Turbines ATJ SV Series User manual

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 1
Turbine engine user manual
ATJ SV series turbine
©Copyright 2008. ATJ Turbine.
All Rights Reserved Manual contents & design: Leading Jet Turbine Co., Ltd

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 2
Welcome!
Congratulations on the purchase of your new ATJ gas turbine engine. ATJ
Turbines are dedicated to the design and production of engines to the
highest standards of quality and reliability that is very latest next generation
engine designs.
ATJ Turbine is our gas turbine engine product line brand name.
Leading Jet Turbine Co., Ltd. Is our company name.
PLEASE READ!
The Leading Jet Turbine Co., Ltd responsibility is limited exclusively to the
repair of the engine and accessories which are outlined in the conditions of
warranty.
Please read these instructions carefully after receiving your turbine and
before the first operations. Keep this manual for later consultation and
check for the latest update on our web site.
Customer satisfaction is important to Leading Jet Turbine Co., Ltd.
Technical support or your local dealer
Leading Jet Turbine Co., Ltd
Web site: www.atj.com.tw
Legal and Disclaimer
All contents are copyright by Leading Jet Turbine Co., Ltd All rights
reserved.
This manual, the pictures and data are property of Leading Jet Turbine Co.,
Ltd and cannot be used or reproduced in any way without written permission
from Leading Jet Turbine Co., Ltd.
The ATJ Turbine engine is a sophisticated piece of machinery. Care should
be taken at all times when using the engine. It should only be operated by
those with the appropriate skills and knowledge to do so. This engine is not
a toy. Incorrect operation or misuse can cause damage to property and
bodily harm operators, spectators and animals. ATJ Turbines accepts no
liability for any kind of damage which may occur.
Disclaimer
ATJ Turbines assumes no responsibility for any errors contained in this
document and is not liable for any damages resulting from such errors.

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 3
The warranty period for the ATJ Turbine engine core is 3 year and electronic
parts (pump , ECU ,GSU ,engine electronic board ..etc) rotor parts (impeller
bearings shaft turbine wheel .. etc) 1 year from the date of purchase. 25hr
service charge contact us for quotation .Warranty is valid solely for the
original owner and is non transferable upon resale. Warranty is limited to
manufacturing and material defects only.
Warranty
Damage or defective operation covered under the warranty terms will be
repaired and tested at no cost the original owner (other than postage and
packaging). Repairs not covered under the terms of warranty will be carried
out by ATJ Turbine, or their appointed agents after agreement of costs.
Before returning the engine or ancillary equipment for service of repair,
please contact ATJ Turbines or a ATJ Turbines approved agent to agree
action and costs.
Please do not disassemble this engine. You will breach your warranty
agreement and you will find it is a precision assembly which you will be
unlikely to re-assemble without considerable difficulty and specialist
equipment. Simply slackening the spinner nut of the rotor will immediately
lose the delicate balance condition, without which the engine may not run
without damage to its rotating assembly.
You may not dismantle the engine further. Any further investigation may only
be undertaken by ATJ Turbines.

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 4
Warranty contents
This warranty is void if any one or more of the following conditions applies.
In such a case ATJ Turbines will accept no responsibility for personal
damages, loss or any other consequences caused by the ATJ turbine
engines
1. The engine cover is dismantled except for the removal of the front
cover to access service connections and the speed sensor.
2. The engine has been subject to any form of operation whilst
containing incorrect fuel, oil, or fuel/oil mix.
3. The engine is crash damaged
4. Unauthorized maintenance or modifications have been made to any
part of the product
5. Parts have been damaged by ingestion of foreign objects (e.g. wires,
sand, water etc).
6. The engine has been operated incorrectly.
7. The product has been misused, neglected or inadequately
maintained.
8. Damage to the engine where blockages in the fuel system have
occurred by unfiltered or contaminated fuel.
9. Don't use the engine cables of other brands on ATJ turbine
engine ,it’s damaged ECU and RPM sensor no warranty
Terms and conditions may change without notice. Buyers are to accept the
latest terms and conditions with no exceptions, which is to be found
at: www.atj.com.tw

