Ultimate Support TS-90B User manual

Rev. 3 03.22.09 . Hang Tag Item #13908T
The TeleLock portable speaker stand
allows one person to easily and safely
raise and lower heavy speakers.
SPEAKER STAND TS-90B
THE MOST
advanced
featuring telelock®

Patented TeleLock®- TeleLock allows one person to easily and safely raise and lower heavy
speakers.
Heavy-Duty Stand - Larger diameter tubing and metal reinforced clamps securely support
more weight than other stands.
Truly Portable - Quickly folds into a compact, lightweight unit. Tote bags available: BAG-90
and BAG-90D.
Limited Lifetime Warranty - Constructed of the finest materials and backed by our award-
winning customer support. For full details, exclusions and limitations as well as information
on obtaining warranty service, visit www.ultimatesupport.com.
features of ts-90b
1. Put the TELELOCK COLLAR into the “RAISE” position. Raise center tube 6” - 10”.
2. Put speaker on stand and raise telescoping tube to desired height. In the “RAISE”
position the TELELOCK COLLAR keeps the telescoping tube from sliding back down.
Set to “LOCK” position.
3. To lower speaker, SLOWLY rotate ARROW on TeleLock collar to “LOWER” position until
speaker starts to lower. To slow descent, turn collar toward the “RAISE” position. Use
caution. 4. When removing the speaker, rotate ARROW to the “LOCKED” position.
NOTE: Instructions for tripod base & socket adapter are available on website.
instructions for setting up the stand
•Item#13908-black
•Height3’8”-6’7”
 (1118mm-2007mm)
•Weight6.2lbs.(2.8kg)
•Basediameter47”(1194mm)
•Loadcapacityof150lbs.(68.2kg)
•Folded43.5”x5.5”
 (1105mmx140mm)
•Fits1-1/2”(38mm),
 1-3/8”(35mm)speakersockets
TS-90B
970.776.1920.www.ultimatesupport.com.Copyright2009,UltimateSupportSystems.AllRightsReserved
Visit www.ultimatesupport.com to download a detailed product
manual, read full warranty details and to register your warranty.
