ujk technology OTORO TTX2 User manual

Planing Mode
Moulding Mode
Planing Width Mode
Router Lift Mechanism
OTORO Palm Router Table
Basch Kit Code 103570
Makita/Dewalt Kits Code 103571
Original Instructions
AT&M: 14/07/2020
BOOK REF: 103572
BOOK VERSION: 02

Index of Contents 02
Parts Breakdown 03
UJK Technology OTORO Palm Router Table Kits 04
Specification 04
Assembly 05-06
Router Assembly/Setup 07-08
Parts Illustration & Description 09-10-11
Router Table Modes
Planing Mode 12
Planing Width Mode 13
Moulding Mode 14
Planing Width Tips 15
Exploded Diagram/Parts List 16-17
Notes 18-19
Index
2
The UJK Technology Otoro Palm Router Table is a
unique and ingenious piece of equipment, well
suited to the needs of any craftsperson wishing to
make smaller sized, precision components. This
makes it ideal for model makers, dolls house
constructors or anyone who needs to accurately
machine small sections of timber.
It’s designed to be used with a quarter inch router/
trimmer, either the Bosch GKF 600 (702335), the
Makita RT0700CX2 (501867) or the DeWalt D26240K
(952707). The Makita router requires the use of a sleeve
adaptor which is supplied with the router table. Coarse
and Fine Feed adjustments are provided to set the
height of the cutter above the table.
Once the table has been assembled, it can be
conveniently stored in a small cupboard and can
be quickly clamped to any surface in a matter of
seconds, which means that it can be used almost
anywhere in the house. Install the router, connect the
dust extractor to the 48.5mm port, and you’re ready for
business! Three modes of operation are possible with
this router table; preparing an edge, planing the board
to width and moulding.
Edge preparation - The Rear Planing Fence consists of
two sections; a fixed outfeed and an adjustable infeed.
The adjustable part works by using a ‘folding wedge’
arrangement, where one slides against the other to create
the depth of cut. Accuracy is assured by a 10:1 scale, thus
moving and locking the leading wedge 10mm produces a
cut of 1mm. A featherboard is included to keep the timber
securely against the fence.
Width planing - The Rear Planing Fence is replaced by
the Rear Featherboard Fence; The Front Fence, complete
with a similar folding wedge adjustment is used to set
the planing width of the board. It should be noted that in
this unconventional, twin fence mode of routing, the Rear
Featherboard Fence pushes the material away from the
cutter so that it’s forced onto the adjustable Front Fence.
In a normal router table, one fence is used and the
material is forced towards it by the featherboards. Thin
strips of material can also be prepared to thickness by
sticking them to a wider carrier using double sided tape.
Moulding - Mouldings can be produced by using the
Rear Planing Fence in the same mode of operation as
edge preparation. Different sized cutters can be used by
changing the table insert, a selection of which can be
conveniently stored underneath the table.
Introduction
UJK Technology OTORO Palm Router Table has been licensed by OTORO
DESIGN INC., Japan, based on patented design of OTORO Multipurpose
Compact Router Table TTX2.
The symbols below advise the correct safety procedures when using this machine.
Fully read manual
and safety instructions
before use
Eye protection
should be worn
Ear protection
should be worn
HAZARDDust mask
should be worn

3
Front Planing Width Fence A
1 No Angled fence casting with operating
lever to set the thickness.
2 No Two part wooden fence with
machined slots and depth scale and
pointer.
2 No Threaded clamping knobs with two
washers and springs.
Rear Planing Fence B
1 No Angled fence casting with machined
slots, integrated extraction port,
fence clamping knob.
2 No Two part Wooden Fence with
machined slots, depth scale and
pointer.
2 No Threaded clamping knobs with two
washers and springs.
Planing Width Featherboard C
2 No Featherboards with spacers, washers
and pan head Phillips screws.
2 No Coutersunk Phillips screws, washers
and threaded clamping cap heads.
Rear Planing Featherboard Fence D
1 No Featherboard fence with router cutter
guarding.
UJK Palm Router Table Assembly E
1 No Router table with removable table
insert rings. Palm router height
assembly beneath with two Bristol
clamping leavers to secure the table
in position.
Bag Containing F
2 No Front/Rear Fence Clamping Handles
1 No Fine Feed Height Adjusting Knob
1 No 8-10mm Spanner
1 No 2.5-3-4mm Hex Keys
Model Number OTORO TTX2
Parts Breakdown
E
C
A B
D
F
Planing Width Featherboard Featherboard Fixings Threaded Clamping Knobs

