Ultra-tow 49804 User manual

Thank you very much for choosing an Ultra-Tow Product! For future reference, please complete
the owner’s record below:
Serial Number/Lot Date Code: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This utility trailer kit is designed for certain applications only. Northern Tool and Equipment
cannot be responsible for issues arising from modification or use of this product in an applica-
tion for which it was not designed. We strongly recommend that this product not be modified
and/or used for any application other than that for which it was designed.
For technical questions, please call 1-800-222-5381.
Table of Contents
Intended Use.......................................................................................................................................1
Technical Specifications....................................................................................................................1
Important Safety Information..............................................................................................................2
Specific Operation Warnings..............................................................................................................2
Assembly Instructions........................................................................................................................3
Before Each Use...............................................................................................................................11
Operating Instructions......................................................................................................................11
After Each Use..................................................................................................................................13
Maintenance.....................................................................................................................................13
Parts Diagram...................................................................................................................................14
Parts List ...........................................................................................................................................14
Replacement Parts ..........................................................................................................................15
Limited Warranty...............................................................................................................................15
Intended Use
The utility trailer kit, with its 40" x 48" bed and 1060lb. payload capacity, is ideal for hauling
mulch, dirt, machinery such as pumps, generators, lawn mowers, or snow blowers or other
similar-sized cargo. The trailer includes fenders to prevent cargo damage from rocks and
debris, and lights make the trailer street legal. Meets all DOT requirements.
Technical Specifications
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS
before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item# 49804
1 of 15
Property
Tires
Wheel
Bed Dimensions
Ball/Coupler Size
Load Capacity
GAWR
GVWR
Dimensions, Assembled
Shipping Weight
Specifications
4.80-12 Tubeless
4 Bolt Demountable
40 in. x 48 in.
1-7/8 in.
1,060 lbs. max
1,200 lbs. with 4.80-12 Tires at 60 PSI Cold
1,200 lbs.
84in.L x 52-1/2in.W x 22in.H
134 lbs.

40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
Important Safety Information
WARNING:
• Read and understand all instructions. Failure to follow all instructions may result in serious injury.
• The warnings, cautions, and instructions in this manual cannot cover all possible conditions
or situations that could occur. Exercise common sense and caution when using this tool.
Always be aware of the environment and ensure that the tool is used in a safe and responsi-
ble manner.
• DO NOT allow persons to operate or assemble this product until they have read this manual
and have developed a thorough understanding of how the product works.
• DO NOT modify the product in any way. Unauthorized modification may impair the function
and/or safety and could affect the life of the product. There are specific applications for
which the product was designed.
• Use the right tool for the job. DO NOT attempt to force a small equipment to do the work of
larger industrial equipment. There are certain applications for which this equipment was
designed. It will do the job better and more safely at the capacity for which it was intended.
DO NOT use this equipment for a purpose for which it was not intended.
• Industrial or commercial applications must follow OSHA requirements.
WARNING:
WORK AREA SAFETY
• Inspect the work area before assembly. Keep work area clean, dry, free of clutter, and well lit.
Cluttered, wet, or dark work areas can result in injury.
• Do not assemble the trailer where there is a risk of causing a fire or an explosion; e.g., in the
presence of flammable liquids, gases, or dust. Assembly can create sparks, which may ignite
the dust or fumes.
• Keep children and bystanders away from the work area while assembling the trailer. Do not
allow children to play on the trailer.
• Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in
your assembly area. Some of these hazards may be below the work surface hidden from your
view and may cause personal harm or property damage if unintentionally contacted.
PERSONAL SAFETY
• Stay alert; watch what you are doing, and use common sense when assembling and towing
the trailer. Do not assemble or tow with the trailer while you are tired or under the influence of
drugs, alcohol, or medication. A moment of inattention may result in serious personal injury.
• Do not wear loose clothing, dangling objects, or jewelry during assembly. Loose clothes,
jewelry, or long hair can be caught between parts.
• During assembly, use ANSI-approved safety goggles or safety glasses with side shields. Use
a dust mask in dusty work conditions. Also use non-skid safety shoes, gloves, and hearing
protection when appropriate.
• Do not overreach. Keep proper footing and balance at all times.