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 5
Contents
Contents list
Safety Notes.....................................................................................................................................................6
Warning ...............................................................................................................................................................7
Before starting the engine........................................................................................................................8
After shutting down the engine..............................................................................................................8
Installation turbine engine .......................................................................................................................9
Turbine engine connection.................................................................................................................... 10
Aligning transmitter with ECU ( Learn R/C )................................................................................. 16
First Turbine Operations (starting engine).................................................................................... 20
Using and Programming the ECU....................................................................................................... 21
Fuel tank ( fuel system ) ......................................................................................................................... 24
Battery & by pass nozzle extension................................................................................................. 26
Maintenance and repair work.............................................................................................................. 27
List of ECU STATUS message codes ............................................................................................... 28
List of ECU Warning message codes ............................................................................................... 29
ATJ Turbine Log.......................................................................................................................................... 30

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 6
Safety Notes
Please remember the turbine engine is not a toy and has the potential to
cause bodily harm to you and others if misused.
The following guidelines should be read carefully and adhered to.
1. Always keep a CO2 or similar fire extinguisher close when starting
and operating the engine
2. Always protect eyes and ears during the starting procedure.
3. Be aware of the extreme intake suction hazard, we advise the use
of a suitable commercial wire mesh Foreign Object Damage guard to
protect the engine intake. Ensure you have no loose items of clothing
(ties, etc.) or equipment which can readily be sucked into the engine
intake, even from adjacent to the engine.
4. Always operate your engine in open air away from confined spaces
as the engine exhaust contains gases which can cause asphyxiation
and nuisance smells.
5. Do not touch the engine whilst it is running. Turbines rotate at a very
high rpm and the engine casing and exhaust can reach very high
temperatures. Ensure anything affected by heat is kept well clear of
the engine and exhaust during operation.
6. Never use the engine near to sources of flammable gases, liquids or
materials.
7. Keep unauthorized persons, spectators, children and animals well
away from the starting area (at least 30ft or 10 metre away).
8. Always handle turbine fuel and oil with care as they are highly
flammable. Store them in appropriate label containers. Never dispose
inappropriately. We recommend the use of suitable disposable
protective gloves for the mixing of turbine oil/fuel.

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 7
Warning
Higher loads occur when driving an R/C aircraft model with a turbine engines
compared to equally powerful drives like propellers or impellers.
This is a result of considerably higher air speeds caused by jet propulsion.
Maximum speeds under jet propulsion can exceed 200 mph, depending on
the model. We would like to remind you that the AMA has issued strict rules
regarding maximum speed for operating turbine powered RC models.
Please refer to the AMA regulations from the link posted above.
During installation, seal the intake and nozzle, as well as kerosene joints to
keep dust and debris out of the engine.

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 8
Before starting the engine
1. Fuel and fuel tank, pump, shut-off kerosene valves , all cables and
turbine engine must be checked for correct.
2. All loose parts in the intake area must be fixed in a way they can never
be sucked in. Loose parts or dirt can damage the turbine engine. We
recommend use of a FOD screen.
3. Have a fire extinguisher (CO2) within reach!
4. Use only Jet A-1 or kerosene or Diesel with a 5% ratio of oil ( fully
Synthetic turbine oil). We recommend “Mobil Jet Oil II “
5. The Fuel system must not be leaking.
6. Start engine must be into the wind.
always keep the turbine with the nozzle facing downwards right before
starting.
7. Charge engine battery.
After shutting down the engine
Move jet model with the nose facing the wind. Wait until the cooling down
process is completed, it will take few minutes depending on the outside air
temperature.
The cooling process after engine shut down. During this process, the
electric power supply of the receiver and the ECU must not be turned off.
Do not touch the turbine during the cool-down because the danger of burning
still exists.
All tube connections must be inspected for leakage after each flight. The
fuel tanks must be emptied in case of extreme outside air temperatures or
when there is no further operations planned for the day (danger of
explosion!).

