Tuncmatik NEWTECH PRO II X9 User manual

info@tuncmatik.com / www.tuncmatik.com
NEWTECH PRO II X9
1-2-3 KVA ONLINE
UNINTERRUPTIBLE POWER SUPPLY
USER MANUAL

1
Table of Contents
1. Important Safety Warning .................................................................................................................2
1-1 Transportation ............................................................................................................................2
1-2 Preparation ..................................................................................................................................2
1-3 Installation...................................................................................................................................2
1-4 Operation......................................................................................................................................3
1-5 Maintenance, service and faults...........................................................................................3
1-6 Symbols used in this guide.....................................................................................................4
2. Installation and setup..........................................................................................................................4
2-1 Unpack checking........................................................................................................................4
2-2 Real panel view ..........................................................................................................................5
2-3 LCD control panel ......................................................................................................................7
2-4 Setup the UPS .............................................................................................................................7
3. Operations................................................................................................................................................ 9
3-1 Button operation........................................................................................................................9
3-2 LCD display.................................................................................................................................10
3-3 UPS setting.................................................................................................................................13
3-4 Operating Mode Description................................................................................................15
3-5 Operational Status and Mode(s) ...................................................................................….16
3-6 Alarm or Fault reference code.............................................................................................17
4. Troubleshooting ...................................................................................................................................18
5. Storage and Maintenance.................................................................................................................19
6. Specification..........................................................................................................................................20

2
1. Important Safety Warning
Important safety instructions –Save these instructions
Please comply with all warnings and operating instructions in this manual strictly. Save
this manual properly and read carefully the following instructions before installing the
unit. Do not operate this unit before reading through all safety information and operating
instructions carefully
There exists dangerous voltage and high temperature inside the UPS. During the
installation, operation and maintenance, please abide the local safety instructions and
relative laws, otherwise it will result in personnel injury or equipment damage. Safety
instructions in this manual act as a supplementary for the local safety instructions. Our
company will not assume the liability that caused by disobeying safety instructions.
1-1 Transportation
Please transport the UPS system only in the original package to protect against shock
and impact.
1-2 Preparation
Condensation may occur if the UPS system is moved directly from cold to warm
environment. The UPS system must be absolutely dry before being installed. Please
allow at least two hours for the UPS system to acclimate the environment.
Do not install the UPS system near water or in moist environments.
Do not install the UPS system where it would be exposed to direct sunlight or near
heater.
Do not block ventilation holes in the UPS housing.
1-3 Installation
Do not connect appliances or devices which would overload the UPS system (e.g.
laser printers) to the UPS output sockets.
Place cables in such a way that no one can step on or trip over them.
Do not connect domestic appliances such as hair dryers to UPS output sockets.
The UPS can be operated by any individuals with no previous experience.
Connect the UPS system only to an earthed shockproof outlet which must be easily
accessible and close to the UPS system.

3
Please use only VDE-tested, CE-marked mains cable (e.g. the mains cable of your
computer) to connect the UPS system to the building wiring outlet (shockproof
outlet).
Please use only VDE-tested, CE-marked power cables to connect the loads to the UPS
system.
When installing the equipment, it should ensure that the sum of the leakage current
of the UPS and the connected devices does not exceed 3.5mA.
1-4 Operation
Do not disconnect the mains cable on the UPS system or the building wiring outlet
(shockproof socket outlet) during operations since this would cancel the protective
earthing of the UPS system and of all connected loads.
The UPS system features its own, internal current source (batteries). The UPS output
sockets or output terminals block may be electrically live even if the UPS system is not
connected to the building wiring outlet.
In order to fully disconnect the UPS system, first press the OFF/Enter button to
disconnect the mains.
Prevent no fluids or other foreign objects from inside of the UPS system.
1-5 Maintenance, service and faults
The UPS system operates with hazardous voltages. Repairs may be carried out only
by qualified maintenance personnel.
Caution - risk of electric shock. Even after the unit is disconnected from the mains
(building wiring outlet), components inside the UPS system are still connected to the
battery and electrically live and dangerous.
Before carrying out any kind of service and/or maintenance, disconnect the batteries
and verify that no current is present and no hazardous voltage exists in the terminals
of high capability capacitor such as BUS-capacitors.
Only persons are adequately familiar with batteries and with the required
precautionary measures may replace batteries and supervise operations.
Unauthorized persons must be kept well away from the batteries.
Caution - risk of electric shock. The battery circuit is not isolated from the input
voltage. Hazardous voltages may occur between the battery terminals and the
ground. Before touching, please verify that no voltage is present!
Batteries may cause electric shock and have a high short-circuit current. Please take
the precautionary measures specified below and any other measures necessary when
working with batteries:
-remove wristwatches, rings and other metal objects

