Jigger Drive Package
Electronic drive package for Jigger
We can equip your Jigger machines
with the latest electronic geared
AC motor drives. A complete drive
package, including motors, gear
boxes, inverters and controller
is available. All components are
pre-programmed and adapted to
each other. Special state-of-the-
art jigger functions are integrated
in the Sedomat controllers. Fabric
tension as well as fabric speed can
be controlled. The concept simplies
constructions and offers you the
possibility to produce your machine
at lower costs.

www.barco.com/sedo
Jigger drive package
Functions:
• Control of fabric tension and speed.
• Heating of bath.
• Hood heating.
• Filling machine to level.
• Filling side tank.
• Dosing:
- Initial dosing in bath (e.g. 30%)
- Continuous additional dosing
via programmable number of
passages.
• Loading:
- Maximum tension is controlled
(tension is set at the unwinding
A-frame).
- Constant speed while loading.
• Sampling always at the same
location.
• Variable balancing time between
the passages (achieve constant
dyeing time for different cloth
lengths).
• Overow rinsing with controlled
water quantity (option).
• Liquor circulation control with
frequency inverter (option).
Minimal investment - latest technology
Jigger package:
•2 AC motors for roller drive with
integrated gear, incremental
transducer and drip cover.
• Roller bearing.
• Panel with:
- 2 frequency inverter with DC
link coupling: brake energy is
converted into drive energy.
- Sedomat controller with internal
IEC1131 PLC and I/O’s.
- Operator control
box for loading,
unloading,
sampling,
forward/backward
motion, open
hood.
- Pneumatic.
- Complete electronics for all
functions.
Options:
• Second operator control box for
two-sided loading.
• Flow meter for overow rinsing.
• Frequency inverter for liquor
circulation.
More advantages:
• No mechanical gear maintenance
required, saving several 1,000’s
Euro overhaul costs per year and
several weeks lost production for
end customers.
• Reduced energy consumption by
DC link coupling (brake energy is
converted into drive energy).
• No extra fabric tension sensor
within the machine which could
be damaged by aggressive
ambient conditions.
• Length registration (without
revolving roll).
• The Sedomat shows the following
data:
- Machine visualization
- Temperature, dosing, etc.
- Consumption of power, energy,
water (when ow meter
connected).
- Length of fabric.
• Integration with SedoMaster/
ColorMaster enables planning,
statistical reports and further
process optimization.
Barco Sedo GmbH, Germany
Neuwies 1, D-35794 Mengerskirchen
Phone: + 49 6476 31-0, Fax: [phone]
[e-mail]
BarcoVision, Belgium
Phone: + 32 56 26 26 11, Fax: [phone]
[e-mail]
Loepfe Brothers Ltd. - Treepoint, Switzerland
Phone: + 41 43 488 11 88, Fax: [phone]
[e-mail]
BarcoVision LTD, UK
Phone: [phone],
Fax: [phone]
[e-mail]
BarcoVision LLC, USA
Phone: [phone], Fax: [phone]
[e-mail]
Technical specications are subject to change without prior notice.
Different types of motors can be used
