U'King King Kong 200B User manual

King Kong 200B Beam Moving
Head Light
User Manual
(Please read the manual carefully before using the product and take care of it properly)

In order to use this product correctly and safely, please read the manual carefully before
installing and using this product. This manual contains important installation and application
information, please strictly follow the instructions when installing and operating the product.
Meanwhile, please keep this manual in a safe place.
Our light which is LED REDSUN King Kong 200W Beam Light using a new and beautiful high
temperature resistant metal body.This product is designed and produced in strict accordance with
CE standards. It conforms to the international standard DMX512 signal protocol. It can be used for
control alone or online. It has the characteristics of fast rotation, low noise and powerful functions.
It is suitable for small and medium-sized concerts, theaters, In studios, nightclubs, bars and other
places.
Please carefully remove the packaging, check whether the product is damaged during
transportation after the packaging is removed, and check whether the following contents are
complete.
Wash Light--------1set Manual--------1copy
Power cable--------1pcs Signal cable--------1pcs
This product is in good condition before leaving the factory. In order to keep the
product in good condition and ensure safe operation, users should follow the safety
precautions and warnings in this manual.
Important:
Damage caused by not following this instruction manual is not covered by the warranty. The
supplier is not responsible for product problems caused by this.
If the product has been exposed to extreme unstable temperature environments (such as after
transportation), please do not connect the product to the power supply immediately, as water
droplets due to temperature changes may damage the product. Please use it after the product has
returned to normal temperature.
This product can be used in the voltage range of 90-240V and is an indoor product. Please make
sure that the ground voltage used is not higher than the product can withstand! ! The power plug
must be inserted into a protected Class I socket. The green or teal conductor must be grounded.
Please check this product grade power cord frequently. Make sure the power cord is not folded or
damaged and not connected to other wires! Special attention is required when connecting the
power cord or related wiring. Always unplug this product when not in use or before cleaning.
Before using the product, please familiarize yourself with the operating functions of the product.
Please keep the product away from children or unprofessionals. Please do not shake this product.
Do not use brute force when installing or operating the product. Do not allow unprofessionals to
operate the product. Most of the damage is caused by unprofessional handling. The product is not
equipped with related maintenance parts. Maintenance and repair of the product should only be
carried out by professionals
Please do not modify this product without authorization, otherwise it may damage the product,

so the damage caused is not covered by the warranty. Also, unprofessional handling may result in
short circuits, burns or electric shocks, etc.
DMX512 Signal Connection:
This light uses the DMX512 signal control mode, and the control signals of each light are in a
parallel relationship. When connecting the signals of multiple lights, it is best to use a double-core
shielded cable. When connecting, each lamp is connected through the DMX signal jack (XLR
Socket) INPUT (input) and OUTPUT (output) are connected, and the 3-pin XLR plug terminals of
the signal line connected to the light must correspond to each other. When connecting the light
signal, it is recommended to use a DMX signal terminator. It can be avoided, due to electric dryness
The DMX signal terminator is a 120 Ω 1W resistor connected between pins 2 and 3 of an XLR plug,
and it is connected to the OUTPUT (output) jack of the last light.
Lamp start address code calculation method:
The starting address code of the current fixture is equal to (the starting address code of the
previous fixture) + (the number of channels of the fixture) Description:
1: The starting address code value of the first light is A001.
2: The number of basic channels of the controller should be greater than or equal to the total
number of channels used by the lamps.
3: Note: When using any controller, each light must have its own starting address code. If the
starting address code of the first light is set to A001, and the number of light channels is 20CH; then
the first The starting address code of the two lights is set to A021; the starting address code of the
third light is set to A041; and so on, (this setting method also needs to be determined according to
different consoles).
Light installation instructions:
The luminaire can be placed horizontally, slanted and upside down. Be sure to pay attention to
the installation method when slanted and upside down. Fixed installation of the luminaire: Before
positioning the luminaire, ensure the stability of the installation site. Do not fall off the lamp on the
support frame, use safety ropes through the support frame and the lamp handle for auxiliary
hanging; to ensure safety. Prevent the lamp from falling and sliding. When the lamp is installed and
debugged, pedestrians are prohibited from passing below, and the safety is checked regularly.
Whether the rope is worn, whether the hook screw is loose, and if the hanging installation is not
stable, the manufacturer does not assume any responsibility for all the consequences caused by the
fall of the lamp.