Specific Operation Warnings
WARNING:
• Before each use, always examine the trailer for proper tire condition and air pressure,
damaged Tail Lights, damaged Side Running Lights, loose bolts and nuts, structural cracks,
bends and any other condition that may affect its safe operation. Do not use the Trailer even
if minor damage appears.
2 of 15
• Before each use, always attach the Safety Chains of the trailer to the towing vehicle. Make
sure the Safety Chains are attached to the towing vehicle with the equal length at each side.
Do not allow the Safety Chains to drag on the ground.
• Always check to make sure the payload being transported properly and safely secured in the
trailer. Load the Trailer evenly from side to side with 60% of the load forward of the Axle.
• Make sure the towing vehicle is capable of towing this trailer and its payload. Make sure the
hitch on the towing vehicle is capable of towing the Trailer and its payload. The towing
capacity of the hitch is typically stamped on the hitch drawbar.
• Make sure the hitch coupler and the vehicle’s Ball Hitch (not included) are of equal mating
size (2in.) and are rated equal to or greater than the weight of the trailer and its payload.
• Do not exceed 45 miles per hour when towing the trailer. Excess speed is a major cause of
vehicle-trailer accidents.
• The Tail Light Bulbs supplied with this trailer are for a 12 Volt DC electrical system only. Do
not attempt to power the Light Bulbs with any other type or voltage electrical current.
• Whenever possible, park the trailers on a flat, level, paved surface and chock both tries to
keep the trailer from accidently moving.
• Before attempting to fold up the trailer, make sure it is on a flat, level, solid surface and chock
both tires.
• DO NOT exceed the 1715 pound weight capacity.
• DO NOT allow anyone to ride in the towed vehicle or on the trailer.
• The coupler must be properly secured to the hitch ball. After assembly and attachment, pull
up and down on the hitch coupler to make sure the hitch ball is snug in the hitch coupler. If
the coupler is not secured properly, it could come loose while the trailer is in motion, causing
property damage, serious personal injury or even death.
• Make wide turns when towing a loaded trailer, avoiding both sharp turns and U-turns. Turning
too sharply can cause damage to the trailer and/or the tow vehicle.
Assembly Instructions
Warning:
• Beams have sharp edges. Wear work gloves to prevent cuts on hands and fingers.
• Wear ANSI Z87.1 compliant safety goggles.
Read the following instructions step-by-step for easy assembly according to the complete parts
and hardware list. Also be sure to read the licensing notice at the end.
NOTE:
• The trailer parts are called out by standing at the rear of the trailer looking forward toward the
coupler (left & right).
• Do not fully tighten any nuts and bolts until the entire trailer is assembled. Installing the
plywood deck (not included) is the last step after tightening all the nuts and bolts.
1. Open the boxes and check the contents of the two boxes to ensure that all parts are present:
Box 1
1 hardware kit
2 wheels
2 fenders
2 fender brackets
3 of 15
2 leaf springs
2 hubs
1 coupler
1 safety chain
3 cross members
1 axle
Box 2
1 tow bar
2 side rails

40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
STEP 1
Parts Needed:
2. Lay out the three cross members (2) and the side rails (1) as shown below.
NOTE: The center holes on the cross members should be facing up and the ‘front’ cross
member is reversed (flanges toward the rear).There are 2 small holes with one regular hole on
the wall of side rail must be toward the front.
3. Attach the side rails with the cross members using M10*25 bolts, ￠10 flat washers and M10
nylon nuts.
Do not fully tighten the nuts yet.
4 of 15
STEP 2
Parts Needed:
4. Attach the towbar (3) to the front and middle cross members using M10*25 bolts, ￠10 flat
washers and M10 nylon nuts, noting the bolt direction shown in the figure below.
5. Attach the front and rear spring hangers (4, 5), noting that the shorter hangers (4) belong
toward the front and the longer hangers (5) in the back, using M10*25 bolts, ￠10 flat washers
and M10 nylon nuts.
5 of 15
Part No.
23
24
25
2
1
Description
M10x25 Bolts
￠10 Flat Washers
M10 Nylon Nuts
Cross Members
Side Rails
Qty.
12
12
12
3
2
Set A
Part No.
23
24
25
3
4
5
Description
M10x25 Bolts
￠10 Flat Washers
M10 Nylon Nuts
Towbar
Front Spring Hangers, Shorter
Rear Spring Slide Plates, Longer
Qty.
