Humbaur 1000 Series User manual

GENERAL CAR Program
PART 1
OPERATING MANUAL
humbaur.com
1000 - 8400 SERIES EN

Humbaur GmbH
Mercedesring 1
86368 Gersthofen
Germany
Tel. + 49 821 24929-0 l [e-mail]
Fax + 49 821 249-100 l www.humbaur.com
Please enter the name of your dealer.
Please enter your trailer type and the identification.
Please enter the manufacturer and type of trailer components installed.
You will find the dimensions / technical data of your trailer in the
vehicle documents: Registration certificate part 1 & part 2
►►
WHD
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
Your trailer:
Model ___________________________________________________
Type (abbreviation) ____________________________________________
Numberplate __________________________________________________
VIN
Your dealer:
Name ___________________________________________
Address ___________________________________________
Tel. _______________________________________________
E-mail ___________________________________________
Trailer components:
Axles(s)
(Type / manufacturer) _______________________________________
Overrun device
(Braked trailer) ______________________________________________
Ball trailer coupling __________________________________________
(Type)
Drawbar ____________________________________________________
(Type)

Your entries
1
Owner 1
First name, Last name
Date of birth
Address
Street, House no.
City
Telephone
Date (from - to)
Owner 2
First name, Last name
Date of birth
Address
Street, House no.
City
Telephone
Date (from - to)
Owner 3
First name, Last name
Date of birth
Address
Street, House no.
City
Telephone
Date (from - to)

Your entries
2
e.g. Special equipment
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
_____________________________________________

Contents
3
Notes on use
We would like to congratulate you on your new Humbaur
trailer and thank you for the trust you have placed in us.
This operating manual will help you use the vehicle for
many years and will allow you to help yourself should any
problems occur.
This operating manual must be carefully read, understood
and complied with in full by anyone who is responsible for
the Humbaur GmbH vehicle and its modules.
Humbaur GmbH accepts no liability for damage or failures
which arise from disregarding this manual!
Pleasereadandcomplywiththisoperatingmanual
with all instructions, warnings and tips before
driving for the first time!
Please note that all illustrations are representative
and may differ from the actual appearance /
equipment.
Please read and comply with the operating
manuals for all components, such as axles,
supports,electricalcablewinch,electricalhydraulic
unit, additional equipment, etc.!
PART 1
This operating manual “Trailers up to 3.5 to
(Part1- General)” is intended for you as the user of a ready-
to-use trailer.
It provides detailed steps on how to handle a trailer
up to 3.5 to.
It contains all relevant details on operation, care / cleaning,
maintenance, troubleshooting and decommissioning /
disposal of a Trailer up to 3.5 to.
PART 2
You will find all the additional information on special
features (e.g. Accessories) in a separate operating manual
(Part 2) for your respective trailer.
You will find the special operating manual (Part 2) on the
Internet at www.humbaur.com under the tab: Downloads
– Operating manuals.
Complete documentation
Thecompletetechnicaldocumentationispartoftheproduct
and should be kept in the towing vehicle for reference
purposes at all times.
Key details for the handling, operation and the requisite
care and maintenance of the trailer are referred to in this
operating instruction manual, and errors can only be
avoided and trouble-free operation guaranteed if you are
familiar with them.
Errors excepted. The manufacturer:
Humbaur GmbH
Mercedesring 1
89368 Gersthofen (Germany)
reserves the right make technical changes to the design,
equipment and accessories with respect to the information
and illustrations in the operating manual.
No claims whatsoever can be derived from the information,
illustrations and descriptions.
Obligations of the operator
The trailer may only be operated in perfect condition.
Ensure that the operating manual is included with the trailer
e.g. if it is sold.
Only utilise trained or instructed personnel.
Ensure that the operating manual is complied with
in all life cycle phases of the trailer and that the
prescribed personal protective equipment (see
“Personal protective equipment” on page 13) is
worn.
Provide the requisite operating and auxiliary materials.
Thisoperatingmanual ispartofthe productandalsoserves
as a CHECK LIST for the regular inspections of your trailer.
User group / personnel qualification
The trailer should only be operated by users with the fol-
lowing prerequisites and knowledge:
Be in possession of a valid driver's license which
includes towing a trailer.
Be in a healthy physical state (without any limitations,
e.g. wheelchair user).
Practical experience with towing (e.g. initiating braking,
manoeuvring backwards).
Knowledgeofload securing/securetransport ofarange
of goods.
Knowledge of the German Road Traffic Act (StVO) and
German Road Traffic Licensing Regulations (StVZO).

