Turbo Garden TGP-BR-216 User manual

Cordless/Lithium
DC 21.6V
Outdoor Blower
USER MANUAL
Model No #：TGP-BR-216

1
Please read this manual carefully before using the product:
●TECHNICAL DATA (Cordless)
Model No.
TGP-BR-216
Voltage
DC.21.6V
Motor(no load speed)
16,000 RPM
Air Speed
135 MPH
Output
21.6 Vdc 0.4 A 9.6 VA
●TECHNICAL DATA (Adapter for Charging Lithium Battery)
Voltage
AC 120V~60Hz
Battery Charging Time
Approximate 3 to 5 hours - New
UL Approved
Class II Transformer
Input
120 Vac 60 Hz 18 VA
●INTENDED USE
Your outdoor blower has been designed for grass, shrubs and leaves and should not to be
used for any other purpose.This product is intended for consumer use only.
Your adapter has been designed for charging lithium batteries supplied with this product and
should not used to charge other batteries.
ASSEMBLY:
Warning! Before assembly, remove the lithium battery pack from the carton box.
·To install the battery pack or converter (sold separately):
1. Hold the product in one hand and the battery in the other hand, Figure (1-1).
2. Align the groove inside the battery with the groove on the inside of the product.
Make sure the battery are exactly in line with the product,Figure (1-2).
3. Push the battery into the product. Make sure the latches on each side of your battery pack
snap in place before beginning operation, Figure (1-3).

2
To remove the battery pack :
2. Locate the latches on the end of the battery pack and press & pull both sides. This will then
release the battery pack from the product, Figure (1-4).
Figure (1-4)
To install the pipe:
Snap the pipe into the main unit, with the end pointed up.
The pipe will fit tightly, in order to maintain maximum power.
OVERVIEW:
1. Blower Main Unit 2. Battery Slide 3. Adapter
4. DC Socket 5. Battery 6. Trigger Switch
7. Pipe

3
OPERATION:
Make sure the parts are placed on correctly.
To operate the machine, simply grip the handle.
CHARGING THE LITHIUM BATTERY:
The battery should be fully charged, when using for the first time and whenever it fails to
operate while in use. If you do not charge fully, you may not have sufficient power. After using
the product for a long period of time, or after a long storage, it is best to fully charge the battery,
to attain full capacity. The lithium battery does not need to be charged after a short use, as it
will not lose any memory.
The battery may become warm while charging; this is normal and does not indicate a problem.
The battery does not need to be removed from the blower when charging. Your battery can be
fully charged for the first time in approximately 3 to 5 hours. Be sure to read all safety
instructions before using your adapter.
The adapter must be serviced at an authorized service center only. This is required to avoid
damage to static sensitive internal components. Read all of the instructions before attempting
to charge the battery pack for your product. Always use the correct battery pack (pack supplied
with the product or a replacement pack exactly like it). Never install any other battery pack as it
could damage your tool and may create a hazard.
1 .Charging procedure:
The adapter requires no adjustment and is designed to be as easy to use as possible. Simply
place your battery pack plug from your adaptor and it will automatically charge the pack.
(a) Connect the output of adaptor to the input of battery.
(b) Plug the adaptor into an appropriate AC power outlet. If the charger RED LED light is
ON, this indicates it is still charging the battery. If the charger GREEN LED is ON, this
indicates the battery is ready for use.
(c) The battery pack should be fully charged in approximately 1 to 2 hours,
after the initial charge. If the green light on the charger does not
illuminate after fully charging, this is perfectly normal. In some geographical

