Twister Display Easy Dunker User manual

ffiffiffiru
il
::-.:
., ii:l
t::
i i i :l
l.,ir
,t

ffiffiWffiWffi
ffime#w'ffi ffi &#s&
Description
Canvas (Vinyl)
Dunking Tank Unit
Protective Cage
Light Kit
Hitch Tongue
Hitch Pins
T" Target
Target Arm
Dunk Tank Balls
Ball Bungees
Wing
Light cable extension
Carriage Bolts 1/4"
Lock Washers 1/4"
Flat Washers 1/4"
Nuts 1/4"
Quantitv
1
1
1
1
1
2
1
1
12
32
1
1
8
8
8
B
w w w, I wist e r
dis
p la
y, c o m
| 800 637-3,656 -

ffiffiffiWffiffi
€ms*fm#ffiwmwmegy
l-,T:'::: :]l:i:? ::'l::::: il'l::i1.1':l^^ cage
NOTE: Trailer and tank are one unit, do not try to sepa-
rate!
2. Remove cage from front of tank. Turn cage over and
line the holes in the cage with the holes along the top of
the tank. Drop a 114" carriage bolt through each hole.
Then put on a flat washer, lock washer, and nut and
tighten down. NOTE: Start at one end of the cage and work your way around to the other end.
3. Place the unit on a level surface. Put the wing perpendicular to the dunk tank (extending from the side of
the frame.) There are two brackets on the side of the wing. Loosen the bottom one only so that it can be
moved up and down the pipe. Protruding from the side of the frame are two posts (one pointing up and one
pointing down). lnsert the top one into the top wing bracket. (You will need to lift the tank slightly.) Drop the
bottom bracket onto the bottom post. Make sure that the wing is in line with the frame, then tighten the bot-
tom bracket.
4. Use the ball bungees to secure canvas to the wing.
5. Place the arm into the trigger mechanism. Put the other end trough the square tubing on the wing and
through the hole in the canvas. Make sure the arm drops into the slot on the side of the frame. lnsert the
target into the end of the arm so the pin holes line up. lnsert the clip pin.
Place one hand on the front of the seat and push down. With the other hand "test" the target to see that it
works properly.
6. Fold wing in against the side of the unit and securely tie off. (Tie a second safety rope to hold wing
frame against tank.) Slowly tilt tank onto its wheels. As you face the back of the trailer (this is actually the
top of the tank), place the tail-light marked "road side" next to the left side light bracket, and place the light
marked "curb side" next to the right side light bracket, Pull out enough cable so that the plug willjust
reach the bottom of the tank. Run the light cord along the bottom of the trailer frame taping or tying it to
the underside of the frame.
Run the yellow/brown cord to the "road side" (left) bracket and feed it through the hole in the bracket. Run
the green/brown cord to the "curb side" (right) bracket and feed it through the hole in that bracket. Cut of
the excess cable on both sides and strip about a 114" of insulation off the ends. lnsert the ends of cable
into their respective holes in the back of the light units. (The white cable can be used for grounding pur-
poses.) Using the nuts included in the light kit attach lights to the brackets.
Using electrical tape or zip ties, attach the light cable extension to the tongue. lt should extend a couple of
feet past the hitch to allow enough slack for turns and the other end should stop about halfway down the
length of the tongue where it would meet the light cable plug on the tank frame when the tongue is in
place. After the trailer is hooked up to a vehicle, be sure to test the turn signals and brake liqhts be-
fore towinq.
Wing
Canvas

ffiffiWffiMffiffi
@wm66mg$ercM
TOWING
1. Fold wing in against the side of the unit and securely tie off. Then slowly tilt tank back onto its
wheels. Place seat in its "up" position and lock.
2. lnsert hitch tongue and use both pins to secure it.
3. Attach trailer to vehicle. Put pin or bolt through hitch release lever and secure. Attach safety
chain to vehicle. NOTE: Always use the safety chain when towing
4. Hook up lights to tow vehicle, and be sure to test the turn signals and brake lights before towing.
5. Place target, target arm, and balls safely in tow vehicle.
SET UP
1. Select a level area for set up.
2. Unhook trailer and lights from tow vehicle and roll to set up area. (NOTE: Trailer and tank are
one unit, do not try to separate!)
3. Raise tongue end of trailer and remove hitch pins from tongue bar. Slide tongue bar out and re-
place pins in bar.
4. Slowly lift up and set tank upright. (Be careful not to drop tank onto its bottom.)
5. Untie rope holding the wing against the tank. Swing wing out into position. NOTE: The winq
MUST BE STRAIGHT out from the tank frame. lf it is at an anqle the triqqer will not work properlv.
Lower the two stabilizing rods on the bottom of the wing so the wind does not move it as this will
cause the target arm to jam.
6. Check drain plug to make sure it is tight and then fill tank to the top with water (approx. 500 gal-
lons).
7. Place the arm into the trigger mechanism. Put the other end trough the hole in the canvas.
Make sure the pin which is welded to the arm drops into the pivot point on the side of the frame.
lnsert the target onto the end of the arm and tighten. With your hand "test" the target to see that it
works properly.
8. Place one hand on the front of the seat and push down. With the other hand "test" the target to
see that it works properly.
9, REVIEW SAFETY RULES!!
I 800 637,3656 - www;twisterdisplay,com

