Tuuci 1005376 Quick reference guide

14
|tuuci
1005376
2
4
3
lights and heaters
Step 4
lock umbrella down by pushing the cam lock handles in the down
position and lock with pins. Mount beauty covers over control boxes.
Step 1
remove all packaging from in and around umbrella
Step 2
pull pin from cam lock and lift the handle to unlock umbrella
Step 3
once you have leveled the stem using the base installation instructions,
slide the beauty cover and umbrella over the security stem
(security stem is included with umbrella).
Note: Ensure that cables are not pinched when inserting the umbrella over
the security stem and when installing the beauty cover.
umbrella
beauty cover
electrical beauty covers
cam lock handles
security stem
pins
cam lock handles

15
|tuuci
1005376
mounting dual canopy frame
Step 5
For shipping purpose trolley carts are tighten with elastic rope.
Remove protective bubble wrap and elastic rope.
remove
rope
lower
trolley cart
for umbrellas with
high wind stabilizers
upper
trolley cart
Step 6
Install 2nd canopy frame by using the 3/8” bushings and screws.
Note: add a drop of provided loctite to the end of the screw threads.
NOTE:
Remove protective
bubble wrap from
electrical sleeve.
Step 7
If applicable connect high wind stabilizers.
a. Mount long arms wind stabilizers to
lower trolley cart
b. Mount short arms wind stabilizers to
upper trolley cart.
Note: add a drop of provided loctite to the
end of the screw threads.
lower
trolley
cart
upper
trolley
cart
long
arms
short
arms
5

16
|tuuci
1005376
electrical sleeve connection
Step 8
mount electrical sleeve to scissor bracket with 3/8” bushing and
3/8”-16 flat head screw
Note: add a drop of provided loctite to the end of the screw threads.
Step 9
Connect cable from electrical sleeve to scissor cable Step 10
push in cable and connector through scissor grommet hole
electrical sleeve
scissor bracket
scissor grommet hole
connector inside scissor arm

17
|tuuci
1005376
Step 11
Plug in the cord of your umbrella into 220V receptacles. The TUUCI logo on the
control panel will be backlit in white, when the umbrella is properly plugged into the
power source.
Step 16
Gently separate each rib individually from the center hub approximately 10 inches. If the rib does not move eas-
ily, do not force. Inspect the product for additional packaging.
CAUTION
Ensure that your umbrella is level (not tipped or tilted). For safety reasons, If the umbrella is tipped,
you will not be able to turn-on the Ambia LED light and/or heaters.
Ensure that there is nothing blocking the canopy of the umbrella from being fully opened.
18
Step 12
Press the Power button on the control panel to turn on the umbrella. The button will
be backlit in red when the power is ON. In addition, when the umbrella is ON, the light
icon and heater icon on the control panels will be backlit in white.
lights and heaters
control
panel
Step 13
Make sure the gear lock button is in the top (unlocked) position before turning the crank handle.
Step 14
Insert and rotate the crank handle counter-clockwise until the cable connector is inline
with the cable bracket.
Note: The canopies and umbrella will remain closed. It is Important to keep tension on the cable
connector as you continue turning the crank in a counter-clockwise position.
Step 15 for each umbrella canopy
a) While the umbrella is still closed make sure the telescope is fully extended out from the mast.
b) Pull the security pin from the trolley car bracket.
c) Pull the cable connector so it aligns with the trolley car bracket.
d) Fasten the cable connecter to the trolley bracket with the security pin.
cable connector
cable bracket
security pin
trolley car

18
|tuuci
1005376
Turning the Ambia LED lights on
Press the light bulb icon button on the control panel to
turn-on the Ambia LED lights under each canopy. The
color will change from white to blue after pressing the
button, signaling that the lights are ON.
The umbrella canopies must be fully opened
for 5 seconds before the Ambia LED lights and/or
heaters can be turned on.
Turning the heaters on
Press the heater icon button on the control panel
to turn-on the heaters under each canopy.
The color will change from white to blue, signaling
that the heaters are ON.
Step 1
Press the heater icon button on the control panel to turn-off the
heaters. After pressing the button it will be flashing for
2 minutes, then color will change to white, signaling that the
heaters are OFF.
Step 2
Press the light bulb icon button on the control panel to turn-
off the Ambia LED lights. After pressing the button, the color
will change to white, signaling that the lights are OFF.
Step 3
Press the power button on the control panel to turn off the um-
brella.
CLOSING UMBRELLA CANOPIES
Instructions to turn-off the Ambia LED light and (4) heaters.
close umbrella during consistent wind conditions that exceed 25mph.
NOTE:
Umbrella should not be closed entirely
until all heaters have cooled down.
Allow at least 10 min. for heaters to cool.
lights and heaters
TURN ON LIGHTS AND HEATERS power on
light bulb
heater
Step 4
Close the umbrella with tie-back when not in use.