4
areas, circuits will never obtain 100% charge and then the green light will not
come on. Go ahead with the operation of this product, as this does not affect
the performance.
Additional safety instructions for batteries and chargers:
Batteries:
·Never attempt to open the battery case for any reason.
·Do not expose or place the battery near water.
·Do not put the battery near any type of heat, as it could explode.
·Do not store in locations where the temperature may exceed 105°F.
·Do not leave the battery pack in the charger when the charging is finished, otherwise battery
leakage may occur.
·Charge the battery only at room temperature.
·Charge the battery only by using the charger provided with the product.
·Before charging, make sure that the battery is dry and clean.
·Use only the correct type of battery for the product.
·When disposing of batteries follow the instructions given in the section "ProtectingThe Environment".
·Under extreme conditions, battery leakage may occur. When you notice liquid on the battery,
proceed as follows:
·Carefully wipe the liquid off using a cloth. Avoid any skin contact.
·In case of skin or eye contact, follow the instructions below.
Immediately rinse with water. Neutralize with a mild acid such as lemon juice or vinegar.
In case of eye contact, rinse abundantly with clean water for at least 10 minutes. If
necessary, consult a physician.
·NOTE: The batteries in your battery pack are the lithium-ion type. Lithium is considered to be
a non-toxic material by the Environmental Protection Agency. Before disposing of damaged or
worn out Lithium-Ion battery packs, check with your local Environmental Protection Agency to
find out about any restrictions on the disposal of these battery packs.
Chargers:
·The adapter’s plug must match the power outlet. Never modify the plug in any way to reduce
risk of electric shock.
·Use your adapter only to charge batteries of the type supplied with your tool. Other batteries
could burst and damage the adapter.
·Only 2 battery packs are allowed to be charged continuously in order to prevent overheating
of the adapter. Necessary rest time is required to let the adapter cool down before further
charging.
·When charging is finished, unplug the adapter from the power outlet.
·Never carry the adapter by its cord or pull it to disconnect from the power outlet. Keep the
cord away from heat, oil and sharp edges.
·Never attempt to charge non-rechargeable batteries.
·The adapter cord is not changeable. Do not continue to use if the cord is damaged.
·Do not expose the battery to water or rain, do not use in wet conditions.

5
·Do not open the battery or adapter.
·This charger is intended for indoor use only.
2. Important Charging Reminders:
Longest life and best performance can be obtained if the battery pack is charged when the air
temperature is between 60°F - 75°F. Do not charge the battery pack in a very low or very high
air temperature. This is important and will prevent serious damage to the battery pack.
(a). The adapter and battery pack may become warm to touch while charging. This is a
normal condition, and does not indicate a problem.
(b). Use the adapter in normal room temperatures whenever possible. To prevent
overheating, do not cover the adapter or battery and do not charge battery packs in direct
sunlight or near heat sources.
(c). If the battery pack does not charge properly check the current at the receptacle by
plugging in a lamp or other appliance. Then move the adapter and battery pack to a
location where the surrounding air temperature is approximately 60°F - 75°F. If charging
problems persist, take or send the blower, battery pack and charger to your local service
center.
(d). The battery pack should be recharged when it fails to produce sufficient power on jobs
which were easily done previously. DO NOT CONTINUE to use under those conditions.
Follow the charging procedure only. You may also charge a partially used pack whenever
you desire with no adverse affect on the battery pack.
(e). Under certain conditions, with the adapter plugged in to the power supply, the exposed
charging contacts inside the charger can be shorted by foreign material. Foreign materials
of a conductive nature such as, but no limited to, steel wool, aluminum foil, or any buildup
of metallic particles should be kept away from charger cavities. Always unplug the adapter
from the power supply when there is no battery pack in the cavity. Unplug the adapter
before attempting to clean.
(f). Do not immerse adapter & battery in water or any other liquid.
WARNING!!!: Do not allow any liquid to get inside the adapter or battery, as electric shock may
occur. To facilitate the cooling of the battery pack after use, avoid placing the
charger or battery pack in a warm environment such as in a metal shed, or an
un-insulated trailer.
CAUTION!!!: Never attempt to open the battery pack for any reason. If the plastic housing of
the battery pack breaks or cracks, return to a service center for recycling.
ELECTRICAL SAFETY:
Your adaptor has been designed for a specific voltage. Always check that the voltage in your
country corresponds to the voltage on the rating plate.
THIS PRODUCT CAN CAUSE SERIOUS INJURIES. Read instructions carefully for the
correct handling, preparation, maintenance, starting and stopping of the product. Be familiar