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 9
Installation turbine engine
1. The engine should be mounted using the ATJ engine mount or an
approved equivalent. The securing strap should be tightened gently so
as not to mark the engine casing.
2. Fuel FASTO fitting should be routed similarly clear of the intake.
3. The fuel pump should be mounted at least 300mm away from the front
of the engine. The pump can emit electrical pulses that cause the speed
sensor to transmit incorrect rpm information to the ECU. The fuel pump
should be mounted with the spindle in the vertical position with the
motor uppermost. In the event of any fuel seeping from the pump this
will not pass through the electric motor. Note the pump is supplied
fitted with built in suppression to reduce radio frequency noise.
4. The centre of the fuel tank should be mounted laterally, as near to the
centre of gravity (CG) of the model as possible. This will minimize the
CG shift as the fuel is used during flight.
5. Any air ducting to the inlet of the engine must have a minimum area of
95mm square.
6. If an extended exhaust duct is required, it should be approved by ATJ
turbine. We have found that an exhaust over 90 mm diameter gives
optimum engine performance, base on turbine engine thrust and size.
7. Extreme care should be exercised to ensure that no foreign object,
loose parts of the model. Or debris is allowed to enter the compartment
where the engine is installed.
We recommend testing the engine on a test stand prior airframe
installation. You should have a clear idea of how to arrange the
components needed to run the engine. The main issue is the fuel tank,
you will need to arrange the CG in the centre of the tank and adjust the
receiver and ECU batteries to achieve the correct location.

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 10
Turbine engine connection
Over all connection
1. Turbine engine core 3 port connector
A: RJ45 8pin for EGT & RPM signal with Valves power control
B: 3 wire power cable for starter and preheat burner power control
C: 4mm FASTO fast fitting for main fuel in to the engine
2. Fuel pump power cable one side to ECU (green 6pin ) the other side to
battery (T connector) , Fuel tube 4mm to engine, fuel filter ,fuel tank, fuel
hand cut off valve.
3. GSU JR connector to ECU

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 11
Fuel pump connection
1. Use good quality 4mm fuel tube for turbine engines.
2. Install fuel filter between fuel pump and fuel tank (low presser side).
3. Change fuel tube every year and keep the fuel tube soft no leaking.
4. Always keep the fuel filter clean.
5. Install hand cut off valve between fuel filter and air trap tank.
(You feed fuel from carry tank into aircraft main fuel tank, close this valve
stop fuel into the engine)

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 12
Turbine signal cable and power cable connection
1. 3 wire power cable with 6 ping connector to the engine
2. RJ45 8ping plug for signal and electronic valves control
*** Important note ***
Don't use the engine cables of other brands on ATJ turbine engine ,it’s
damaged ECU and RPM sensor no warranty

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 13
Signal cable connection
1. 4 pin connector have “ GV “ symbol aim at ECU “ Gas valve”
2. 6 pin connector have “ EGT” symbol aim at ECU “ Thermocouple “
3. The Signal cable connection very important, double check connection
before running the turbine engine.
*** Important note ***
Don't use the engine cables of other brands on ATJ turbine engine ,it’s
damaged ECU and RPM sensor no warranty

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 14
Throttle signal JR cable connection (to ECU Throttle input )
GSU or System Analyzer connection (to ECU Data T/PC)

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 15
Engine 3 wire power cable connection
Main power cable and pump cable connection

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 16
Aligning transmitter with ECU ( Learn R/C )
RE: below show old type GSU or new type System Analyzer the same
function
Turn on the 7.4V main engine battery power, then Transmitter and Receiver
power, you can view this screen changes to the first main monitor each 2
seconds pressing the second button from the left (Menu Up) the second
informative screen is shown. In
the first line you have the
measure of the pulse width
received from your RC system,
and the relative stick position.
Second line is show the voltage
of the battery and the software
version. If the current drawn from
the battery is higher than 0,5A,
then the ECU display the battery
voltage and the battery current in
Amp.
Next menu let you to choose in four submenus, selected by pressing the
button under of each option.
Start: Jump to the parameters
used on startup
Info: Information and test menus
Radio: Adjust the radio throws
Run: Set the parameters used
during engine run.