Contents
4
Keyword index
Use the keyword index from page 5 to search for
specific topics.
Refer to the technical documentation of the
installed components for additional information.
1 Safety
– from page 7
– Safety-relevant information
– Read this chapter before driving for the first time
2 General information
– from page 19
– Information on how to identify the trailer
– Trailer components and accessories
3 Operation
– from page 29
– Information on loading and unloading
– Correct load distribution
– Securing against rolling away / parking
4 Chassis
– from page 73
– Operating the chassis
– Supports, coupling, overrun brake
5 Body
– from page 101
– Operating the body
– Drop sides, bodies
– Load-securing elements
6 Electrical system
– from page 133
– Lighting system
– Plug connections / configuration
– Interior lighting
– Power supply, external
7 Testing, care and maintenance
– from page 143
– Maintaining operational safety
– Regular maintenance
– Necessary cleaning, care
8 Troubleshooting guide
– from page 183
– Service addresses
– Self-help in the event of a problem
9 Proof of inspection
– from page 193
– Initial inspection / handover inspection
– Enter inspections

Keywords
5
–
230 Volt mains connection ................................ 142
A
Accessories
Bodies / covers.............................................. 28
Action in the case of faults ................................ 184
Address
Manufacturer .................................................. 3
B
Ball coupling ................................................... 68
Bicycle stand.................................................. 128
Body............................................................. 101
C
Cable / parking socket...................................... 135
Calculate cargo bed / volume.............................. 23
CE declaration of conformity............................... 21
Chapter
Body......................................................... 101
Chassis....................................................... 73
Electrical system........................................... 133
General information......................................... 19
Operation ............................................... 29, 65
Proofs of Inspection ....................................... 193
Safety........................................................... 7
Testing, care and maintenance .......................... 143
Troubleshooting guide..................................... 183
Chassis
Handling...................................................... 73
Checking the wheels / tyres............................... 150
Tyre pressure............................................... 152
Tyre size .................................................... 152
COC-Certificate of Conformity............................. 22
Conditions for operating a trailer............................ 8
Contact
Address Humbaur GmbH................................. 184
Humbaur Service Partners ............................... 184
Parts logistics............................................... 184
Technical customer service .............................. 184
Cover net ...................................................... 130
D
Departure check ............................................... 31
Disposal
Components, operating materials ....................... 182
Drawbar load (s)............................................... 46
Driving with the towing vehicle and trailer............... 29
Drop sides..................................................... 102
E
Electrical supply.............................................. 134
Electrical system............................................. 133
maintain..................................................... 169
Environmental pollution
Toxins ....................................................... 182
Explanation of warning signs
Important pictograms........................................ 14
Personal protective equipment............................. 13
Signal words.................................................. 12
F
Flat cover...................................................... 115
Side wall extensions....................................... 116
Front drop side extension ................................. 111
G
General information........................................... 19
General inspection / safety check....................... 144
Greases........................................................ 160
Gross weight / mass.......................................... 46
H
Hand brake / Parking brake................................. 59
Handling
Body......................................................... 101
Chassis ....................................................... 73
Height-adjustable drawbar (HV) ........................... 87
H-frame ........................................................ 112
High-pressure cleaner...................................... 176
Hydraulic pumps............................................... 92
Electric pump with emergency hand pump............... 93
Manual pump................................................. 93
I
Instructions for use Operating manual.................... 3
J
Jockey wheel................................................... 74
K
Keywords......................................................... 5
L
Lashing material............................................... 51
Licensed to be driven at 100 km/h...................... 158
Lighting system .............................................. 134
Lights
Rear light assemblies ..................................... 140
Load capacity................................................... 46
Load securing for transport ................................. 49
Locks ........................................................... 104
Lubrication
Central lubrication ......................................... 160
M
Maintenance
Automatic jockey wheel................................... 161
Ball coupling................................................ 161
Changing the wheels...................................... 155
Check wear on brake pad ................................ 168
Electric system / lighting.................................. 169
Electric systems ........................................... 169
Hand brake................................................. 162
Height-adjustable drawbar ............................... 163
Jockey wheel............................................... 162
Lubrication.................................................. 160
Numberplate light “LED".................................. 172
Overrun / deflection device............................... 163
Overrun brake, wheel brake.............................. 167