4
-use only tools with insulated grips and handles.
When changing batteries, install the same number and same type of batteries.
Do not attempt to dispose of batteries by burning them. This could cause battery
explosion.
Do not open or destroy batteries. Escaping electrolyte can cause injury to the skin
and eyes. It may be toxic.
Please replace the fuse only with the same type and amperage in order to avoid fire
hazards.
Do not dismantle the UPS system.
1-6 Symbols used in this guide
WARNING!
Risk of electric shock
CAUTION!
Read this information to avoid equipment damage
2. Installation and setup
NOTE: Before installation, please inspect the unit. Be sure that nothing inside the
package is damaged. Please keep the original package in a safe place for future use.
2-1 Unpack checking
Don’t lean the UPS when moving it out from the packaging
Check the appearance to see if the UPS is damaged or not during the transportation,
do not switch on the UPS if any damage found. Please contact the dealer right away.
Check the accessories according to the packing list and contact the dealer in case of
missing parts.

5
2-2 Real panel view
1kVA standart:
1kVA Ex. Batt:
2kVA Standart:

6
2-3kVA Ex Batt:
3KVA Standart:
1. AC input
2. Network / Fax / Modem Surge Protection(option)
3. Input circuit breaker
4. EPO(option)
5. USB communication port(option)
6. RS-232 communication port
7. SNMP intelligent slot (option)
8. Output receptacles
9. Battery Terminal
10. Output Terminal

7
2-3 LCD control panel
LCD control panel introduction
(1)LED(from top to bottom: “alarm”, “bypass”, “battery”, “inverter”)(2)LCD display (3)
Select button:enter to next item (4)Off button (5)On button
2-4 Setup the UPS
Step 1: UPS input connection
Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension
cords.
For 200/208/220/230/240VAC models: The power cord is supplied in the UPS
package.
Step 2: UPS output connection
For socket-type outputs, simply connect devices to the outlets.
For terminal-type input or outputs, please follow below steps for the wiring
configuration:
a) Remove the small cover of the terminal block
b) Suggest using AWG14 or 2.1mm2power cords for 3KVA
(200/208/220/230/240VAC models).
c) Upon completion of the wiring configuration, please check whether the wires are
securely affixed.
d) Put the small cover back to the rear panel.

8
Step 3 Communication connection
Communication port:
To allow for unattended UPS shutdown/start-up and status monitoring, connect the
communication cable one end to the USB/RS-232 port and the other to the communication
port of your PC. With the monitoring software installed, you can schedule UPS
shutdown/start-up and monitor UPS status through PC.
The UPS is equipped with intelligent slot perfect for either SNMP or Relay card. When
installing either SNMP or Relay card in the UPS, it will provide advanced communication
and monitoring options.
NOTE: USB port and RS-232 port can’t work at the same time.
Step 4: Turn on the UPS
Press the ON button on the front panel for two seconds to power on the UPS.
Note: The battery charges fully during the first five hours of normal operation. Do not expect
full battery run capability during this initial charge period.
Step 5: Install software
For optimal computer system protection, install UPS monitoring software to fully configure
UPS shutdown. You may insert provided CD into CD-ROM to install the monitoring
software.
Step 6: External battery connection
If your UPS is not including batteries. Please connect external batteries as below chart.

9
3. Operations
3-1 Button operation
Button
Function
ON Button
Turn on the UPS: Press and hold ON button for at least
2 seconds to turn on the UPS.
Down key: Press this button to display next selection
in UPS setting mode.
Exit setting mode:Press this button to confirm
seletion and exit setting mode when LCD display the
last selection in UPS setting mode.
OFF Button
Turn off the UPS: Press and hold this button at least
2 seconds to turn off the UPS in battery mode. UPS will
be in standby mode under power normal or transfer to
Bypass mode if the Bypass enable setting by pressing
this button.
Switch to bypass mode: When the main power is normal,
press and hold this button for 2 seconds. Then UPS will
enter to bypass mode. This action will be ineffective
when the input voltage is out of acceptable range.
Up key: Press this button to display previous selection
in UPS setting mode.
Select/Mute
Button
Switch LCD message: Press this button to change the LCD
message for input voltage, input frequency, battery
voltage, output voltage and output frequency etc.
Mute the alarm: When the UPS is on battery mode, press
and hold this button for at least 2 seconds to disable
or enable the alarm system. But it’s not applied to
the situations when warnings or errors occur.
Switch to UPS self-test mode: Press and hold this
button for 2 seconds to enter UPS self-testing while
in AC mode.
OFF + Select
Button
Setting mode: Press and hold this button for 5 seconds
to enter UPS setting mode.

