Types S402 pro Guide

S402 PRO

4K Dual View Dashcam with 2K Cabin Facing Cam

Important, retain for future reference:

Read carefully

WP ITM. BT532871

Care & Use Instructions

TABLE OF CONTENTS

1. Introduction ...............................................................................................................................................................................3

2. Package Contents ...................................................................................................................................................................4

3. Product Specications ..........................................................................................................................................................5

4. Product Dimension ................................................................................................................................................................5

5. Product Overview ....................................................................................................................................................................6

6. Button Conguration .............................................................................................................................................................7

7. Before You Start........................................................................................................................................................................8

8. Installation ..................................................................................................................................................................................8

9. Initial Setup .............................................................................................................................................................................. 10

10. Menu Settings.... ...................................................................................................................................................................11

11. Camera Status & LED Indicators .....................................................................................................................................17

12. Recording Time .....................................................................................................................................................................17

13. Time-lapse Recording Logic ...........................................................................................................................................18

14. Technical Specications ...................................................................................................................................................18

15. Downloading and use the TYPE S Drive App ..........................................................................................................19

16. App Setup ............................................................................................................................................................................. 20

17. App Settings ......................................................................................................................................................................... 23

18. Viewing and Managing Media Files Using A Computer ................................................................................... 26

19. Safety Information ............................................................................................................................................................. 27

20. Maintenance & Warranty ................................................................................................................................................ 29

21. General Information ......................................................................................................................................................... 32

Please read all of the installation instructions carefully before installing the product. Improper

installation will void manufacturer’s warranty. The installation instructions do not apply to all types

of vehicles, and are written as guidelines to assist in installing the product.

Consult an experienced technician if you are not comfortable installing the product. You can also

contact TYPE S at 866.294.9244 to speak to one of our installation specialists if you have any

specic questions regarding the Dashcam.

BEFORE using the Dashcam, please read the safety information provided in this user manual.

ALWAYS use the product as outlined in this user manual.

Please make sure to read and understand all local laws and regulations regarding cameras and their

use in a vehicle. Laws vary by state.

1. INTRODUCTION

www.typesauto.com/register

(beyond the standard one year warranty), along with special product offers and announcements.

Registre este producto dentro de los 30 días siguientes a la compra para recibir 1 AÑO GRATUITO de

cobertura de garantía adicional (más allá de la garantía estándar de un año), junto con ofertas de productos

y anuncios especiales.

Enregistrez ce produit dans les 30 jours suivant l'achat pour recevoir une couverture supplémentaire

GRATUITE DE 1 AN (au-delà de la garantie standard d'un an), ainsi que des offres et des annonces spéciales.

STOP

ARRÊT

DETÉNGASE

Mon-Fri, 8am-5pm PST / Lundi au vendredi, 8h à 17h HNP /

Lun-vie, 8 a. m. a 5 p. m. Hora del Pacífico

[email protected] / (866) 294-9244

Please contact our customer service before returning this product to

the store. Our friendly representatives are happy to help with any

questions or concerns you have.

Póngase en contacto con nuestro servicio a clientes antes de regresar

este producto a la tienda. Anuestros amables representantes les dará

mucho gusto ayudarle con cualquier pregunta o inquietud que tenga.

Veuillez communiquer avec notre service à la clientèle avant de

retourner le produit au magasin. Nosreprésentants se feront un plaisir

de vous assister pour toute question ou préoccupation.

Product code / Code de produit / Código del producto : BT533004

@TypeSAuto

ML-533004DNR_V1

Dash C am Ins tall ation Step

Please remove the static screenprotector before use it

and stick the static into the windshield at a proposition.

Please stick the 3M stickers from the mount into the

central location of static stickers.

1. 2.

3. 4.

5. 6.

7. 8.

9. 10.

2. PACKAGE CONTENTS

1. 1 x 4K Dual View Dashcam with

2K Cabin Facing Cam

2. 1 x 12 / 24V Power Adapter

3. 1 x Windshield Mount

4. 1 x Mounting Bracket with 3M VHB™

Double-sided Tape

5. 1 x 3M VHB™ Double-sided Tape (Spare)

6. 1 x Static Sticker

7. 1 x 32GB MicroSD Card

8. 1 x 3.28’ / 1m USB-A to USB-C File

Transfer Cable

9. 1 x Instruction Manual

10. 1 x Warranty Card

3. PRODUCT SPECIFICATIONS

4. PRODUCT DIMENSION

Screen:

Resolution:

Frequency:

Operating Voltage:

Operating Temperature:

Viewing Angle:

Image Sensor:

Maximum Signal Range:

2.4" IPS

4K UHD - Ultra High Denition (3840 x 2160p)

2.4 GHz

DC 12 / 24V - Cigarette Lighter Adapter (CLA)

14F~140F (-10C~60 C)

139.4° (Front Camera), 132° (Cabin View Camera)

5MP

9.84 Feet/3 Meters

(without interference or obstruction)

4.17 in / 106 mm

1.77 in /

45 mm

1.53 in / 39 mm

5. PRODUCT OVERVIEW

1. Function Buttons

2. Display Screen

3. Mounting Socket

4. Microphone

5. Front View Camera

6. Cabin View Camera

7. Status Indicator

8. Reset Button

9. USB-C Data Port

10. MicroSD Card Slot

Open Menu (click once)

Switch between Front/Cabin/Rear/

3-in-1 view (click once)

Snapshot (click once)

Return to Video Mode (click once)

Screen On/O (click once)

Power On/O (press and hold for 3 sec)

Microphone On/O (click once)

Switch between Front/Cabin/Rear/

3-in-1 view (click once)

Lock/Unlock Video (click once)

Record (click once)

Screen On/O (click once)

Power On/O (press and hold for 3 sec)

6. BUTTON CONFIGURATION

Apply conguration and settings to the Dashcam

using the 5 function buttons. Refer to the screen

display below for the buttons and their

corresponding functions in dierent modes.

Function Buttons

Video Mode

Camera Mode

Camera ModeCamera Mode

Video ModeVideo Mode

Note: Rear and 3-in-1 view only available when the 1080P Rear Camera (sold separately) is connected.

Plug the USB-C power cable into the

input port on the Windshield Mount.

(Optional) Plug the 1080P Rear

Camera power cable into the

AV-IN port.

* 1080P Rear Camera (BT532838) sold separately.

Attach the Dashcam

to the Windshield

Mount using the

socket on the top.

7. BEFORE YOU START

Peel o the protective lm

from the display screen.

Insert the MicroSD card into the slot

if not pre-installed.

8. INSTALLATION

Before installing onto your vehicle, please test the product by powering it on and connecting it to

the TYPE S Drive App (Section 16). Please use this document for detailed instructions and product

information.

NOTE: The GPS receiver

is located inside the

Windshield Mount.

To ensure the best

performance, please

avoid placing it under a

physical obstacle.

Attach the Dashcam onto the windshield:

- Apply the static sticker onto the cleaned windshield and peel o the protective lm.

- Slide the Mounting Bracket into the Windshield Mount.

- Peel o the 3M VHB™ tape backer from the mount and attach the Dashcam onto the static sticker.

Recommended

mounting position

WARNING: When installing, please ensure that it won't obstruct the driver's eld of vision.

Route the power cable to your 12/24V outlet (cigarette

lighter) and hide the cable in the headliner and pillars.

We recommend going through the passenger side so

the cable doesn't get into the driver's way.

9. INITIAL SETUP

Set date & time. The date

stamps that appear on all

future recordings will follow

this setting.

Adjust the Cabin View Camera’s

position to get the best view of the

interior of your vehicle.

Event 1/15