Keywords
6
Rims......................................................... 151
Side marker lights.......................................... 172
Supports .................................................... 166
Tandem compensator / brake cables ................... 163
Towing ring ................................................. 164
Turntable (fifth wheel) ..................................... 165
Tyres/wheels ............................................... 150
Maintenance / Repair....................................... 144
Maintenance intervals
One-off maintenance work......................... 147, 148
Maintenance of axles / wheels ........................... 144
Maintenance regime ........................................ 147
Mandatory signs .............................................. 13
Manoeuvring................................................... 55
Manufacturer..................................................... 3
Mass of trailer (own mass) ................................. 46
Materials / surfaces ......................................... 177
Motorcycle stand............................................. 129
O
Operating materials
disposal ..................................................... 182
Operation .................................................. 29, 65
Trailer safety................................................. 65
Optional accessories......................................... 26
P
Plug
13-pin (DIN ISO 11446)................................... 134
7-pin (DIN ISO 1724)...................................... 134
Adapter plug................................................ 136
Plug configuration
13-pin........................................................ 138
7-pin ......................................................... 137
Plug connection
Charging lead (battery).................................... 139
Prohibition signs .............................................. 13
R
Rail .............................................................. 114
Ramps for vehicles........................................... 94
Retrofitting clamping device................................ 67
S
Safety.............................................................. 7
Safety components.......................................... 145
Securing elements ............................................ 68
Securing with snap hook..................................... 72
Sources of danger
for tippers..................................................... 11
in the body area.............................................. 11
in the chassis area........................................... 11
Spare wheel................................................... 153
Steam cleaner................................................ 176
T
Tarpaulin cover / roofbow ................................. 119
Edscha cover............................................... 126
Sliding tarpaulin............................................ 125
Technical data.................................................. 22
Main dimensions............................................. 23
Testing, care and maintenance.......................... 143
Text signs........................................................ 12
Tie-down options .............................................. 49
Tie-down points................................................ 50
Tightening torques
Screw connections ........................................ 146
Toolbox........................................................... 97
Towing connection ............................................ 87
Traffic signs..................................................... 14
Trailer load towing vehicle................................... 46
Trailer materials.............................................. 177
Trailers
Commissioning............................................... 30
decommissioning .......................................... 182
disposal ..................................................... 182
Load distribution ............................................. 46
Load securing in general ................................... 46
Parking........................................................ 56
Securing (braked)............................................ 70
Securing (unbraked)......................................... 69
Troubleshooting
Axles, tyres / wheels ...................................... 188
Ball coupling................................................ 187
Braking system............................................. 186
Electrical system........................................... 186
Gas pressure damper, shock absorber................. 189
Load / Road handling ..................................... 185
Turntable trailer (articulated drawbar).................... 90
Type plate....................................................... 24
Components.................................................. 25
U
Use
Foreseeable misuse.......................................... 9
Intended ....................................................... 8
V
Ventilating / drying the inside............................. 177
VIN - vehicle identification number........................ 22
W
Warranty......................................................... 10
Wheel chocks .................................................. 57
Wheel shock absorbers.................................... 159
Wheels / tyres.................................................. 99
Wood/aluminium cover..................................... 127

