ReVolt Bass - User Guide
3-Channel All-Analog Bass Amp Simulator / DI
Thank you for purchasing ReVolt Bass, you’re about to embark on a world of next-generation tonal
possibilities!
The bass: It’s the bedrock of any performance, demanding nothing short of tonal excellence. Enter
ReVolt Bass, a forward-thinking all-analog 3-channel preamp primed to serve as the beating-heart of
your rig. The latest-iteration of Two notes’ critically-acclaimed preamp solutions has been engineered
with a singular mission: to empower players with the ultimate in foundation tone. Forget any
preconceptions of a run-of-the-mill amp-in-a-box, preamp or DI: ReVolt Bass stands-apart. It’s inspired
by a trio of iconic tones; It’s fuelled by 200V and genuine tube power; It’s born to assimilate into a
myriad of usage scenarios; it gives you edge when you need it, thanks to an integrated Drive Channel
Dry/Wet Blend. Two notes’ gets it: Your Tone Matters. Why settle for anything short of perfection?
The complete electronic version of this manual, as well as the Two notes Audio Engineering software
and hardware products, are subject to updates. You can download the most recent versions of the
products on the Two notes Audio Engineering website.
This manual describes ReVolt Bass and provides instructions for its operation. It is highly
recommended that you read this document before using the product. The contents of this manual
have been thoroughly verified and it is believed to accurately describe the product at the time of
Last update:
2022/12/12 14:25 revolt_bass:revolt_bass_user_s_manual https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
https://wiki.two-notes.com/ Printed on 2022/12/12 17:37
shipment from the factory or downloaded from our website.
Two notes Audio Engineering is a registered trademark of:
OROSYS SAS
76 rue de la Mine
34980 Saint-Gély-du-Fesc
France
Tel: +33 (0)484 250 910
Fax: +33 (0)467 595 703
Contact and support: http://support.two-notes.com
Website: http://www.two-notes.com
This document is the exclusive property of OROSYS SAS. In the interest of product development,
OROSYS SAS reserves the right to change technical specifications, modify and/or cease production
without prior notice. OROSYS SAS cannot be held responsible for any damage, accidental or
otherwise, that results from an inappropriate use of the Torpedo Captor X Please refer to the safety
instructions included in this manual. The reproduction of any part of this document is strictly
forbidden without the written authorization of OROSYS SAS.
All product names and trademarks are the property of their respective owners. Product names and
trademarks found in this document were used during the development of ReVolt Bass but are in no
way associated or affiliated with OROSYS SAS.
Foreword
1. Important Safety instructions
Before using the product, it is necessary to carefully read and consider the following
information. Keep this document in a safe place; it is important for the protection of both the
user and the product. If any malfunction of the product is suspected, Two notes Audio
Engineering advises seeking the assistance of a qualified technician.
Please verify that the voltage required by the mains power adapter matches the voltage
specifications of your country. If not - or if unsure - do not connect the product to the wall
outlet. This could result in damage to the mains power adapter, the product and injury to the
user. This product must not be used when there is lightning present. In case of severe weather
with a risk of lightning, unplug the power adapter to reduce the risk of electric shock and fire.
The mains power adapter provided with the product complies with the standards of the country
where you purchased the product. If replacement is needed, please use a standard compliant
mains power adapter.
ReVolt must never be used near a heat source, near a flame, in the rain, in damp areas or near
any liquid of any sort. When transporting the unit, care needs to be taken to avoid any shocks
that could result in damage requiring the assistance of a qualified technician.
Always use a dry and soft cloth with no alcohol or solvents for cleaning. Please keep the unit
2022/12/12 17:37 3/16 ReVolt Bass - User Guide
User's manuals - https://wiki.two-notes.com/
clean and free from dust
All maintenance operations must be carried out by service centers approved by Two notes
Audio Engineering or by qualified technicians. Never attempt to repair the product by yourself.
2. Package Contents
The shipped package contains:
One ReVolt unit in a protective sleeve
One power adapter
One ⅛” TRS jack-to-MIDI Type-A adaptor
One quickstart guide
The complete electronic version of this manual, alongside the manuals for Torpedo Wall of Sound and
GENOME are subject to change. You can download the most recent versions of the bundled software
and the related user guides on the Two notes Audio Engineering website.
3. Declaration of Conformity
Manufacturer: OROSYS SAS
Category of product: analog audio signal processor
Product: ReVolt
Test Manager: Guillaume Pille
The Two notes ReVolt is certified to be compliant to the CE and FCC standards:
EN 55103-1 : 1996 and EN 55103-2 : 1996.
