CuisineSeriesHeavyDuty
Griddle Top Range
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
Cuisine Series Heavy Duty Griddle Top Range
Models:
C836-1 C0836-1 C0836-1M
C836-1-1 C0836-1-1 C0836-1-1M
Specifications:
U.S. Range Cuisine 36" (914mm) wide Heavy Duty Range Series.
Model ________ with total BTU/hr rating of ________when
used with natural/propane gas. Stainless steel front and sides.
6" (152mm) legs with adjustable feet.
Ovens - One piece oven door. Stainless steel oven interior with
a heavy- duty, “keep-cool” door handle. Standard oven comes
with a thermostat with a temperature range from 150° (low) to
500°F (66°-260°C). One chrome plated oven rack for standard
ovens and three for convection ovens.
Griddle Tops - 1” (25mm) thick steel plate griddle with 3"
(76mm) wide grease trough. Burners rated 30,000 BTU/hr each.
One burner per 12” (305mm) section.
Standard Features:
• Griddletopwith1"(25mm)thick
steel plate.
• Full-rangevalvecontrol(-1)
• Griddlecontrol,withembedded
thermostat sensor bulb
Low to 500F (260C) (-1-1)
• Stainlessfrontandsides
• Stainlesssteelfrontrailw/position
adjustable bar
• 11/4"NPTfrontgasmanifold
• Canbeconnectedindividuallyorina
battery
• 6"(152mm)highstainlesssteelstub
back
• 6"(152mm)chromesteeladj.legs
• Stainlesssteeloveninteriorw/
removable porcelain bottom
• 40,000BTUburner
• Chrome plated rack with four posi-
tions, 1 per oven
• Fullyinsulatedoveninterior
• 100%safetyovenpilot
• Oventhermostatcontrol-150°-500°F
(66°-260°C)
Optional Features:
Grooved griddle - (12"W sections)
Range base convection oven (add RC)
 c/wNema5-15Pcord&plug,1/3Hp
motor, 120V 60 Hz 0.6amps.
 Porcelainoveninteriorinlieuof
stainlesssteelinteriorNC
Single or double deck high shelf or
back riser
Modular unit with legs and shelf (add
"M")
Modular unit w/o legs on Refrig. Base
(add"PC")
Stainless steel intermediate shelf for
cabinet base
Stainless steel door(s) for cabinet
base units
Stainless steel back
Continuous plate shelf, 48-72" for
battery installations
Gas shut-off valves - 3/4", 1", 1 1/4"
NPT(Specify)
Gasregulator:3/4"-11/4"NPT(Specify)
Gas flex hose w/ quick disconnect
3/4", 1", 1 1/4" (Specify)
Stainless steel legs (set of four)
Flanged feet set of four
Set of (4) polyurethane non marking
swivel casters w/front brakes.
Extra oven rack
 RearGasConnection:3/4"NPT(max
250,000 BTU’s)
Stainless steel burner box top
interior
Model C836-1
Range with 36" GriddleValve
or Thermostat Controlled
NOTE:Rangessuppledwithcastersmustbeinstalledwithan
approved restraining device.
Note:Range-basedconvectionovenmodels
can be located in the middle of a battery,
banked back-to-back with other equipment,
and can be positioned against a wall

Garland Commercial Ranges Ltd.
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
General Inquires 1-905-624-0260
USA Sales, Parts and Service 1-800-424-2411
Canadian Sales 1-888-442-7526
Canada or USA Parts/Service 1-800-427-6668
10"
(254mm)
4-1/2"
(114mm)
7-1/8"
(180mm)
8-5/8"
(219mm)
11-1/8"
(282mm)
22-1/4"
(565mm)
27-1/2"
(698mm)
30"
(762mm)
6" (152mm)
36"
(914mm)
34-5/16"
(871mm)
16"
(406mm)
39-3/8"
(1000mm)
RAIL
OPEN
37-7/8"
(962mm)
RAIL
CLOSED
34-11/16"
(830mm)
34-3/16"
(868mm) RC OVEN
24-1/4"
(616mm)
REAR GAS
CONNECTION
FOR -1 ONLY
54-7/16"
(1382mm)
CCHS
HI-SHELF
65-7/8"
(1662mm)
CCDHS
HI-SHELF
36-1/8"
(917mm)
CSTUB
BACKGUARD
Model # Description Total BTU
(NAT. Gas)
Shipping
Cu Ft Lb/Kg
C836-1 36" Manual Valve Control Griddle Top - w/Oven 130,000 50 706/320
C0836-1 36" Manual Valve Control Griddle Top - w/Storage 90,000 50 527/239
C0836-1M 36" Manual Valve Control Griddle Top - Modular Top 90,000 20 405/184
C836-1-1 36" Thermostatic Control Griddle Top - w/Oven 130,000 50 706/320
C0836-1-1 36" Thermostatic Control Griddle Top - w/Storage 90,000 50 527/239
C0836-1-1M 36" Thermostatic Control Griddle Top- Modular Top 90,000 20 405/184
Interior Dimensions: In (mm)
Product Height Width Depth
Standard Oven 13-1/2(323) 26-/1/4 (667) 29 (737)
Convection 13-1/2(323) 26-/1/4 (667) 25 (635)
Cabinet Base 20 -1/2 (521) 32-1/4 (819) 31 (787)
Individual Burner Ratings (BTU/hr)
Burner NATURAL PROPANE
Griddle 30,000 30,000
Standard Oven 40,000 35,000
Convection Oven 37,000 35,000
Cuisine Series Heavy Duty Griddle Top Range
2-/12"
[64mm]
RANGE
3" MIN
[75mm]
5" MAX
[133mm]
Vermin
Proof
DAIS Mounting
6-31/32" [177mm]
9-15/32" [241mm]
MODULAR TOP
Combustible Wall Clearance
Sides Back
6" (152mm) 6" (152mm)
Gas Pressure NAT. PRO.
Min. Supply 7" WC 11" WC
Operating 6" WC 10" WC
GasManifold1-1/4"NPT
Form# C836-1 (03/17/14)