12
12
12
1
2
2
Set A

40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
STEP 4
Parts Needed:
8. Remove the dust caps (18) and take out the cotter pin.
9. Carefully slide the hub assemblies (13) onto the axle ends followed by the 3/4” flat washers
(16) then put on the castle nuts (17) as shown below. Tighten the nuts snuggly then back
them out slightly so the hubs can turn freely.
10. Insert the cotter pins and bend them so they stay in place.
11. Fill the dust caps (18) 1/4” full of automotive grease and push them firmly on the hubs.
12. Place the tire/wheel assemblies (14) on the hubs making sure the air valves are on the
outside of the tires. Apply four lug nuts (29) per tire and tighten them to 90 ft-lbs.
Double-check that the axle is perpendicular to the side rails.
7 of 14
STEP 3
Parts Needed:
6. Put the slipper springs (9) on the spring hangers making sure the spring eyes are forward
(see figure below). Secure the springs with M14*80 bolts, ￠14 flat washers and M14nylon
nuts (bolt set B), noting the bolt direction shown in the figure below.
7. Place the axle (10) on top of the slipper springs. Place the M10 U-bolts down over the axel
and on either side of the slipper springs then through the holes in the spring plates and
fasten with￠10 flat washers and M10 nylon nuts from bolt set C.
6 of 15
Part No.
9
26
27
28
10
12
11
24
25
Description
Slipper Springs
M14x80 Bolts
￠14 Flat Washers
M14 Nylon Nuts
Axle
M10 U-Bolts
Spring Plates
￠10 Flat Washers
M10 Nylon Nuts
Qty.
2
4
4
4
1
4
2
8
8
Set B
Set C
Part No.
13
14
15
16
17
18
19
29
34
Description
Hub Assembly
Tire/Wheel Assembly
Bearings
3/4” Flat Washers
Castle Nuts
Dust Caps
Cotter Pins
M12x1.25 Lug Nuts
Grease Fittings
Qty.
2
2
4
2
2
2
2
8
2

Part No.
20
21
30
23
24
25
6L
6R
Description
Coupler
Safety Chain
M10x85 Bolts
M10x25 Bolts
￠10 Flat Washers
M10 Nylon Nuts
Left Tail Light Bracket
Right Tail Light Bracket
Qty.
1
1
2
8
10
10
1
1
Part No.
8L
8R
7
22
31
32
33
Description
Left Tail Light
Right Tail Light
License Plate bracket
Side Running Lights
Self-Tapping Screw
M6 Padded Nuts
Fenders
Qty.
1
1
1
2
4
4
2
Set D
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
STEP 6
Assembly Check
• Double-check the assembly to be sure all the steps were followed and all the parts are used.
Check that the frame, axle and wheels are square then fully tighten all bolts and nuts.
• Do not remove the VIN sticker from the tow bar.
STEP 7
Wiring the Trailer
19. Install the 4-wire vehicle connector in the trunk area of the tow vehicle.
20. Position the connector plug near the hitch ball of the vehicle and arrange the wires as
shown in the diagram below.
21. Connect the white wire to the frame or body of the vehicle;
22. Attach the white ground wire at the plug end of the wiring harness to the small hole in the
tow bar with a self-tapping screw.
23. Leave about 18” of wire beyond the coupler and arrange the wires on the inside of tow bar
and the front cross-member as shown in the diagram below. Push on the wire clips to hold
the wires in place on the tow bar (see wire clip figure A and the ‘A’ locator symbols in the
diagram).
24. From the tow bar/front cross-member point, split the yellow/brown and green/brown wires
and arrange the yellow/brown wire along the left side and the green/brown wire along the
right side. Push on the wire clips to hold the wires in place on the front cross-member (see
the ‘A’ locator symbols on the cross-member in the diagram).
Connect the wires to the lights in the following steps by stripping wires and taping connec-
tions.
25. Connect the wire leads from the side running lights to the brown wire on each side with the
wire connectors. See connector figures D and E in the diagram. Use pliers to squeeze the
connector closed.
26. Cut the yellow/brown and green/brown wires to appropriate lengths to go down the side
rails to the tail lights and strip the wire ends by 3/4".Push on the wire clips to hold the wires
in place along the side rails (see the ‘A’ locator symbols on the side rails in the diagram).
