ubiolabs WSP1001 User manual

Wireless Speaker & Charging Hub
Thank You For Purchasing Our Wireless Speaker & Charging Hub
Please Read Carefully Before Operating This Equipment
Please keep it in a safe place for future reference
Model: WSP1001

2
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous voltage
within the product`s enclosure that may be
of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
FCC NOTICE:
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC
rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not Installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
●Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
●Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
●Consult the dealer or an experienced radio/
TV technician for help.
FCC WARNING:
To assure continued compliance, follow the
attached installation instructions and use only
shielded cables when connecting to other
devices. Modifications not authorized by the
manufacturer may void user`s authority to
operate this device.
Before using the unit, be sure to read all
operating instructions carefully. Please note
that these are general precautions and may
not pertain to your unit.
1 ) Read these instructions
All the safety and operating instructions should
be read before the product is operated.
2 ) Keep these instructions
The safety and operating instructions should be
retained for future reference.
3 ) Heed all warnings
All warnings on the product and in the operating
instructions should be adhered to.
4 ) Follow all instructions
All operating and use instructions should be
followed.
5 ) Do not use this apparatus near water
Do not use this product near water and moisture,
for example: near a bathtub, washbowl, kitchen
sink or laundry tub; in a wet basement or near a
swimming pool.
6 ) Clean only with dry cloth
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a dry cloth for cleaning.

3
IMPORTANT SAFETY INSTRUCTIONS
7 ) Do not block any ventilation openings.
Install in accordance with the manufacturer's
instructions.
Slots and openings in the cabinet and in the back
or bottom are provided for ventilation, to ensure
reliable operation of the product and to protect it
from overheating. These openings must not be
blocked or covered. The openings should never
be blocked by placing the product on a bed,
sofa, rug or other similar surface. This product
should never be placed near or over a radiator or
heat source. This product should not be placed
in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer's instructions have been adhered
to.
8 ) Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9)Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the
third prong are provided for your safety.
If the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10 ) Protect the power cord from being walked
on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11 ) Only use attachments/accessories specified
by the manufacture .
12 ) Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
An appliance and cart
combination should be
moved with care.
Quick stop, excessive force and uneven surfaces
may cause the appliance and cart combination to
overturn.
13 ) Unplug this apparatus during lightning
storms or when unused for long periods of
time.
To protect your product from a lightning storm,
or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system.
This will prevent damage to the product due to
lightning and power-line surges.
14 ) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture does not operate normally, or
has been dropped.
15 ) Power source
This product should be operated only from the
type of power source indicated on the marking
label.
If you are not sure of the type of power supply
to your home, consult your appliance dealer or
local power company. For products intended
to operate from battery power, or other source,
refer to the operation instructions.
16 ) Power lines
An outside antenna system should not be
located in the vicinity of overhead power lines or
other electric light or power circuits, or where it
can fall into such power lines or circuits.
When installing an outside antenna system,
extreme care should be taken to keep from
touching such power lines or circuits as contact
with them might be fatal.
17 ) Overloading
Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric
shock.
18 ) Object and liquid entry
Never push objects of any kind into the product
through openings as they may touch dangerous
voltage points or short out parts that could result
in fire or electric shock. Never spill or spray any
type of liquid on the product.
Portable Cart Warning

4
IMPORTANT SAFETY INSTRUCTIONS
19 ) Outdoor antenna grounding
If an outside antenna is connected to the product,
be sure the antenna system is grounded so as to
provide some protection against voltage surges
and built up static charges. Section 810 of the
National Electric Code ANSI/NFPA 70 provides
information with respect to proper to grounding of
the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge product,
size of grounding conductors, location of antenna
discharge product, connection to grounding
electrodes and requirements for the grounding
electrodes.
20 ) Service
Do not attempt to service this product yourself
as opening or removing covers may expose you
to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
21 ) Replacement parts
When replacement parts are required, be sure
the service technician uses replacement parts
specified by the manufacturer or those that have
the same characteristics as the original parts.
Unauthorized substitutions may result in fire or
electric shock or other hazards.
22 ) Safety check
Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operational condition.
23 ) Wall or ceiling mounting
The product should be mounted to a wall
or ceiling only as recommended by the
manufacturer.
24 ) Damage requiring service
Unplug this product from the wall outlet and refer
service to qualified service personnel under the
following conditions.
a ) When the power-supply cord or plug is
damaged.
b ) If liquid has been spilled or objects have fallen
into the product.
c ) If the product has been exposed to rain or
water.
d ) If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions, as an adjustment of
other controls may result in damage and will
and require extensive work by a qualified
technician to restore in the product to its
normal operation.
e ) If the product has been dropped or the
cabinet has been damaged.
f ) When the product exhibits a distinct change
in performance-this indicates a need for
service.
25 ) Note to CATV system installer
This reminder is provided to call the CATV
system installer's attention to Article 820-40
of the NEC that provides guidelines for proper
grounding and, in particular, specifies that the
cable ground shall be connected to the grounding
system of the building, as close to the point of
cable entry as practical.
NOTE: Refer all servicing to qualified service
personnel servicing is required when the unit
has been damaged in any way such as the
following: the power supply cord or plug has
been damaged, liquid has been spilled into unit,
the unit has been exposed to rain or moisture,
the unit has been dropped or the unit does not
operate normally.

