turck PD67-UNI Series User manual

Your Global Automation Partner
Instructions for Use
PD67-UNI-…
RFID Handheld

2Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com

V01.00 | 2020/03 3
Table of Contents
1 About these Instructions................................................................................................................... 5
1.1 Target groups................................................................................................................... 5
1.2 Explanation of symbols used ........................................................................................ 5
1.3 Other documents ............................................................................................................ 5
1.4 Naming convention ........................................................................................................ 5
1.5 Feedback about these instructions.............................................................................. 5
2 Notes on the Product.........................................................................................................................6
2.1 Product identification..................................................................................................... 6
2.2 Scope of delivery ............................................................................................................. 6
2.3 Legal requirements......................................................................................................... 6
2.4 Manufacturer and service.............................................................................................. 7
3 For Your Safety.................................................................................................................................... 8
3.1 Intended use..................................................................................................................... 8
3.2 General safety instructions............................................................................................9
4 Product Description .........................................................................................................................10
4.1 Device overview ............................................................................................................10
4.1.1 Operating elements ......................................................................................................................10
4.1.2 Display elements............................................................................................................................10
4.2 Properties and features................................................................................................11
4.3 Functional principle......................................................................................................11
4.4 Functions and operating modes ................................................................................11
4.4.1 HF operation....................................................................................................................................11
4.4.2 UHF operation.................................................................................................................................11
4.4.3 Barcode scanner.............................................................................................................................12
5 Connecting ........................................................................................................................................13
5.1 Battery charging............................................................................................................13
6 Commissioning .................................................................................................................................14
7 Operation ...........................................................................................................................................15
7.1 Aligning the handheld .................................................................................................15
7.2 Switching the display on and off................................................................................15
7.3 Start screen – Overview................................................................................................15
7.4 Performing a scan operation.......................................................................................16
7.4.1 Performing a scan operation with the Turck RFID app ....................................................16
7.4.2 Performing a scan operation via buttons on the device .................................................16
7.5 Reading and writing tags.............................................................................................18
7.5.1 Reading and writing tags - Extended functions .................................................................19
7.5.2 Example: Read data.......................................................................................................................20
7.5.3 Example: Write data ......................................................................................................................25
7.6 Reading a barcode ........................................................................................................30
7.7 Exchanging data with a PC ..........................................................................................30
8 Setting ................................................................................................................................................31
8.1 Operating mode setting...............................................................................................32
8.2 Assign password............................................................................................................32
8.3 Setting the scan screen ................................................................................................33

Table of Contents
4Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
8.3.1 Area: Sending data – Parameters.............................................................................................34
8.3.2 Area: Scanning – Parameters.....................................................................................................39
8.3.3 Area: Display – Parameters.........................................................................................................39
8.3.4 Area: Security – Parameters........................................................................................................39
8.4 Integrating the RFID app in the web application....................................................40
8.4.1 Transferring configuration parameters – URL format ......................................................40
8.4.2 Overview of the configuration parameters..........................................................................40
8.5 Adapting the RFID app.................................................................................................42
8.5.1 RFID app – Source code...............................................................................................................42
9 Troubleshooting ...............................................................................................................................47
10 Maintenance......................................................................................................................................48
10.1 Battery replacement .....................................................................................................48
10.2 Carrying out a Firmware Update................................................................................48
11 Repair..................................................................................................................................................48
11.1 Returning devices..........................................................................................................48
12 Disposal ..............................................................................................................................................48
13 Technical Data...................................................................................................................................49
14 Appendix: Conformity Declarations and Approvals..................................................................50
14.1 EU declaration of conformity ......................................................................................50
14.2 FCC/IC Digital Device Limitations (PD67-UNI-NA…)..............................................50

