TypeS BT530028 User manual

Important, retain for future reference:
Read carefully
HD BACKUP CAMERA
5” HD Monitor Wirelessly Displays Rearview
WP ITM. BT530028
Care & Use Instructions

TABLE OF CONTENTS
1. Introduction ........................................................................................................................................................................ 1
2. Package Contents ............................................................................................................................................................. 2
3. Product Specications .................................................................................................................................................... 3
4. Product Overview .............................................................................................................................................................. 3
5. Camera Status & LED Indicators.................................................................................................................................... 4
6. Connect to power .............................................................................................................................................................. 5
7. Installation Guide .............................................................................................................................................................. 7
8. Settings and Operation .................................................................................................................................................. 9
9. Safety Information .......................................................................................................................................................... 13
10. Maintenance & Warranty ...........................................................................................................................................16
11. General Information .....................................................................................................................................................19

1
Please read all of the installation instructions carefully before installing the product. Improper
installation will void manufacturer’s warranty. The installation instructions do not apply to all types of
vehicles, and are written as guidelines to assist in installing the system.
Consult an experienced technician if you are not comfortable installing the product. You can also
contact TYPE S at 866.294.9244 to speak to one of our installation specialists if you have any specic
questions regarding the HD Backup Camera - 5”HD Monitor Wirelessly Displays Rearview.
BEFORE using the HD Backup Camera - 5”HD Monitor Wirelessly Displays Rearview, please read
the safety information provided in this user manual. ALWAYS use the product as outlined in this
user manual.
Please make sure to read and understand all local laws and regulations regarding cameras and their
use in a vehicle. Laws vary by state.
1. INTRODUCTION

2
2. PACKAGE CONTENTS
Hardwire Installation Kit Spare Fuse (250V 2A)
HD Backup Camera 5”HD Monitor
12V / 24V CLA Power Adapter Windshield Mount Dash Mount

3
3. PRODUCT SPECIFICATIONS
4. PRODUCT OVERVIEW
Frequency: 2.4 GHz
Camera Resolution: 110º
Camera View Angle: HD 720P
Camera Water Resistance Rating: IP67 Waterproof Rating
Operating Temperature: 14ºF ~ 122ºF (-10ºC ~ 50ºC)
Operating Voltage: DC 12V / 24V
LED Light
Camera Lens
133mm / 5.23“ 45.6mm / 1.79“
53 mm
/ 2.08“
(without interference or obstruction)
Maximum Signal Range: 33 Feet / 10 Meters

4
5. CAMERA STATUS & LED INDICATORS
Power / Mode Status Backup Camera LED Indicator 5”HD Monitor LED Indicator
Power On Blue LED light ashes 2 times when the Backup
Camera is powered on. Blue LED light stays on when the Backup Camera is powered on.
Power O LED light is o. LED light is o.
Pairing Mode Blue LED light ashes until update is successful. Blue LED light stays on.
139mm / 5.47“
76 mm
/ 2.99“
21.5 mm
/ 0.85“
21.5 mm / 0.85“

5
6. CONNECT TO POWER
This installation is based on powering the camera over the reverse tail lights.When installed as directed,
the camera image will only appear when the vehicle is in reverse.
Caution: This unit is designed to operate on a 12V/24V DC NEGATIVE GROUND electrical system.
Connecting to other types of electrical systems will cause damage to your vehicle. Please contact the
manufacturer if you are unaware of the system type in your vehicle.
1. Remove your license plate.
2. Determine the best route for the Camera Cable from the top of your license plate to the inside
of the vehicle. You may need to drill a small hole in the panel behind where the license plate is
situated.
3. Take the Camera and run the cable through the Rubber Ring Grommet, then from the outside of
your car to the inside. Pull the cable through so that there is a small amount of slack and you can
still move the Camera around the license plate.
4. Locate the reverse taillights wiring behind your reverse light. You may need to remove the interior
panel in order to locate. You only need to attach the Camera to ONE of the reverse lights, not
both. If you cannot manually locate the taillight cables, please contact the vehicle manufacturer
or reference a wiring diagram for your vehicle.
5. At your taillight, remove the light bulb socket from the reverse light housing.

6
Hardwire cable for Camera
Snap!
Reverse Light Power Wires
6. Determine the reverse light power wires for your car, designating the positive and negative wires.
If you are not sure of which are the power wires, then please contact your vehicle manufacturer or
reference a wiring diagram for your vehicle.
7. Connecting the Camera Power Cable:
a. Take the open wire end of this cable, and connect it to the power wires of your car (as
determined in step 4). Using the Snap Lock Splice Connectors, connect the Camera’s Red
wire to reverse light’s Positive wire. Connect the Camera’s Black Wire to reverse light’s
Negative wire.
b. Use pliers to squeeze the metal tabs of the Snap Lock Splice Connectors and ensure a solid
connection, then snap the plastic cover closed.
8. While sitting in the driver’s seat of your car with the key in the accessory position. The monitor will
automatically start when connected to a power source. If the monitor shows no image when you
place the vehicle in reverse, go to the section“Settings and Operation” for more information.

