Regal Series Snap Action
Thermostat Control Griddle
Models:
RGTSA-2424-1 RGTSA-2436-1 RGTSA-2448-1
Regal Series Snap Action Thermostat Control Griddle
Specification:
Shall be U.S. Range Regal Snap Thermostat Control
Griddle. Model ________ with a total BTU/hr rating
of ________ when used with natural or propane
gas. Finish is to be stainless steel front and sides.
• Temperature range 100°F - 450°F
(32°C - 232°C)
• 1" (25mm) thick steel griddle plate
• 4" (102mm) legs with adjustable feet
• 3/4" rear gas connection w/ regulator
• One year parts and labor warranty
Optional Features:
 Stainless steel equipment stand with interme-
diate shelf
Swivel casters on stand
RGTSA-2448-1
Standard Features:
• Stainless steel front, sides and landing ledge
• 24" (610mm) - 72" (1829mm) wide
• 14 Gauge splash guard
• Built-in front grease trough
• Large capacity, removable grease container
• Aluminized steel burners, one every 12"
(305mm)
• 24,000 BTU/hr per burner
• Snap action thermostat control
• 110V cord/plug provided

Garland Commercial
Industries, LLC
185 East South Street
Freeland, PA 18224
Phone: [phone]
Fax: [phone]
Garland Commercial Ranges Ltd
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
Phone: [phone]
Fax: [phone]
Enodis UK LTD
Swallowfield Way,
Hayes, Middlesex
UB3 1DQ ENGLAND
Telephone: [phone]
Fax: [phone]
Regal Series Snap Action Thermostat Control Griddle
Form# RGTSA (06/07)
Model # Dimensions: In. (mm) No. of
Burners
Total
BTU*
Griddle Size; In. (mm)
Width Depth Height Width Depth
RGTSA-2424-1 24(610) 30-1/4(768) 16-3/4(425) 2 48,000 24(610) 22(559)
RGTSA-2436-1 36(914) 30-1/4(768) 16-3/4(425) 3 72,000 36(914) 22(559)
RGTSA-2448-1 48(1219) 30-1/4(768) 16-3/4(425) 4 96,000 48(1219) 22(559)
* Natural and Propane Gas
Shipping Information
Model No. Weight
Lb/Kg Cube
RGTSA-2424-1 270/122 18.0
RGTSA-2436-1 370/168 25.0
RGTSA-2448-1 441/200 33.0
Manifold Operating Pressure
All Models
Natural Gas Propane
"WC Mbar "WC Mbar
5 12.5 10 25
Many local codes exist and it is the responsibility of the
owner and installer to comply with those codes.
10"
[254mm] 3/4" MALE GAS NPT
2-1/2"
[63mm]
110V, 0.25 AMP
ELECTRICAL
CORD & PLUG
30-1/4"
[768mm]
13-1/2"
[343mm]
1-1/4"
[32mm]
FLUE
5"
[127mm]
ELECTRIC
6-1/2"
[165mm]
GAS
WIDTH
16-3/4"
[425mm]
4"
[102mm]
Garland/U.S. Range products are not approved
or authorized for home or residential use, but
are intended for commercial applications only.
Garland/U.S. Range will not provide service, war-
ranty, maintenance or support of any kind other
than in commercial applications.
