Tuncmatik DIGITECH PRO 650 VA User manual

USER MANUAL
DIGITECH PRO
650/850 VA
UNINTERRUPTIBLE POWER SUPPLY
UPS
ENGLISH

Front View
AC Input
USB Communication Port
RJ 11/45 Protection Port
Output Receptacles
1
2
3
Back View
Product Overview
4
Power Switch
LCD Display
1
2
650 VA / 850 VA

Product Features
Modern, stylish concept
Today the IT users not only want functional products, but also nice looking
products which they will enjoy to see every day. Digitech Pro is a unique design
and has a display which looks up, if you think 90% of the UPS work under your
table on the floor; this makes the user to see the display without bending down.
Multi funtion LCD display with voltage meter
Digitech Pro has his own way of communicating to it’s user; you can see many
information from the LCD display like the input/output voltage, load level, battery
level, overload etc.
CPU control for reliability
Digitech Pro is a digital UPS which has a high speed CPU ensuring that it does all
of it’s functions right and on time. This very critical especially for protection of the
UPS; as all the overload, overvoltage, undervoltage protections and controlled
digitally by the CPU, it provided exceptional reliability to the UPS.
Simulated sine wave
Digitech Pro provides simulated sinewave form which is suitable PC and IT
equipment.
LCD Display
Input
Voltage
Load
Level
Over
Load
Fault
Line Mode Battery Mode Output
Voltage
Battery
Level
Low
Battery

Buck and boost AVR function
Digitech Pro acts as a voltage stabilizer as well, if the line voltage is too high it will
reduce it to the normal limits or if there is a brownout, Digitech Pro UPS will increase
the voltage level to protect it’s connected equipment.
USB communication port and software
Digitech Pro comes with a CD and USB cable, you can connect your Digitech Pro UPS
to your PC via the USB port. When you load the software to your computer (Windows,
Linux or Mac compatible), you can monitor your UPS from your monitor or you can
program your UPS on how to function in case of a power failure. Digitech Pro is a
smart UPS and can be controlled through your computer or it can make a orderly
shutdown by saving all your application data, closing your software and shutting
down your operating system and finally shutting down your computer.
Charging when UPS is off
Your UPS can charge it’s batteries even when it is not working, you don’t have to
leave your UPS on order to charge your batteries at night. Your Digitech Pro will
safely charge it’s batteries even if it’s not switched on.
RJ 11/45 (modem/internet) protection port
Digitech Pro is equipped with a special protection port to protect your, telephone line
or modem against power surges.
Overload, low and high voltage protection
Digitech Pro provides full reliability by providing several electronic protections to
ensure a problem-free long life product. As an example, you can not damage your
Digitech Pro by an accidential overloading, it will sense the load and protect itself
without any hardware damage.
Low-and high-voltage protection
High capacity battery
Most UPS systems will charge their battery to full in 8 to 10 hours, but Digitech Pro
can fill it’s batteries in 4 hours to ensure a safe operation in regions where electric
failures are very often.

Please place the UPS
away from other units
at least 20cm to avoid
interference.
Plug in the AC input cord to the wall outlet. The unit charges its battery while
connecting to the utility. For the best results, suggest to charge the battery at
least 6 hours before initial use.
• Before installation, please inspect the unit. Be sure that nothing
inside the package is damaged.
• Install the UPS in a protected area that is free of excessive dust
and has adequate air flow.
•Do NOT operate the UPS where the temperature and humidity is outside the
specific limits. (Please chech the technical specs for the limitations)
Güç
Anahtarı
Installation and initial startup
Connect to utility and charging
Plug in the loads to output receptacles on the rear panel of the UPS. Simply turn
on the power switch of UPS unit, then devices
connected to the UPS will be protected by UPS unit.
Connect the loads
Turn on the UPS unit by pressing the power switch.
Turn off the UPS unit by pressing again the power
switch.
Turn On/Off the unit
D
O
N
’
T
C
O
N
N
E
C
T
A
L
A
Z
E
R
P
R
I
N
T
E
R
T
O
T
H
E
U
P
S
U
N
I
T
T
H
I
S
M
A
Y
C
A
U
S
E
T
H
E
D
A
M
A
G
E
O
F
T
H
E
U
N
I
T

