Turtle Beach Ear Force X32 User manual

лчиттничюнльтцию.
глтчн.Бзвыдны
www.sotmarket.ru
дбняинфмциятв,
тзывы,бзыиы
Инструкция для
Turtle Beach Ear Force X32
Перейти в карточку товара
8 800 775 98 98

1
dual band wireless
WiFi
5GHz
User Guide

What’s in the Box
product support and warranty information:
www.TurtleBeach.com/support
X32 Headset
X32 Wireless Digital
RF Transmitter
(2) AAA Batteries
XBOX 360
Talkback Cable
Turtle Beach Sticker
T
U
R
T
L
E
B
E
A
C
H
.
C
O
M
watch X32 training videos at:
www.youtube.com/TurtleBeachVideos
X32 Headset pg 1
X32 Transmitter
Overview pg 2
Using the Transmitter pg 3
Pairing the Headset and Transmitter pg 4
Setup pg 5
Equalizer and Sound Field Expander Presets pg 11
Chat Boost™pg 12
Technical Specifications pg 13
Troubleshooting pg 14
Important Safety Information pg 14
Table of Contents
RCA Splitter Cable
TONE
R

12
OPEN
TONE
X32 Headset
Tone Button: Press this button to activate the
different EQ presets. A beep will indicate which
preset is selected. (see pg. 11)
XBOX Controller Jack: Insert the straight
connector on the talkback cable here. (see pg. 8)
Effects Button: Press this button to activate
the different Sound Field presets. A beep will
indicate which preset is selected. (see pg. 11)
Game Volume: Turn to adjust the game sound
level. The XBOX LIVE chat volume may be
independently set by the volume control on the
talkback cable.
Power Button: Turn on the headset by pressing
the power button for a couple of seconds, then
release. You will hear 2 beeps and the power
LED should start flashing. Turn off the headset
by pressing the button until the LED stays on and
you hear 2 beeps, then release. To enter Pairing
Mode, press and hold the power button for about
6 seconds until you hear 2 fast beeps and the LED
begins to flash rapidly (see pg 4). The headset
will turn off after several minutes if there’s no
audio detected or if the transmitter is turned off.
Battery Compartment Cover
Slide down the panel on the right ear cup to
access the battery compartment. The headset
is powered by (2) AAA batteries (included)
which should provide up to 15 hours of use.
Rechargeable NiMH batteries may also be used.
A tone will sound every 6 seconds when battery
power is low.
NOTE: Be sure to insert the batteries as shown.
X32 Transmitter
1
2
3
4
5
1
2
3
4
Power/Link LED: When the transmitter is powered on and
communicating with the headset, this LED will be on solid. When the
headset is turned off, the LED on the transmitter will turn off. A slowly
pulsing LED indicates that the transmitter can’t communicate with the
headset. This could happen when the headset is out of range or not
paired with the transmitter. (see pgs. 3-4)
Game Audio Input Jack
Insert the 3.5mm end of the included RCA Splitter Cable into this jack.
Auxiliary Input Jack: Provides a 3.5mm input for digital music players
or additional audio sources. (3.5mm cable sold separately)
Pairing Button: Press and hold to activate pairing mode. (See pg. 4)
5
6
6
1
2 3 4
4
3
1
2