27. Connect the tail lights according to figures B and C in the diagram and the following color
code.
Left Side
Yellow-yellow wire
Brown- brown wire
White- tighten with tail light bolt
9 of 15
STEP 5
Parts Needed:
13. With assistance, turn trailer assembly over, right-side-up.
14. Bolt the coupler (20) to the tow bar with M10*90 hex bolts, ￠10flat washers and M10 nylon
nuts then attach the safety chain to the coupler with bolt M10*90 by putting the bolt through
the center link of the chain (21), then lock with ￠10flat washers and M10 nylon nuts. NOTE:
Make sure the safety chain is the same length on each side.
15. Remove the left tail light (8L) from the light bracket (6L) then attach the bracket to the left
side rail with M10*25 bolts, ￠10flat washers and M10 nuts as shown below. Install the left
tail light and the license plate bracket (7) (with clear lens facing down) with the M6 nuts (32)
on the light.
16. Remove the right tail light (8R) from the light bracket (6R) then attach the bracket to the
right side rail with M10*25 bolts, ￠10flat washers andM10 nuts as in the previous step.
Install the right tail light with M6 nuts (32) on the light.
17. Remove the lenses of the side running lights (22), feed the wire through the hole in the
center of the light and the center hole in the frame and attach the lights to the frame with
self-tapping screws (31). Replace the lenses on the lights.
18. Attach the fenders (33) to the side rails using M10*25 bolts, ￠10flat washers andM10 nuts.
8 of 15
Right Side
Green-green wire
Brown- brown wire
White- tighten with tail light bolt

40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
Before Each Use
Check for loose, damaged, or cracked parts on the trailer before each use. Carefully check that
the trailer will operate properly and perform its intended function, including the tire condition
and pressure (see Operating Instructions below). Replace damaged or worn parts immediately.
Never use the trailer even if minor damage is present.
Operating Instructions
Plan your towing, and use the correct trailer for the job. Tools do a better and safer job when
used in the manner for which they are designed.
TOW VEHICLE
• Make sure the tow vehicle is capable of towing the load.
• Excess speed is the second highest cause of car-trailer accidents. Recommended maximum
speed for all passenger cars towing trailers is 45 MPH.
HITCH, BALL, COUPLER
• Check that the hitch on the tow vehicle is capable of towing the trailer. The capability of the
hitch is normally stamped on the hitch bar and the capacity of the ball is stamped on the ball.
• Make sure the coupler and the ball the same size (1-7/8 inch) and are rated equal to or
greater than the load. Only attach the proper size ball to the coupler for towing.
SAFETY CHAINS
• Always use safety chains.
• Check that the safety chains are attached to the tow vehicle with the same length on each side.
• Always cross the chains under the coupler and connect the safety chains to the tow vehicle frame.
• Do not allow the chains to drag on the ground.
LOADING
• Never overload the trailer. Maximum load is 1060 lbs.
• Trailer load size should not exceed trailer’s bed-
board size (40’ x 48’).
• Load the trailer evenly from side to side with 60% of
the load forward of the axle (see picture at right). It is
important that the trailer coupler press down on the
vehicle hitch, but not beyond the trailer capacity of
1060 lbs.
• Reduce the weight in the car trunk and rear seat areas
by the amount of the hitch force from the trailer.
• It is unsafe and also against the law to carry passengers in any trailer.
LIGHTING
• Check lighting before each use and every 100 miles to be sure the stop, tail, and turn signals
are working properly. REPLACE ANY BROKEN LENSES, EFLECTORS, OR BULBS.
• Check the wires for good connections and possible fraying or wearing of insulation.
• Lights supplied with this trailer are for 12-volt DC systems only. Do not attempt to power the
bulbs with any other type of voltage.
TIRES
• Check tires for wear, damage and proper inflation before each use and every 100 miles.
• Tire pressure should be kept at 60 PSI.
• Check and tighten the lug nuts. Torque to 85-90 ft.-lbs.
• Re-torque the lug nuts after the first 25, 50 and 100 miles and before each tow thereafter.
11 of 15
TRAILER LICENSING NOTICE:
Some states may consider that this trailer kit is and specially constructed or a homemade
vehicle for registration, licensing and/or titling purposes.