V01.00 | 2020/03 5
1 About these Instructions
These operating instructions describe the structure, functions and the use of the product and
will help you to operate the product as intended. Read these instructions carefully before using
the product. This is to avoid possible damage to persons, property or the device. Retain the in-
structions for future use during the service life of the product. If the product is passed on, pass
on these instructions as well.
1.1 Target groups
These instructions are aimed a qualified personal and must be carefully read by anyone
mounting, commissioning, operating, maintaining, dismantling or disposing of the device.
1.2 Explanation of symbols used
The following symbols are used in these instructions:
DANGER
DANGER indicates a dangerous situation with high risk of death or severe injury if
not avoided.
WARNING
WARNING indicates a dangerous situation with medium risk of death or severe in-
jury if not avoided.
CAUTION
CAUTION indicates a dangerous situation of medium risk which may result in minor
or moderate injury if not avoided.
NOTICE
NOTICE indicates a situation which may lead to property damage if not avoided.
NOTE
NOTE indicates tips, recommendations and useful information on specific actions
and facts. The notes simplify your work and help you to avoid additional work.
uCALL TO ACTION
This symbol denotes actions that the user must carry out.
aRESULTS OF ACTION
This symbol denotes relevant results of actions.
1.3 Other documents
Besides this document the following material can be found on the Internet at www.turck.com:
nData sheet
nApprovals
nConfiguration manual
1.4 Naming convention
Common synonyms for "data carriers" include "tag", "transponder", and "mobile storage
device". Read/write heads are also described as "transceivers" or "readers".
1.5 Feedback about these instructions
We make every effort to ensure that these instructions are as informative and as clear as pos-
sible. If you have any suggestions for improving the design or if some information is missing in
the document, please send your suggestions to [email protected].

Notes on the Product
Legal requirements
6Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
2 Notes on the Product
2.1 Product identification
These instructions apply to the following handhelds:
RSWBG Interface
Interface
RRFID reader
S2D Barcode scanner
WWLAN
BBluetooth
GGPS
PD 67 –UNI –NA –RSWBG
PD 67 Handheld –
Protection class
67 IP67
Handheld
UNI Frequency Range –
Frequency Range
UNI RFID: HF and UHF adjustable
NA Country of Deployment –
Country of Deployment
NA USA, Canada, Mexico
EU EU, Turkey, India
CHN China
AUS Australia
BRA Brazil
KOR Korea
RUS Russia
SGP Singapore
PER Peru
The device variants for Australia, Brazil, Korea, Russia, Singapore and Peru are available on re-
quest.
2.2 Scope of delivery
nHandheld
nUSB charging cable
nPower supply unit
nQuick start guide
2.3 Legal requirements
The devices comply with the following regulations:
Device Region of use Regulations
PD67-UNI-EU-… Europe n2014/30/EU (electromagnetic compatibility)
n2014/53/EU (RED Directive)
PD67-UNI-NA-… USA nFCC Rules Part 15
Canada nIndustry Canada RSS-210
PD67-UNI-CHN-… China nSRRC
Notes on other variants are available on request.

V01.00 | 2020/03 7
2.4 Manufacturer and service
Hans Turck GmbH & Co. KG
Witzlebenstraße 7
45472 Mülheim an der Ruhr
Germany
Turck supports you with your projects, from initial analysis to the commissioning of your applic-
ation. The Turck product database contains software tools for programming, configuration or
commissioning, data sheets and CAD files in numerous export formats. You can access the
product database at the following address: www.turck.de/products
For further inquiries in Germany contact the Sales and Service Team on:
nSales: [phone]
nTechnology: [phone]
Outside Germany, please contact your local Turck representative.