●Display menu description
Menu desktop：
001
Menu first interface:
TEMP:**℃
Show current TEMP
Address code
DMX-512 mode
current running mode
◆Address：Click to enter address code settings
◆Setting：Click to enter system settings
◆Manual：Click to enter manual mode
◆Calibration：Click to enter the password to enter the system calibration mode
◆Reset：Click to enter system reset mode
◆Information：Click to view system information

Screen auto-rotate function
The system can automatically rotate the screen according to the direction of gravity
without manual rotation. The auto-rotate feature can also be turned off.
Manual control
This interface is used to control the current fixture.
Press the "OK" key to enter the editing state. Press the "Up" and "Down" keys to change
the channel value. Press "OK" again to save the modified value and exit editing, press
"Exit" to directly exit editing without saving the modified value
System calibration
A layer of password is set here to prevent non-professional misoperation. The default
password for booting is "6***", and the default is to directly press the "OK" key to enter.
main menu
secondary menu
Level 3 menu/parameter
Address
001 - 512
(The number of channels is added
each time, and the subtraction is
normal)
system settings
runing mode
DMX/Sound cotrol/Auto 1/Auto 2
channel mode
20CH
horizontal inversion
On/off
vertical inversion
On/off
Hall error correction
On/off
optocoupler error
correction
On/off
signal hold
On/off
screen protector
On/off
screen flip
On/off/Auto
Synchronization Update
On/off
language
Middle/EN
reset
manual mode
current channel mode
channel
0-255
System
calibration
enter password
Fixture calibration
System reset
effect motor reset
Scan motor reset
Reset all motors
system message
reset information
Display reset error message
DMX Data monitoring
Receive the channel value of the
console
sensor information
Hall Information
X Optocoupler Information
Y Optocoupler Information
hardware version
Display hardware version
software version
Display software version

Options
Description
Initial position
calibration
After entering the sub-interface, you can adjust the starting position of the X-
axis, Y-axis, color wheel, pattern, prism, and focus motor to make up for the
error in hardware installation. The adjustment range is 0~255, and 127
means no adjustment.
Stroke calibration
After entering the sub-interface, you can adjust the strokes of the X-axis, Y-
axis, prism, and focus motor. The adjustment range is 0~255, and 127
means no adjustment.
Other calibration
Power, MIC sensitivity calibration, and password modification.
Reset
Press the "Up" and "Down" keys to switch the reset mode, and press "OK" to reset
directly.
Options
Description
effect motor reset
Effects motor resets other than XY
Scan motor reset
XY axis reset
Reset all motors
Lamp reset
System Information
Options
Description
reset information
If the red ERR indicator is on, it means that the lamp is running incorrectly.
For details, you can enter the sub-interface to view the details.
DMX Data
monitoring
From here, enter the sub-interface, and display the channel value in
numerical value for viewing
sensor
information
Real-time monitoring of the status of sensors such as optocouplers and Hall
on the lamp
Hardware version
number
Fixture hardware version
software version
number
Luminaire software version

Channel table:
20 channel
Channel function
Value
Effect
1
X axis
0-255
0-540°
2
X-axis fine-tuning
0-255
X-axis fine-tuning
3
Y axis
0-255
0-260°
4
Y-axis fine-tuning
0-255
Y-axis fine-tuning
5
XY speed
0-255
From fast to slow
6
colorful fog
0-127
Colorful fog cut out
128-189
Fog cut in
190-255
Colorful cut in
7
Strobe
0-3
No effect
4-99
Synchronized strobe
100-149
Pulse strobe
150-199
Sharply strobe
200-249
Random strobe
250-255
consecrated
8
Total dimming
0-255
Dimming(from dark to brightness)
9
LED dimming
0-255
Dimming(from dark to brightness)
10
light strip red
0-255
Red(from dark to brightness)
11
light strip green
0-255
Green(from dark to brightness)
12
light strip blue
0-255
Blue(from dark to brightness)
13
built-in color
0-255
Foreground Color Gradient
14
Dynamic effect
0-4
No effect
5-9
Effect 1
10-14
Effect 2
15-19
Effect 3
20-24
Effect 4
25-29
Effect 5
30-34
Effect 6
35-39
Effect 7
40-44
Effect 8
45-49
Effect 9
50-54
Effect 10
55-59
Effect 11
60-64
Effect 12
65-69
Effect 13
70-74
Effect 14
75-79
Effect 15
80-84
Effect 16
85-89
Effect 17
90-94
Effect 18
95-99
Effect 19
100-104
Effect 20
105-109
Effect 21
110-114
Effect 22
115-119
Effect 23
120-124
Effect 24
125-129
Effect 25
130-134
Effect 26
135-139
Effect 27
140-144
Effect 28
145-149
Effect 29

