UBTECH RAD001 User manual

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
Sensor-controlled
safety sign
USER MANUAL

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
CONTENT
CONTENT..........................................................................................................................................2
Introduction........................................................................................................................................ 3
Part 1 Product Overview................................................................................................................. 4
1.1 Package List....................................................................................................................... 4
1.2 Product View.......................................................................................................................4
1.3 System Framework........................................................................................................... 5
Part 2 Safety Information................................................................................................................ 5
2.1 Device Security.................................................................................................................. 6
2.1.1 General.................................................................................................................... 6
2.1.2 Operation Instruction............................................................................................. 6
Part 3 Device System Operation................................................................................................... 7
Part 4 Sensor-controlled safety sign Services.............................................................................7
4.1 Caution................................................................................................................................ 8
4.2 Switch.................................................................................................................................. 8
4.3 Intrusion detection and disinfection device state indicator......................................... 8
4.4 Sensor-controlled safety sign State Indicator............................................................... 9
4.5 Bluetooth pairing (Web).................................................................................................... 9
Part 5 Transporting, Clean and Storage.....................................................................................10
5.1 Transportation.................................................................................................................. 10
5.2 Maintenance..................................................................................................................... 10
Part 6 Reference.............................................................................................................................11
6.1 Device Specification........................................................................................................11
6.2 Replacement Parts.......................................................................................................... 11
6.3 FAQ/Troubleshooting...................................................................................................... 11
Part 7 Declaration of Conformity..................................................................................................12
7.1 FCC compliance statement............................................................................................12
7.2 FCC Radiation Exposure statement.............................................................................12

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
Introduction
◆Thank you for purchasing Sensor-controlled safety sign equipment from UBTECH
ROBOTICS CORP LTD. This user manual is only applicable to the operation of Sensor-
controlled safety sign.
◆In order to ensure safe use of Sensor-controlled safety sign and quickly grasp the
usage method, please read this manual carefully.
◆Children under 12 years old should use this product under the guidance of adults.
◆This manual is for user's reference and guidance only, and the description may
not be detailed enough. If you encounter problems that cannot be solved, please contact
our company for technical support.
◆This manual will be updated from time to time, and the latest user manual will add
the latest content and pictures without further notice.
◆The model approval code of this product is displayed in the form of "product
nameplate label". The nameplate label is affixed to the lower part of the back of the robot.
◆This product contains a wireless Bluetooth module. This module is an integrity
module and has FCC certification. The model approval code is FCC ID: *****-RAD001.

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
Part 1 Product Overview
1.1 Package List
•UVC Sensor-controlled safety sign (Door Sensor) *1
•User manual *1
NOTE:
•Sensor-controlled safety sign use AA battery *8
1.2 Product View
•Front：LED *2、Caution Slogan

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
•Back：Power On button、Mode button
•Side：Battery cover
1.3 System Framework
Part 2 Safety Information
Please read the following information carefully, the company will not be responsible
for direct or indirect losses caused by improper use of the product.
Note: To ensure safety, it is strongly recommended that users follow the following
safety regulations when operating the robot.
This manual does not guarantee to cover all possible situations.
The "ADIBOT" and "equipment" ("it", "its") referred to in this manual are Sensor-
controlled safety sign equipment, and "you" ("your") refers to the user.
Note:
Please guardians to ensure that children under 6 years old stay away from Sensor-
controlled safety sign!
Please keep pets away from Sensor-controlled safety sign!

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
2.1 Device Security
2.1.1 General
If you have no experience in operating Sensor-controlled safety sign, you need to be
especially careful. Because you may not be familiar with Sensor-controlled safety sign
operation at first.
Do not use robots to implement operations related to personal safety.
2.1.2 Operation Instruction
Danger
If there is no emergency, it is recommended not to touch it while ADIBOT is
performing its task.
Warning
Please ask professional technical personnel or personnel familiar with product to
operate Sensor-controlled safety sign.
Do not insert any foreign objects into the gaps in the device, otherwise it may cause
electric shock or short-circuit failure.
Please keep Sensor-controlled safety sign dry, and avoid contact with oil, steam,
water vapor, moisture, dust layer and other substances of the camera driven by the
device.
The normal working humidity range of Sensor-controlled safety sign is 10%-95%.
The normal working temperature range of Sensor-controlled safety sign is 0-40
degrees Celsius (32-104 degrees Fahrenheit).
Please keep Sensor-controlled safety sign away from open flames and heat sources,
and avoid direct sunlight, so as not to damage the sensor.
Do not cover its door sensor, otherwise it may affect the communication.
All maintenance work should be carried out under the guidance or supervision of
caution technicians.
Attention
When ADIBOT is working, please do not move the Sensor-controlled safety sign, so
as not to affect the correct indication of the working state of the Sensor-controlled safety
sign.

