Ubiquiti UVC-G3-BULLET User manual

Camera Cable Gland Screw Anchors (Qty. 2)
Self-Tapping Screws (Qty. 2) Pole Mount Bracket Machine Screws (Qty. 2)
Package Contents
Installation Requirements
Shielded Category 5 (or above) cabling should be used for all wired Ethernet
connections and should be grounded through the AC ground of the PoE.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

We recommend that you protect your networks from harmful outdoor environments
and destructive ESD events with industrial-grade, shielded Ethernet cable from
Ubiquiti. For more details, visit ui.com/toughcable
Hardware Overview
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Ethernet Port
Reset Button
10/100 RJ45 port connects to an 802.3af PoE switch for PoE power and data.
To reset to factory defaults, press and hold the Reset button for more than 10
seconds while the camera is powered on.
Hardware Installation
Wall/Ceiling Mount
1.
2.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

3.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

4.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

5.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

OR
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

6.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

7.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

8.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

9.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Pole Mount
1.
2.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

3.
4.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

5.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Connecting Power
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

UniFi Protect App
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

Launch the UniFi Protect app and follow the on-screen instructions to complete setup.
UniFi Video App
Note: For UniFi Video 3 deployments, there is a UniFi Video mobile app
available for download in the App Store® for iOS devices and Google
Play™ store for Android-based devices.
For details on using the UniFi Video software, refer to the User Guide at:
ui.com/download/unifi‑video
Adjusting the Camera View
1.
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

2.
Specifications
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

UVC-G3-BULLET
Dimensions Ø 75 x 140 mm
(Ø 2.95 x 5.51")
Weight 300 g
(10.58 oz)
Enclosure Injection-Molded Polycarbonate and
Die-Cast Aluminum
Networking Interface (1) 10/100 Ethernet Port
Sensor 1/3" 4-Megapixel HDR Sensor
Lens EFL 3.6 mm, f/1.8
Viewing Angle
Before Lens Correction 85° (H), 44.8° (V), 98.1° (D)
After Lens Correction 72° (H), 42.9° (V), 80.4° (D)
Night Mode IR LEDs with Mechanical IR Cut Filter
Video Compression H.264
Resolution 1080p Full HD (1920 x 1080)
Maximum Frame Rate 30 FPS
Image Settings Brightness, Contrast, Sharpness, Saturation, Noise
Reduction, 50/60 Hz
Processor Ambarella S2L
Memory 512 MB DDR3L
Management Interface UniFi Protect, UniFi Video
Microphone Yes
Max. Power Consumption 4W
Create PDF in your applications with the Pdfcrowd HTML to PDF API PDFCROWD

UVC-G3-BULLET
Power Method 802.3af or 24V Passive PoE
Power Supply 802.3af PoE Switch
Buttons Factory Reset Button
Mounting Wall/Ceiling (Kits Included)
Pole (Kit Not Included)
Operating Temperature -20 to 50° C
(-4 to 122° F)
Operating Humidity 20 to 90% Noncondensing
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: Hot surface. Do not touch.
WARNING: Do not use this product in location that can be submerged by water.
WARNING: Avoid using this product during an electrical storm. There may be a remote
risk of electric shock from lightning.
Electrical Safety Information
