UGMO UG1000 Series User manual

Quick Installation & Start Guide
The UgMO UG1000B-A Bridge is part of the UG1000 family of products. The Bridge is responsible for
ma ing the internet connection between the UG1000 system and UgMO Knows.
• Remote configuration and alert reporting
• Software upgradeable to allow for future feature
expansion
• Embedded Linux processor provides smart device
intelligence

UG1000 Internet Bridge
The UG1000B-A Internet Bridge serves as the gateway or avenue by which all networ and sensor data is passed to the
UgMO Data Base. Each Bridge contains an embedded Linux processor. The bridge also serves as a repeater in any
networ and can forward data pac ets toward their final destinations.
To install the Bridge, you will need a 110 Volt AC power source that is near a router or other direct Ethernet connection.
Using the supplied 5 Volt transformer, insert the barrel connector into correct port located on the bottom of the Bridge and
the two-pronged bloc into the nearest 110 Volt outlet. Next, plug one end of an Ethernet cable into a router using your
WAN and the other end into the Ethernet slot located on the bottom of the bridge. Finally, to mount the hardware you can
use a screw and the eyhole slot in the bac of the bridge or simply hang the Bridge from the supplied plastic stand.
Once powered, a red LED on the front of the bridge will aluminate followed by a series of Green LEDs as the bridge
searches the area for any existing hardware or networ s. The LEDs are very helpful in determining the current state and
operation of the bridge.
The USB port is intended for use with a USB memory stic . It is a host port that must not be connected to a personal
computer. The Ethernet port is intended to be connected to a DHCP server to obtain an IP address to establish Internet
connectivity. It should not be directly connected to a personal computer.
