TUYA TCLWRQS1 User manual

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 1 V2.0.0
1. Product Overview
TCLWRQS1 is a Wi-Fi module developed by Hangzhou Tuya Inc ,which takes the
communication with 5V TTL signal . It consists of a highly integrated RF chip (RTL8710BN)、
external Flash IC and DC-DC components, It embedded with Wi-Fi network protocol stack and
robust library functions，Besides it also contains with a low-power ARM-CM4 MCU, 2 MB flash
memory, 256KB SRAM, WLAN MAC，1T1R WLAN and rich peripheral resources.
1.1 Features
 Embedded with32 bit CPU, which can be used as an application processor
 Dominant frequency: up to 125 MHz
 Working voltage: 5 V
 Peripherals: 1*UART (5V TTL)
 Wi-Fi connectivity
 802.11b/g/n/HT20/HT40
 Channels 1 to 14 at 2.4 GHz(Ch1-11 for US/CA,Ch1-13 for EU/CN)
 WPA, WPA2, WEP, and TKIP security modes
 Up to +17 dBm Avg output power in 802.11b mode
 STA, AP, and STA+AP working modes
 Smart and AP network configuration modes (for Android and iOS devices)
 PCB On board antenna
 Working temperature: –20°C to 85C
Tuya TCLWRQS1 Wi-Fi Module
Version: 2.0.0 Date: 2020-2-26 No:
Product
Manual
Global Intelligent Platform

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 2 V2.0.0
1.2 Applications
 Intelligent building
 Smart household and home appliances
 Industrial wireless control
 Handheld device
Change History
No. Date Change Description Version After Change
1 2020-2-25 First release. 2.0.0

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 3 V2.0.0
Contents
1. Product Overview ............................................................................................................ 1
1.1 Features.................................................................................................................. 1
1.2 Applications ............................................................................................................ 2
2 Module Interfaces ............................................................................................................. 5
2.1 Dimensions and Footprint ...................................................................................... 5
2.2 Pin Definition .......................................................................................................... 6
2.3 Test Pin Definition ................................................................................................... 6
3 Electrical Parameters ........................................................................................................ 7
3.1 Absolute Electrical Parameters .............................................................................. 7
3.2 Electrical Conditions ............................................................................................... 7
3.3 RF Current .............................................................................................................. 8
3.5 Working Mode Current Consumptions ................................................................... 8
4 RF Features ...................................................................................................................... 9
4.1 Basic RF Features .................................................................................................. 9
4.2 Wi-Fi Output Power ................................................................................................ 9
4.3 Wi-Fi RX Sensitivity .............................................................................................. 10
5 Antenna Information ........................................................................................................ 10
5.1 Antenna Type .......................................................................................................... 10
5.2 Antenna Interference Reduction ................................................................................ 10
5.3 Antenna Connector Specifications ....................................................................... 11
6. Packaging Information and Production Instructions ...................................................... 11
6.1 Mechanical Dimensions ........................................................................................... 11
6.2 Production Instructions ......................................................................................... 11
7 MDQ and Packing Information ....................................................................................... 12
8 Appendix: Statement ....................................................................................................... 12

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 4 V2.0.0
Figures & Tables
Figure 1 TCLWRQS1 front views......................................................................................... 5
Figure 2 TCLWRQS1 back views ........................................................................................ 5
Table 1 TCLWRQS1 interface pins ...................................................................................... 6
Table 2 TCLWRQS1 test pins .............................................................................................. 6
Table 3 Absolute electrical parameters ................................................................................ 7
Table 4 Normal electrical conditions .................................................................................... 7
Table 5 Current during constant transmission and transmitting .......................................... 8
Table 6 RX power consumption during constant receiving ................................................. 8
Table 8 Basic RF features.................................................................................................... 9
Table 9 TX power during constant emission ........................................................................ 9
Table 10 RX sensitivity ....................................................................................................... 10
Figure 3 TCLWRQS1 mechanical dimension .................................................................... 11

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 5 V2.0.0
2 Module Interfaces
2.1 Dimensions and Footprint
TCLWRQS1 dimensions: 49.3mm±0.35mm(L)×30.8±0.35mm(W) ×7.8±0.15mm (H).
Note :(H) is the total height of Bottom surface components and Top surface components of
the transfer plate
Figure 1, Figure 2 shows the TCLWRQS1 dimensions.
Figure 1 TCLWRQS1 front views
Figure 2 TCLWRQS1 back views