The M.C.O. (Manufacturer’s Certificate of Origin) supplied with your trailer must be filled out and
signed by the dealer transferring ownership to you.
When licensing your trailer, you will need the signed M.C.O., a purchase invoice, cash register
receipt, or bill of sale showing the purchase and retail sales tax or use tax collection by the
retailer. Take these to your local Department of Motor Vehicles and upon payment of the
appropriate State fees, you will be issued a title, registration and license plate (if required).
Some states will require inspection of the assembled and finished trailer kit before issuing a title
registration/license.
If you require additional information or guidance on licensing or titling, please consult your
State Department of Motor Vehicles.
10 of 15

40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
After Each Use
Check for damaged or cracked parts on the trailer after each use, including the tire condition
and pressure. This way replacement parts can be purchased and replaced before the next use.
Wash off the trailer to prevent dirt and road grime from hardening on the components.
Maintenance
Maintain your trailer. It is recommended that the general condition of any tool be examined
before it is used. Keep your tool in good repair by adopting a program of conscientious repair
and maintenance including the following points:
• Use only identical replacement parts on the trailer. Parts that may be suitable for a different
trailer may create a risk of injury when used with this trailer.
• Check and maintain the trailer, coupler, ball and hitch before each use and every 200 miles.
• To prevent bearing damage, disassemble and repack the wheel bearings with a good grade
of wheel bearing grease every 2000-3000 miles or yearly. If you do not know how to repack
wheel bearing, take your trailer to a qualified service technician.
• When servicing the trailer, check that the tire pressure is 60 PSI when the tires are cold. Refill
the tire with air as needed.
Store the trailer when it is not in use. Inspect the trailer for good working condition prior to
storage and again before re-use.
13 of 15
OPERATION
• Tighten the trigger lock on the coupler and hook the safety chains securely (see Safety
Chains above and Coupler Operation below).After assembly and attachment, pull up and
down on the hitch coupler to make sure the hitch ball is snug in the hitch coupler. If the
coupler is not secured properly, it could come loose while the trailer is in motion, causing
property damage, serious personal injury or even death.
• Know how to properly control your tow vehicle-trailer combination on the highway under all
conditions. Remember the loaded weight of the trailer will increase your braking and
stopping distances appreciably.
• DO NOT allow anyone to ride on the trailer.
• Make wide turns when towing a loaded trailer, avoiding both sharp turns and U-turns. Turning
too sharply can cause damage to the trailer and/or the tow vehicle.
• CAUTION: Care must be taken when backing up the trailer; only back up the trailer on a
straight path. The trailer could jackknife if allowed to turn off the straight path while backing
up and possibly cause severe damage to the trailer and the tow vehicle.
• When towing a trailer over long distances, stop and check the tightness of all connections,
lights, and running gear every 100 miles.
• Carry emergency flares, and a fire extinguisher if required for operation in your state.
• It is recommended to carry extra bulbs and fuses if you are towing the trailer at night or over
any great distance.
• Whenever possible, park the trailer on a flat, level, paved surface and chock both tries to
keep the trailer from unexpectedly moving.
COUPLER OPERATION
1. Temporarily remove the “R” pin and safety pin. Then, pull up on the trigger and lift up on the
handle. NOTE: To reduce friction between the hitch ball and coupler, apply a layer of heavy
weight grease over the hitch ball.
2. With assistance, place the trailer coupler over the vehicle’s hitch ball and pull back on the
trigger and push down on the handle until the trigger locks in the slot.
3. Pull up and down on the coupler to make sure the hitch ball fits snuggly in the coupler. There
should be no play between the hitch ball and coupler.
IMPORTANT: If there is play, tighten the adjustment nut (shown below, right) until no play is
present – after unlocking the handle, the nut retaining plate (holding the adjusting nut in
place) needs to be pressed back while the nut is tightened. After the nut is tightened, the
retaining plate needs to be fit in place against the flats of the nut to prevent it from moving.
This adjustment should be done by two people. If the adjustment nut is too tight, the handle
will not lock.
After an adjustment of the nut, repeat steps 2 and 3 to properly attach the hitch and coupler.
4. Replace the safety pin and the “R” pin.
12 of 15

40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
Parts Diagram & parts list
14 of 15
Replacement Parts
• For replacement parts and technical questions, please call Customer Service at
1-800-222-5381.