For Your Safety
Intended use
8Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
3 For Your Safety
The product is designed according to state-of-the-art technology. However, residual risks still
exist. Observe the following warnings and safety notices to prevent damage to persons and
property. Turck accepts no liability for damage caused by failure to observe these warning and
safety notices.
3.1 Intended use
These devices are designed solely for use in industrial areas.
Passive RFID tags can be written and read with the handheld. The device can be set to HF or
UHF operation. In HF operation, the device operates at a frequency of 13.56MHz.
The following table shows the operating frequency of the device in the UHF range:
Type code Operating frequency Region
PD67-UHF-EU-… 865.7…867.5 MHz Europe, Turkey, India
PD67-UHF-NA-… 902.75…927.25 MHz North America (USA, Canada,
Mexico)
PD67-UHF-CHN-… 920.25…924.75 MHz China
PD67-UHF-AUS-… 920.25…925.75 MHz Australia, New Zealand
PD67-UHF-BRA-… 902…907.5MHz and
915…928MHz
Brazil
PD67-UHF-KOR-… 917…920.5 MHz Korea
PD67-UHF-RUS-… 916…921 MHz Russia
PD67-UHF-SGP-… 920…925 MHz Singapore
PD67-UHF-PER-… 916…928 MHz Peru
The device must only be operated in countries in which the particular frequency range is per-
missible for the use of UHF RFID.
Barcodes can also be read with the PD67-…RSWBG handheld.
The devices may only be used as described in these instructions. Any other use is not in accord-
ance with the intended use. Turck accepts no liability for any resulting damage.

V01.00 | 2020/03 9
3.2 General safety instructions
nThe device only meets the EMC requirements for industrial areas and is not suitable for use
in residential areas.
nThe device may only be assembled, installed, operated, parameterized and maintained by
professionally-trained personnel.
nThe device may only be used in accordance with applicable national and international regu-
lations, standards and laws.
nAny extended stay within the area of radiation of UHF devices may be harmful to health. Ob-
serve minimum distances from the actively radiating surface of the UHF device:
Region Max. permissible
total radiant output power
Safety distance
Europe, Russia, China, Turkey,
India
2 W ERP (according to ETSI) 0.24m
USA, Canada, Mexico 30 dBm ERP > 0.22 m
The minimum distances for other regions can be obtained from Turck on request.
nThe radiation of UHF devices may impair the operation of electrically controlled medical
equipment. Maintain an additional distance from active radiation sources up to the max-
imum transmission distance.
nChanges or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

Product Description
Device overview
10 Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
4 Product Description
The PD67 series handheld comes with protection to IP67 and is contained in a plastic housing
with a front display. The device can be operated in the HF and in the UHF frequency range. A
Wifi and a Bluetooth interface are also provided. 2D barcodes can be read and processed with
the PD67-…RSWBG device variants.
4.1 Device overview
214.0 [8.43"]
105.7 [4.16"]
50.5 [1.99"]
71.1 [2.80"]
114.4 [4.51"]
214.0 [8.43"]
105.7 [4.16"]
50.5 [1.99"]71.1 [2.80"]
114.4 [4.51"]
Fig.1: Scale drawing – Device without grip
handle
Fig.2: Scale drawing– Device with grip handle
4.1.1 Operating elements
The handheld is provided with four buttons:
nPower button for on/off switching (A)
nTwo programmable buttons on the sides of the housing (B)
nTrigger button for operating via an additional pistol grip handle (C)
BB
A
B
A
C
Fig.3: Position of the buttons
4.1.2 Display elements
The device is provided with a 5" LCD display with an 800×480px resolution and a capacitive
touch screen.

