UCONNECT INTERNATIONAL BLE RS-232 User manual

BLE RS-232 Reader user manual V2.1 2019.06.20
1
BLE RS-232 Reader
Model: S2B5232E
1. Package content:
BLE Beacon RS-232 Reader
White Box Dimension: 11 x 6 x 5 (cm)
Total Package Weight: 105 g
Package Contents:
BLE RS-232 adapter x 1
A4 User manual x 1
Mini USB Cable x 1
2 dBi dipole antenna
2. Profile:
2.1 Top view:
LED
Description
Blue
Flash when data received
Red
Solid when power on
DB9 (Female)
Mini USB (Power)
▲+ (5 VDC)
▼GND
Reset to Default
LED:
Link: Blue
PWR/Data: Red
Radio Frequency area:
Don’t cover any metal
material or painting.

BLE RS-232 Reader user manual V2.1 2019.06.20
2
2.2 DB9 connector: (Male)
Pin
Signal
DTE Direction
DCE Direction
Description
1
N/A
2
RxD
Output
Input
Transmitted data
3
TxD
Input
Output
Received data
4
N/A
5
GND
Ground
6
N/A
7
RTS
8
CTS
9
Vin
Power Input (5 VDC)
2.3 Rear Side:
2.4 Default: All pin is “0”, Baud rate 9,600 bps., 8 Data bits, None parity, 1 Stop bit.
DIP Switch
▲DCE
▼DTE
2: RX 3: TX
5: GND 9: Vin
DCE/DTE:
Swap TX & RX

BLE RS-232 Reader user manual V2.1 2019.06.20
3
2.5 Baud rate option: DIP No. 9 is set to “1” (On): The baud rate is 115,200 bps, 8 Data
bits, None parity, 1 Stop bit.
3. Packet Format:
3.1 Default: All DIP switch is “0”.
$<msg type>,<reader id>,<tag type>,<tag id>,<battery>,<button>,<G-sensor>,<sensor>,<RSSI>#
Example:
$1,00A05053849D,1,00A050172A2C,30,0,0,,-71#
$2,00A05053849D,0,58E72F0CEF88,0,0,0,0,-48#
$3,00A05053849D,0,772BB24ADC36,0,0,0,0,-48#
$4,00A05053849D,0,012AC345EB45,0,0,0,0,-49#
1.2 Raw BLE packet: The Bluetooth discovering broadcast will be filtered. All BLE
beacon will be reported. DIP No. 1 is set to “1” (On) and “0” else
Prefix: “$”
First column: RSSI value
Raw packet data is between “$” and “CR” ”LF”
Suffix: CR LF
EX:
$-78,0201061BFF5900AABC0100A050172A2C1E00000000000000000000000000BB
$-83,1EFF06000109200073C68487B4DFB227B7546E97078954811C4EB1E40DC1DF
1.3 Add the “>” at the end of Raw BLE packet: DIP No. 2 is set to “1” (On) and “0” else

BLE RS-232 Reader user manual V2.1 2019.06.20
4
Prefix: “$”
First column: RSSI value
Raw packet data is between “$” and “>”
Suffix: “>”
EX: $-85,02010605166E2A850A04160F18090F09425055434B205420383030423635>
4. Power supply:
4.1 Voltage: 5 VDC, Don’t exceed the limit.
4.2 The mini USB cable is inside the standard package.
Federal Communications Commission (FCC) Statement
RADIO FREQUENCY INTERFERENCE STATEMENT
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Warning : A shielded-type power cord is required in order to meet FCC emission limits and also to prevent
interference to the nearby radio and television reception. It is essential that only the supplied power cord be used.
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void your authority to operate the equipment.
FCC ID: XJ8-S2B5232E