1
7
Safety

1Use
8Safety
Intended use
HUMBAUR vehicles and vehicle bodies are constructed in
accordance with the latest state of technology and
recognisedsafetyregulations.Ifnotused as intended could
pose a risk to the user of third parties and could result in
material damage.
HUMBAUR vehicles and vehicle bodies are manufactured
solely for prescribed transport applications in accordance
with carriage regulations.
Intended use includes complying with regulations,
descriptions and information providing in this operating
manual and with any third-party supplier operating and
maintenance instructions.
Ensure you ask Humbaur GmbH or any HUMBAUR
authorised workshop before making any retrospective
changes to your HUMBAUR vehicle or vehicle body.
Only attach any accessory components to your HUMBAUR
vehicle or vehicle body after consulting Humbaur GmbH or
a HUMBAUR authorised workshop.
Regularly presenting the trailer for a general inspection and
safety tests carried out by qualified personnel and proof of
this are a prerequisite for driving it on public roads.
The operator / user of the trailer is responsible for regular
care / cleaning and maintenance.
HUMBAURvehicles/vehiclebodiesallhaveaVIN.
Ifyou haveanyqueriesandwhenplacingorders for
spare parts, you should always quote the VIN!
The manufacturer Humbaur GmbH rejects any liability for
any damages incurred by non compliance - the user bears
the risks for this alone.
Permitted are:
– Transporting goods.
– Operation with a permitted vehicle and a permitted
coupling unit.
– Only operate if in perfect technical condition.
– Comply with all warning / safety notices on the trailer
and in the complete product documentation (operating
instructions, licensing papers, etc.)
– Driving with a properly secured load.
The driver of the towing vehicle is responsible for
securing the load and the equipment for load securing.
– Driving while complying with the max. permissible top
speed by law as well as a suitable speed for bad road or
weather conditions.
– Loading and unloading in a secured area or with
additional safeguarding measures suitable for public
roads.
– Operating within the permissible gross weight
(See information in registration certificate part II).
– Operating with even weight distribution of load.
– Securing the trailer against rolling away when parked.
– Regular care / cleaning of your trailer removing dirt /
foreign bodies.
– Regularly presenting your trailer for technical
examination / inspection.
– Complying with the maintenance and repair work as
specified by the manufacturer.
Thefollowingconditions for operating a trailer up to
3.5 to within the context of “Intended use” must be
met:
1. Trailer licensing
– Licensing is country-specific.
– As a general rule, you need to insure your trailer and get
a permit to use it on public roads.
2. Driving license for driving with a trailer
– Depending on the individual country, it may be
necessary to have a specific driving license to drive with
a trailer.
Find out about the specific conditions in your country.
3. Presence of vehicle documents and type plate
– Carry the vehicle documents for your trailer with you.
Check that the type plate is in place.
4. Periodic examination / general inspection
– The regulations on a general inspection are country-
specific. Please find out,
- when a general inspection is required and
- where you can have a general inspection carried out.
– Carry out regular maintenance / repair.
5. Driving at a speed of 100 km / h (in Germany)
– A special permit is required for driving at a speed of
100 km / h.
You will find information about this at
www.humbaur.com/ Useful information.

Use
9Safety
1
Foreseeable misuse
Any use extending beyond the prescribed transport
applications is regarded as other than intended.
This applies to all models.
– Transporting people.
– Transporting animals is types of trailers not designated
for animal transport.
– Transporting hot materials (e.g. tar).
– Transporting goods which are subject to special
legislation and / or require special types of vehicle
(e.g. chemicals, foodstuffs, hazardous goods).
– Loading with a payload that is too heavy.
– Driving with poorly secured / unsecured load.
– Driving with a poor load distribution (one-sided, spot
loading).
– Drivingatanunsuitablespeedinbadweatheraswellas
on a bad road surface.
– Driving with vehicle body not closed (covers, drop side,
side wall extensions, tarpaulin, etc.).
– Drivingwithafaultylightingsystemormalfunctionofthe
lighting system.
– Exceeding the max. permissible axle / drawbar and
trailer load.
– Not reaching the minimum drawbar load
(negative drawbar load).
– Making constructional changes to the trailer not
approved or authorised by the manufacturer.
– Using unapproved spare parts or accessories.
– Removing the type plate or VIN on the trailer or making
them illegible.
– Exceeding the max. permissible top speed of 80 km / h
or 100 km / h respectively.
– Parking the trailer without taking safety precautions
against it rolling away, such as applying the hand brake,
using wheel chocks.
– Operating the trailer with visible wear of parts or
breakage of safety-relevant components and
accessories.
– Operating the trailer when it is damaged, which can
cause danger on public roads and could also lead to
personal injury.
– Passingonthetrailerwithouthandingovertheoperating
manual or providing an explanation of the known
residual risks.
– Maintenance of safety-relevant components, such as
brakes, drawbar, hydraulic system, etc. by a layperson.
As the manufacturer, we do not accept any liability
for personal injury or material damage caused by
foreseeable misuse.
Disclaimer
Any liability of the manufacturer becomes null and void if:
– the trailer and its components are altered without
authorization.
– Original parts or conversion parts / accessories
approved by Humbaur GmbH are replaced by other
components.
– retrospective changes have been made to the trailer
(e.g. new drill holes in the frame or the reboring of
existing drill holes in the frame). This is considered by
Humbaur GmbH to be a structural change, and the type
approval therefore becomes null and void.
– Non-approved accessories or third-party spare /
component parts which are not original HUMBAUR
parts are attached or installed. The type approval of the
trailer, possibly even the insurance cover, becomes null
and void.
– care and maintenance intervals prescribed by the
manufacturer are not complied with.
Any risks and liability exclusions resulting from this also
exist if:
– Acceptance inspections have been carried out by
inspectors / authorised experts of the technical
inspection authorities or officially recognised
organisations.
– Official approvals are available.

