Tuff & Gusty TG10-3CDO Assembly instructions

OWNER’S MAN AL
SAFETY INSTR CTIONS
Please read and keep these instructions with the fan.
MODEL: TG10-3CDO
For use in Non-Explosive/Non-Flammable environments only.
Purchase Date: ___________________ Serial No. ___________________
Dealer: ______________________________________
www.schaeferfan.com
©2012 Schaefer Ventilation Equipment. All rights reserved.
-TG10-3CDO

SCHAEFER LIMITED WARRANTY
If you are the original purchaser of a new Tuff & Gusty Fan, then you are entitled to a limited warranty subject to the
terms and conditions set forth herein. To qualify for the limited warranty you must complete the enclosed registration
card and mail it to Schaefer within (30) days of the purchase so that there is a record of your purchase. Schaefer’s
limited warranty is for the replacement or repair of any part that proves to be defective in workmanship or materials
for a period of (90) days from the date of purchase by the original purchaser. During the first (90) days, Schaefer will
provide all parts necessary to correct any defects, free of charge. This limited warranty extends only to the original
purchaser who retains ownership of the Fan. This limited warranty is not transferable to any subsequent purchaser or
second-hand user.
The limited warranty extends only to the repair or replacement of parts found upon Schaefer's examination to be
defective. Unless any part or assembled unit replaced hereunder is returned, freight pre-paid, together with a letter
describing the problem to Schaefer or an authorized Schaefer dealer, this limited warranty will be void and of no
effect.
This warranty is limited to ninety (90) days for labor from the date of the purchase. Thereafter, any labor costs
incurred will be charged to the customer at the prevailing hourly rate.
This limited warranty shall not extend to a product that has been used in an improper manner, or that has been
disassembled, altered or improperly maintained. Nor shall this limited warranty apply if the Fan has been subjected to
corrosive chemicals, improper voltage, unauthorized repairs, fire, flood, abnormal wear or any causes beyond
Schaefer's control.
This limited warranty does not apply if the serial number has been removed, obliterated, or defaced.
Schaefer Ventilation reserves the right to make changes to the Fan in design, materials or specifications as
necessary and without prior notice. Schaefer shall not be obliged to make alterations or modifications to existing
products previously manufactured.
To obtain replacement parts pursuant to this limited warranty, you must write to Schaefer or call (320) 251-8696 to
receive an authorization number.
Replacement parts will not be provided unless the customer first provides the serial number of the Fan and also
receives an authorization number from Schaefer.
OTHER THAN THE FOREGOING IMITED WARRANTY, THERE ARE NO FURTHER WARRANTIES OR ANY
AFFIRMATIONS OF FACT OR PROMISES BY SCHAEFER WITH RESPECT TO THE FAN. THE DURATION OF
ANY IMP IED WARRANTIES ARE IMITED TO THE TERMS OF THE ABOVE IMITED WARRANTY. SOME
STATES DO NOT A OW IMITATIONS ON HOW ONG AN IMP IED WARRANTY MAY AST, SO THE ABOVE
IMITATIONS MAY NOT APP Y TO YOU. WITHOUT IMITING THE GENERA ITY OF THE FOREGOING,
SCHAEFER EXPRESS Y DISC AIMS ANY INFRINGEMENT OR ANY AFFIRMATIONS OF FACT OR QUA ITY
NOT EXPRESS Y CONTAINED HEREIN. SCHAEFER VENTI ATION AND ITS AFFI IATES NEITHER ASSUME
NOR AUTHORIZE ANY PERSON TO ASSUME FOR THEM ANY OTHER OB IGATION OR IABI ITY IN
CONNECTION WITH ITS PRODUCTS. THERE ARE NO OTHER WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE HEREOF. IN NO EVENT SHA SCHAEFER VENTI ATION BE IAB E FOR
SPECIA , INCIDENTA OR CONSEQUENTIA DAMAGES, OR FOR OSS OF PROFITS OF ITS CUSTOMERS
OR USERS OF PRODUCT. SOME STATES/JURISDICTIONS DO NOT A OW THE EXC USIONS OR
IMITATIONS OF INCIDENTA OR CONSEQUENTIA DAMAGES, SO THE ABOVE IMITATIONS MAY NOT
APP Y TO YOU. THIS IMITED WARRANTY GIVES YOU SPECIFIC EGA RIGHTS, AND YOU MAY A SO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
Notes

INTRODUCTION
Congratulations on your selection of a new Carpet Dryer from Schaefer Ventilation. Our goal is to provide you
with the very best in high performance air ventilators. Reading this Owner's Manual will help you achieve the
maximum benefit from your portable air ventilator. If you do not understand any portion of this Manual, please
contact Schaefer, or your authorized Schaefer dealer for proper assistance prior to operating this Fan.
Do not allow anyone to operate the Fan without first reading the Operator's Manual and becoming familiar with its operation.