EN 60065 05/2002 + A1 05/2006.
EMC directive 89/336/EEC and Low Voltage Directive 73/23/EEC.
FCC Part 15 : 2008.
ICES-003 : 2004.
AS/NZS 3548 class B for Australia and New Zealand.
IEC : 2008 - CISPR 22 class B.
Last update:
2022/12/12 14:25 revolt_bass:revolt_bass_user_s_manual https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
https://wiki.two-notes.com/ Printed on 2022/12/12 17:37
4. Disposal of Waste Equipment by Users in Private
Household in the European Union
This symbol on the product or on its packaging indicates that this product must
not be disposed of with your other household waste. Instead, it is your
responsibility to dispose of your waste equipment by handing it over to a
designated collection point for the recycling of waste electrical and electronic
equipment. The separate collection and recycling of your waste equipment at the
time of disposal will help to conserve natural resources and ensure that it is
recycled in a manner that protects human health and the environment. For more
information about where you can drop off your waste equipment for recycling,
please contact your local city office, your household waste disposal service or the
shop where you purchased the product.
5. Warranty
OROSYS SARL warrants that this TWO NOTES AUDIO ENGINEERING product shall be free of defects in
parts and workmanship when used under normal operating conditions for a period of two (2) years
from the date of purchase. This warranty shall apply to the original purchaser when purchased from
an Authorized TWO NOTES AUDIO ENGINEERING dealer.
IMPORTANT: PLEASE RETAIN YOUR SALES RECEIPT, AS IT IS YOUR PROOF OF PURCHASE COVERING
YOUR LIMITED WARRANTY. THIS LIMITED WARRANTY IS VOID WITHOUT YOUR SALES RECEIPT.
Defective products that qualify for coverage under this warranty will be repaired or replaced, (at
OROSYS SAS’s sole discretion) with a like or comparable product, without charge. In the event that
warranty service be required, Please contact your authorized TWO NOTES AUDIO ENGINEERING dealer
in order to obtain an RMA to return the complete product to the Authorized TWO NOTES AUDIO
ENGINEERING Service Center closest to you, with proof of purchase, during the applicable warranty
period.
Transportation costs to the service center ARE NOT INCLUDED in this limited warranty. OROSYS SAS
will cover the cost of standard ground return transportation for repairs performed under this warranty.
This limited warranty becomes void if the serial number on the product is defaced or removed, or if
the product has been damaged by alteration, misuse including connection to faulty or unsuitable
ancillary equipment, accident including lightning, water, fire, or neglect; or if repair has been
attempted by persons not authorized by OROSYS SAS.
Any implied warranties, including without limitation, any implied warranties of merchantability or
fitness for any particular purpose, imposed under state or provincial law are limited to the duration of
this limited warranty. Some states or provinces do not allow limitations on how long an implied
warranty lasts, so the above limitations may not be applicable.
OROSYS SAS ASSUMES NO LIABILITY FOR PROPERTY DAMAGE RESULTING FROM ANY FAILURE OF THIS
PRODUCT NOR ANY LOSS OF INCOME, SATISFACTION, OR DAMAGES ARISING FROM THE LOSS OF USE
OF SAME DUE TO DEFECTS OR AVAILABILITY OF IT DURING SERVICE.
In case you must absolutely send your TWO NOTES AUDIO ENGINEERING product to any other
2022/12/12 17:37 5/16 ReVolt Bass - User Guide
User's manuals - https://wiki.two-notes.com/
location, it is of vital importance that you keep the original packing materials. It is very difficult to
avoid damage when shipping the product without these materials. OROSYS SAS is not responsible for
damages caused to the product by improper packaging and reserves the right to charge a reboxing
fee for any unit returned for service without the original packing material.
THE FOREGOING CONSTITUTES THE ONLY WARRANTY MADE BY OROSYS SAS WITH RESPECT TO THE
PRODUCTS AND IS MADE EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED.