34
TONE
Using the Transmitter Pairing the Headset and Transmitter
Transmitter Range
The transmitter sends game audio from your Xbox 360 to the headset via digital radio frequency (RF) signal, so a direct line of sight is not
required. When you’re out of range, you may hear popping or clicking sounds if the headset loses the RF signal. For best performance,
place the transmitter in an open area that is unobstructed by objects that might absorb RF signals from the internal antenna.
Avoid placing it on a metal surface, such as the top of a home theater A/V receiver.
Optimum range: within 20 ft.
The headset and transmitter in this package are “paired”, which means they’re synchronized to ensure they work together. When
the headset and transmitter are communicating, the top LED on the front panel of the transmitter will be on solid. If this LED is instead
slowly pulsing, it means the transmitter can’t communicate with the headset. This could happen when the headset is out of range or not
paired with the transmitter. If the LED is slowly pulsing when the headset is on and within range, then they might need to be “paired” as
described below:
Step 1:
Make sure the headset is turned off.
Step 2:
Press and hold the headset power button for about 6 sec-
onds until you hear 2 fast beeps and the LED begins to flash
rapidly, then release.
Step 3:
Press and hold the PAIR button on the transmitter. The
transmitter LED will beging to flash rapidly. When the
Power/Link LED on the transmitter turns off, release the
button.
After a few seconds, the Power/Link LED on the transmitter
should be on solid and the headset LED should be flashing
about once per second, indicating that the units are paired.
1
3
2
Dual-Band WiFi
The X32 uses advanced “Dual-Band WiFi” radio technology to help eliminate interference with additional wireless devices and WiFi
networks. The dual-band radio uses both 5GHz and 2.4GHz signals to transmit high fidelity digital audio and help eliminate interference
with other wireless devices. Unlike the RF technology used in most other wireless headsets, this dual-band WiFi radio technology coexists
with wireless networks for optimum performance.
TONE
R
Interference from Two Headsets
Only one headset can be paired with the transmitter. If you pair two headsets with the same transmitter, they’ll interfere with each
other as they compete for the transmitter RF signal. This will cause one headset to shut off. So don’t try to pair two headsets with the same
transmitter!
dual band wireless
WiFi
5GHz

56
XBOX 360 Setup (HDMI)
*All XBOX 360 models require an XBOX 360 Audio Adapter Cable for audio output when used with an HDMI connection (available from third party sellers).
NOTE: If your HDMI TV has red/white RCA AUDIO OUT jacks you can use it to feed the sound from your TV to your Turtle Beach headset. (AUDIO IN jacks
will not send sound out to your headset, you need AUDIO OUT as shown in the alternate setup.)
XBOX 360
Audio Adapter Cable*
(sold separately)
HDMI
Transmitter USB Cable
RCA Splitter Cable
(included)
XBOX 360 Setup (HDMI)
(Alternate Setup)
HDMI
Transmitter USB Cable
RCA Splitter Cable
(included)

78
XBOX 360 Setup (RCA)
Configure XBOX 360 Settings
1. Insert the right angle plug into the headphone
jack on the XBOX 360 controller.
2. Insert straight plug into the controller jack on the
left ear cup of the headset.
XBOX 360 Chat Setup
XBOX 360
AV Cable
Transmitter USB Cable
RCA Splitter Cable
(included) 1. Press the XBOX 360 Guide Button, select
"Settings > Preferences > Voice"
2. Voice Volume = 10
3. Game Volume = 10
4. Voice Output = Play Through Headset
Voice Volume 10
Voice
Mute Kinect
Voice Output
Play Through Headset
Play Through Speakers
Voice Output
Game Volume 10
TONE
R
Chat VolumeMic Mute
Xbox 360 Controller
Xbox 360
Talkback Cable
Xbox 360
Input

910
USB Power Cable
(included with
DSS2)
Connecting a Digital Music Player
The X32 features an auxiliary input for connecting digital music players or other analog sources so you can listen to your
own music along with the game audio. The Auxiliary Input volume can be adjusted directly from the digital music player.
Digital Music
Player
Auxiliary Input
3.5mm Cable
(sold separately)
Connect the digital music player to the
Auxiliary Input if you want to hear the
music along with the game audio.
DUALBAND
LINEINAUXIN
Connecting a DSS or DSS2
The X32 can be upgraded to Dolby® Digital surround sound by adding the Ear Force DSS or DSS2 surround sound processors
(sold separately). Visit www.turtlebeach.com/DSS2 to learn how you can upgrade your X32 headset with surround sound.
3.5mm Cable
(included with
DSS2)
Digital Optical
Cable
(included with
DSS2)
Transmitter USB Cable*
*Both the X32 transmitter USB cable and the DSS/DSS2 USB power cable
must be plugged into separate USB ports directly on the Xbox 360 console
for power. Do not plug the transmitter USB cable into the USB OUT port
on the DSS or DSS2, as this may cause overloading of the USB ports.
X32 Stereo
Sound Field
X32 Sound Field with Dolby Digital
Surround Sound Processing
Setup
Add a DSS or DSS2 to Upgrade
to Surround Sound