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 6 V2.0.0
2.2 Pin Definition
Table 1 describes the interface pins.
Table 1 TCLWRQS1 interface pins
No. Symbol I/O Type Function
1 Vin P Power supply pin 5v input
2 GND P Power supply reference ground pin
3 TXD I/O TX port, output 5V TTL
4 RXD I/O RX port, input 5V TTL
Note: P indicates power-supply pins, I/O indicates input and output pins.
2.3 Test Pin Definition
Table 2 describes the test pins.
Table 2 TCLWRQS1 test pins
No. Symbol I/O Type Function
1 3.3V P Internal 3.3V Power pin for downloading and authorizing
2 GND P Internal GND pin
3 UART_Rx
I/O Used for authorization
4 UART_Tx
I/O Used for authorization
5 Log_Tx I/O Log Tx，Used for debugging to print the log information
6 Log_Rx I/O Log Rx，Used for debugging to print the log information
7 - Used for RF test
Note: Test pins cannot be used.

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 7 V2.0.0
3 Electrical Parameters
3.1 Absolute Electrical Parameters
Table 3 Absolute electrical parameters
Parameter Description Minimum
Value
Maximum
Value
Unit
Ts Storage temperature –20 85 °C
VBAT Power supply voltage - 5.5 V
Static electricity voltage
(human body model)
Tamb = 25°C N/A 2 kV
Static electricity voltage
(machine model)
Tamb = 25°C N/A 0.5 kV
3.2 Electrical Conditions
Table 4 Normal electrical conditions
Parameter Description Minimum
Value
Typical
Value
Maximum
Value
Unit
Ta Working temperature –20 N/A 85 °C
VBAT Power supply voltage 4.5 5 5.5 V
VIL IO negative level input -0.3 - VCC*0.25 V
VIH IO positive level input VCC*0.75 - VCC V
VOL IO negative level output - - VCC*0.1 V
VoH IO positive level output VCC*0.8 - VCC V
Imax IO drive current - - 12 mA

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 8 V2.0.0
3.3 RF Current
Table 5 Current during constant transmission and transmitting
Working
Status
Parameter
Typical
Value Unit
Mode Rate TX Power
TX
802.11b 11 Mbit/s 18.76 dBm 270 mA
802.11g 54Mbit/s 17.48 dBm 255 mA
11n BW20/BW40 Mcs7 16.56dBm 235 mA
3.4 Wi-Fi RX Power Consumption
Table 6 RX power consumption during constant receiving
Symbol Mode Rate Typical Value Unit
IRF CPU Sleep 11 Mbit/s 90 mA
IRF CPU
Active
54 Mbit/s 120 mA
3.5 Working Mode Current Consumptions
Table 7. Working current consumption
Mode AT TA=25℃ Typical Max* Unit
EZ Mode Module is under EZ paring mode, wifi indicator
light flashes quickly
95 245 mA
AP Mode Module is under AP paring mode, wifi indicator
light flashes slowly
88 150 mA
Operation Mode Module is connected, wifi indicator light is on 45 220 mA
Note：the above parameters are different according to the firmware functions.

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 9 V2.0.0
4 RF Features
4.1 Basic RF Features
Table 8 Basic RF features
Parameter Description
Frequency band 2400 GHz to 2483.5 MHz
Wi-Fi standard IEEE 802.11b/g/n20 /n40(channels FCC:1-11 CE:1-13)
Data transmission rate
802.11b: 1, 2, 5.5, or 11 (Mbit/s)
802.11g: 6, 9, 12, 18, 24, 36, 48, or 54 (Mbit/s)
802.11n: HT20 MCS0 to MCS7
802.11n: HT40 MCS0 to MCS7
Antenna type Onboard PCB antenna
4.2 Wi-Fi Output Power
Table 9 TX power during constant emission
Parameter Minimu
m Value
Typical
Value
Maxim
um
Value
Unit
Average RF output power, 802.11b CCK mode
1
Mbit/s
N/A 18.76 N/A dBm
Average RF output power, 802.11g OFDM
mode
54
Mbit/s
N/A 17.48 N/A dBm
Average RF output power, 802.11n OFDM
mode
MCS7 N/A 16.65 N/A dBm
Frequency error –20 N/A 20 ppm