10
3-2 LCD display
There are 8 interfaces available in the LCD display
1) Input information display area: input voltage and frequency;
2) Output information display area: output voltage and frequency
3) Battery information display area: battery status and capacity;
4) Load information display area: UPS load
5) Logo
1
4
2
5
3

11
Item
Interface Description
Content Displayed
01
Input voltage
02
Battery voltage
03
Output voltage
04
Load

12
05
Temperature
(Heatsink Temperature &
Environment Temperature)
Note
:
UDC9101 only has
Heatsink Temperature.
06
Firmware Version & UPS
model.
07
CODE
(Operational status and
mode)
08
Alarm Code(Warming
Message)
All alarm codes are
present when abnormal
behavior(s) occur(s)

13
09
The charging status can
also be shown on the
screen as below while the
charger is on.
3-3 UPS setting
The setting fuction is controled by 3 buttons (Select ,Off, On): Select + Off---goes into the setting
page, Select --- value adjustment; Off & On ---for choosing different pages(Off ▲ & On ▼).
After the UPS turn ON, press buttons Select & Off for 5 seconds and then goes into the setting
interface page.
Note: Figure at left corner is the page number of the setting pages.
Item
Settings
Content Displayed
01
Mode setting
Press select button Select to change
the setting (ECO CF or NOR).
Press UP button ▲to select the
previous setting.
Press DOWN ▼button to select the
next setting.
02
Output voltage setting
Press select button to change the
setting (100,110,115,120,127 or
200,208,220, 230, 240).
Press UP button ▲to select the
previous setting.
Press DOWN ▼button to select the
next setting.

14
03
Frequency setting
Press select button to change the
setting (50 or 60Hz).
Press UP button ▲to select the
previous setting.
Press DOWN ▼button to select the
next setting.
04
Battery capacity setting
Press select button to change the
setting (Battery capacity range is
1-200Ah).
Press UP button ▲to select the
previous setting.
Press DOWN ▼button to select the
next setting.
05
Bypass voltage upper limit
setting
Press select button to change the
setting(The bypass voltage upper limit
range is 230-264Vac ).
Press UP button ▲to select the
previous setting.
Press DOWN ▼button to select the
next setting.
06
Bypass voltage lower limit
setting
Press select button to change the
setting(The bypass voltage lower limit
range is 170-220Vac).
Press UP button ▲to select the
previous setting.
Press DOWN ▼button to select the
next setting.

15
07
Voice setting
Press select button to change the
setting(ON or OFF).
Press UP button ▲to select the
previous setting.
Press DOWN ▼button to save and
exit the setup.
3-4 Operating Mode Description
Operating mode
Description
Display
Online mode
When the input voltage is
within acceptable range,
UPS will provide pure and
stable AC power to output.
The UPS will also charge
the battery at online mode.
Inverter led light
ECO mode
Energy saving mode:
When the input voltage is
within voltage regulation
range, UPS will bypass
voltage to output for energy
saving.
Bypass led light
Battery mode
When the input voltage is
beyond the acceptable
range or power failure and
alarm is sounding every 4
second, UPS will backup
power from battery.
Battery led light

16
Standby mode
UPS is powered off and no
output supply power, but
still can charge batteries.
All LEDs turn off
Bypass mode
When input voltage is within
acceptable range but UPS is
overload, UPS will enter
bypass mode or bypass mode
can be set by front panel.
Alarm is sounding every 10
second.
Bypass led light
3-5 Operational Status and Mode(s)
item
Content Displayed
1
Initialized
2
Standby Mode
3
No Output
4
Bypass Mode
5
Utility Mode
6
Battery Mode
7
Battery Self-diagnostics
8
Inverter is starting up
9
ECO Mode
10
EPO Mode
11
Maintenance Bypass Mode
12
Fault Mode