V01.00 | 2020/03 11
4.2 Properties and features
nMobile reading and writing of RFID tags
nHandheld with HF and UHF antenna
nCustom Android ROM
nIncl. Turck RFID app for reading and writing tags
nCustom software solution on request
nWIFI 802.11 b/g/n and Bluetooth Low Energy V4.0
nRemovable lithium ion battery (2400 mAh)
nIncl. PD67-BATTERY, PD67-DOCK docking station with power supply unit and USB C cable,
PD67-STYLUS stylus
nProtection class IP67
nWithstands several drops from a height of 1.5m on smooth concrete
4.3 Functional principle
RFID (radio frequency identification) is a contactless process for the automatic identification of
static or moving objects by means of alternating electromagnetic fields. It uses, for example,
the serial number of the object, which is saved on a mobile tag (transponder/tag) and is read
without contact by a read/write device over a distance of up to several meters. The RFID tech-
nology also enables multiple objects to be identified simultaneously. A direct line of sight con-
nection between the tag and the read/write head is not necessary.
4.4 Functions and operating modes
Passive RFID tags can be written and read anywhere with the device. For this the devices form a
transmission zone that varies in size and range according to the tags used and the operating
conditions of the application.
4.4.1 HF operation
The Turck HF system operates at a frequency of 13.56MHz. Tags in compliance with ISO 15693
(NFC Type 5) can be written and read with the handheld.
4.4.2 UHF operation
The Turck UHF system uses nationally specified operating frequencies for the communication
between the tags and read/write heads. These national frequencies for UHF are required due to
the frequency ranges specified by the national regulation bodies.
The operating frequency of the devices in the UHF band is for example 865…868 MHz for
Europe and 902…928 MHz for the USA. The BL ident handhelds in the UHF band can therefore
only be used in the countries they are intended for and must not be put into operation outside
of these regions. As the BL ident UHF tags are passive, and therefore do not radiate their own
radio waves, these are suitable for use worldwide.
Turck offers different tag variants that are specially designed and optimized for national fre-
quency bands in order to achieve as large a communication range as possible. Wide-band
multi-range tags for international use are also available as an alternative.
The various Turck handhelds support the following transmission frequencies:
n865.7…867.5 MHz (Europe, Turkey, India)
n902.75…927.25 MHz (USA, Canada and Mexico)
n920.25…924.75 MHz (China)
n920.25…925.75 MHz (Australia)
n902…907.5 MHz and 915…928 MHz (Brazil)
n917…920.5 MHz (Korea)
n916…921 MHz (Russia)
n920…925 MHz (Singapore)
n916…928 MHz (Peru)

Product Description
Functions and operating modes
12 Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
The relevant national specifications for UHF such as frequency range, output and the status of
any national regulations can be obtained from the Internet at:
http://www.gs1.org/docs/epcglobal/UHF_Regulations.pdf
For more detailed information please contact the regulation authorities of the country where
you wish to use the UHF RFID system.
HF RFID systems can be run parallel to UHF RFID systems in an installation.
4.4.3 Barcode scanner
The PD67-UNI-…-RSWBG handhelds are provided with an integrated barcode scanner for pro-
cessing 2D barcodes. The handhelds can be used to read the following barcode formats:
nUPC
nCode 39
nCode 128
nCode 93
nComposite code
nInterleaved 2 of 5
The following code formats can be read in addition to barcodes:
nAztec code
nQR code
nData matrix
nPDF-417

V01.00 | 2020/03 13
5 Connecting
5.1 Battery charging
NOTE
Turck recommends that the device should be charged for at least two hours before
initial commissioning.
Connect a USB plug connector to the network adapter.
Connect the mains adapter to the electricity supply.

Commissioning
14 Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
6 Commissioning
Charge the handheld with the power supply unit provided.
Keep the Power button depressed until the display appears.
Start the Turck RFID app.
Select the operating mode via the display (HF or UHF).
Press Scan, Read/Write or Barcode on the display.
Position the tag within the detection range of the handheld.

V01.00 | 2020/03 15
7 Operation
7.1 Aligning the handheld
To perform a write or read operation the handheld must be aligned to the required tag or bar-
code.
Reading or writing an HF tag: Place the tag on the yellow area of the handheld.
Reading or writing a UHF tag: Hold the handheld over the required tag.
Reading a barcode: Align the barcode reader of the handheld to the barcode.
7.2 Switching the display on and off
The display can be switched on and off during operation in order to save power in the battery.
With the display switched on: Press the Power button momentarily to switch off the dis-
play.
With the display switched off: Press the Power button momentarily to switch on the dis-
play.
7.3 Start screen – Overview
Fig.4: Start screen
The start screen provides access to the following elements:
nBattery and power supply indication
nSelect HF/UHF in order to set the operating mode
nScan button for starting the scan
nRead/Write button for reading and writing RFID tags
nBarcode for reading 2D barcodes
nSettings button for setting and configuring the handheld