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 10 V2.0.0
4.3 Wi-Fi RX Sensitivity
Table 10 RX sensitivity
Parameter Minimum
Value
Typical
Value
Maximum
Value Unit
PER < 8%, 802.11b CCK mode 1 Mbit/s N/A –90 N/A dBm
PER < 10%, 802.11g OFDM mode 54 Mbit/s N/A –73 N/A dBm
PER < 10%, 802.11n OFDM mode MCS7 N/A –70 N/A dBm
5 Antenna Information
5.1 Antenna Type
TCLWRQS1 uses the onboard PCB antenna.
5.2 Antenna Interference Reduction
To ensure optimal Wi-Fi performance when the Wi-Fi module uses an onboard PCB antenna,
it is recommended that the antenna be at least 15 mm away from other metal parts.
To prevent adverse impact on the antenna performance, do not use copper or route cables
along the antenna area on the PCB.
For details about the onboard PCB antenna area on a module, see Figure 3.

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 11 V2.0.0
5.3 Antenna Connector Specifications
There is no antenna connector for this module
6. Packaging Information and Production Instructions
6.1 Mechanical Dimensions
Figure 3 TCLWRQS1 mechanical dimension
6.2 Production Instructions
1. Storage conditions for a delivered module are as follows:
(1) The moisture-proof bag is placed in an environment where the temperature is
below 30°C and the relative humidity is lower than 70%.
(2) The shelf life of a dry-packaged product is six months from the date when the
product is packaged and sealed.
Attention:
(1) In the whole process of production, operators at all stations must wear
electrostatic rings.If the 30% circle is pink, bake the module for 4 consecutive
hours.
(2) During operation, strictly prevent water or dirt from touching the module

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 12 V2.0.0
7 MDQ and Packing Information
8 Appendix: Statement
Federal Communications Commission (FCC) Declaration of Conformity
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled rolled
MOQ and packing information
Product
Model MOQ Packing Method
Number of Modules
in Each Reel Pack
Number of Reel
Packs in Each Box
TCLWRQS1 Tray

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 13 V2.0.0
environment. This equipment should be installed and operated with minimum distance 20cm between the
radiator and your body.
Important Note
This radio module must not installed to co-locate and operating simultaneously with other radios in host
system except in accordance with FCC multi-transmitter product procedures. Additional testing and
equipment authorization may be required to operating simultaneously with other radio.
The availability of some specific channels and/or operational frequency bands are country dependent
and are firmware programmed at the factory to match the intended destination. The firmware setting is
not accessible by the end user.
The host product manufacturer is responsible for compliance to any other FCC rules that apply to the
host not covered by the modular transmitter grant of certification. The final host product still requires Part
15 Subpart B compliance testing with the modular transmitter installed.
The end user manual shall include all required regulatory information/warning as shown in this manual,
including: This product must be installed and operated with a minimum distance of 20 cm between the
radiator and user body.
This device have got a FCC ID：2ANDL-TCLWRQS1.The final end product must be labeled in a visible
area with the following: “Contains Transmitter Module FCC ID:2ANDL-TCLWRQS1”
This device is intended only for OEM integrators under the following conditions:
1)The antenna must be installed such that 20cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed.
Declaration of Conformity European notice
Hereby, Hangzhou Tuya Information Technology Co., Ltd declares that this module
product is in compliance with essential requirements and other relevant provisions
of Directive 2014/53/EU,2011/65/EU.A copy of the Declaration of conformity can be
found at https://www.tuya.com
Hereby, Hangzhou Tuya Information Technology Co., Ltd declares that this module
product is in compliance with essential requirements and other relevant provisions
of Directive 2014/53/EU,2011/65/EU.A copy of the Declaration of conformity can be
found at https://www.tuya.com

TCLWRQS1 Datasheet
Hangzhou Tuya Information Technology Co., Ltd. 14 V2.0.0
This product must not be disposed of as normal household waste, in accordance with EU
directive for waste electrical and electronic equipment (WEEE- 2012/19/EU). Instead，it
should be disposed of by returning it to the point of sale, or to a municipal recycling
collection point.