6
with all controls and proper use of the product.
Additional safety instructions for the unit:
·Do not expose the product to rain or high humidity.
·Only use the product in daylight or good artificial light.
·Never allow children to use the product.
·Beware of overhead power lines.
·Avoid operating while people, especially children are nearby.
·If the product fails on its duty, immediately switch it off. Remove the battery before attempting
to remove any obstructions or charging.
·Remove the battery before checking, maintenance or working on the product.
·While operating the tool be always sure of a safe and secure operating position especially
when using steps or a ladder.
·Do not attempt to repair the product.
·Do not operate the product with a damaged or excessively worn cutting device.
·Always ensure that all guards are fitted when using the product. Never attempt to use an
incomplete tool or a tool with unauthorized modifications.
·Always use two hands to operate the product.
·When transporting or storing the product always unplug from the outlet.
·Always be aware of your surroundings and stay alert for possible hazards that you may not
hear due to the noise of the product.
·Do not carry the product with your hands on the switch unless the battery has been removed.
·If you have not used this product before, preferably seek practical instruction by an
experienced user in addition to studying this manual.
·Never block any things with the bottom air vent section while the product is running.
·Do not put the product down until the product has come to a complete stop.
·Take care to avoid hard objects (e.g. metal wire, railings) when using the product. Should you
accidentally hit any such object immediately switch the product off and check for any damage.
·Should the product start to vibrate abnormally, immediately switch it off and check for any
damage.
Safety Reminder:
Warning! When using electric tools, basic safety precautions should always be followed
to reduce the risk of fire, electric shock and personal injury, including the following.
Read all these instructions before attempting to operate the machine.
For safe operation:
1. Keep work area clean:
Cluttered areas and cluttered work benches may invite injuries.
2. Consider your work area environment:

7
Do not expose power tools to rain. Do not use power tools in damp or wet locations.
Keep working area well lit. Do not use power tools in the presence of flammable liquids
or gases.
3. Keep all children away from the product:
Do not let children contact the product. All children should be kept away from the work
area.
4. Store your idle tools:
When not in use, tools should be stored in dry, high, or locked-up place, out of the reach
of children.
5. Do not change the product specifications:
This product is designed for the type of jobs in which it was intended.
6. Use the right product for the job:
Do not use this product to do the job of product needed for other jobs.
7. Dress properly:
Do not wear loose clothing or jewelry. They can be caught in moving parts. Rubber
gloves and nonskid footwear are recommended when working outdoors. Wear protective
hair covering to contain long hair.
8. Use safety glasses:
Please use face or dust mask if cutting operation is dusty.
9. Do not abuse the cord:
Never carry product by cord or yank it to disconnect it from receptacle. Keep cord from
heat, oil and sharp edges or children.
10. Do not overreach:
Keep proper footing and balance at all times.
11. Maintain product with care:
Keep product clean for better and safer performance. Follow instructions for lubricating
and changing accessories. Inspect product cords periodically and, if damaged, have it
repaired by authorized service facility.
12. Disconnect product:
Always disconnect the product when not in use or before servicing and when changing
accessories.
13. Avoid unintentional starting:
Do not carry plugged-in product with finger on switch. Be sure switch is off when
plugging in.
14. Outdoor use of extension cords:
When product is used outdoors, use only extension cords intended for use outdoors
only.
15. Stay alert:
Watch what you are doing. Use common sense. Do not operate tools when you are
tired.
16. Check damaged parts:
Check product to see if any parts are damaged. Damaged parts should be properly

