INTRODUCTION
I. Description
This device is a high power, audio amplifier. Use it responsibly. Very
loud music can cause permanent hearing loss. This amplifier is intended
for installation in vehicles with a 12 Volt, negative ground electrical
system. Attempting to connect or operate the amplifier in another type of
electrical system may cause damage to the amplifier or the electrical
system.
II. About This Manual
Read the Instructions-
Be sure that you have read all operating instructions and understand all
safety precautions before installing and operating the amplifier. We
recommend that you have your DigitalisDigitalis amplifier installed by a
specialist.
Follow the Instructions-
The instructions are intended to help you safely obtain the best
performance from the amplifier. Carefully follow all installation and
operating instructions.
Save the Operating Manual-
Keep the manual in a safe place after installing the amplifier. You may
have questions later.
Text Conventions used in this Manual-
Bold-
Headings and important information.
Bold, Underlined-
Very important information.
"Bold"-
As labeled on the amplifier, or quoted from elsewhere in this
manual.
III. Safety and Operating Precautions-
Caution!
This symbol warns the user of a potential risk or hazard if instructions are
not followed.
⇒This arrow symbol points to a specific instruction for avoiding a
potential hazard.

1
1. Installation
1.1 Installation-Mounting the Amplifier
Step 1-Disconnect the negative (-) battery cable before mounting the
amplifier or making any connections. Check the battery and alternator
ground (-) connections. Make sure they are properly connected and free of
corrosion
Step 2-Choose a mounting location for your amplifier. Find a location
on a flat surface away from heat and moisture. Be sure the mounting
location and the drilling of pilot holes for mounting will not present a
hazard to any wires, control cables, fuel lines, fuel tanks, hydraulic lines,
or other vehicle systems or components. Common mounting locations are
under the front passenger seat, or in the trunk area. Choose a location
with unimpaired air circulation. The amplifier will dissipate heat more
efficiently if mounted vertically.
Step 3-Place the amplifier in the mounting location, and mark the
positions of the holes with a marker, pen or pencil. Carefully drill the
mounting holes in the marked positions.
Caution!
⇒Check carefully before drilling any pilot holes.
Step 4-Use the supplied mounting screws to securely fasten the amplifier
to the mounting surface. Wrap the screw driver shaft with electrical tape
to avoid marring the area around the mounting holes.
1.2 Installation-Power Connections
Step 1-Run a power cable from the battery to the amplifier mounting
location. Use rubber grommets to protect the cable anywhere it has to go
through metal. Use #4 AWG or larger power and ground cable.
Step 2-Connect one end of an in-line fuse holder to the power cable.
Connect the other end of the fuse holder to the positive battery post with
20 cm (or less) of the same cable. This fuse location will protect the
system and the vehicle against the possibility of a short circuit in the
power cable. Be sure to use a fuse and fuse holder adequate for the
application. Do not place a fuse in the holder at this time.
The maximum fuse rating for the Digitalis DTDigitalis DT22--800800 is:
3 X 40 Amps
Caution!
⇒Bridging fuses or replacing a fuse with one of a higher rating may
cause damage to the amplifier and the vehicle's electrical system. 2
Step 3-Run a remote turn on cable from the switched +12V source you
will be using to turn on the system components. This may be a toggle
switch, a relay, or your source unit’s remote trigger wire, or power
antenna trigger wire. Run this lead to the amplifier mounting location.
Use #18 AWG wire or larger.
Step 4-Locate a secure grounding connection as close to the amplifier as
possible. Make sure the location is clean and provides a direct electrical
connection to the frame of the vehicle. Connect one end of a short piece
of the same size cable as the power cable to the grounding point. Run the
other end of the cable to the amplifier mounting location.
Step 5-connect the ground cable to the screw terminal labeled
“POWER, GND”.
Step 6-Connect the power cable to the amplifier at the screw terminal
labeled “POWER, +12V”.
Step 7-Connect the remote turn on cable to the screw terminal labeled
“POWER, REM”.
1.3 Installation-Speaker Connections
Step 1-Run #14 AWG or larger connecting wire from your speakers to
the amplifier mounting location. Keep speaker wires away from power
cables and amplifier input cables. Use grommets anywhere the wires have
to pass through holes in the metal frame or sheet metal. Connect to the
speakers according to the type of terminals on each speaker.
Step 2-Strip 3/8" of insulation from the end of each wire and twist the
wire strands together tightly. Make sure there are no stray strands that
might touch other wires or terminals and cause a short circuit.
Step 3-Crimp spade lugs over the wire ends or tin the ends with solder to
provide a secure termination.
Step 4-Connect the wire ends to your amplifier as follows:
SPEAKER TERMINALS
Follow the (L+, R+) (L-, R-), channel and
polarity markings, making sure they match the
channel and polarity of the connections at the
speakers.
L+ L- R+ R-
BRIDGED