11 12
Tone (EQ) Presets
The X32 features multiple Equalizer presets to enhance your gaming audio experience. Press the
TONE button on the X32 headset to cycle through the EQ presets as illustrated below:
Equalizer (EQ) Presets:
1. Flat
2. Bass Boost
3. Treble Boost
4. Bass and Treble Boost
Effects (Sound Field Expander) Presets
Chat Boost™
Chat Boost is a dynamic talkback expander built into the X32 headset that automatically increases chat volume during loud
moments in your game, so you can always hear your teammates or other players, regardless of the game volume.
Typically, if you turn up a headset’s game volume, the incoming chat level from other players could become difficult to hear
over the game sound. However, with Chat Boost, as the game audio increases, the chat volume also increases. When the game
volume quiets down again, Chat Boost automatically returns the chat level to your original volume setting.
To properly set the Chat Boost function:
1. Turn down the volume control on the headset so there’s no game audio.
2. Adjust the volume control on the talkback cable so you can hear the chat voices at a comfortable level.
3. Turn up the headset game volume and the chat volume will increase whenever the game gets louder, just as if the talkback
volume control is being automatically turned up along with the game level. Note that if the volume on the talkback cable
is set too loud, Chat Boost might increase the volume so much that the voices will distort. If that happens, turn down the
talkback volume on the talkback cable.
WITHOUT Chat Boost,
chat volume is overwhelmed by loud game audio
WITH Chat Boost,
chat volume increases along with game
volume, so you can always hear teammates
NOTE: If the volume on the talkback cable is set too loud, Chat Boost might increase the volume so much that the voices
will distort. If that happens, turn down the talkback volume on the talkback cable.
Tone (Sound Field Expander) Presets:
1. Normal
2. Narrow
3. Wide
The Sound Field Expander improves your ability to hear sounds coming from a distance by boosting sounds on the left and right sides
and lowering sounds in the center. Press the EFFECTS button to cycle through the three settings as illustrated below:
TONE
Tone Button
Effects Button

13 14
X32 Transmitter Technical Specifications
· 50mm diameter speakers with neodymium magnets
· Game audio frequency response: 20Hz - 20kHz, >120dB SPL @ 1kHz
· Condenser microphone frequency response: 50Hz - 15kHz
· Game audio Dual Band WiFi Digital 2.4GHz/5.8GHz RF wireless reception
· Headphone amplifier: Stereo 27mW/ch, THD <1%
· Operates on (2) AAA batteries or (2) AAA rechargeable NiMH batteries
· Automatic shut down after approx 5 minutes of carrier loss or audio silence to conserve battery power
· Battery booster circuit extends battery life for up to 15 hours
· Dual Band WiFi Digital 2.4GHz/5.8GHz RF wireless transmission with up to 30 foot range
· Frequency response: 20Hz - 20kHz
· Stereo 3.5mm line input jack
· Stereo 3.5mm aux input jack
· Maximum analog input level: 2Vpp (700mV rms)
· USB Power – (5V DC @ 180mA max)
X32 Headset Technical Specifications Troubleshooting
No sound




communicating with the headset. If the headset is on solid and the transmitter LED is slowly pulsing, then the headset and
transmitter need to be “paired” as described in the section “Pairing the Headset and Transmitter”.
Audio Drops, Popping or Clicking Sounds
Audio dropouts, popping or clicking sounds on the headset are caused by poor reception. This can occur when:
Voice Chat Drops
please be patient. In extreme cases, you may have to leave a game and return to reset the chat function.

A wired connection from your modem/router to your console is recommended for best results.
Safety Notice
To avoid potential damage to the device, always disconnect all cables before transporting it.
WARNING: Permanent hearing damage can occur if a headset is used at high volumes for extended periods of time, so it is important
to keep the volume at a safe level. Over time, your ears adapt to loud volume levels, so a level that may not cause initial discomfort can still
damage your hearing. If you experience ringing in your ears after listening with the headset, it means the volume is set too loud.
The louder the volume is set, the less time it takes to affect your hearing. So, please take care to listen at moderate levels.

then slowly increase it to a comfortable level.