Operation
Performing a scan operation
16 Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
7.4 Performing a scan operation
7.4.1 Performing a scan operation with the Turck RFID app
Press the Scan button on the start screen.
Press Start.
aThe handheld starts the scan for tags in the detection range. The Turck RFID app opens
the Scan screen.
aThe handheld confirms each detected tag with an audible signal.
aThe EPCs or UIDs of the detected tags are displayed and can be edited. Further informa-
tion on this is provided in the section “Reading and writing data”.
Fig.5: Turck RFID app: Scan screen
Interrupting a scan
Press Pause.
aThe scan is interrupted and can be continued at a later time. The displayed time is
stopped until the scan is continued.
Aborting a scan
Press Stop.
aThe scan is aborted. The displayed time is reset with the next scan. The read EPCs or UIDs
can be sent by email.
7.4.2 Performing a scan operation via buttons on the device
Starting a scan operation via buttons on the device: Press the left programmable button.
Starting the scan operation via the trigger button: Press the trigger button on the handle.
aThe handheld starts to search for tags in the detection range.
aThe handheld indicates each detected tag with an audible signal.
aThe EPCs or UIDs of the detected tags are displayed and can be edited. Further informa-
tion on this is provided in the section “Reading and writing data”.

V01.00 | 2020/03 17
Interrupting a scan
Press the right programmable button.
aThe scan is interrupted and can be continued at a later time. The displayed time is
stopped until the scan is continued.
Aborting a scan
Aborting a scan operation via the buttons on the device: Press the left programmable
button.
Aborting the scan operation via the trigger button: Press the trigger button on the
handle.
aThe scan is aborted. The displayed time is reset with the next scan. The read EPCs or UIDs
can be sent by email.

Operation
Reading and writing tags
18 Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
7.5 Reading and writing tags
The Read/Write window is used for reading, writing, protecting or permanently deactivating
(killing) tags.
Fig.6: Turck RFID app – Screen: Read/Write
The Read/Write screen provides access to the following elements:
nEPC (UHF) or UID (HF): Displays the EPC or UID of the selected tag.
nUHF applications: Selection of the memory bank on the tag (Kill, Access, PC, EPC, TID and
USER selectable)
nStart byte for the required action (hexadecimal and decimal formats selectable)
nNumber of bytes: If All is selected, as many bytes are read as are available in the particular
memory bank of the tag. If Some is selected, a specific number of bytes must be entered.
nDisplay of user data (hexadecimal, decimal and ASCII data formats selectable)
nUser data: The read data is displayed and can be edited.
nMore button: Opens the menu for other functions.
nRead button: Starts the read operation.
nWrite button: Starts the write operation.

V01.00 | 2020/03 19
7.5.1 Reading and writing tags - Extended functions
NOTE
The extended functions are only available for UHF applications.
The following extended functions are available:
nTag access password to use: Uses the access password when accessing tags.
nChange lock/unlock state: Locks or unlocks the selected memory area. The following states
can be selected:
State Description
Writable Tag can be written with and without access password
(default setting: without access password)
Permanently writable Tag can be written with and without access password
(status cannot be changed)
Write restricted Tag can only be written with the access password
Permanently unwritable Tag cannot be written (status cannot be changed)
nSend data via email: Send read data via email.
nLoad data: Load previously saved data from the memory of the handheld.
nSave data: Save data for later use on the handheld.
nKill tag: Permanently deactivate tag.
Open extended functions: On the Read/Write screen press the More button.
Fig.7: Read/write – Extended functions

Operation
Reading and writing tags
20 Hans Turck GmbH & Co. KG | T [phone] | F [phone] | [email protected] | www.turck.com
7.5.2 Example: Read data
A read operation can either be started from the start screen or from the Scan screen.
Starting the read operation from the start screen
If no EPC or UID was selected, the device normally reads the first tag found. The nearest tag is
normally found first of all. However, this is not guaranteed. The mode without EPC or UID selec-
tion should be used if only one tag is located in the vicinity of the handheld.
Press Read/Write on the start screen.
Fig.8: Start screen
UHF applications: Select the memory bank to be read.
Fig.9: Selecting the memory bank