UJK Technology OTORO Palm Router Table Kits Specification
Bosch Kit Code 103570 Makita/DeWALT Kit Code 103571
To fit the 1/4" Bosch Router
Bosch GKF 600
1/4” Router 230V
Code 702335
Bosch GKF 600
1/4” Router 110V
Code 950704
Makita Sleeve Adaptor
4
2-1 Router 1/4"
Code 952707
To fit the 1/4" Makita & DeWALT Router
Makita RT0700CX2 1/4”
Router Trimmer Kit 230V
Code 501867
DeWALT D26204K
Product Name UJK Technology OTORO Palm Router Table
Model TTX2
Product Dimensions Width 410 x Depth 300mm x Height 240mm
Table Size Width 315mm x Depth 300mm x Thickness 8mm
Workbench Portible Size Maximum Size: 50mm
Maximum Bit Height Adjustment 30mm
In-Feed Fence Range Adjust-
ment
3mm
Centre Ring Size Without Centre Ring: 40mm
With large Centre Ring: 24mm
With small Centre Ring: 12mm
Dust Extraction Port
(Outside Diameter) 48.5mm
Weight 6.6kg

5
Assembly
Router Table Planing Width Featherboard
1
2
3
4
5
6
1 4
2 5
3 6
Continues Over....
Fence Clamping Handle
Fine-feed adjusting knob

6
Assembly
7
8
9
10 1 4
11 2 5
12 36
Front/Rear Fence Rear Featherboard Fence
Brass clamping block

7
Router Assembly/Setup
1 4 7 10
11
2 5 8
3 6 12 9
Make sure the table is secure
Secure the router in place
Loosen the caphead bolts
Un-lock
Un-lock
Table insert
Lock
Raise
Select the appropriate table insert
Fine-feed adjuster
Fine feed lock
Bosch 1/4" GKF 600 Router
Continues Over....

8
Router Assembly/Setup
Makita 1/4" Router Trimmer DeWALT 1/4" D26204K Router
13
3
2
4
4
5
2
Makita sleeve
Sleeve lip
1
Please note you will not be able to use
the ‘Fine-feed function control’ as the
‘DeWALT’ router control head is too bulky.
Please remove and place safely aside.
Use the ‘UJK Height & Depth Gauge’ to
accurately set the cutter height.
Secure the router in place
IMPORTANT! the slits in the sleeve
and router housing must be aligned
Remove the fine-feed control
UJK Height & Depth Gauge
Slits

9
Parts Illustration & Description
Table insert
Rear planing fence assembly
Front planing width fence assembly
Router table
Featherboard
In-feed fence
In-feed clamping knob
Out-feed clamping knob
Out-feed fence
Adjustable planing fence
Brass clamping block
Planing width operating lever
Planing width clamping knobs
Planing width assembly clamping handle
Planing scale and pointer
Planing assembly clamping handle
Dust extraction outlet
Table insert Planing width scale/pointer Planing operating lever

10
Parts Illustration & Description
In-feed fence clamping knob
48.5mm Dust extraction outlet
Planing width stop Adjustable fence clamping knob
Out-feed fence clamping knob
Planing assembly clamping handle
Planing width operating lever
Planing scale/pointer
Rear planing featherboard fence
Planing width scale/pointer

11
Parts Illustration & Description
Bristol locking handle
Table clamping foot
Fine-feed control knob
Fine-feed locking wheel
Router height operating lever
Router housing
Table inserts
Adjusting gib strip grub screws Height assembly
clamping handle

12
Router Table Modes
1. Using a known straight edge set the fence flush with the cutter, see figs 1-2.
2. The in-feed fence works on a router of 10-1 so when the scale reads 5mm this
will make a 0.5mm cut, see figs 3-4.
Planing Mode
2
1
3
4

13
Router Table Modes
Planing Width Mode
1. Setup the router table as shown in figure 1.
2. With the timber in position, adjust the front planing fence so the timber is in contact
with the router cutter’s body, see fig 2. (NOTE: Not the TCT blade) This will create a
1mm cut.
3. Start your router and make the first cut, see fig 3. Measure the timber’s thickness
using a ruler or vernier caliper. Using the 10-1 scale, (10mm on the scale creates a
1mm cut). Make further cuts to the required thickness, see figs 4-5-6-7-8-9-10.
1
2
3
4
8
9
10
5
6
7
Router cutter body

14
Router Table Modes
Moulding Mode
1. Set the cutter’s height using the operating lever, see fig 1-2.
2. Set both fences so they are in line with the bearing of the cutter, see fig 3.
3. Before making your first cut, make sure the material is firmly against the in-feed
fence, (more right to left), see fig 4.
4. Apply even pressure when cutting until the material exits the out-feed fence, see fig 5.
1
3
4
5
2
Operating lever
Bearing

15
Router Table Modes
If you want to Plane thin strips of of timber, follow the steps as shown using double
sided tape, see figs 1 to 7.
Planing Width Tips
1
2
3
4
5
6
7
Double sided tape
Timber