7
7. INSTALLATION GUIDE
HD BACKUP CAMERA INSTALLATION
1. Peel o the cover of the double-sided tape from the HD Backup Camera and attach the Camera to
the license plate. Press rmly to the license plate to secure the Camera.
RECOMMENDATION: Thoroughly clean & dry the mounting surface area of the license plate
before attaching.
2. Press the license plate and the Camera rmly to the car to secure and get full contact between the
license plate and the double-sided tape. Screw the license plate back onto the rear of your vehicle.
3. As a last check, note the position of the view from the Camera when you place the vehicle in
reverse. Adjust the position of the Camera as necessary to achieve the best rear view.
9. Put the vehicle in reverse. If you can see clear picture, put the vehicle back in park and turn the key
to the o position. You are now ready for nal steps.
10. Use the provided zip ties to secure wires neatly within your car.
11. Replace the light socket back into the reverse light housing.
12. Replace any interior panels that may have been removed to access the taillight and close your
trunk or rear hatch.

8
5”HD MONITOR INSTALLATION
1. Place Magnetic Windshield Mount on the windshield and adjust to your desired position.
2. Attach the 5”HD Monitor on to the Magnetic Windshield Mount.
3. Remove the 5”HD Monitor protective overlay.
4. To power the 5” HD Monitor: Take the 12V/24V Power Adapter and plug adapter into the right side
of the 5”HD Monitor. Plug the other end into 12V/24V power port in your car.
WARNING: Many vehicles provide constant power to the 12V outlet. If your outlet provides
constant power, please remember to unplug the 5” HD Monitor when not in use to avoid draining
the vehicle battery.
OR

9
POWER ON/OFF
• The 5”HD Monitor will automatically turn ON when it is connected to a power source.
• Hold the Power button to turn ON/OFF the unit, if necessary.
• Press the Power button to return to previous page from each of the Menu setting pages.
PARKING AID LINE
• You can turn ON/OFF the Parking Aid Line by pressing the Parking Aid Line button when the
reverse image appears on screen.
• You can adjust the Parking Aid Line that appears on the Monitor. When the Parking Aid Line is
engaged, press and hold the Parking Aid Line button for 3 seconds until the parking line ashes,
then press the “+” or “-” to adjust up or down on the Monitor. There are a total of 10 adjustments
that can be made.
• You can go into the setting function page when you press the Parking Aid Line in the Menu, then
you can congure the settings function when you press Parking Aid Line in any setting page.
BRIGHTNESS AND CONTRAST
You can adjust the contrast and brightness of the Monitor according to your desired level.
NOTE: Contrast and Brightness setting ONLY works while the camera image is appeared on the screen.
Power Parking Aid Line / Enter
Up
Menu
Down
8. SETTINGS AND OPERATION

10
PAIRING
The HD Backup Camera is already paired with the Monitor. If you cannot see the Camera image, pair
the Camera with the following steps:
1. Power on the HD Backup Camera.
2. On the Monitor:
Press“Menu”
Go to“Pair Camera”
Press“Parking Aid line”to conrm
The unit is now in pair mode - if the Monitor is able to connect with the camera, the display will
show“Pair OK”.
If no camera is found, then the display will show “Pair Fail”. In this case, cut o power and reboot the
Monitor. If you keep receiving the“Pair Fail”message after several attempts, please call our technical
support to assist in troubleshooting.

11
ROTATE CAMERA
1. Press“MENU”
Go to“Rotate Camera” by pressing“–“
2. Press“Parking Aid Line”to enter
3. Press“+” or“-” to rotate screen direction
4. Press“Parking Aid Line”to conrm and exit
TO ADJUST BRIGHTNESS
1. Press“MENU”
2. Go to“Brightness”by pressing“– “
3. Press“Parking Aid Line”to enter
4. Press“+ “ or“– “ to adjust the contrast level
5. Press“Parking Aid Line”to conrm and exit

12
TO ADJUST CONTRAST
1. Press“MENU”
2. Go to“Contrast” by pressing“– “
3. Press“Parking Aid Line”to enter
4. Press“+ “ or“– “ to adjust the contrast level
5. Press“Parking Aid Line”to conrm and exit
EXIT
Exit the setting page and back to parking view.