5
LOCATION OF CONTROLS
Top side view:
123 4 5 678
1. Skip Previous Button
2. Play/Pause Button
Press and Hold to Reset to Factory settings
3. Skip Next Button
4. Volume Down Button
9. Speaker
10. Wireless Charging Surface
11. Wireless Charging Base
5. Volume Up Button
6. Source Switch Button
7. Wifi/Bluetooth Indicator
8. Power Indicator
99
10
11
Front side view:

6
LOCATION OF CONTROLS
POWER SOURCE
Back side view:
12 13 14
12. USB Connector Port 1
13. DC IN Jack
14. USB Connector Port 2
1. Connect the power adaptor to the wall outlet having AC 100-240V~; 50/60Hz.
2. Insert the small plug of the power adaptor to the DC IN Jack on the back of unit.
Note: To save energy, unplug the power adaptor from the wall outlet if you may not use the unit for an
extended period of time.

7
CONNECTING THE NETWORK
Attention:
~ Before connecting the wireless network, please make sure that your smart phone (not included) was
connected with a Wi-Fi network.
~ While connected to the power source, your Wireless Speaker & Charging Hub will access to the
network connecting mode directly with white Wi-Fi indicator flashes fast.
~ You can stream musics to your Wireless Speaker & Charging Hub after connected with Wi-Fi
network, choose the music and control playback on the your smart phone or on your speaker
device.
Connecting Wi-Fi with Google Home:
1. Click Google Home to enter the APP interface and tap "+" on the left top side to access "Add
and manage" interface.
2. Click "Set up device" then "Set up new devices" to access "Choose a home" interface.
3. Select a name from the home list or you can create a new one while choose "Create another
home".
4. Click "Next" to look for your device (e.g. Ubiolabs-WSP1001-2058).
5. Click "Next" to access "Connecting to Chromecast built-in speaker...", a test sound will be heard to
inform you that you're connected to the right Chromecast built-in speaker.
6. Click "Yes" to access "Help improve Chromecast built-in speaker" and then click "Yes, I'm in" to
select your region then click "Continue" to access "Where is this device?" interface.
7. Select a location and click "Next" to access "Connect to Wi-Fi" interface.
8. Choose a Wi-Fi network, click "Next" to enter the Wi-Fi password and confirm by clicking
"Connect". A sound will be heard to confirm that the network has been connected completly and
indicator on top of your device will light with solid white.
9. Click "Continue" to link your chromecast built-in speaker and click "Next" to complete almost
setup.
10. Choose a sample clip to learn how to cast, then tap the Cast button and select your speaker, a
sound will be heard while playing through your speaker.
11. Click "Finish Tutorial" and find something to listen to.
Connecting Wi-Fi with Home APP:
1. Click "Home" APP and tap "Add Accessory" to access add accessory interface.
2. Click "I Don't Have a Code or Cannot Scan" to look for nearby accessories.
3. When your device has been found, tap it simply and click "Allow" to comfirm the connecting.
4. While the device has been connected correctly, "Accessory added" shows on Home APP and
your new accessory is ready to use.
5. Click "Done" on the right top of interface to complete with default device name, or you can create
a new name for it.
Note:
● While connecting to Wi-Fi network, make sure that your smart phone has already downloaded
the Google Home or Home APP.
● If you want to connect with another Wi-Fi network, press and hold Play/Pause button until
the Wi-Fi indicator flashed fast, then following above steps to connect with a new Wi-Fi network.

