UBF BonePods-001 Manual
Set up your UBF BonePods-001
1. Charge
⚫Earphone
When Earphone is charging in the charge box, lights are long-red. When fully
charge, lights turn out.
⚫Charge case
Charge the UBF BonePods-001 with the included TYPE C charging cable.
Charge case owns two kind of lights. When lights with charging are flash-red,
and fully charging lights are long-red.
When charge case is on discharge, high potential (>3.2V), green light is on; medium
potential (3.2V-2.8V) green light flashes; low potential (< 2.8V) green light is dark.
(Refers to the case where the headset is in the charging case)
2. Pair
Take out the earphone from the charging case and the LED indicator will flash green
and green repeatedly while in discovery. Red and green lights in both ears indicates
that it has not been paired.
(Important Hint: Turning on the charging box switch before opening the charging box
is a prerequisite for the earphone to automatically turn on)
3.Connect
Enable the Bluetooth settings on your device and select “UBF BonePods-001”. The
LED indicator will turn green once connected.
Both the left and right earphones can be connected separately and used with other
Bluetooth devices. The earphones are put into the charging case to enter the
charging mode, and the earphones are automatically turned off. If Bluetooth is not
connected within 3 minutes, the headset will automatically shut down.
Earphone touch function description
Function
Operating
Play/pause music /Answer/end call
Click once left or right earphone
Volume Down
Double-click left earphone
Volume Up
Double-click right earphone
Next
Three-click right earphone
Previous
Three-click left earphone
Call Siri
Press and hold both buttons for 3
seconds Left or Right earphone
Turn on / Turn off
Press and hold both buttons for 5
seconds Left or Right earphone
Remove old Bluetooth connections
Shutdown Long press for 10 seconds
Please pay attention: press one time within 500ms, press again will be regard as
press twice. Press one time over 800ms, will be regard as long-press.
LED Indicator lights
Solid green-Charge case
Charging complete
Flashes green-Charge case
Charging
Discharge-Charge case
High potential (>3.2V), green light is on;
medium potential (3.2V-2.8V) green
light flashes; low potential (< 2.8V)
green light is dark.
Solid green-Earphone
Charging
Earphone’s lights off
Earphone with fully charge
Binaural green and green flashes
alternately
Earphone match mode
Binaural green flashes
Earphone matching successfully
Binaural green-green flashes
Earphone did not match yet
Earphone Specification
Part number UBF BonePods -001
Speaker Bone Conduction Speaker
Frequency response 20Hz~20KHz
Wireless range 10 meters
Bluetooth Version 5.0 Channel Stereo
Support Bluetooth dual modes
Single and binaural bilateral stereo
UCompatible profiles
A2DP, HFP 1.7, HSP 1.2, A2DP 1.3,AVRCP 1.6, SPP 1.2 and PBAP 1.0
Earphone battery 70mAH
Charge case battery 500mAH
Earphone fully-charged Duration
About 90 mins
Charge case fully-charged Duration
About 120 mins
Continuous play
Music Play duration about 4 hours, Call duration about 3.5 hours and Standby
duration about 5 days. Earphone in charge case could be charged about 3-4 times
Microphone Sensitivity -40dB ± 2dB
Waterproof Level IP55
Earphone Weight 16g
Charging case Weight 48g
Storage and Preservation
⚫The headphones are sweat resistant, but are NOT waterproof. DO NOT
submerge the headphones in water
⚫After storing the headphones for an extended period, charge the unit before
using it again.
⚫Warning statement: To prevent possible hearing damage, do not listen at high
volume levels for long periods.
⚫Do not charge your headphones immediately after exercising, as any sweat or
moisture inside the charging port could lead to a circuit burning.
Charge box charging voltage/current 5V/1A
Accessories List:
⚫Earphone case: 1 set
⚫Big ear hook: 1 set
⚫Small ear hook: 1 set
⚫Earmuffs: 1 set
⚫Ear cover：1set
⚫Type C-Charging cable: 1pcs
FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould
voidtheuser’sauthoritytooperatetheequipment.Thisequipmenthasbeentestedandfoundto
complywiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.These
limitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential
installation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryto
correcttheinterferencebyoneormoreofthefollowingmeasures:
‐‐ Reorientorrelocatethereceivingantenna.
‐‐ Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowing
twoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and
(2) this device must accept any interference received, including interference that may
cause undesiredoperation.
The device has been evaluated to meet general RF exposure requirement.