Schaefer has endeavored to provide you with the finest equipment available for providing air for portable ventilation pur-
poses. The possibility does exist, however, that the Fan can be subjected to applications not intended by Schaefer. Misuse
an /or misapplication of the Fan can lea to the possibility of serious amage, injury or even eath. Anyone operat-
ing the Fan should refer to current OSHA job safety and health rules and regulations pertaining to the construction industry,
with a particular emphasis on 29 CFR 1910, which contains rules governing Permit-Required Confined Spaces for General
Industry.
Recor the Fan mo el an serial number in the space provi e below.
Mo el No.____________________ Serial No. ________________________ Date Purchase ______________________
All specifications are general in nature and are not intended for specific application purposes. Schaefer accepts no responsi-
bility for variations which may be evident in actual products, specifications, pictures and descriptions contained in this publi-
cation.
MAINTENANCE
DANGER
ALWAYS SHUT OFF THE FAN AND UNPLUG IT FROM ITS POWER SOURCE TO PREVENT ACCIDENTAL STARTING
AND THE POSSIBILITY OF ELECTRICAL SHOCK AND/OR ELECTROCUTION. BE SURE THE FAN BLADE HAS
STOPPED ROTATING BEFORE PLACING ANY OBJECTS OR FINGERS NEAR THE FAN GRILL.
I. Visually check all fasteners and individual components for loose or broken parts. Tighten or replace items as required, with
genuine, factory approved replacement parts only.
2. Keep the Fan blade clean from debris. Accumulation of dust, dirt, paint, etc. on the Fan blade will throw the blade rotation
out of balance resulting in damage. To clean the Fan blade, be sure the plug is disconnected and the blade has stopped ro-
tating. Remove one grill and wipe blade and interior shell housing clean of debris with a damp cloth and mild liquid soap. Dry
all parts thoroughly. DO NOT PRESSURE WASH THE FAN. Replace grill prior to next operation.
DANGER
DO NOT OPERATE THE FAN WITHOUT THE INLET AND OUTLET GRILL PROPERLY IN PLACE.
3. Contact Schaefer directly for Fan maintenance or repair not described in this manual (or if you are unsure whether main-
tenance is required.) at Tel# (320) 251-8696 or at www.schaeferfan.com.
MOTOR SPECIFICATIONS GENERAL INFORMATION & DIMENSIONS
Voltage 115V AC-- Type Centrifugal
Frequency 60 Hz
Phase Single Height 18" (45.7 cm)
Electric Motor 1/2 HP, 3 Speed Width 16" (40.6 cm)
Current (amps) 5.0 ength 18" (45.7 cm)
R.P.M 1100/1000/900 Weight 23.5 lbs (10.66 kg)
AIR FLOW RATES
Description CFM M³/Min
High 1012 28.66
Medium 954 27.01
ow 890 25.20

SAFETY PRECA TIONS
DANGER
THE FAN IS DESIGNED FOR PORTABLE AIR VENTILATION PURPOSES ONLY. THE FAN IS NOT DESIGNED
FOR TRANSPORTING LIQUID OR SE I-SOLID ATERIALS. THE ELECTRIC MOTOR AND FAN HO SING ARE
NOT DESIGNED FOR OPERATION IN AN EXPLOSIVE OR FLAMMABLE ATMOSPHERE. OPERATION OF
THE FAN IN AN EXPLOSIVE OR FLAMMABLE ATMOSPHERE MAY RES LT IN PROPERTY DAMAGE, PER-
SONAL INJ RY OR EVEN DEATH. INCORRECT USE OF THE FAN CAN RESULT IN AN ELECTRICAL SHOCK
AND/OR ELECTROCUTION. ALWAYS OPERATE THE FAN IN CO PLIANCE WITH CURRENT OSHA AND NA-
TIONAL ELECTRIC CODE REGULATIONS.
DANGER
INCORRECT USE OF THE FAN CAN RESULT IN PROPERTY DA AGE, PERSONAL INJURY OR EVEN DEATH.
TO REDUCE THIS RISK, GIVE CO PLETE AND UNDIVIDED ATTENTION TO THE JOB AT HAND. AN ENVIRON-
ENT AT OSPHERE CONSTANTLY CHANGES; THEREFORE, IT'S RECO ENDED THAT AIR ONITORING/
GAS DETECTION EQUIP ENT BE USED FREQUENTLY. IF TESTS SHOW THAT THE AT OSPHERE QUALI-
FIES AS A HAZARDO S LOCATION (AN AREA WHERE THE POSSIBILITY OF EXPLOSION AND FIRE IS CRE-
ATED BY THE PRESENCE OF CO BUSTIBLE LIQUIDS, FLA ABLE GASES, VAPORS, DUST, FIBERS,
FLA ES OR FILINGS.) DO NOT SE THIS FAN. READ AND UNDERSTAND THE FOLLOWING PREPARATION
ITE S AND GENERAL SAFETY INFOR ATION.
