
If the ArtPower is not connected to any device, the LED indicator will go off in 35 seconds and
the ArtPower will switch off.
If there is no connected device, the LED indicators will go off after 35
seconds and the mobile power unit will automatically be switched off after
120 seconds.

8
Charging the ArtPower
Please connect your cable to the ArtPower Micro USB port or Type-C port, and charging will
start when you connect the USB connector to a USB-compatible charger or your computer.
• The LED lights will flash to indicate the charge status during the charging process.
• When the charging is finished, all of the 4 LED indicators will illuminate continuously.
How to charge the ArtPower

9
When the ArtPower is locked or goes into short-circuit protection mode due to misuse, please
charge and restart it.
* A charger and computer are not supplied with the product. The charging time depends on the
charger’s power output.
How to charge the ArtPower

10
Charging your device with the ArtPower
Suitable for the following devices:
1. You can use your original USB data cable or the Micro USB cable included in the pack to
connect your device.
2. Using the cable, connect your device to the USB port of the ArtPower.
3. Press the power on button.
4. The LED power indicator will illuminate continuously when your device is being charged.
5. Disconnect your device after it is fully charged.
iPad PSPiPhone MP3/MP4Phone

11
Checking the remaining power capacity of the ArtPower
•After you press the Power On/Off button, the LED lights will show the remaining capacity.
•The LED lights will go off automatically after approximately 35 seconds.
On Off Flashing Remaining
Less than 25%
Between 25% and 50%
Between 50% and 75%
Between 75% and 99%

12
Important safety instructions
• In order to maximize battery life, please fully charge the ArtPower before the first use.
• Please keep The ArtPower in a cool, dry place.
• Please do not leave The ArtPower in hot and humid environments.
• The operating temperature should be between -10°C and 45°C.
• If the ArtPower has not been used for a long time, you should charge and discharge it at
every three months.
• The ArtPower may get hot when charging a device. This is normal and there is no need
for concern.
• The battery performance will reduce in a few years under normal conditions.
• Please do not put the ArtPower in extremely hot environments or into fire.
• Please do not use hazardous chemicals or detergents to clean the ArtPower.
• Misuse, dropping or excessive force may damage the device.

13
Safety Information
• Please remove the product carefully from the packaging and store all the accessories in
the box in order to avoid losing them. Please check the product for transportation damage.
Please do not expose your device to shocks during transportation.
• If your product is damaged and not working please notify your point of purchase im-
mediately.
• If your product has been shipped directly to you, please notify the shipper immediately.
• There are no user-serviceable parts inside your product. In the case of faults please contact
an authorized service station (Please see the list of authorized service stations) or the
authorized seller that you purchased your product from.

14
Information on misuse
• Errors caused by not using the product as specified in the manual,
• Short circuits that occur when the product is used in hot and extremely humid environ-
ments,
• Using additional connection cables other than those supplied by the manufacturer inside
the product packaging,
• User intervention or adding/removing parts,
• External physical impact on the product and damage such as breaking the product,
• Damaging or removing the product serial number,
• Failure caused by not using the original accessories,
• Damage caused by natural disasters such as fire, lightning, floods, and earthquakes.

15
Disclaimer
This battery can only be used with compatible electronic equipment. Please read the
instructions on your equipment’s packaging to make sure this battery is suitable for your
equipment. The manufacturer will not be held responsible for damage to electronic equip-
ment that occurs during the usage of this product.
The manufacturer will not be held responsible for damage to the battery caused by misuse
or by the intentional or unintentional actions of the buyer or third parties with regards to
equipment and accessories that are not compatible with this battery. As stated above, the
manufacturer will not be held responsible for damage to the battery due to misuse.

16
Maintenance
Your device is a product of advanced design and workmanship, and must be main-
tained properly. The following recommendations will help you preserve your warranty
coverage.
· Please store all accessories and attachments out of children’s reach.
· Please keep the device dry. Rain, moisture, and all kinds of liquids contain minerals that
may be corrosive to electronic circuits. If your device gets wet please dry it thoroughly.
· Please do not use or store the device in dusty and/or dirty environments. Moving parts and
electronic parts may become damaged.
· Please do not store the device in hot environments. High temperatures may shorten the
life of electronic devices, damage batteries, and cause certain plastic parts to deform or
melt.

17
· Please do not store the device in cold environments. When the device returns to normal
temperature, moisture may build up inside it and electronic circuits may be damaged.
· Please take care not to drop, bang or shake the device. Rough handling may cause breaking
of internal circuits and sensitive mechanical parts.
· Do not use abrasive chemicals, cleaning solvents or strong detergents to clean the device.
· Do not paint the device. Paint may restrict the moving parts and prevent them from
functioning properly.
All the recommendations above apply to the device, batteries, charger or all the other
accessories. If the device does not function properly, please take it to the nearest authorized
service center.

18
Technical Assistance for Damages
• Product fails to operate due to not following operating instructions,
•An unexpected change in performance,
• Product is dropped or damaged,
• Problems due to improper use or negligence,
• Damage to power source or connection cable,
• Liquid spillage or insertion of objects into the product,
• Opening or removing any of the labels,
• Any signs of attempts to open and/or tamper with the product.

19
INFORMATION ON MAINTENANCE, REPAIR, AND
PRODUCT CLEANING
Your product does not require maintenance as long as the instructions in the user manual are
followed.
The “LIFETIME” of the device is 3 years in terms of spare parts supply and proper functioning.
Note: Our company is not responsible for any errors that may occur during writing and printing.
*** This product complies with the AEEE Directive.
*** This product is marked in accordance with and regulations.
***This product complies with the RoHS Directive.

20
RoHS Statement
All our company’s lead-free products comply with the Restriction of the Use of Certain
Hazardous Substances (RoHS) European directive. This means that our production processes
and products are strictly “lead-free” and do not contain hazardous substances as defined
in the directive.
The crossed-out wheelie bin symbol indicates this product should be collected separately
within the European Union at the end of its lifetime. This applies to your product and its
attachments that have this symbol. Please do not dispose of these products as unclassified
domestic waste.