13
WARNING: A failure to read and follow these warnings and instructions may result in a serious
accident, including damaged property or a serious injury, including loss of life.
• The HD Backup Camera is designed as an aid to the driver in detecting large stationary objects to
help avoid damaging the vehicle. However, you, the driver, must use it safely and properly. Use of
the HD Backup Camera is not a substitute for safe, proper and legal driving.
• Never back up while looking only at the screen. You should always check behind and around the
vehicle when backing up just as you would if the vehicle did not have the HD Backup Camera.
Always make sure your intended path is clear. If you back up while looking only at the screen,
you may hit a vehicle, pedestrian, bicyclist, child, pet or other object resulting in injury or death.
Always back up slowly.
• Never depend on the HD Backup Camera entirely when backing up. The image on the screen is
dierent from actual conditions. Objects viewed in the screen dier from actual distance because
a wide-angle lens is used. Objects in the screen will appear visually opposite than when viewed in
the rear view and outside mirrors. Use the inside mirror or glance over your shoulder to properly
judge distances to other objects.
• The area displayed by the HD Backup Camera is limited. The HD Backup Camera does not display
objects that are close to or below the bumper, underneath the vehicle, or objects out of the
Camera’s eld of view. The area displayed on the screen may vary according to vehicle orientation
or road conditions.
• Be sure to check the Camera’s position and mounting angle before each use.
• Make sure the trunk, hatch, or backdoor is completely and securely closed when backing up.
• If the back of the vehicle is hit, the position and mounting angle of the HD Backup Camera may
IMPORTANT SAFETY INSTRUCTIONS
1. SAVE THESE INSTRUCTIONS– This manual contains important safety and operating instructions of
Model BT530028.
2. Before using the product, read all instructions and cautionary markings.
3. Use of an attachment not recommended or sold by the product manufacturer may result in a risk
of re, electric shock, or injury to persons.
4. Do not disassemble the HD Backup Camera; take it to a qualied serviceperson when service
or repair is required. Incorrect reassembly may result in a risk of electric shock or re.
9. SAFETY INFORMATION

14
change.
• When washing the vehicle with high pressure water, be sure not to spray it around the HD
Backup Camera. Otherwise, water may enter the Camera unit causing water condensation on the
lens, a malfunction, re or an electric shock.
• Do not strike the HD Backup Camera. It is a precision instrument. Otherwise, it may malfunction
or cause damage resulting in a re or an electric shock.
• This product will only provide images of items that are within the eld of view of the HD
Backup Camera. Thus, it is imperative that the HD Backup Camera should be kept clean and
unobstructed, and should be mounted so that its eld of view includes the entire area behind
your vehicle.
• Adhere to all applicable trac laws and motor vehicle regulations applicable to the device.
• Consult local laws and regulations for any restrictions on installation or use.
• Never allow children to play with the device. Small parts may be a choking hazard.
• There is a plastic cover over the HD Backup Camera. Do not scratch the cover when cleaning dirt
or snow from the cover.
• The HD Backup Camera has a water resistant construction. Do not detach, disassemble or modify
it. This may cause incorrect operation. HD Backup Camera is waterproof.
• Do not submerge HD Backup Camera in water, which can cause internal damage to the Camera.
• If the temperature changes rapidly, such as when hot water is poured on the vehicle in cold
weather, the system may not operate normally. The Digital Camera can withstand the eects of
rain, snow, and inclement weather.
• When strong light directly enters a camera, objects may not be displayed clearly.
• The screen may icker under uorescent light.
• The colors of objects on the screen may dier somewhat from those of the actual object.
• If dirt, rain or snow attaches to the Camera, the screen may not clearly display objects. If water
droplets, snow or mud adhere to the Camera lens, rinse with water and wipe with a dry cloth.
• Do not use alcohol, benzene or thinner to clean the Camera. This will cause discoloration. To
clean the Camera, wipe with a clean cloth dampened with mild cleaner diluted with water and
then wipe with a dry cloth.
• Will work up to 33 feet.

15
• ALWAYS engage Parking/Emergency/Hand Brakes of the vehicle when testing the system.
SAFETY AROUND AND BEHIND OTHER VEHICLES
Using a HD Backup Camera is not enough to completely overcome a vehicle’s blind spot. Many
preventable injuries and deaths occur in driveways or parking lots when drivers do not see children,
pets, or others near their vehicles. Here are a few safety tips that will help you to avoid a back-over
accident:
• Walk completely around your vehicle before getting in. Check for kids, toys, and pets before
entering the vehicle and starting the engine.
• Know where children are. Have children stand in a place where they are in full view.
• Be aware of young children. Young children are small and hard to see.
• Parents, caregivers and all adults need to be vigilant in supervising children, especially when
children are in the yard, driveway or parking lot playing near parked cars.
• Roll down your window so you will be able to hear what is happening outside your vehicle.
• Owners of SUVs, trucks, and vans need to take extra care to avoid hitting or running over a child.
• Teach children to move away from a vehicle whenever it is started.