1Service and warranty
10 Safety
The warranty covers
Defects that occur during proper use of the trailer as specified,
or which are design related or can be attributed to material
faults.
Repairs carried out during the guarantee period do not extend
it. As the contracting party, the dealer is responsible for the
warranty.
Requirements
Original replacement parts must be used for repairs. Repairs
mustbe carriedout bya specialistworkshop.Themaintenance
instructionsand regulationsof themanufactureraslistedinthis
operating manual must be observed.
Defects must not be attributable to
–Non-compliance with technical and legal regulations listed
in this operating manual, improper use of the trailer of lack
of experience of the user.
–Unauthorised alterations to the trailer and the use of fittings
not approved by Humbaur GmbH. These will invalidate the
warranty.
– Non-compliance with the respective statutory
regulations.
The following are not defects
Each trailer is a hand-made product. Despite the greatest of
care, minor superficial traces which have no effect on the
intended use can occur during assembly. Stress cracks in the
surface(hairlinecracks) caused duringmanufacturecannot be
avoided.Thesehairline cracks havenoeffect on stabilityorthe
use of the trailer.
The small gap between the drop sides and loading bridge
required for it to work is also not considered to be a defect.
Polyester components are not 100% colour-fast. Here, too, UV
and weather effects can colour changes.
Rubber parts will degenerate when exposed to UV light; it is
also possible for small cracks to form or for the surface to fade.
Parts coated with the electrocoat process are not colour-fast.
They can fade as a result of UV irradiation.
Galvanised parts are not normally shiny as they lose their
bright finish after a short time. This is not a defect but rather a
desired effect, as full protection against rusting of the metal is
only guaranteed after oxidation.
Wood is a natural material. That is why despite the various
types of processing and coating, it can be subject to natural
weather-dependent expansion or shrinkage which can cause
tension. Wood grain and irregularities are normal for this
natural material and can appear on the surface. Colour
changes are also possible as a result of UV irradiation and
weathering effects. A manufacturing tolerance is specified for
the thickness of the wooden components used. Claims will not
be accepted for deviations within the tolerance.
As the trailers are not generally insulated, temperature
fluctuations can result in the formation of condensation under
tarpaulins and polyester covers. In this case, adequate
ventilation should be provided to prevent mould growth.
Furthermore, the trailers are not 100% watertight. Water
ingress at doors, flaps and windows is still possible, even with
extremely careful workmanship and the use of rubber seals.
The warranty will not be valid if
–The operating, maintenance, cleaning and inspection
regulations are not complied with for technical changes to
the trailer.
–In the event of independently added fittings and
superstructures which have not been approved by
Humbaur.
–In the event of overloading and improper use of the trailer.
–If non-original Humbaur replacement parts are used.
– If the safety instructions on the trailer are not observed.
–If the service intervals are not adhered to, including for
Humbaur-fitted parts such as the axle, brakes, drawbar,
hydraulic systems etc.
–In the event of incorrect surface treatment of the materials
used.
–In the event of continued use of the trailer even though
defects have already been detected and reported and the
use has been prohibited by the manufacturer until repairs
have been carried out.
–In the event of continued use of the trailer with known
defectswhere repairisnotpossibleor istime-consuming or
is only possible with significant additional expense and
reduced function.
The warranty does not include
–Expenditure for ongoing maintenance.
–Costs due to normal wear and tear or after not being used
for a long time.
–Faults that can be attributed to not treating the trailer as
specified.
–Defects that can be attributed to the use of non-original
Humbaur replacement parts.
–Defects as a result of an improper repair.
–Defects that can be attributed to structural alterations or
assembly work on the vehicle.
–Damagewhichcanbetraced backto snowandwater loads
on tarpaulin / plywood or poly bodies.
– The manufacturer reserves the right to make design
changes.