8
repaired or replaced by an authorized service center unless otherwise indicated
elsewhere in this instruction manual.
17. Always have your product repaired by an expert:
This product is manufactured in accordance with the relevant safety rules. Repairing of
electric appliances may be carried out only by experts; otherwise it may cause
considerable danger.
MAINTENANCE:
Your product has been designed to operate over a long period of time with a minimum of
maintenance.
Continuous satisfactory operation depends upon proper product care and regular cleaning.
Your adapter does not require any maintenance apart from regular cleaning.
1. Before performing any maintenance on the product, remove the battery from the product.
Unplug the adapter before cleaning it.
2.After use, carefully clean the product.
3. After cleaning, apply a film of light machine oil or other approved cleaning solution to prevent
the product from rusting.
4. Regularly clean the ventilation slots in your product by using a soft brush ordry cloth.
Accessories:
Caution: Only Turbo Garden Product accessories are recommended for use with your product.
The use of any other accessory or attachment will void the warranty. The accessories listed in
this manual are available at extra cost from your Turbo Garden products service center.
TG-216-B . . . . . . . . . . . . . . . 21.6 Volt Lithium Battery
TG-216-CHR . . . . . . . . . . . . Battery Charger/120 Volt Adapter
Additional accessories, not listed above, are available from our customer service department by
visiting our website at www.turbogardenproducts.com, or by calling the toll free number
(1-866-674-8746).
Warning!
This product contains chemicals known to the state of California to cause cancer, birth
defects or other reproductive harm.

9
Return Policy
Your satisfaction is guaranteed. If you are not satisfied with your purchase, simply return
the item in its original condition and original carton box, within 30 days, for a full refund,
less shipping. The buyer is responsible for return shipping charges. Returns are subject to a
restocking fee of up to 40% of the purchase price. Missing parts will be charged at full
suggested retail cost. After 30 days, returns are only accepted for repair or replacement
under the manufacturer’s warranty. All shipping charges are the responsibility of the buyer.
Turbo Garden Products guarantees all our products to be free from defects. Defective
products may be returned within 7 days of receipt of the product for repair or replacement
only. After 7 days, the buyer is responsible for return shipping charges as stated in the
manufacturer’s warranty.
Please contact Turbo Garden Products toll free at 1-866-674-8746 for an RMA number
before returning the product. Return shipping labels will be e-mailed to the customer if
approved.
There are no returns on parts orders.

10
LIMITED WARRANTY PARTS AND LABOR
Turbo Garden Products warrants this product to be free from defects in material and
workmanship within the following warranty period, starting from the date of sale to the original
consumer only.
If this product proves defective within the TWO (2) YEAR warranty period Turbo Garden
Products will repair or replace (at Turbo Garden’s sole discretion) the defective product. Said
product must be first returned, with your sales receipt, to the retailer of purchase. If the retailer
does not honor the 2 year warranty period contact Turbo Garden Products customer service for
repair or replacement options. The transportation cost to the service depot is the responsibility
of the owner. The transportation back to the consumer is the responsibility of Turbo Garden
Products.
This warranty does not apply to any Turbo Garden Product which is used for commercial,
rental, or industrial purposes, is damaged by accident, misuse, abuse, improper line voltage,
water, lighting, or any acts of God. This warranty is void if product is altered, modified, or if any
parts or service covered by this warranty are furnished by anyone other than Turbo Garden
Products or one of its independent Authorized warranty Stations. This warranty does not cover
cartons, carrying straps, batteries, cosmetic parts, or any other accessories used in connection
with the product or consequent damages due to a defect in the product.
ALL IMPLIED WARRANTIES ARE LIMITED TO THE DURATION OF THIS WARRANTY. THIS
IS THE COMPLETE WARRANTY STATEMENT AND NO OTHER EXPRESSED WARRANTY
IS VALID AGAINST TURBO GARDEN PRODUCTS. SOME STATES/ PROVINCES DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR AN
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTAL DAMAGES, SO THE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOTAPPLYTO YOU.
This warranty gives you specific legal rights, and you may have other rights which may vary
from state to state (province to province).
TURBO GARDEN PRODUCTS
by The Darien Group
50 Stradtman Street
Buffalo, NY 14206
PhoneToll Free (1-866-674-8746)
Fax: [phone]
E-Mail to: [e-mail]
For registration of your product, please call
our toll free number, as shown above, or visit our website at:
www.turbogardenproducts.com
KEEP YOUR SALES SLIP WITH THIS WARRANTY STATEMENT
YOUR REGISTRATION INFORMATION WILL NOT BE SOLD OR SHARED WITH ANY OTHER
COMPANY