3
MULTIPLE SPEAKER CONNECTION
PARALLEL-Each additional speaker decreases the load impedance
for the amplifier. The amplifier delivers more current and works
harder.
SERIES-Each additional speaker increases the load impedance for
the amplifier. Impedances higher than 8 ohms are rarely used for car
audio.
1.4 Installation-Self-Bridging, 2+1 Mode
BRIDGED MONO-
Connect a 4Ωohm speaker to the terminals marked “(+), BRIDGE, (-)”,
making sure they match the polarity of the connections at the speakers.
Caution!
⇒Speaker or multiple speaker loads totaling less than 4 ohms are not
recommended for “Bridged” or “2+1 Mode”, and may damage the
amplifier.
2+1 MODE-(TRI-MODE)
(+)
(-)
+
-
(+)
(-)
4 Ohm 2 Ohm
PARALLEL CONNECTION USING 4 OHM SPEAKERS
A
M
P
L
I
F
I
E
R
O
U
T
P
U
T
(+)
(-)
+
-
(+)
(-)
4 Ohm 8 Ohm
SERIES CONNECTION USING 4 OHM SPEAKERS
A
M
P
L
I
F
I
E
R
O
U
T
P
U
T
4
Simultaneous stereo and mono operation, “2+1 Mode”, requires a passive
crossover to send low frequencies to the mono speaker and higher
frequencies to the stereo speakers. The following table lists the
component values for a 6 dB/Octave crossover at common frequencies
using 4 ohm speakers for stereo and an 8Ωspeaker for mono(subwoofer):
FREQUENCY INDUCTOR CAPACITOR
80 Hz 16 mH 470 uF
100 Hz 7.5 mH 330 uF
120 Hz 7.5mH 330 uF
150 Hz 7.5 mH 220 uF
2+1 MODE WIRING DIAGRAM-
Use 100 Volt, non-polar capacitors, and connect them in series with the
stereo speakers as shown in the diagram. Connect the inductor in series
with the mono speaker as shown in the diagram. Be sure the inductor is
rated to handle the power of your amplifier.
1.5 Installation-Input
Connections
Low Level, High Impedance, Gold Plated RCA Input
and Output Jacks-
Connect the input jacks to a source providing preamp
level outputs. Use heavy duty RCA patch cords designed
for mobile applications . Run the patch cables carefully,
maintaining as much distance as possible from power,
speaker, and accessory wiring. Make sure the RCA plugs
fit tightly for a secure connection.
Connect the output jacks to any component that can accept preamp level
inputs.
(+)
(-)
(+)
(-)
(+)
(-)
(A+)
(A-)
(B+)
(B-)
CAPACITORSINDUCTOR
L
R
INPUT

5
GAIN
MIN MAX
INPUT
-12dB
ON
OFF
BOOST
0dB 18dB
45HZ 5KHZ
LPF
ON
OFF
1.6 Installation-Check all Connections
Recheck all connections before reconnecting the negative(-) battery cable.
Insert the correct value fuse in the fuse holder at the battery before
attempting to turn on the system.
2. Operation
2.1 Operation-Input Level adjustments
Adjust the input level for the marked channel(s) with a
small screwdriver through the opening marked
“GAIN”. Turn clockwise to increase the level,
counter clockwise to decrease. Amplifiers will run
cooler and produce less system noise at lower level
settings.
A –12dB attenuator can be switched in by pushing in the switch marked
“INPUT –12dB” for sources with very high signal levels.
Consult an experienced installation specialist for assistance in balancing
the levels in multi-amplifier systems, or systems with signal processing
accessories.
2.2 Bass Boost-
Turning the “BOOST” control clockwise increases the
level of frequencies around 45Hz by up to 18dB when fully
clockwise.
2.3 Operation-Built-in
Crossovers
CROSSOVER FILTER SELECTION
The DigitalisDigitalis amplifiers have built-in crossover
filters for low-pass, high-pass or band-pass operation.
Select " LPF,” or “HPF" by pushing the switch in.
If the switch is in the “OFF” position, the filter is not
active. "LPF" selects the low pass filter. "HPF" selects the high pass
6
FUSES
40A
POWER
(GREEN)
PROTECT
(RED)
filter. If both buttons are in the “OFF” position, the amplifier is
operating full range. If both switches are pushed in, the amplifier is in the
band-pass mode.
FREQUENCY ADJUSTMENT
After selecting the crossover function, adjust the low pass or high pass
frequency control with a small screwdriver through the opening marked
“LPF 45HZ 5KHZ” or "HP 45HZ 5KHZ". Turn clockwise to set to a
higher frequency, counter clockwise to set to a lower frequency.
2.4 Operation-Protection Circuits and
L.E.D. Indicators
L.E.D. INDICATOR-Dual color LED turns green to
provide a visual indication that the amplifier is turned on, or
red to indicate that a problem exists and the protection
circuitry has protected the amplifier by shutting it down.
Turn the system off and correct the problem before turning
the system on.
THERMAL PROTECTION-The amplifier will shut down if its
temperature exceeds a safe operating level. The amplifier will remain off
until it cools to a safe operating temperature. Exercise care, the exterior of
the amplifier may get uncomfortably hot to the touch before shutting
down.
OVERLOAD AND SHORT CIRCUIT PROTECTION-The amplifier
will shut down if a short circuit condition exists, or if electrical current
demands exceed safe levels.
FUSE PROTECTION-A blown fuse indicates a
problem that should be corrected before the fuse is
replaced. Always replace with the same value fuse.
Never substitute a larger value fuse.