PREPARATION
1) Become familiar with the Fan operations before utilizing this Fan. Read and understand all Cautions and Warn-
ings in this anual. Refer to current OSHA publications for complete job safety and health rules and regulations
(CFR 1926 and 1910).
2) Confirm that the Fan is in its original, factory configuration and has not been modified in any manner.
3) inors should not be allowed to operate the Fan. Close attention is necessary when used, especially when used
near children or animals.
4) Guard against the possibility of back-related injuries. Always lift the Fan with leg muscles and not with the back.
5) Periodically inspect the Fan visually for damaged or worn parts. Check for loose and/or broken parts. Be sure that
the Fan and accessories are in good working condition before operating.
6) Ground the motor securely. The (U.S.) Fan utilizes a NE A 5-15P plug. It is designed to operate ONLY from a
grounded, 115 volt nominal AC~, 60Hz, single phase power source that utilizes a NE A 5-15R receptacle. The use
of a ground fault circuit interrupter (GFCI) gives additional on the job protection from electrical shock hazards
caused by ground faults in commercial, industrial and residential applications.
7) Know how to stop the Fan quickly in an emergency. Turn unit off at (on/off) switch located on side of unit or un-
plug Fan from power supply.
GENERAL SAFETY INFORMATION
1) Never place the Fan in standing water because of extreme shock hazard.
2) Never allow air intake grill to become blocked.
3) Never discharge flammable solvents or kerosene based chemicals through the Fan air intake grill.
4) Do not use the Fan in areas where flammable or combustible liquids, gases, vapors, dust, fibers, or filings
may be present.
5) Never put any object in the air intake grill.
6) Never run the Fan outside when it is raining. Never store the Fan outdoors.
7) Do not use the Fan as a toy.
8) Use the Fan only with a properly grounded outlet.
9) Unplug the Fan from outlet when not in use and before servicing.
WARNING: To reduce the risk of fire or electric shock, do not use this fan with any
solid state speed control device.
GENERAL SAFETY INFO. (Continued)
10) Do not use the Fan with a damaged cord or plug. Do not pull or carry the Fan by its cord, do not use cord as a
handle, do not close a door on the cord, and do not pull cord around sharp edges or corners. Keep cord away from
heated surfaces. Do not unplug the Fan by pulling on cord, grasp the plug and not the cord. Do not handle the plug
or cord with wet hands.
11) Keep hair, loose clothing, fingers and all parts of the body away from the air intake grill.
12) Do not allow water inside the motor. If the motor becomes wet for any reason, unplug the Fan and thoroughly
dry it before using again.
13) Never remove the ground from the power cord or plug, as this may result in electrical shock or electrocution.
Removing the ground would void the warranty.
14) If the Fan has been dropped, left outdoors, or dropped into water, etc...,please thoroughly inspect it prior to use.
If the Fan is not working or if you have a question about its safe operation, do not operate it. Contact Schaefer
Ventilation directly at (320)251-8696 or at www.schaeferfan.com.
OPERATION
1) Your new Fan comes to you completely assembled and ready to operate. Upon removing the Fan from its carton,
inspect it for any possible damage in transit.
2) Before operating the Fan, please read all the safety Precautions and General Safety Information about the proper
and safe use of the Fan.
3) Assess your job site. Certain job site locations are classified as being hazardous because the atmosphere may
contain gas vapor or dust in explosive quantities.
DANGER
THE ELECTRIC MOTOR AND FAN HO SING ARE NOT DESIGNED FOR OPERATION IN AN EX-
PLOSIVE AND/OR FLAMMABLE ATMOSPHERE OF ANY CLASS OR GRO P. OPERATION OF
THE FAN IN AN EXPLOSIVE OR FLAMMABLE ATMOSPHERE MAY RES LT IN PERSONAL IN-
J RY OR DEATH.
4) Locate a properly grounded outlet.
5) Prior to plugging the Fan into a grounded outlet, inspect the inlet and outlet grills and remove debris which may
restrict airflow movement. Never operate the Fan without the inlet and outlet grills properly secured and in place.
Never replace the grills with anything other than factory supplied replacement units.
6) Note the directional airflow indicator on the external shell. This is the way the air moves.
7) Place the Fan on secure footing to prevent it from shifting while in use.
8) Do not stand directly in front of and/or face the Fan outlet. Personal injury can result from being struck by debris
thrown at a relatively high velocity from the Fan blade.
9) Position Fan air inlet away from walls and other obstructions to allow for maximum air intake.
10) For safe operation, use the Fan only in combination with thorough gas detection tests and continual
retesting.
DANGER
ALWAYS ASS ME A CONFINED SPACE WORK AREA IS CONTAMINATED NTIL IT HAS BEEN
PROVEN SAFE FOR WORK PERSONNEL. NEVER ENTER A CONFINED SPACE WORK AREA
NTIL IT HAS BEEN THORO GHLY TESTED WITH APPROPRIATE GAS DETECTION EQ IP-
MENT AND PROVEN SAFE FOR WORK PERSONNEL.