ReVolt Bass Key Features
3-channel bass amp simulator featuring an all analog signal path
Inject some warmth and bite into your tone courtesy of a 12AX7 preamp tube running at high
voltage
DRY/WET to adjust the balance between the dry BASS IN signal and the MODERN DRIVE channel
signal
Expertly engineered Analog Cab Sim for seamless DI whether it’s in the studio or on stage
4-Cable mode, FX Loop and MIDI In/Out for effortless integration into existing setups
Robust, made-to-move design that’s perfectly sized for pedalboards and fly-rigs
Includes a lifetime license to Wall of Sound and GENOME, the final word in digital app- and
plugin-based tone-shaping for the forward-thinking player (VST/AU/AAX/Standalone)
Includes the ReVolt: Series-B DynIR Cabinet Collection (valued at 100€/$) featuring 10 exquisite
DynIR captures inspired by leading guitar amplifier brands
1. Top Panel
Last update:
2022/12/12 14:25 revolt_bass:revolt_bass_user_s_manual https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
https://wiki.two-notes.com/ Printed on 2022/12/12 17:37
A - CLASSIC CLEAN
Name Function
BASS Adjusts the passive low frequency voicing section. \\As the knob is rotated the signal is
attenuated (down to -20dB) or boosted (up to +20dB), below 80Hz.
TREBLE As the knob is rotated your signal is attenuated (down to -20dB) or boosted (up to +20dB),
above 2.5kHz.
GAIN Adjusts the amount of gain feeding the CLASSIC CLEAN channel. Increasing the gain can
lead to signal distortion, and in extreme cases, unwanted clipping.
VOLUME
Adjusts the output volume of the CLASSIC CLEAN, the volume is positioned pre the FX
Loop. In the instance unwanted clipping occurs, try lowering the volume to ensure any
subsequent devices in your signal path are not overdriven.
B - VINTAGE DIRT
Name Function
GAIN Adjusts the amount of gain feeding the VINTAGE DIRT channel. Increasing the gain can
lead to signal distortion, and in extreme cases, unwanted clipping.
VOLUME
Adjusts the output volume of the VINTAGE DIRT channel. The volume is located pre-FX
Loop. In the instance unwanted clipping occurs, try lowering the volume to ensure any
subsequent devices in your signal path are not overdriven.
C - MODERN DRIVE
Name Function
GAIN Adjusts the amount of gain feeding the MODERN DRIVE channel. Increasing the gain can
lead to signal distortion, and in extreme cases, unwanted clipping.
VOLUME
Adjusts the output volume of the MODERN DRIVE channel, the volume is positioned pre
the FX Loop. In the instance unwanted clipping occurs, try lowering the volume to ensure
any subsequent devices in your signal path are not overdriven.
2022/12/12 17:37 7/16 ReVolt Bass - User Guide
User's manuals - https://wiki.two-notes.com/
Name Function
DRY/WET Adjusts the balance of the input signal and the MODERN DRIVE channel signal
D - Shared EQ for VINTAGE DIRT / MODERN DRIVE Channels
Name Function
BASS
Adjusts the Low Frequency content of the shared tone stack.
As the knob is rotated the signal is attenuated (down to -15dB) or boosted (up to +7dB),
below 80Hz
MID As the knob is rotated the signal is attenuated (down to -10dB) or boosted (up to +10dB),
centered at 620Hz
TREBLE
Adjusts the High frequency content of the shared tone stack.
As the knob is rotated the signal is attenuated (down to -17dB) or boosted (up to +6dB),
above 2.5 kHz
2. Footswitch & LED Functionality
2.1 Channel Activation
Each of the channels can be activated by pressing the CLEAN, DIRT, and DRIVE footswitches. The LED
above the footswitch will light up when the channel is active:
Green for the CLASSIC CLEAN channel
Orange for the VINTAGE DIRT channel
Blue for the MODERN DRIVE channel
Simultaneously pressing the CLEAN and the CRUNCH switches will bypass ReVolt.
3. Front Panel
Last update:
2022/12/12 14:25 revolt_bass:revolt_bass_user_s_manual https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
https://wiki.two-notes.com/ Printed on 2022/12/12 17:37
E - 4-CABLE METHOD
This switch determines the behavior of ReVolt’s effects loop alongside its bypass behavior. See the
section Supercharge your amp with the 4 cable method for comprehensive setup guidelines for this
feature.
F - CAB SIM
Enables the analog cabinet simulation applied to the BALANCED and Headphone outputs of ReVolt by
engaging the CAB SIM switch (I Position). For ReVolt Bass, the analog simulation is inspired by an
Ampeg SVT-810E cabine
G - AUX IN
Connect your music player here and control the playback level via the source’s controls. This input is
stereo.
H - Headphone Output
The headphone output is a 1/8” TRS jack socket. This output is calibrated for headphones rated up to
100Ω. ReVolt’s signal is mono - the AUX IN can only be heard in stereo via headphones. The cabinet
simulation applied with the CAB SIM switch can also be heard through the headphone output.