17
3-6 Alarm or Fault reference code
Event log
UPS Alarm Warning
Buzzer
LED
1
Rectifier Fault
Beep continuously
Fault LED lit
2
Inverter fault(Including Inverter
bridge is shorted)
Beep continuously
Fault LED lit
9
Fan fault
Beep continuously
Fault LED lit
13
Battery Charger fault
Beep continuously
Fault LED lit
15
DC Bus over voltage
Beep continuously
Fault LED lit
16
DC Bus below voltage
Beep continuously
Fault LED lit
17
DC bus unbalance
Beep continuously
Fault LED lit
18
Soft start failed
Beep continuously
Fault LED lit
19
Over Temperature
Twice per second
Fault LED lit
26
Battery over voltage
Once per second
Fault LED blinking
29
Output Short-circuit
Once per second
Fault LED blinking
31
Bypass over current
Once per second
BPS LED blinking
32
Overload
Once per second
INV or BPS LED
blinking
33
No battery
Once per second
Battery LED blinking
34
Battery under voltage
Once per second
Battery LED blinking
35
Battery low pre-warning
Once per second
Battery LED blinking
36
Over load time out
Once per 2 seconds
Fault LED blinking
37
DC component over limit.
Once per 2 seconds
INV LED blinking
39
Mains volt.Abnormal
Once per 2 seconds
Battery LED lit
40
Mains freq. abnormal
Once per 2 seconds
Battery LED lit
41
Bypass Not Available
BPS LED blinking
42
Bypass unable to trace
BPS LED blinking
43
Inverter on invalid
44
Not at Inverter side

18
4. Troubleshooting
If the UPS system does not operate correctly, please solve the problem by using the table below.
Symptom
Possible cause
Remedy
No indication and alarm even
though the mains is normal.
The AC input power is not
connected well.
Check if input power cord
firmly connected to the
mains.
The AC input is connected to
the UPS output.
Plug AC input power cord to
AC input correctly.
Alarm code is shown as “33”
and battery led blinking.
The external or internal
battery is incorrectly
connected.
Check if all batteries are
connected well.
Alarm code is shown as “26”
and battery led blinking.
Battery voltage is too high or
the charger is fault.
Contact your dealer.
Alarm code is shown as “34”
and battery led blinking
Battery voltage is too low or
the charger is fault.
Contact your dealer.
Alarm code is shown as “32”
and INV or BYPASS led
blinking.
UPS is overload
Remove excess loads from
UPS output.
Alarm code is shown as “29”
and FAULT led light.
The UPS shut down
automatically because short
circuit occurs on the UPS
output.
Check output wiring and if
connected devices are in
short circuit status.
Alarm code is shown as “9”and
FAULT led light.
Fan fault.
Contact your dealer.
Alarm code is shown as “01,02,
15,16,17,18”
A UPS internal fault has
Contact your dealer.

19
occurred.
Battery backup time is
shorter than nominal value
Batteries are not fully
charged
Charge the batteries for at
least 5 hours and then check
capacity. If the problem still
persists, consult your dealer.
Batteries defect
Contact your dealer to
replace the battery.
5. Storage and Maintenance
Operation
The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at
25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case,
please contact your dealer.
Storage
Before storing, charge the UPS 5 hours. Store the UPS covered and upright in a cool, dry
location. During storage, recharge the battery in accordance with the following table:
Storage Temperature
Recharge Frequency
Charging Duration
-25°C - 40°C
Every 3 months
1-2 hours
40°C - 45°C
Every 2 months
1-2 hours
Be sure to deliver the spent battery to a recycling facility or ship it to
your dealer in the replacement battery packing material.
Table of contents
Other Tuncmatik UPS manuals

Tuncmatik
Tuncmatik NEWTECH PRO 3 KVA User manual

Tuncmatik
Tuncmatik DIGITECH PRO 650 VA User manual

Tuncmatik
Tuncmatik PowerUp One PF 1 6K User manual

Tuncmatik
Tuncmatik LITE II 650 VA User manual

Tuncmatik
Tuncmatik NEWTECH ECO 6kVA User manual

Tuncmatik
Tuncmatik NEWTECH PRO User manual

Tuncmatik
Tuncmatik Eco 1-2-3 kVA User manual

Tuncmatik
Tuncmatik DIGITECH PRO 1000 User manual

Tuncmatik
Tuncmatik Digitech Eco 2000 VA User manual