7
DIGITALIS
L
R
INPUT
L
R
OUTPUT
GAIN
MIN MAX
BOOST
0dB 18dB
INPUT
-12dB
ON
OFF 45HZ 5KHZ ON
OFF
HPF
45HZ 5KHZ ON
OFF
LPF
1 2 3 4 5 6 7 8 9
1 2 3 4
40A
40A
40A
FUSES
POWER
(GREEN)
PROTECT
(RED)
+12V GND REM
POWER SPEAKER
BRIDGED
L+ L- R+ R-
2.4 Operation-Location of Terminals,
Controls and LED indicators
1. RCA input jacks 2. Input attenuator 3. Input level adjust
4. Bass Boost 5. High pass freq. 6. High pass on/off
7. Low pass freq. 8. Low pass on/off 9. RCA output jacks
1. Fuse(s) 2. Power terminals 3. LED
4. Speaker terminals
8
Features and Specifications:
DT2DT2--800800
2ΩΩ Stable Yes
Bridgeable Yes, 4Ω
Tri-mode Yes
Terminals Gold plated RCA jacks, speaker and power terminals
Soft Start Yes
Inputs RCA line level inputs
Crossover Low Pass, High Pass, Band Pass, 12dB/Octave, 45-5kHz.
Bass Boost Variable, 0 to 18dB @ 45Hz
Protection Thermal, short-circuit, DC offset, fuse
Power
Supply Pulse Width Modulated, MOSFET power supply,
+12V/Negative Ground
Power, 4ΩΩ,
2 X 200 Watts RMS <0.05% THD
Power, 2ΩΩ,
2 X 400 Watts RMS <0.2% THD
Bridged
Power, 4ΩΩ 800 Watts RMS <0.3% THD
Signal to
Noise Ratio >90dBA
Frequency
Response 15Hz –25kHz
Separation >60dBA
Input
Sensitivity 400mV –4V
12dB Attenuator
Fuse 3 X 40A
These specifications are subject to change in the continuing effort to
improve the product.

9
Troubleshooting:
Condition Possible Cause Possible Solution
No sound Low or no remote turn
on voltage, or no remote
turn on connection
Check the remote turn on
connection and the voltage at
the amplifier and source unit
Blown fuse(s) Check all system fuses
Wiring problems Recheck all connections
Check for short circuits
Blown speakers Check speakers on another
amplifier
Amplifier
shut down Protection circuit protecting against
overheating or overload
Check for adequate ventilation
Check load impedance(2 ohm
stereo, 4 ohm bridged)
Check speaker wiring for short
to the vehicle chassis
Reduce input level
Distortion Input level not properly
adjusted
Speaker damage
Readjust amplifier input level
Check speakers on another
amplifier
Poor bass
response Speakers out of phase
Recheck speaker wiring
Reverse polarity of one channel
Ticking
noise Radiated noise from spark plug wires Reroute amplifier input wiring
Install a noise filter
Whining
noise Alternator noise caused by poor grounding of
amplifier, source, other
component, battery, or
alternator
Check all ground connections
Install a noise filter on the
source unit’s power cable
Install a coupling transformer
in the signal path to improve
ground isolation for the signal
path