4. Back Panel
2022/12/12 17:37 9/16 ReVolt Bass - User Guide
User's manuals - https://wiki.two-notes.com/
1 - IN
Connect your instrument here. The input is a ¼” TS (unbalanced) jack socket.
2 - SEND
Use this unbalanced output to connect to effects pedals or to an amp’s Instrument input when the 4-
CABLE METHOD switch (E) is activated. The SEND output is a ¼” TS jack socket.
When the 4-CABLE METHOD switch is activated, and when ReVolt is bypassed (no active channel), the
SEND outputs the dry/unaffected guitar signal to the connected amplifier/device.
3 - RETURN
Use this unbalanced input to connect the output of any external effects to ReVolt, or connect the
amp’s effects loop SEND to this input when the 4-CABLE METHOD switch (E) is activated. The RETURN
input is a ¼” TS jack socket panel-mount connector.
When using effects pedals (delay, reverb, etc.), ensure the 4-CABLE METHOD is set to O. The
processed signal of the effects will be heard when a channel is active on ReVolt.
4 - OUT
This unbalanced output (¼” TS jack) sends the dry signal of ReVolt’s channels - the CAB SIM is never
applied to this output.
5 - MIDI IN/OUT
The MIDI In/Out sockets are ⅛” TRS jack panel-mount connectors. One TRS 1/4” jack to MIDI type A
adapter cable is provided with ReVolt.
By default, ReVolt sends and receives Program Change (PC) messages from 1 to 7 . Edit all MIDI
messages through ReVolt’s dedicated MIDI Setup menus (see the MIDI SETUP section of the manual
for more details)
6 - BALANCED OUT
Use this balanced output to connect directly to your audio interface, monitors or mixing desk. Apply
speaker simulation to this output with the Cab Sim Switch (F). The GND/LIFT switch eliminates
unwanted hum caused by ground loops when activated.
Last update:
2022/12/12 14:25 revolt_bass:revolt_bass_user_s_manual https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
https://wiki.two-notes.com/ Printed on 2022/12/12 17:37
7 - MAINS POWER ADAPTOR
Connect the provided power supply here. ReVolt needs 12V DC, 600mA and a center negative polarity
to work.
USE CASES
1. Go Direct - On Stage & In The Studio
Use ReVolt to go-direct to mixing desks audio interfaces when on stage or recording respectively.
Using the BALANCED OUT with the CAB SIM engaged, send your complete guitar tone out of ReVolt.
Further refine your tone by adding effects in the FX Loop of ReVolt.
You can also use a C.A.B. M+ connected to either the effects loop or OUT output to add our class-
leading DynIR cabinet emulation to your rig.
2. Supercharge Your Amp With The 4 CABLE METHOD
2022/12/12 17:37 11/16 ReVolt Bass - User Guide
User's manuals - https://wiki.two-notes.com/
If your amp is equipped with an effects loop, add ReVolt’s 3 channels to your amplifier’s channel
specification. Engage the 4-CABLE METHOD on ReVolt, and combine ReVolt’s effects loop with the
amp’s using the following connectivity guidelines.
Connect your instrument/pedalboard to ReVolt’s IN1.
Connect ReVolt’s SEND to the amp’s input2.
Connect the amp’s effects loop send to the ReVolt’s RETURN3.
Connect ReVolt’s OUT to the amp’s effects loop return4.
When ReVolt is bypassed, the dry bass signal passes through the amp’s input and all the amp’s
features/tone shaping are unaltered by ReVolt’s all-analog processing. When a channel is activated on
ReVolt, the signal passes through the instantiated ReVolt preamp and companion tone stack, feeding
only the amplifier’s power amp.
3. Take Your Tone Further With Wall of Sound
Connect the OUT output to your audio interface’s instrument input and combine ReVolt’s channels
with Wall of Sound for enhanced cabinet simulation and additional post-processing effects.
Alternatively, disengage the CAB SIM, and use the BALANCED OUT with your audio interface’s mic
preamp to record / process your signal with Wall of Sound.