19
|tuuci
1005376
North America version:
208-240V, 2 phases 60Hz (requires a minimum 15 Amp circuit)
Umbrella comes with (2) 10ft Power Cords & Plugs. Oneforeach circuit required.
(Use with 20A - 250 Volts, NEMA 6-20R Receptacle compatible with NEMA 6-20P Plugs)
Europe version:
220-240V, 1 phase 50Hz (requires a minimum 16 Amp circuit)
Umbrella comes with (2) 10ft Power Cords & Plugs. Oneforeach circuit required.
(Use with 16A - 250 Volts, Schuko Receptacle compatible with Schuko 16A - 250 Volts Plugs)
Customer must connect to a protected power source circuit with proper Current Rating “Amps”, near the umbrella,
using an above ground Junction box, according to their local electrical codes and regulations.
warnings & safety instructions
1. Read and understand entire owner’s manual before assembling or operating umbrella.
2. Read and understand the warnings posted on the umbrella and/or components installed on the umbrella.
3. Disconnect electrical power to umbrella during inclement weather.
4. There is a risk of fire if heaters contact flammable materials or liquids.
5. Keep children away from power cords on or around umbrella.
6. Disconnect power before removing or servicing umbrella.
7. Allow sufficient cooling of heaters before closing umbrella.
8. Do not use this umbrella for other than its intended use.
9. Replace warning labels if they become obscured or removed.
10. Make sure the umbrella is properly electrically grounded.
11. Provide for adequate space to open and close umbrella without obstructions.
12. Customer’s electrical power source connections if any, are to be installed / connected by a certified electrician. check local codes for guidance.
13. When closing / opening umbrella keep hands and face clear of all pinch points, or protruding umbrella components.
Emergency shut-down or interrupt Feature
Press the Power button on the control panel to shut-down or interrupt the operation of any function (Ambia LED lights and heaters).
The red light on the Power button will turn OFF. The white lights on the heater icon and the light icon will turn OFF. Press the Power
button to turn the umbrella back ON.
Control panel indicator when the Umbrella is not level (tipped or tilted on an angle)
The Power button will be flashing in yellow when the umbrella is not level. All functions (Ambia LED lights and heaters) are inactive.
The TUUCI logo is not backlit. When the umbrella is level and no longer tipped or tilted, it will return to a powered down state with the
TUUCI logos backlit in white and all other functions OFF. Press the Power button to turn-on the umbrella. Then, turn-on the various
functions.
Lock-out unauthorized users from turning-on or -off various features of the Umbrella
There is a lock-out feature to prevent unauthorized user access. To turn-on the lock-out feature, press and hold the Power button for
5 seconds. All functions (Ambia LED lights and heaters) will maintain their original state of ON or OFF. The power button will be a solid
yellow when the lock-out feature is activated.
To turn-off the lock-out feature, press and hold the Power button for 5 seconds. All functions (Ambia LED lights and heaters) will maintain
their current state of ON or OFF. Users will have access again to turn ON-OFF the various functions.
If the Power button is pressed during a lock-out condition, activating the emergency shut-down or interrupt feature, the Ambia LED
lights and heaters will be turned-off. All icon button lights will be OFF, except for the TUUCI logos.
Heater Automatic Turn Off Safety Feature
As a safety feature, the heaters on the Automated Umbrella will automatically turn off after 2 hours of operation.
To turn the heaters back on, press the heater icon button.
lights and heaters features and functions
for frequently asked questions visit tuuci.com/automationCL
Power Supply:
Main Input Voltage: 208-240VAC
50/60 Hz
Max. Amps: 13.7 A @220Volts AC
12.6 A @240Volts AC
Max. Watts: 3010 Watts
(2) Light Units, (4) Heaters Electrical Specs:
This dual canopy umbrella requires two electrical circuits (one circuit for each canopy side).
Each circuit will consist of (1) light unit and (2) heaters, for a total of (2) light units and (4) heaters.
Specifications for each circuit will be:
