U-Line 2175DWRR Manual

8900 North 55th Street ▪Milwaukee, WI ▪53224-9540 ▪414-354-0300 ▪(fax) 414-354-7905
ÉCHELON
2115/CLR2160 27 11/16” H x 14 1/32” W
2175 27 11/16” H x 23 1/32” W
2175DWRR/CO2175DWR 12 15/32” H x 23 1/32” W
¼” CUSTOM INSERT PANEL SIZES
o Zero clearance with a flush/flat door panel.
o Door will accept a raised panel. Allow proper clearance,
on hinge side when installing a raised panel. Amount of
clearance will depend on raised panel thickness.
o The maximum panel thickness when inserted into the
door reveal (channel) is ¼” thick.
o For raised panels the depth of the reveal is ¼” on both
sides and bottom and ¼” on top.
o Panel not to exceed 20 pounds.
o Conversion information: 1 inch = 2.54 cm
30165