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 17
Turn on the transmitter and receiver. Using the “menu up” and (-) buttons
move to the “Radio” menu. First screen will be this one:
If you are sure that you want to modify the radio settings then press the right
hand button (+) and the screen will change to:
On your transmitter, raise the throttle stick and trim to full. Ensure stick is
firmly against the stop. Now holding the stick against the stop, press the
right button (+) to set the value into the ECU.
IMPORTANT NOTE: Pressing any other button the setting WILL NOT be
stored.

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 18
The screen will now change to:
Move the trim (or switch the “engine cut” switch to on) and throttle stick
back to zero and again press the right hand button (+). The display will now
change to:
Leaving the throttle stick in the minimum position, raise the throttle trim
to the full up position or switch “Engine Cut” switch to off, and again
press the “+” button. The ECU will store the current position as IDLE.
If you have done all steps correctly the green LED located directly above
the data terminal socket will light up in the ECU when the “Idle” command.
(Trim and throttle stick set to idle positions on the transmitter).

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 19
Lower your throttle trim and the green LED will go out indicating correct
reading of
The transmitter engine shut off signal by the ECU.
On rare occasions, usually when using a Futaba transmitter, it has been
found that the
throttle channel sense of movement may require reversing (Servo reverse)
and repeat the transmitter alignment.
Correct reading of throttle % by the ECU can be verified in the second
screen,
percentage of the throttle position is shown on, 0% in the position of
engine stop (trim and stick down), 100% with stick/trim full up and
between 10% and 30% at idle.
This now completes your radio setup and should only need doing again if
the radio settings
in the TX are changed.

LEADING JET TURBINE Co., Ltd. ATJ TURBINES 20
First Turbine Operations (starting engine)
Initial steps
1. Fill the fuel tank with jet turbine fuel, include 5% turbine oil mix.
2. Make sure the tank breather is open, no bubbles in fuel system.
3. Filter your fuel when filling up using a line filter on your carry fuel tank.
4. Make sure that both the ECU battery and the receiver battery are
charged and in good conditions.
5. Test your remote control range with and without the ECU turned on.
6. Always place the jet aircraft with the nose into the wind and make sure
that the jet blast will not be set in the direction of persons or equipment.
Prime the Fuel Pump feed the fuel into engine first time.( page 21 )
Turn the transmitter and the receiver ON.
Turn the engine main power ON
Set the throttle stick down and the
trim up. “Idle” - Confirm that the
LED in the ECU is illuminated and
the screen shows "Ready" - !
Move the stick to 100% and then
back to idle again. Do not leave the
stick at 100% more than 3 seconds.
The ECU will automatically check
the glow plug circuit and if OK
energize it, wait 10 second then
apply power to the starter and open
the gas solenoid. In the screen of
the ECU it will show the word "Ignition"
The gas will ignite. You will hear a "flame sound" confirming this, the
temperature indicator in the screen of the ECU will begin to up.
When the ECU detects an increase in temperature of 80~100ºC from the
temperature read at the moment the start is initiated, the screen will
change to "preheating". The fuel pump will begin to operate and power to
the glow plug will be disconnected.
Next the screen will change to "Fuel ramp". In this phase the ECU will
be gradually increasing the starter power and fuel flow. When 18.000 RPM is
reached the ECU will automatically disconnect power to both the starter and
gas solenoid valve. When the rotor speed reaches idle, the screen will
change to "running" and the engine speed stabilized.