SPECIFICATIONS
Input Size Function / Specifications
IN 6.35mm (1/4“) Jack 6.35mm (1/4”) unbalanced (TS, Tip/Sleeve)
Impedance: 1MΩ
SEND 6.35mm (1/4”)
Jack 6.35mm (1/4“) unbalanced (TS)
Max output level: 11dBu
Impedance: 10kΩ
Last update:
2022/12/12 14:25 revolt_bass:revolt_bass_user_s_manual https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
https://wiki.two-notes.com/ Printed on 2022/12/12 17:37
Input Size Function / Specifications
RETURN 6.35mm (1/4“)
Jack 6.35mm (1/4“) unbalanced (TS)
Max input level: 11dBu
Impedance: 1MΩ
Unbuffered, directly connected to Output when active
OUT 6.35mm (1/4”)
Jack 6.35mm (1/4”) unbalanced (TS)
Max output level: 11dBu
Impedance: 300Ω
MIDI IN 3.5mm (⅛”) MIDI adapter cable. Pinout: TIP=DIN 5 RING=DIN 4 SLEEVE=DIN 2
MIDI OUT 3.5mm (⅛”) MIDI adapter cable. Pinout: TIP=DIN 5 RING=DIN 4 SLEEVE=DIN 2
GND LIFT PUSH BUTTON With the switch engaged it opens (disconnects) the connection
between the ReVolt ground and the balanced audio output.
BALANCED OUT XLR XLR, balanced Impedance: 600Ω balanced, 300Ω unbalanced
Max output level: 11dBu
12V DC 600mA 2.1mm Mains power adaptor DC Jack 2.1mm, negative center Input voltage;
12V DC Power consumption; approx. 6W Current draw: 600mA
Advanced Functionality
1. Using the Setup Menu System
The setup menu is entered by holding down footswitch A and providing power to the device. When the
setup menu is entered, the “tube window” will show the “first page” color.
Press footswitch B to go to the next page.
Press footswitch A to go to the previous page.
Press footswitch C to enter a page.
When the last page is selected, pressing footswitch B will select the first menu and the channel
LEDs will flash quickly.
When the first page is selected, pressing footswitch A will select the last menu and the channel
LEDs will flash quickly.
To enter a sub-menu, press the footswitch C button. The “tube-window” color will quickly blink.
Once in a sub-menu, a power-cycle is required to exit.
Valid settings are saved immediately
Every time there is a number displayed to the user, it is done using the channel LEDs:
Channel A : 100s
Channel B : 10s
Channel C : units
Example: Number 123 is reported as 1 blink on channel A, 2 blinks on channel B and 3
blinks on channel C. The same process applies for error messages.
2022/12/12 17:37 13/16 ReVolt Bass - User Guide
User's manuals - https://wiki.two-notes.com/
2. Menu Pages
Setup Menu Pages and Color Reference
The Page order is as follows:
FX loop defaults : Pink
MIDI Monitor : White
MIDI learn : Blue
MIDI Channel : Orange
MIDI PC Number : Purple
FX LOOP MIDI CC : Turquoise
FW VERSION / Factory Reset : Red
3. MIDI SETUP
3.1 MIDI Monitor
The MIDI monitor uses the RGB LED behind the tube window to display the type of MIDI (PC, CC, or
SYSEX) message received.
Typical behavior when a MIDI message is received is as follows:
Valid message received, channel is wrong - show ORANGE
Valid message received, PC - GREEN, CC - BLUE. The message # is displayed on the channel
LEDs.
Valid SYSEX received, display PINK. The message byte count, if less than 999, is displayed on
the channel LEDs.
3.2 MIDI Learn
This menu can be used to set the MIDI PC number associated with each ReVolt Channel (including the
Boost state per channel) and the Bypass Mode The Default MIDI PC values are as follows :
Channel A Channel
A+boost Channel B Channel
B+boost Channel C Channel
C+boost Bypass
Guitar PC 1 PC2 PC3 PC4 PC5 PC6 PC7
BASS PC 1 - PC2 - PC3 - PC4
While in this setup menu, pressing a footswitch will set the pedal for the message to be programmed:
Corresponding LEDs will light for 1s before displaying the current assigned PC number for this channel
Last update:
2022/12/12 14:25 revolt_bass:revolt_bass_user_s_manual https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
https://wiki.two-notes.com/ Printed on 2022/12/12 17:37
3.2.1 Assigning "Channel On" PC (A, B, or C)
Press A, B, or C - the corresponding channel LED will momentarily turn ON
After one second, ReVolt will use the channel LEDs to flash the currently assigned PC number.
The user can now send a valid MIDI PC message
If Valid - the channel LED will remain solid for 1 second, then ReVolt will begin flashing the
newly assigned PC number
If Invalid - if the PC message is already assigned to another channel function - the channel LEDs
will flash 3 times. The device remains in assignment mode and will await a valid PC message.
