uAvionix SkyEcho Installation and operating instructions

UAV-1006630-00
ECCN 7A994 Page 1 | 10
REV A
United Kingdom Addendum to
SkyEcho Installation and Pilot’s
Guide

UAV-1006630-00
ECCN 7A994 Page 2 | 10
REV A
© 2021 uAvionix Corporation. All rights reserved.
uAvionix Corporation
300 Pine Needle Lane
Bigfork, MT 59911
http://www.uavionix.com
https://uavionix.com/support/
Except as expressly provided herein, no part of this guide may be
reproduced, transmitted, disseminated, downloaded or stored in any
storage medium, for any purpose without the express written permission of
uAvionix. uAvionix grants permissions to download a single copy of this
guide onto an electronic storage medium to be viewed for personal use,
provided that the complete text of this copyright notice is retained.
Unauthorized commercial distribution of this manual or any revision hereto
is strictly prohibited.
uAvionix®is a registered trademark of uAvionix Corporation, and may not
be used without express permission of uAvionix.

UAV-1006630-00
ECCN 7A994 Page 3 | 10
REV A
1 Revision History
Revision
Date
Comments
A
5/1/2022
Initial release migrating contents from
Revision L of SkyEcho Installation and Pilot’s
Guide

UAV-1006630-00
ECCN 7A994 Page 4 | 10
REV A
2 Warnings / Disclaimers
The following required statement from the Federal Communications
Commission (FCC) applies to United States based entities with the
exception of direct sales to the U.S. Government and units directly
exported by uAvionix.
This device has not been authorized as required by the rules of the Federal
Communications Commission. This device is not, and may not be offered
for sale or lease, or sold or leased, until authorization is obtained.
All device operational procedures must be learned on the ground.
Received traffic information is to be used as an aid to situational awareness
and is merely supplemental and advisory in nature.
uAvionix is not liable for damages arising from the use or misuse of this
product.
This equipment is classified by the United States Department of
Commerce's Bureau of Industry and Security (BIS) as Export Control
Classification Number (ECCN) 7A994.
These items are controlled by the U.S. Government and authorized for
export only to the country of ultimate destination for use by the ultimate
consignee or end-user(s) herein identified. They may not be resold,
transferred, or otherwise disposed of, to any other country or to any person
other than the authorized ultimate consignee or end-user(s), either in their
original form or after being incorporated into other items, without first
obtaining approval from the U.S. government or as otherwise authorized by
U.S. law and regulations.

UAV-1006630-00
ECCN 7A994 Page 5 | 10
REV A
3 Limited Warranty
uAvionix SkyEcho products are warranted to be free from defects in
material and workmanship for one year from purchase. For the duration of
the warranty period, uAvionix, at its sole option, will repair or replace any
product which fails in normal use. Such repairs or replacement will be
made at no charge to the customer for parts or labor, provided that the
customer shall be responsible for any transportation cost.
This warranty does not apply to cosmetic damage, consumable parts,
damage caused by accident, dropping, abuse, misuse, water, fire or flood,
damage caused by unauthorized servicing, or product that has been
modified or altered.
IN NO EVENT SHALL UAVIONIX BE LIABLE FOR ANY INCIDENTAL,
SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES, WHETHER
RESULTING FROM THE USE, MISUSE OR INABILITY TO USE THE
PRODUCT OR FROM DEFECTS IN THE PRODUCT. SOME STATES DO
NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
Warranty Service
Warranty repair service shall be provided directly by uAvionix.

UAV-1006630-00
ECCN 7A994 Page 6 | 10
REV A
4 Contents
1Revision History...................................................................................3
2Warnings / Disclaimers ........................................................................4
3Limited Warranty..................................................................................5
4Contents ..............................................................................................6
5International Use Limitations................................................................7
6United Kingdom Regulation .................................................................7
6.1CAA CAP 1391 Declaration ..........................................................7
6.2 Mode-S or ATCRBS Limitations....................................................8
6.3 Declaration of Conformity (DoC) ...................................................8
6.4 Country Specific Configuration Items ............................................9
6.4.1 Transmit Control......................................................................9
6.4.2 Receiver Mode ........................................................................9
6.4.3 Aircraft Address Programming (ICAO Address).......................9
6.4.4 Call Sign................................................................................10
6.4.5 Emitter Category ...................................................................10
7Contact uAvionix................................................................................10

UAV-1006630-00
ECCN 7A994 Page 7 | 10
REV A
5 International Use Limitations
At the time of publishing of this revision, portable ADS-B OUT transmitters
are not permitted for global use (including the United States). Operating
SkyEcho outside of approved airspace, the transmit function must be
disabled. SkyEcho can be used as a receiver in all locations.
6 United Kingdom Regulation
EC devices are intended for voluntary carriage on registered and non-
registered UK Annex II aircraft, non-complex EASA aircraft of <5700kg
MTOM and for gliders and balloons (including those covered under ELA 1
and ELA 2) within uncontrolled UK airspace. EC Devices do not replace the
need for a transponder when required by airspace/flight rules. Aeronautical
Information Circular (AIC) Y 141/2019 allows for the use of EC devices
simultaneously with ATCRBS or Mode S transponders which are not
Extended Squitter (ES) or ADS-B OUT enabled. If your aircraft is ADS-B
OUT enabled, you must disable the transmit function of SkyEcho from the
configuration settings.
6.1 CAA CAP 1391 Declaration
An EC device that operates using ADS-B at 1090MHz must have a
Declaration of Capability and Conformance (DoCC) from the manufacturer
before you can legally use it on board an aircraft. The pilot in command of
the aircraft is responsible for ensuring that the EC device has a valid
declaration. Please refer to the CAA EC Web page for more information:
https://www.caa.co.uk/General-aviation/Aircraft-ownership-and-maintenance/Electronic-
Conspicuity-devices/
Reference number
Issue number
Manufacturer
Type number
Category
UK.CAA.DoCC.000007
Issue 0
uAvionix Inc
SkyEcho 2
Intermediate

