E-TEN M500 Manual

1
\
\
I In nf fr ra ar re ed d P Pa ar rt t /
/
Installing and Setuping the Virtual Modem
This section explains how to use the Pocket PC to simulate a Wireless
Modem. After connecting successfully to the desktop computer through the
infrared (IR) device, you can use the desktop computer to perform tasks, such
as connecting to a network, etc.
PC System Requirements
1. Supports IrDA port function
2. Microsoft Windows 2000 or XP
Setting up
1. Personal computer side:
(1) Use the Internet to download and install the PC driver program. Refer to
the documentation and screen instructions to establish a new connection.
(2) Click , Settings, Control Panel, and then Network and Dial-up
Connections.
(3) Look for the new connection you just established and click the right
mouse button. Then, run Dial on the pop-up menu to connect successfully.

2
(4) End the ActiveSync connection between the personal computer (desktop
or notebook) and the Pocket PC. Under the ActiveSync program on the
personal computer, tap File and then Connection Settings.Make sure you
did not check “Allow serial cable or infrared connection to this COM
port.”
2. Pocket PC side:
(1) Install a SIM card with GPRS function.
(2) Make sure that the ActiveSync connected between the personal computer
(desktop or notebook) and the Pocket PC has been disconnected.
(3) Pay attention that the infrared ports of the two devices are properly
aligned. The area in the effective range should be kept unobstructed. A
deviation angle within ±15 degrees and a distance within 30~50
centimeters are acceptable.

3
(4) Tap , Programs, Phone, and
then Wireless Modem to use the
Irda function to connect the
personal computer to the Pocket
PC.
Tap Irda.
Connect Button: Tap to connect.
When connection succeeds, the
screen will display “Connecting”
and the continuous connection
time.
Disconnect Button: If the personal
computer does not have to access a
network, tap this button to
disconnect.
(5) When your Pocket PC is simulating a modem, you can use the personal
computer to access a network.



4
Installing Infrared Connection Options
Use the Internet to download and install the Wireless Link file, it is a PC
driver program. We need to establish a new connection. After your Pocket PC
connecting successfully to the desktop computer, you can use the desktop
computer to perform tasks, such as connecting to the network, etc.
Refer to the following explanation to set up a
virtual COM port.
1. Unzip the
“IrCOMM2k” file you
downloaded. Run
Setup.exe, and enter the
IrCOMM2k setup
program.
2. Click Install.
3. Select a virtual COM
port, it is prepared for
the Infrared port.

5
Refer to the following explanation to set up.
1. Click , Settings,
Control Panel, and
then Wireless Link.
2. Select the Image
Transfer tab, confirm
not to check “Use
Wireless Link to
transfer images from a
digital camera to your
computer.”

6
Refer to the following explanation to set up a
virtual modem.
1. Click , Settings,
Control Panel, and
then Phone and
Modem Options.
2. Select the Modems tab
and then click Add to
add a new virtual
modem.
3. Check “Don’t detect
my modem; I will
select it from a list,”
and then click Next.
4. Select “Standard
33600 bps Modem,”
and then click Next.

7
5. Select the same COM
port you selected
earlier using the
IrCOMM2k setup
program, and then
click Next.
6. Click Finish.You
have set up a virtual
modem successfully.

8
Refer to the following explanation to set up
properties of the virtual modem.
1. Click , Settings,
Control Panel, and
then Phone and
Modem Options.
2. Select the Modems tab
and select the virtual
modem you have just
set up, and then click
Properties.
3. Select the Advanced
tab and input
“AT+CGDCONT=1,"I
P","APN","",0,0”.
Change the “APN” to
the name specified by
your telecom
company.
4. Finally, click OK to
complete and exit
Phone and Modem
Options.

9
Refer to the following explanation to
establish a new connection.
1. Click , Settings,
Control Panel,
Network and Dial-up
Connections, and then
Make New
Connection.
2. Click Next.
3. Select “Dial-up to the
Internet,” and then
click Next.
4. Select “I want to set up
my Internet connection
manually, or I want to
connect through a local
area network (LAN),”
and then click Next.

10
5. Select “I connect
through a phone line
and a modem,” and
then click Next.
6. Do not check “Use
area code and dialing
rules”.
Input *99#” in the
Telephone Number
field and click Next.
7. Input your Internet
account user name and
password. If you don’t
have this information,
leave these 2 fields
blank and click Next
directly.

11
8. Input any name you
want to use and click
Next.
9. Select No and click
Next.
10. Click Finish.You
have established a
new connection
successfully.
MyConnt

12
Refer to the following explanation to set up
properties of the new connection.
1. Click , Settings,
Control Panel, and
then Network and
Dial-up Connections.
2. Look for the new
connection you just
established and click
the right mouse button.
Select Properties from
the pop-up menu.
3. Select the General tab
to confirm that you
have selected the
virtual modem you
have just set up and
click Configure.
MyConnt

13
4. Do not check the
following items:
Enable hardware flow control
Enable modem error control
Enable modem compression
Enable modem speaker
Finally click OK to
save.
5. Select the Networking
tab and confirm that
you have selected
“Internet Protocol
(TCP/IP),” and click
Properties.
6. Click Advanced.

14
7. Do not check “Use IP
Header compression.”
8. Finally, click OK.You
have finished setting
up all properties for
this new connection.
Now you can exit
Network and Dial-up
Connections.