3.2.2 Assigning "Channel On BOOST" PC (A, B, or C)
Press A, B, or C 2 times, the “tube window” indicates boost mode (very red) - the corresponding
channel LED will momentarily turn ON
After one second, ReVolt will use the channel LEDs to flash the currently assigned PC number.
The user can now send a valid MIDI PC message
If Valid, the channel LED will remain solid for 1 second, then ReVolt will begin flashing the newly
assigned PC number
If Invalid - if the PC message is already assigned to another channel function - the channel LEDs
will flash 3 times. The device remains in assignment mode and will await a valid PC message.
3.2.3 Assigning BYPASS PC
Press A+B: All LEDS will blink for 2*500ms.
After one second, ReVolt will use the channel LEDs to flash the currently assigned PC number.
The user can now send a valid MIDI PC message
If Valid, the channel LED will remain solid for 1 second, then ReVolt will begin flashing the newly
assigned PC number
If Invalid - if the PC message is already assigned to another channel function - the channel LEDs
will flash 3 times. The device remains in assignment mode and will await a valid PC message.
3.3 MIDI PC Number
Please note, by default the MIDI PC start value is set to 0.
This menu page allows the user to configure the starting MIDI PC message value when pressing one of
the 3 channel footswitches. PC messages sent are as follows:
Channel A Channel
A+boost Channel B Channel
B+boost Channel C Channel
C+boost Bypass
Guitar PC number PC number +
1
PC number +
2
PC number +
3
PC number +
4
PC number +
5
PC number
+ 6
BASS PC number - PC number +
1-PC number +
2-PC number
+ 3
2022/12/12 17:37 15/16 ReVolt Bass - User Guide
User's manuals - https://wiki.two-notes.com/
The current PC number is displayed via the channel LEDs
The PC number can be incremented by pressing footswitch A,B or C
FS A = -1 FS B = +1 FS C = +10
Note: If you program the pedal to go further than max permitted MIDI PC starting value (122 for
ReVolt Guitar, 125 for ReVolt Bass), it will revert back to the first option and vice versa.
3.4 MIDI CHANNEL
Please note, by default ReVolt’s MIDI Channel configuration is set to 17 (OMNI)
This menu page allows the user to configure which MIDI Channel is utilized by ReVolt. The available
MIDI Channel values within ReVolt are as follows:
01 to 16 17
MIDI OFF, only
THRU active
MIDI Messages are received and sent
on this channel number
OMNI : MIDI messages are received on all
channels and sent on channel 1
The current channel number is displayed via channel LEDs
The channel number can be incremented by pressing footswitch A, B or C
FS A = -1 FS B = +1 FS C = +10
Note: If you program the pedal further than the max allowed number (17), it will remain set at 17; the
same behavior is consistent for minimum values.
4. FX Loop
4.1 Default State
Please note, by default ReVolt’s default FX Loop State is set to All On.
Using this setup menu allows the user to select the FX loop state for each channel, when not using the
4CM mode.
Once inside the menu, if the Channel LED shows ON, the FX loop is active for this channel. Press the
corresponding channel footswitch to toggle between the ON/OFF FX loop states for the associated
channel.
Last update:
2022/12/12 14:25 revolt_bass:revolt_bass_user_s_manual https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
https://wiki.two-notes.com/ Printed on 2022/12/12 17:37
4.2 FX Loop CC
Please note, by default ReVolt’s default FX Loop CC state is set to 14.
Using this setup menu allows the user to select the FX Loop CC state per channel. The CC number is
displayed and incremented in the same manner that the MIDI PC number is actioned. For further
details, please see the “PC Number” section.
5. Firmware Version / Factory Reset
Using this setup menu allows the user to view the current Firmware version installed on the ReVolt
unit as well as options to action a Factory Reset.
Upon entering this setup menu, the current Firmware Version number is displayed on ReVolt’s
channel LEDs.
To action a Factory Reset, press Channel A’s footswitch 3 times. With each press, the Channel LED
color shifts to white. After completing the sequence, the tube window will show white and the Channel
LEDs remain on for 2 seconds indicating that the factory reset has occurred correctly. Once the
Factory Reset has been actioned, the unit will resume to display the current Firmware Version across
the channel LEDs.
From:
https://wiki.two-notes.com/ - User's manuals
Permanent link:
https://wiki.two-notes.com/doku.php?id=revolt_bass:revolt_bass_user_s_manual
Last update: 2022/12/12 14:25
Table of contents