ffiffiffiWffiffi/WWW
#pmrefftrg6mM
OPERATION
'1. Check to see that seat is properly locked and is released when the target is pressed. Be sure
to show this operation to the person who will be on the tank as they will need to know how to reset
the seat and trigger mechanism each time it is released, before they get back onto the seat. ln-
struct them to use the grip handles for supporl when climbing up out of the tank. A/so, be sure in-
struct the dunkee on the proper use of the seat safety latch, which is located behind the seat, to
keep it secure until they are ready to be dunked.
Please remind the dunkee to keep their hands on their knees and sit fonuard on the seat.
2. Use ONLY the balls that came with the EASy DUNKER.
3. Monitor water level to keep it full.
TAKE DOWN
1. As soon as you are finished using the dunker, open the drain and let the tank empty.
2. Fold wing in against the side of the unit and securely tie off. When towing EASY DUNKER , tie
a second safety rope to hold wing frame against tank. Then slowly tilt tank back onto its wheels.
3. Place seat in its "up" position and lock.
4. lnsert hitch tongue and use both pins to secure it.
5. Attach trailer to vehicle. Put pin or bolt through hitch release lever and secure. Attach safety
chain to vehicle.
6. Hook up lights to tow vehicle, and be sure to test the turn signals and brake lights before tow-
ing.
7. Place target, target arm, and balls safely in tow vehicle.
I 800' 6,37-3656 - www,twisterdisplay,com

w.
&
ffiffiWffiffi
ffimtuffig ffiffiw# s
&e sure to rer$mw ffi&& safe$ rg,fes wif$r d{lmfu {ank operator and sll "du'Ifrse$" prfon *$ sse,
r Easy Dunker on dutY when in use'
o When tank is going to be unattended, always drain water'
ATTENDED!
cordon off a ,,dange t zone,,in front of, to the sides of, and behind the tank. Keep people out of the zone to
avoid getting hit by an errant or deflected throw. children should never be allowed inside this "danRer zone'"
Never place the dunk tank on a platform or stage. (NorE: when filled the dunk tank weighs over 4,500 pounds')
Keep Easy Dunker away from electricity'
Keep water level filled to at least 8" from the top of the tank'
only one person at a time should be allowed on the seat or in the tank.
Keep all non-swimmers, anvone less than 5' tall, or over 250 pounds off of the tank'
Anyone with medical conditions which may place limitations on their physical exertion (such as, but not limited
to: heart condition, pregnancy, back injury, etc.) should stay off of the dunk tank'
To keep from slipping, the dunkee must always wear rubber sole shoes.
Before (and each time)the dunkee climbs onto the seat, they must first
place and that the safetv latch is engased'
r The dunkee should use the handles to assist in climbing out of the tank and for getting back up onto the seat
after being dunked. However, the
The dunkee must move toward the front of the tank when coming up out of the water to avoid hitting their head
on the seat.
Never use hard balls.
Never stand or kneel on seat.
When being dunked, the dunkee must keep hands on knees and sitforward on the seat'
Do not allow anvone to hit target with hands'
Do not operate Easy Dunker during a storm'
ffiessre ge &wwe eg$dwss&*emffepereg@r$ effide$$
w
ffi
%#ersm eew* reed effiS fffi#$fe$ A&& $effiry m$mw-

@
B
ffiffiWffiWWWM
GrcfuWgf ffiee#es
Easy Dunker must alwavs have an adult operator on duty when in use.
When tank is going to be unattended, always drain water. NEVER LEAVE A DUNK TANK FILLED WITH WATER UN
ATTENDEDI
Cordon off a "danger zone" in front of, to the sides of, and behind the tank. Keep people out of the zone to avoid getting
hit by an errant or deflected throw. Children should never be allowed inside this "danqer zone."
Never place the dunk tank on a platform or stage. (NOTE: When filled the dunk tank weighs over 4,500 pounds.)
Keep Easy Dunker away from electricity.
Keep water level filled to at least 8" from the top of the tank.
Only one person at a time should be allowed on the seat or in the tank.
Keep all non-swimmers, anvone less than 5' tall, or over 250 oounds off of the tank.
Anyone with medical conditions which may place limitations on their physical exertion (such as, but not limited to: heart
condition, pregnancy, back injury, etc.) should stay off of the dunk tank.
To keep from slipping, the dunkee must always wear rubber sole shoes.
Before (and each time) the dunkee climbs onto the seat, they must first make sure the seat is securely locked in place
and that the safetv latch is enqaqed.
The dunkee should use the handles to assist in climbing out of the tank and for getting back up onto the seat after being
dunked. However, the dunkee must not hold onto the handles while beinq dunked.
The dunkee must move toward the front of the tank when coming up out of the water to avoid hitting their head on the
seat.
Never use hard balls.
Never stand or kneel on seat.
When being dunked, the dunkee must keep hands on knees and sit forward on the seat.
Do not allow anvone to hit tarqet with hands.
Do not operate Easy Dunker during a storm.
I have read and agree to comply with all of the above safety rules.
ffi
W
il
Signed: Date: / _J