150-154
Effect 30
155-159
Effect 31
160-164
Effect 32
165-169
Effect 33
170-174
Effect 34
175-179
Effect 35
180-184
Effect 36
185-189
Effect 37
190-194
Effect 38
195-199
Effect 39
200-204
Effect 40
205-209
Effect 41
210-214
Effect 42
215-219
Effect 43
220-224
Effect 44
225-229
Effect 45
230-234
Effect 46
235-239
Effect 47
240-244
Effect 48
245-249
Effect 49
250-254
Effect 50
255
Effect 51
15
effect speed
0-127
Forward from slow to fast
128-255
Reverse slow to fast
16
色盘
0-6
White color
7-11
Color 1
12-16
Color 2
17-21
Color 3
22-26
Color 4
27-31
Color 5
32-36
Color 6
37-41
Color 7
42-46
Color 8
47-51
Color 9
52-56
Color 10
57-61
Color 11
62-66
Color 12
67-71
Color 13
72-75
White color+Color 1
76-79
Color 1+Color 2
80-83
Color 2+Color 3
84-87
Color 3+Color 4
88-91
Color 4+Color 5
92-95
Color 5+Color 6
96-99
Color 6+Color 7
100-103
Color 7+Color 8
104-107
Color 8+Color 9
108-111
Color 9+Color 10
112-115
Color 10+Color 11
116-119
Color 11+Color 12
120-123
Color 12+Color 13
124-127
Color 13+white color

128-189
Counterclockwise flow from fast to
slow
190-193
Stop
194-255
Clockwise flow from slow to fast
17
Gobo wheel
0-2
white light hole
3-6
Gobo 1
7-10
Gobo 2
11-14
Gobo 3
15-16
Gobo 4
19-22
Gobo 5
23-26
Gobo 6
27-30
Gobo 7
31-34
Gobo 8
35-38
Gobo 9
39-42
Gobo 10
43-46
Gobo 11
47-50
Gobo 12
51-54
Gobo 13
55-58
Gobo 14
59-62
Gobo 15
63-66
Gobo 16
67-70
Gobo 17
71-77
Gobo 1 shaking from slow to fast
78-84
Gobo 2 shaking from slow to fast
85-91
Gobo 3 shaking from slow to fast
92-98
Gobo 4 shaking from slow to fast
99-105
Gobo 5 shaking from slow to fast
106-112
Gobo 6 shaking from slow to fast
113-119
Gobo 7 shaking from slow to fast
120-126
Gobo 8 shaking from slow to fast
127-133
Gobo 9 shaking from slow to fast
134-140
Gobo 10 shaking from slow to fast
141-147
Gobo 11 shaking from slow to fast
148-154
Gobo 12 shaking from slow to fast
155-161
Gobo 13 shaking from slow to fast
162-168
Gobo 14 shaking from slow to fast
169-175
Gobo 15 shaking from slow to fast
176-182
Gobo 16 shaking from slow to fast
183-189
Gobo 17 shaking from slow to fast
190-221
Clockwise flow from fast to slow
222-223
Stop
224-255
Flow counterclockwise from slow to
fast
18
Prims
0-31
Prims cut out
32-63
Prims cut in
64-255
Prism rotation from slow to fast
19
Zooming
0-255
Linear zooming
20
Reset
0-219
No effect
220-255
Reset all

Technical parameter:
Voltage：AC100-240V 50/60HZ
Light source：120W
Power：200W
Gobo：17 patterns+white color,with two-way flow, variable speed shaking
effect
Color wheel：13 colors+white,Bidirectional variable speed rainbow
flowing water effect,fog + Colorful
Prim：8+16 prims,one-way variable speed rotation
Light strip:44 pcs 0.2W RGB 3in1
Dimming：0-100% Linear dimming
Channel：20CH
Control mode：DMX512,Auto,Sound,Lamp bead overheating protection
Protection grade: high temperature engineering plastic, IP20
With RDM function, controllable station address code
Horizontal：540°
Vertical：260°
After-sales service:
Attention! When the lamps leave the factory, they have undergone strict quality inspection, and the
packaging is in good condition. Please operate according to the instruction manual. The machine failure
caused by human reasons is not covered by the warranty.
1. The company provides technical advice to customers for lifetime.
2. If the product fails and needs to be repaired, please show the product warranty card and fill in the
relevant content truthfully. At the same time, we also hope that customers will promptly feedback the
product problems to us, so that we can improve the product as soon as possible.