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
If Sensor-controlled safety sign works abnormally, especially when you detect
unusual sounds, smells or smoke, please take precautions and immediately turn off the
power, remove the battery, and contact the technical support center.
Part 3 Device System Operation
When the disinfection equipment is worked indoors, the UV light will cause harm to
the human body, so it is necessary to place the Sensor-controlled safety sign outside the
room to warn the personnel not to approach. At the same time, as an accessory product,
the Sensor-controlled safety sign needs to work with the disinfection equipment, which
can intelligently feedback the various states of the disinfection equipment. Use the
Sensor-controlled safety sign according to the following steps:
Step 1 Install 8*AA batteries
Step 2 Place the Sensor-controlled safety sign at the door of the room to be
disinfected, and turn on the Sensor-controlled safety sign switch
Step 3 Through the web software to match the Sensor-controlled safety sign with the
designated disinfected equipment
Step 4 After disinfection, close the Sensor-controlled safety sign
Part 4 Sensor-controlled safety sign
Services
Basic features：
No. Feature Description
1Caution
Sensor-controlled safety signs are used to
remind people not to enter the room to be
disinfected
2Switch
Power on Power on the Sensor-controlled safety sign
Detection
switch Turn on Intrusion Detection
Pairing switch Bluetooth pairing mode switch
3Disinfection
State Indicator State feedback Indicate the status of disinfection device paired with the Sensor-controlled safety sign,

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
for example safety, fault and son on
Intrusion
detection
If any intrusion is detected through the
movement and dumping of Sensor-controlled
safety signs, the equipment shall be informed
to stop disinfect in time
4
Sensor-
controlled safety
sign State
Indicator
Through the LED or buzzer to indicate the
status of the Sensor-controlled safety sign
itself, such as pairing, low power, etc
5Bluetooth pairing Bluetooth pairing feature on Web
4.1 Caution
•Alert people who want to enter the disinfection room with a striking Sensor-controlled
safety sign "caution, UV infection do not enter!"
•The size of the Sensor-controlled safety sign is "524 (L) * 322 (W) * 752 (H) mm",
which can prevent people from bypassing the Sensor-controlled safety sign and
entering the room to be disinfected; the Sensor-controlled safety sign is 2.2kg, and
its weight can avoid shaking itself
4.2 Switch
The Sensor-controlled safety sign has several switches, which are described as follows:
•Sensor-controlled safety sign switch (toggle switch on / off). The switch of the main
power supply of the Sensor-controlled safety sign. Power on after opening. At this
time, the Sensor-controlled safety sign only indicates the status of the disinfection
equipment that has been paired successfully
•Intrusion detection switch (tap switch mode)
Press and hold for 3 seconds, and the buzzer will sound three times to turn on
the intrusion detection. At this time, the Sensor-controlled safety sign has the
ability to send touch alarm
Long press for 3 seconds and the buzzer will sound to turn off the intrusion
detection
•Paired mode switch (tap switch mode). Press three times continuously (interval <
0.5s), the Sensor-controlled safety sign will enter the pairing state, and the
disinfection equipment will scan, select and match in the setting interface
4.3 Intrusion detection and disinfection device state
indicator
•Intrusion detection. When the Sensor-controlled safety sign is detected to be moved,

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
the disinfection equipment will be informed in time to stop disinfect. After the
disinfection equipment stops disinfect, the status of the equipment will be fed back to
the Sensor-controlled safety sign
•The disinfection equipment status includes the non safety state of normal operation
of the disinfection equipment, the safe state after the disinfection equipment is shut
down, the non safety state when the disinfection equipment fails, and the state of
disconnection from the disinfection equipment
Indicates the disinfection device status
State LED Buzzer
The disinfection equipment is in a
safe state
● ● ：Green LED long
and bright
/
Disinfection equipment in
disinfection state (unsafe)
●●：Blue LED long and
bright
/
Disinfection equipment failure
(unsafe)
●●：Red LED long and
bright
Periodic sound, once
every 5 seconds
Lost disinfection device
connection, try to restore
connection
● ● ：Orange LED long
and bright
Periodic sound, once
every 5 seconds
4.4 Sensor-controlled safety sign State Indicator
In the Bluetooth pairing process between the Sensor-controlled safety sign and the
disinfection device, the status of low power and access control board is indicated:
State LED Buzzer
Enter Bluetooth pairing
status
●●：blue quick flashing /
Pairing complete ● ● ：blue goes out and
returns to working state
/
Low battery Any color light, periodic slow
flashing (3S)
/
Turn on door sensor
detection
/ Three buzzers
Turn off door sensor
detection
/ Buzzer 1 sound
Sensor-controlled safety
sign is touched (under
non security state)
The indicator light remains
unchanged
Make a long sound until the
Sensor-controlled safety
sign stops moving
4.5 Bluetooth pairing (Web)
As the peripheral equipment of disinfection equipment, the Sensor-controlled safety
sign should be paired through Bluetooth. The [peripheral] tab of [system settings]
provides the pairing of Sensor-controlled safety sign.
•One disinfection device allows multiple Bluetooth Sensor-controlled safety signs
•The communication distance of the Sensor-controlled safety sign is not less than 20