16
10. MAINTENANCE & WARRANTY
CLEANING
• If dirt, rain or snow attaches to the Camera, the screen may not clearly display objects. If water
droplets, snow or mud adhere to the Camera lens, rinse with water and wipe with a dry cloth.
• Do not use alcohol, benzene or thinner to clean the Camera. This will cause discoloration. To
clean the Camera, wipe with a clean cloth dampened with mild cleaner diluted with water and
then wipe with a dry cloth.
WARRANTY
• TYPE S
LIMITED WARRANTY
TYPE S warrants, to the original purchaser, that its products are free from defects in material
and workmanship for 1 year from the date of original purchase. Where permitted by law, TYPE
S liability shall be limited to that set forth in this limited express warranty. This limited express
warranty shall be the exclusive remedy of the purchaser and TYPE S makes no other warranty of
any kind aside from the limited express warranty stated above.
NOTE: Warranty only applies for North American customers of purchases made in North America.
CONDITIONS OF WARRANTY
If during the 1 year warranty period your new product is found to be defective, TYPE S will repair
such defect, or replace the product, without charge for parts or labor subject to the following
conditions:
1. All repairs must be performed by TYPE S.
2. All warranty claims must be accompanied by a copy of the sales receipt or bill of sale.
3. The equipment must not have been altered or damaged through negligence, accident,
improper operation, or failure to follow the product instructions for installation, use, or
care.
4. The replacement of parts is excluded from the warranty when replacement is necessary
due to normal wear and tear.
5. Repair or replacement parts supplied by TYPE S under this warranty are protected only

17
for the unexpired portion of the original warranty.
6. This is a“repair or replace”warranty only, and does not cover the costs incurred for the
installation, removal or reinstallation of the product, or damage to any mobile phone
device or vehicle.
OWNER’S RESPONSIBILITIES:
TYPE S will make every eort to provide warranty service within a reasonable period of time.
SHOULD YOU HAVE ANY QUESTIONS ABOUT SERVICE RECEIVED OR IF YOU WOULD LIKE
ASSISTANCE IN OBTAINING SERVICE, PLEASE CALL TOLL FREE 1.866.294.9244 DURING REGULAR
BUSINESS HOURS MONDAY THROUGH FRIDAY 8:00 AM TO 5:00 PM.
NOTE: Toll Free # is for North America Customers ONLY. See Customer service section for
customer contact numbers for other regions/oces.
For customer service and technical support, please call us at 1.866.294.9244. If at that time it is
determined that a replacement unit is needed, the support representative will issue a Return
Authorization and instruct on how to get a new unit.
TYPE S makes no other warranty of any kind aside from the limited express warranty stated
herein.
DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF MERCHANTABILITY AND WARRANTY OF
FITNESS FOR PARTICULAR PURPOSE: EXCEPT AS SPECIFICALLY SET FORTH HEREIN, NO WARRANTY
OR REPRESENTATION, EXPRESS OR IMPLIES, IS MADE AS TO THE HD Backup Camera. EXCEPT AS
EXPRESSLY SET FORTH HEREIN, TYPE S AND/OR ITS AFFILIATES EXPRESSLY DISCLAIMS, WITHOUT
LIMITATION, ANY STATUTORY WARRANTIES AND ALL IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TYPE S and/or its aliates do not guarantee or promise that the user of HD Backup Camera will
not be in an accident or otherwise not collide with an object and/or person. Our HD Backup

18
Camera is not intended in any way to be a substitute for careful and cautious driving or for the
consistent adherence to all applicable trac laws and motor vehicle safety regulations.
The HD Backup Camera is not intended to be a substitute for rearview mirrors or for any other
motor vehicle equipment mandated by law. Even when properly installed, our HD Backup
Camera has a limited eld of vision and does not provide a comprehensive view of the rear
area of the vehicle. You should always look around outside your vehicle and use your mirrors to
conrm rearward clearance and that your vehicle can back up safely.
TYPE S and/or its aliates are not responsible for a user’s intended or actual use of the HD
Backup Camera. In no event shall TYPE S and/or its aliates have any liability for any losses
(whether direct or indirect, in contract, tort or otherwise) incurred in connection with the HD
Backup Camera, including but not limited to damaged property, personal injury and/or loss of
life. Neither shall TYPE S and/or its aliates have any liability for any decision, action or inaction
taken by any person in reliance on the HD Backup Camera, or for any delays, inaccuracies and /or
errors in connection with the HD Backup Camera and its functioning.
TYPE S and/or its aliates shall have no responsibility or liability for damage and/or injury
resulting from accidents occurring with vehicles having the installed, and TYPE S and/or its
aliates, the manufacturer, distributor and seller shall not be liable for any injury, loss or damage,
incidental or consequential, arising out of the use or intended use of the product.