SAFETY - WARNING
This UPS utilizes voltages that may be hazardous.
Do not attempt to disassemble the unit. The unit
contains no user serviceable parts. Only factory
service personnel may perform repairs.
Internal battery voltage is 12Vdc. Sealed, lead-acid,
6 cells battery. Connection to any other type of
receptacle other than a two-pole, three-wire
grounded receptacle may result in shock hazard as
well as violate local electrical codes.
In the event of an emergency, press the Smart
On/Off Button for 4 seconds and disconnect the
power cord from the AC power supply to properly
disable the UPS.
Do not allow liquids or any foreign object to enter
the UPS. Do not place beverages or any other
liquid-containing vessels on or near the unit.
This unit intended for installationina controlled
environment (temperature controlled, indoor area
free of conductive contaminants). Avoid installing
the UPS in locations where there is standing or
running water, or excessive humidity.
Do not plug the UPS input into its own output.
Do not attach a power strip or surge suppressor to
the UPS.
Do not attach to non-computer-related items, such
as medical equipment, life-support equipment,
microwave ovens, vacuum cleaners, lazer printers or
washing machine.
To reduce the risk of overheating the UPS, do not
cover the UPS
cooling vents and avoid exposing the unit to direct
sunlight or installing the unit near heat emitting
appliances such as space heaters or furnaces.
Unplug the UPS prior to cleaning and do not use
liquid or spray detergent.
Do not dispose of batteries in a re as they may
explode.
Do not open or mutilate the battery or batteries.
Released electrolyte is harmful to the skin and eyes.
lt may be toxic.
Attention, hazardous through electric shock. Also
with disconnection of this unit from the mains,
hazardous voltage still may be accessible through
supply from battery. The battery supply should be
therefore disconnected in the plus and minus pole
of the battery when maintenance or service work
inside the UPS is necessary.
Servicing of batteries should be performed by
authorized personnel. Keep unauthorized personnel
away from batteries.
A battery can present a risk of electrical shock and
high short circuit current. The following
precautions should be observed when working on
batteries:
1) Remove watches, rings, or other metal objects
from the hands.
2) Use tools with insulated handles.
3) Wear rubber gloves and boots.
4) Do not lay tools or metal parts on top of
batteries.
5) Disconnect charging source prior to connecting
or disconnecting batteries terminals.
When replacing batteries, replace with the same
number and type of sealed lead-acid battery. The
maximum ambient temperature raling is 40˚C.
This pluggable type A equipment with battery
already installed by the supplier is operatar
installable and may be operated by laymen.
During the installation of this equipment it should be
assured that the sum of the leakage currents of the
UPS and the connected loads does not exceed 3.5
mA.
The mains socket outlet that supplies the UPS
shall be installed near the UPS and shall be easily
accessible.

TROUBLE SHOOTING
Use the table below to solve minor problems.
SolutionsProblem Possible Cause
Low batteryNo LED display on
the front panel
Alarm continuously
sounds when the
mains is normal
Charge the UPS at least 6 hours
Battery fault Replace the battery with the same
type of battery (Please see
Safety-Warning page)
The UPS is not turned on
The UPS is overload
Press the On/Off button at least 1
second to turn on the UPS
Remove some loads first. Before
reconnecting equipment, please
verify that the load matches the UPS
capability specified in the specs.
(Please see Technical Specification
table)
When power fails,
back-up time is
shorten
The UPS is overload Remove some critical load
The mains is normal
but LED color in red
is flashing
Power cord is loose Reconnect the power cord properly, if
the problem can’t be solved please
consult nearest technical service
Battery voltage is too
low
Charge the UPS at least 6 hours
Battery defect. It might
be due to high
temperature operation
environment, or improper
operation to battery.
Replace the battery with the same
type of battery (Please see
Safety-Warning page)

TECHNICAL SPECIFICATIONS
± %10
2-6 ms, 10 ms max.
Simulated sine wave
4-6 hours recover to 90% capacity
321 x 123,5 x 163,5
12V 7Ah x 1 12V 9Ah x 1
4.15 5.15
650 VA
360 W
850 VA
480 W
0-40˚C 0-90% (non-condensing)
< 40 dBA
220/230/240 VAC
162-265 VAC
DIMENSIONS AND WEIGHT
INPUT
OUTPUT
BATTERY
ENVIRONMENT
CAPACITY
Voltage range
Transfer time
Waveform
Dimensions D x W x H (mm)
Net weight (kg)
Type & Number
Charging time
Humidity
Noise level
Voltage
Voltage range