UAV-1006630-00
ECCN 7A994 Page 8 | 10
REV A
6.2 Mode-S or ATCRBS Limitations
EC Devices do not replace the need for a transponder when required by
airspace/flight rules. Aeronautical Information Circular (AIC) Y 141/2019
allows for the use of EC devices simultaneously with ATCRBS or Mode S
transponders which are not Extended Squitter (ES) or ADS-B OUT
enabled. If your aircraft is ADS-B OUT enabled, you must disable the
transmit function of SkyEcho from the configuration settings. Receive
functionality may still be used. Deactivation of the transmitter is
accomplished by removing device power or disabling the transmit capability
via the configuration settings. These regulations are subject to change.
Please be informed of the most current regulations at:
https://www.caa.co.uk/General-aviation/Aircraft-ownership-and-maintenance/Electronic-
Conspicuity-devices/
6.3 Declaration of Conformity (DoC)
uAvionix Corporation declares that that the SkyEcho 2 ADS-B Transceiver
conforms with with the pertaining EU harmonization legislation and, since
31 January 2020, appropriate UK equivalents where applicable. Reference
the following standards which are applied:
•EN 62368-1:2014
•EN 62311:2008
•EN 61000-4-2:2009
•EN 61000-4-3:2006/A1/A2
•EN 303 413 V1.1.1
•Final Draft EN 301 489-1 V2.2.2 & EN 301 489-19 V2.1.1
•EN 300 328 V2.1.1 & EN 301 489-17 V3.2.4
The Notified Body Telification B.V., with Notified Body number 0560
performed: applicable Modules B+C
Where applicable:
The issued EU-type examination certificate: 192140399/AA/01

UAV-1006630-00
ECCN 7A994 Page 9 | 10
REV A
Description of accessories and components, which allow the radio
equipment to operate as intended and covered by the DoC: SkyEcho 2 to
be used in conjunction with tablet running EFB APP like SkyDemon,
EasyVFR, Foreflight Mobile, and others.
6.4 Country Specific Configuration Items
The following configuration items augment the configuration instructions
found in the SkyEcho Installation and Pilot’s Guide with UK specific
information.
6.4.1 Transmit Control
Transmission must be deactivated when used on an aircraft with an air
traffic control radar beacon system (ATCRBS) Mode-S transponder which
has ADS-B OUT enabled.
6.4.2 Receiver Mode
The SkyEcho contains dual receivers. The primary receiver is permanently
configured for 1090MHz ADS-B. The secondary receiver can be
configured for either 978MHz UAT ADS-B, or 868.4MHz FLARM®
reception (European frequency only). Only one option can be selected.
When selecting UAT, SkyEcho will be able to receive 978MHz UAT ADS-B
weather and traffic information if available.
When selecting FLARM, encrypted FLARM data is received and
transmitted to the EFB application for processing. Specific FLARM
functionality is dependent upon the EFB functionality implemented.
6.4.3 Aircraft Address Programming (ICAO Address)
The ICAO address is a 24-bit number issued to the aircraft by the
registration authority of the aircraft. These addresses are usually written as
a 6-digit hexadecimal number, although you may also encounter one

UAV-1006630-00
ECCN 7A994 Page 10 | 10
REV A
written as an 8-digit octal number. The SkyEcho understands the
hexadecimal format, so you must first convert an octal number to
hexadecimal before entering. Sometimes this value is referred to as Mode
S code. It is critical that the correct address is used. Incorrect addresses
can disturb the service to other airspace users and may have regulatory
compliance consequences. In the UK to find the ICAO address of the
aircraft you will be flying go to https://siteapps.caa.co.uk/g-info/
Refer to UK CAA guidance for using 24-bit addresses with EC devices at
the following URL:
https://www.caa.co.uk/General-aviation/Aircraft-ownership-and-
maintenance/Electronic-Conspicuity-devices/
6.4.4 Call Sign
This is a maximum 8 character code that corresponds to the tail number of
the aircraft. (0-9, A-Z). The value should be entered without dashes: G-
ABCD should be entered as GABCD.
6.4.5 Emitter Category
To assist ATC tracking of aircraft, an aircraft category is transmitted. Select
the aircraft category that most closely matches the aircraft.
Note EC devices are not approved for all emitter categories. EC devices
are intended for voluntary carriage on registered and non-registered UK
Annex II aircraft, non-complex EASA aircraft of <5700kg MTOM, Permit
aircraft, and for gliders and balloons (including those covered under ELA 1
and ELA 2) within uncontrolled UK airspace.
7 Contact uAvionix
For additional questions or support please visit http://uavionix.com/support
