U-Line 29 Series Configuration guide

CO29

mARinE / RF

Black White

FEATURES

• 2.1 cubic feet overall refrigerator capacity maximizes storage of food and

beverage items

• High output daily ice rate of up to 18 lbs and storage of up to 13 lbs of

crescent ice (1/2" W x 3/4" H x 2-1/2" L)

• Temperaturesettingfrom34to45˚Fprovidesexibilityforpreservingawide

variety of items

• No drain required makes it easy and inexpensive to install and requires only a

1/4" outside diameter water line

• Conserves energy by using less electricity than a 75-watt light bulb

• Uses under 3 gallons of water to produce 25 lbs of ice

• Mechanical controlled passive cooling system

• Manual defrost maximizes ice making potential

• 220 volt model available with a 4 – 6 week order lead time

• Vinyl coated cabinet helps withstand tough marine environments

• Corrosion and UV resistant marine grade hardware provide better product

longevity in harsh environments

• Aluminum framed door with anodized durable aluminum handle weathers outdoor

elements on white model

• Fieldreversibledoorwithzeroclearancedoorswingsimpliesinstallation

• Black model will accept a 1/4" insert panel

• No additional clearance around sides, top or rear of unit is needed for ventilation

• Sleek and contemporary look provides a very clean, high-end aesthetic

• Donotobstructfrontgrilleairow

• For proper installation and cut-out dimensions, see backside for details

CO29

inTEGRATiOn inTERiOR / ExTERiOR PERFORmAnCE

8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX 414.354.7905 U-LINE.COM

DIMENSIONS AND SPECIFICATIONS

Please visit www.u-line.com for installation guide.

All specifications are subject to change without notice.

OVERALL DIMENSIONS

8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX 414.354.7905 U-LINE.COM

CO29

MARINE / RF

23" *

28-1/2"

20-13/16"

*Add 15/16" To Depth For Water Line Clearance

24"

Minimum

21-1/16"

Typical

Counter

Height

34-1/4"

35-1/8"

Cut-Out

Height

28-5/8"

28-7/8"

Filler Panel (Not Provided by U-Line) –

May Be Added Above or Below Unit

to Enclose for a Built-In Look

3-5/9"

2-4/9"

2-5/16"

4-1/16"

Legend: E - Electrical W - Water

CO29

Black 110V U-CO29B-03

Black 220V U-CO29BTP-20

White 110V U-CO29WH-03

White 220V U-CO29WHTP-20

Height 28-1/2" (72.4)

Width 20 -13/16" (52 .9)

Depth 23" (58.4)

Shipping weight: 98 lbs (44 kg)

Running amps 2.5

Maximum start-up amps 18.0

Amps pertain to voltage rating 110/115 volt, 60 Hz

Optional in 220/230 voltage, 50/60 Hz

Capacities:

Defrost technology Manual defrost

Refrigerator volume 2.1 Cu. Ft

Approximate daily ice production Up to 18 lbs

Ice Storage Up to 13 lbs

*Wheninstallingaleft-handhingemodel,allowa145˚door

swing for proper removal of ice bin

CO29B Black Model

* Add 15/16" to depth for water line clearance