8
BLUETOOTH OPERATION
CHARGING
CLEANING
After initial pairing, your Wireless Speaker & Charging Hub will stay paired unless you unpaired it
manually, or erased due to a reset device. If this occurs or you find the unit is unable to connect,
please repeat below steps:
1. Press and hold the Source Switch button until the bluetooth indicator on top side flashes fast.
2. Activate the bluetooth function on your bluetooth device and choose "Ubio-WSP1001", after a
while, the pairing will be connected automatically.
The indicator on top of your device will light with solid blue.
4. During playing:
~ Press the Play/Pause button to pause, press it again to resume the playing.
~ Press Skip Next or Previous button to select the desired track.
~ Press the VOL- or VOL+ button to adjust the volume level.
Note: To reconnect to a different device, deactivate the bluetooth on unwanted unit, then access the
bluetooth settings and activate the bluetooth function on the new device which you wish to pair with
your Wireless Speaker & Charging Hub.
Wireless Charging Mode:
The wireless charging surface allows the user to place the most recent generations of iPhone
and Galaxy smartphone and other compatible smart phones on the surface in portrait mode and
immediately begin wireless charging. This is a QI compatible, EPP design with PPDE to allow iPhone
and Samsung fast-charging.
Note: While charging in wireless charging mode, the indicator on top of device lights with solid white,
and the charging symbol on your smart phone shows to inform you that your smart phone was placed
correctly on Wireless Charging Surface .
Charging with USB Cables:
1. Insert one end of the USB cable to the USB connect port on back side of the device.
2. Plug the other end to the DC IN Jack on your smart phone.
Note: There have two USB outputs on back side of device can be used to charge almost any
additional USB devices simultaneously while in wirless charging.
1. To prevent fire or shock hazard, disconnect your unit from the AC wall outlet when cleaning.
2. The finish on your unit may be cleaned with a dust cloth and cared for as other furniture. Use
caution when cleaning and wiping the plastic parts.
3. Mild soap and a damp cloth may be used.

9
TROUBLESHOOTING
SPECIFICATIONS
Input: ....................................................................................................................................18V/4A 72W
Output: ......................................................................................................................................18V/3.5A
USB output: .....................................................................................................................5V 2.4A 12W*2
Speaker Power: .............................................................................................................................2*12W
WIFI Requirements: ......................................................................................................2.4G & 5G 1T1R
Bluetooth version: .........................................................................................................................BT 4.2
Bluetooth effective working range in open area....................................................................up to 32 feet
Accessories:
1 x User Manual
1 x AC Adaptor
SYMPTOM
No Power
No Sound or
Sound Weak
Sound Distortion
/Rattle
Bluetooth
Reception Failure
The adapter is not
connected
Volume level in
minimum position
Volume level too high
The external BT device is
too far from the unit
Bluetooth have not paired
The paired/connected
device is not in playback
mode
Increase the volume level by press
and release the + button on the top
of device repeatedly
Decrease the volume level by press
and release the - button on the top
of unit repeatedly
Reduce the volume level of the
paired/connected device
Put the external bluetooth device
close to the unit
Pair the unit with the bluetooth
device as described previous
Play music/movie in the paired/
connected device as usual and
make sure the volume level of it is in
high level
Connect the adapter to the unit and
wall outlet
POSSIBLE CAUSE POSSIBLE SOLUTION

FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate
the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
To comply with RF exposure requirements, a minimum separation distance Of 20cm must be maintained between the user’s body and the
antenna.

IC STATEMENT
This device complies with Industry Canada licence-exempt RSS standard(s)
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. End user must follow the specific operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
To comply with RF exposure requirements, a minimum separation distance Of 20cm must be maintained between the user’s body and the antenna.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence.
Ce dispositif est conforme aux normes autoriser-exemptes du Canada RSS d'industrie
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.Cet équipement
est conforme avec l'exposition aux radiations IC définies pour un environnement
non contrôlé. L'utilisateur final doit respecter les instructions de fonctionnement spécifiques pour satisfaire la conformité aux
expositions RF. Cet émetteur ne doit pas être co-localisées
ou opérant en conjonction avec une autre antenne ou transmetteur.Pour se conformer
aux exigences d'exposition aux radiofréquences, une distance minimale de 20cm doit être
maintenue entre le corps de l'utilisateur et le combiné, y compris l'antenne. Les pinces de
ceinture, les étuis et autres accessoires similaires utilisés par cet appareil ne doivent pas
contenir de composants métalliques. Les accessoires portatifs qui ne répondent pas à ces
exigences peuvent ne pas se conformer aux exigences d'exposition RF et doit être évitée.
Utilisez uniquement l'antenne fournie ou une antenne approuvée
