Features & Benefits
8900 North 55th Street • Milwaukee, Wisconsin 53223 • Phone: [phone] • Fax: [phone]
www.u-line.com
ADA HEIGHT COMPLIANT REFRIGERATOR
MODEL ADA24R
Capacity: 5.3 cubic feet all refrigerator
Defrost Type: Automatic (cycle) Defrost
Colors: Stainless Steel, Black
Feature Benefit
ENERGY STAR and CEE Tier 3
rating
Save energy, money and our natural resources. Glass door
models are ENERGY STAR / CEE Tier 1 rated. Solid door
models are ENERGY STAR and CEE Tier 3 rated; the most
efficient energy rating currently available.
ADA height compliant Meets ADA height requirements.
Standard door lock Customized desired look with the comfort of knowing that
stored items are secure.
Four full-depth, removable, chrome
plated, heavy-duty wire shelves
Storage capacity for different size items with ability to customize
storage layout. 5.3 Cu. Ft. capacity holds more than 7-1/2 cases
of 12 oz. cans.
Automatic touch-control interface Accurate digital temperature readout that is easily accessible and
manages key model functions and user alerts.
Accepts 1/4” flat or 3/4” raised
custom panel
Ability to match surrounding decor cabinetry. Available on black
solid door model only. Product ships without panel.
Field reversible doors Flexible installation options, applies to black models only.
Stainless steel model Offers a bold commercial style stainless steel wrap door with a
black “cap” on top and bottom of door. Black cabinet and grille.
Must order right- or left-hand hinge.
Fan driven cooling technology 60% faster pull-down to temperature rate and a 3 degree
temperature range from top to bottom. Fan motor is quiet,
maintenance free, provides energy savings and speedy recovery
after door openings.
Maximum protection for commercial installation.Commercial grade water resistant
plug
More precise under counter fit.Leveling legs included
Automatically illuminates when door is open. Does not
interfere with storage or access to product.
Recessed interior light
Easy to understand and use. Shuts off all lights and control
displays. Automatically resets after 36 hours.
Sabbath or Black Out mode
ADA24RGLS-13
ADA24RGLB-13
ADA24RB-13
ADA24RS-13

8900 North 55th Street • Milwaukee, Wisconsin 53223
Phone: [phone] • Fax: [phone] • www.u-line.com
10/28/09 © 2009 U-Line Corporation Printed In U.S.A.
Dimensions & Specifications
1-15/16
(4.9)
11-1/8
(28.3)
BACK OF ADA24R
POWER CORD
23-7/8
(60.6)
24-15/16
(63.4)
23-1/8
(58.7)
20-7/8
(53)
23-5/16
(59.2)
1-1/16
(2.7)
32
(81.3)
FULL
RETRACT
HEIGHT
33
(83.8)
FULL
EXTEND
HEIGHT
U-ADA24RB-13
U-ADA24RGLS-13
INCHES (CENTIMETERS)
Specifications Capacities
(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.
Stainless steel models must be ordered right- or left-hand hinged.
Stainless steel models: Allow 2-1/2" clearance on hinge side for 90° door opening when installed against a wall.
Please visit www.U-Line.com for Installation Guide.
All specifications subject to change without notice.
Shipping Weight:
Solid Door Models
Glass Door Models
114 lbs (52 kg)
116 lbs (53 kg)
(1) Running Amps 2.4
(1) Maximum Start-up Amps 9.8
Refrigerator volume 5.3 cubic
feet
Freezer volume N/A
Approximate daily ice production N/A
Ice storage N/A
Refrigerator Model ADA24R