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
meters, which can block a conventional room door (such as hotel or hospital room
door)
•Users can upgrade firmware via Bluetooth OTA
•Pairing steps of Sensor-controlled safety sign:
When it is not paired, it will prompt "there is no pairing Sensor-controlled safety
sign"
Find the Bluetooth device and list the devices that can be found after searching
for a period of time
Note: the Bluetooth MAC address is pasted on the body of the caution for user
identification. At the same time, the interface prompts the user that "the Sensor-controlled
safety sign should open the pairing mode".
Start pairing and select any Sensor-controlled safety sign. If it is successful, it
will prompt "the selected Sensor-controlled safety sign are paired successfully!"
Otherwise, it will prompt "matching of the selected Sensor-controlled safety sign
failed!"
If the pairing is successful, the information of the paired Sensor-controlled safety
sign will be displayed. At the same time, the paired disinfection devices
broadcast voice
Continue to add Sensor-controlled safety sign, up to 4 at present. Or you can
cancel the pairing with the Sensor-controlled safety sign
Part 5 Transporting, Clean and Storage
5.1 Transportation
If you need to transport ADIBOT, please put it in the box.
5.2 Maintenance
Warning:
Do not use abrasives, aerosols, alcohol containing liquids or other liquids to clean
the Sensor-controlled safety sign, because they may contain flammable substances or
may damage the plastic shell, cloth and printed characters on the cloth. Do not spray or
spray the Sensor-controlled safety sign with water or other liquids. Please keep the
Sensor-controlled safety sign dry.
Follow the steps below to ensure safety and avoid damaging the Sensor-controlled
safety sign:
1. Press the power button on the side of the main control box to close the caution
sign;
2. Open the back cover of the main control box and take out the battery to ensure
that the access plate is completely powered off;
3. Clean the outside of the Sensor-controlled safety sign with a soft damp cloth;
4. Wipe the outside of the Sensor-controlled safety sign thoroughly with a soft dry
cloth;
5. Check whether the Sensor-controlled safety sign is dry.
Note: take out the battery when the Sensor-controlled safety sign is not used for a

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
long time. It is found that there is no indication after the Sensor-controlled safety sign is
opened. Please make sure that the battery has power.
Part 6 Reference
6.1 Device Specification
Dimensions
Size 524(L) * 322(W) * 752(H) mm
Weight 2.2kg
Operating temperature 0℃~40℃
Operating humidity 10 to 85% relative humidity (indoor use only)
Storage temperature -40℃~60℃
Storage humidity ≤95% (non-condensation indoor only)
Device Body Material Stainless steel，PC+ABS
Device System
Main Processor Nordic nRF52833, 512KB Flash, 128K Ram
Wireless Module Bluetooth 5.0
Acoustics 1x 2W Buzzer
LED LED * 2
Button Mode Button * 1
Switch Power Switch * 1
Power Supply
Input Voltage 6V DC
Current 20mA
6.2 Replacement Parts
Description Part #
Warning label cloth
AA Battery *8
User Manual
6.3 FAQ/Troubleshooting
Question Solution
The Sensor-controlled
safety sign cannot be
-Check whether the switch key on the side of the
control box is loose, abnormal or open;

UBTECH Sensor-controlled safety sign USER MANUAL
UBTECH ROBOTICS CORP LTD
activated
-Check whether the battery socket in the control
box is loose, abnormal or insufficient;
-If the problem persists, please contact product
technical support center.
Sensor-controlled safety
sign connection failed
-The distance between entrance guard and
disinfection equipment is too far. You can try to shorten
the distance or add multiple Sensor-controlled safety
signs.
Part 7 Declaration of Conformity
7.1 FCC compliance statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the follo
wing two conditions: (1) this device may not cause harmful interference, and (2) this devi
ce must accept any interference received, including interference that may cause undesire
d operation.
Changes or modifications not expressly approved by the party responsible for compli
ance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B dig
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide re
asonable protection against harmful interference in a residential installation. This equipm
ent generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communicat
ions. However, there is no guarantee that interference will not occur in a particular installa
tion.
If this equipment does cause harmful interference to radio or television reception, wh
ich can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment into an outlet on a circuit different from that to which the rece
iver is connected
•Consult the dealer or an experienced radio/TV technician for help
7.2 FCC Radiation Exposure statement
This equipment complies with FCC radiation exposure limits set forth for an uncontro
lled environment. This equipment should be installed and operated with minimum distanc
e 20cm between the radiator and your body. This transmitter must not be co-
located or operating in conjunction with any other antenna or transmitter.