• Not all product components are available for replacement. The illustrations provided are a
convenient reference to the location and position of parts in the assembly sequence.
• When ordering parts, the following will be required: Model Number, Serial Number/Lot Date
Code, and Description.
• The distributor reserves the rights to make design changes and or improvements to product
lines and manuals without notice.
Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser
only ("You'' or “Your”) that the Ultra Tow product purchased will be free from material defects in
both materials and workmanship, normal wear and tear excepted, for a period of one year from
date of purchase. The foregoing warranty is valid only if the installation and use of the product
is strictly in accordance with product instructions. There are no other warranties, express or
implied, including the warranty of merchantability or fitness for a particular purpose. If the
product does not comply with this limited warranty, Your sole and exclusive remedy is that We
will, at our sole option and within a commercially reasonable time, either replace the product or
product component without charge to You or refund the purchase price (less shipping). This
limited warranty is not transferable.
Limitations on the Warranty
This limited warranty does not cover: (a) normal wear and tear; (b) damage through abuse,
neglect, misuse, or as a result of any accident or in any other manner; (c) damage from
misapplication, overloading, or improper installation; (d) improper maintenance and repair; and
(e) product alteration in any manner by anyone other than Us, with the sole exception of
alterations made pursuant to product instructions and in a workmanlike manner.
Obligations of Purchaser
You must retain Your product purchase receipt to verify date of purchase and that You are the
original purchaser. To make a warranty claim, contact Us at 1-800-222-5381, identify the
product by make and model number, and follow the claim instructions that will be provided. The
product and the purchase receipt must be provided to Us in order to process Your warranty
claim. Any returned product that is replaced or refunded by Us becomes our property. You will
be responsible for return shipping costs or costs related to Your return visit to a retail store.
Remedy Limits
Product replacement or a refund of the purchase price is Your sole remedy under this limited
warranty or any other warranty related to the product. We shall not be liable for: service or labor
charges or damage to Your property incurred in removing or replacing the product; any
damages, including, without limitation, damages to tangible personal property or personal
injury, related to Your improper use, installation, or maintenance of the product or product
component; or any indirect, incidental or consequential damages of any kind for any reason.
Assumption of Risk
You acknowledge and agree that any use of the product for any purpose other than the
specified use(s) stated in the product instructions is at Your own risk.
15 of 15
Q’ty
2
2
1
1
2
32
42
42
4
4
4
8
2
4
4
2
2
1
Part No.
1
2
3
4
5
6L
6R
7
8L
8R
9
10
11
12
13
14
15
16
17
Description
Side Rails
Cross Members
Tow bar
Front Spring Hangers Shorter
Rear Spring Slide Plates Longer
Left Tail Light Bracket
Right Tail Light Bracket
License Plate Brake
Left Tail Light
Right Tail Light
Slipper Springs
Axle
Spring Plates
M10 U-Bolts
Hub Assembly
Tire/Wheel Assembly
Bearings
3/4" Flat Washers
Castle Nuts
Q’ty
2
3
1
2
2
1
1
1
1
1
2
1
2
4
2
2
4
2
2
Part No.
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
Description
Dust Caps
Cotter Pins
Coupler
Safety Chain
Side Running Lights
M10x25Bolts
￠10 Flat Washer
M10 Nylon Nuts
M14x80 Bolts
￠14 Flat Washer
M14 Nylon Nuts
M12x1.25Lug Nuts
M10x90 Bolts
M4x12Self Tapping Screw
M6 Padded Nuts
Fenders
Grease Fitting
Wire

40" X 48" ALUMINUM UTILITY TRAILER KIT
Owner’s Manual
Governing Law
This limited warranty gives You specific legal rights, and You also may have other rights which
vary from state to state. Some states do not allow limitations or exclusions on implied warran-
ties or incidental or consequential damages, so the above limitations may not apply to You.
This limited warranty is governed by the laws of the State of Minnesota, without regard to rules
pertaining to conflicts of law. The state courts located in Dakota County, Minnesota shall have
exclusive jurisdiction for any disputes relating to this warranty.
Distributed by
Northern Tool + Equipment Co., Inc.
Burnsville, MN 55306
NorthernTool.com
Made in China