16
Exploded Diagram/Parts List

17
Exploded Diagram/Parts List
NO PARTS
NO
DESCRIPTION SIZE QTY
1 50105028 Phillips pan screw M6x1.0Px30L 1
2 24081009 Clamp body 1
350201013 Hex nut M6H.0P 2
4 50404009 O ring G35 2
5 24081002 Collar-large 1
6 50301082 Flat washer 6.5x19x2t 4
750203001 Wing nut M6x1.0P 1
8 50104014 Round head screw M5x0.8Px10L 4
9 24081013 Clamping plate 2
10 24081101 Clamping handle assembly 2
11 24081105 Front wood fence assembly 1
11.1 24081040 Front wood rear fence 1
11.2 18028003 Nut insert 2
12 24081039 Front wood front fence 1
13 24081041 Front fence body 1
14 50123003 Round head tapping screw M4x12L 4
15 24081015 Fence guide front 2
16 50163028 Knob l/4”-20UNC 4
17 24081035 Spring 2
18 24081027 Guide bushing 2
19 24081104 Depth adjusting handle 1
20 24081043 Nut 1
21 50304009 Spring washer WW-6 1
22 24081026 Lock piece 2
23 50602002 Pin 3x12L 2
24 50114045 Universal handle M6x1.0Px20L 3
25 50105027 Phillips pan screw M4x0.7Px12L 1
26 24081004 Trimmer base 1
27 50102037 Cap screw M5x0.8Px20L 2
28 24081025 Plastic gib 4
29A 24081008 Adaptor-small 1
29B 24081007 Adaptor-large 1
29C 24081046 Adaptor-medium 1
31 24081018 Guide rod 1
32 24081020 Spring 2
33 24081014 Rear fence body 1
34 24081016 Dust chute 1
35 50104044 Round head screw M5x0.8Px6L 2
36 24081031 Rear wood fence-right rear 1
37 24081108 Rear wood fence assembly-
left
1
37.1 24081030 Rear wood fence-left 1
37.2 18028003 Nut insert 1
38 24081109 Rear wood fence assembly-
right front
1
38.1 24081032 Rear wood fence-right
front
1
38.2 18028003 Nut insert 1
39 50123002 Round head tapping screw M5x12L 4
40 24081038 Pull bracket 1
41 24081003 Collar-small 1
42 50107021 Button head hex socket
screw
M5x0.8Px16L 10
43 50302006 Spring washer M5 4
44 50107001 Button head hex socket
screw
M5x0.8Px8L 3
45 24081001 Table 1
46 24081017 Bib 1
47 24081005 Dovetail base 1
48 50201021 Hex nut M5x0.8P 3
49 50103060 Set screw M5x0.8Px23L 3
50 24081055 Base cover 1
51 24081037 Spring 1
52 24081036 Side support 1
53 24081102 Stroke controller 1
54 50304010 Wave washer WW-10 1
55 50301102 Flat washer 8]2x16xlt 3
56 50206002 Hex nut M8x1.25P 2
57 24081019 Guide block 1
58 50102021 Cap screw M5x0.8Px25L 2
59 24081103 Handle assembly 1
60 24081107 Feather board assembly-
left
1
60.1 24081034 Feather board base-left 1
60.2 18028003 Nut insert 1
61 50161018 Phillips pan tapping screw 5x12L 4
62 24081024 See through guard 1
63 24081029 Chip guide 1
64 24081033 Feather board 2
65 24081106 Feather board assembly-
right
1
65.1 24081028 Feather board base-right 1
65.2 18028003 Nut insert 1
67 24081047 Fence guide rail 2
68 24081048 Flat washer 1
69 24081049 Pointer 2
70 24081050 Rule 2
71 50107013 Button head hex socket
screw
M5x0.8Px10L 4
72 50301004 Flat washer 5.2x12xlt 2
73 24081051 Sponge 2
74 50101045 Hex screw M6x1.0Px30L
75 24081052 Fix plate
76 50111013 Knob M6x1.0Px13L
77 71026006 Spring
78 24081056 Collar
79 50111016 Knob M6x1.0Px42L

18
Notes

19
Notes

The UJK brand was launched by Axminster in 2012
with the intention of encompassing a range of
carefully selected products that Axminster held in
particular high esteem. Many of these products are
designed by and manufactured by Axminster. The
range includesrouting, measuring and wood
jointing products and has proven to be extremely
popular. Axminster continually strive to develop and
increase the range of quality, innovative products.
Please dispose of packaging for the product in a
responsible manner. It is suitable for recycling. Help to
protect the environment, take the packaging to the local
recycling centre and place into the appropriate recycling
bin.
Do not dispose of electric tools together with
household waste material. In observance of European
Directive 2002/96/EC on waste electrical and electronic
equipment and its implementation in accordance with
national law, electric tools that have reached the end of
their life must be collected separately and returned to an
environmentally compatible recycling facility.
Only for EU countries
axminstertools.com/ujk
Axminster Tools Axminster, Devon EX13 5PH