1
Check, adjust and secure before each journey
11Safety
Sources of danger
It is absolutely essential to comply with the following points:
– Coupling and uncoupling the trailer - prohibited to stand in
the danger zone
– Loadingandunloadingthetrailer -prohibited tostandinthe
danger zone
– Driving with unsecured support devices
– Driving with unlocked drop sides / doors / flaps / ramp walls
– Clearance heights on the route, while loading and
unloading
– Exceeding the permissible gross weight or one-sided over-
loading through incorrect loading
– Poorly secured or unsecured goods and / or body compo-
nents
– Reversing - keep an eye on the area behind the trailer
– Excessive turning when manoeuvring e.g. on turntable
trailers
– Overloading the trailer, axles and brakes
– Overstressing caused by fitting incorrect wheel and tyre
sizes
– Use of wheels with incorrect offsets, one-sided run-out or
centrifugal imbalance
– Overstressing as a result of reckless and inappropriate
driving or handling
– Impact and shock stress of the axles
– Speedinappropriate forthe roadconditions andthe loading
status of the trailer, especially around bends
– The parked trailer can roll away, tip or sink in on soft,
uneven ground
– Non-compliance with the conditions for driving with 100 km/
h permit
– Driving on terrain with steep inclines
– Loading / unloading of the trailer in an area with a steep
gradient
– Inadequate cleaning of the cargo bed after every use
For trailers which can be tipped / lowered
– Standing under an unsecured cargo bed
– Jerky braking during tipping / lowering process
– Driving with a tipped / raised cargo bed
– Tipping the cargo bed without adequately observing the
area at the rear / side
– Tippingouttheloadtooclosetoaslopeorexcavationpit
– Standing on a tipped / moving cargo bed
– Tipping the cargo bed on uneven, soft ground
– Tipping viscous load materials e.g. asphalt, soil, loamy
sand
– Tipping large rocks
– Tipping with an inclined combination
– Driving vehicles onto the cargo bed without paying
attention to the centre of gravity of the vehicle driving on
In the body area
Close and secure all body components, such as:
– Drop sides
– Tailgate / ramp door
– Doors / flaps
– Cover net / tarpaulin
– Toolbox
– Access ladder / folding step
– Ensure that the load distribution is balanced / even
In the chassis area
Note the following in general:
– Lock the coupling properly
– Check that the ball head coupling and the ball head
coupling are not damaged
– Establish the electrical connections
– Check the trailer lights, repair faulty lights
– Retract the support devices and lock them
– Check the tyres and rims for damage
– Check the tyre pressure, including the spare wheel
– Check the tightening torque of the wheel nuts
– In the case of a new trailer, re-tighten the wheel nuts
after 50 km and after the first journey with a load
– Secure the: spare wheel / spare wheel holder, wheel
chock
– Comply with the permissible gross weight
– Check that all plates and stickers are present and clean

1Signal words / warning signs / pictograms
12 Safety
Safety first!
Inthismanual, youareinformed aboutthedifferentdegrees
of risk as follows:
Signal words
DANGER
Possible risk with high level of risk
Notpreventing this risk would result in fatal orserious injury.

WARNING
Possible risk with medium level of risk
Not preventing this risk could result in fatal or serious injury.
CAUTION
Possible risk with low level of risk
Not preventing this risk could result in slight or minor injury.
NOTICE
Possible risk of material damage
Not preventing this risk could result in material damage.
General mandatory signs
Indicates information which must be noted and
complied with to ensure safe use.
Pass all warning and instructions on to other users or to the
support staff as well!
Text sign
You will find the following symbol in front of the text in the
manual:
(arrow) Call to action
– (line) List
1. (number) List of components
Warning signs used
The following warning signs may be used in this operating
manual and on the product.
Pay attention to these warning signs and in this case, act
with particular care.
Warning about danger points!
Be careful - people could be injured.
Risk of crushing!
For limbs such as: Hands / fingers / feet.
Risk of crushing!
For body / body parts.
Risk of falling!
Risk of electric shock!
Dangerous voltage.
Risk of impact!
Falling objects.
Burn hazard!
Hot surfaces.
Risk of suffocation!
Lack of oxygen.
Risk of chemical burns!
Leaking battery acid.
Risk of being poisoned!
Toxic materials.
Risk of injury!
Obstacles at head height.
Risk of slipping!
Wet surfaces.
Risk of tripping!
Obstacles on moving surfaces.
Risk of explosion!
Explosive operating materials.

Signal words / warning signs / pictograms
13Safety
1
Personal protective equipment
Wear the stipulated personal protective equipment (PPE)
for all the work described in this manual.
This includes the following:
Safety shoes, sturdy shoes
Protective gloves
Safety helmet
Safety goggles
High-visibility clothing, high-visibility vest
Protective mask, breathing protection
Hearing protection
Protective clothing
Mandatory signs
Keep to the following commands / calls for action for all the
work described in this manual.
Important note!
Note and comply with to ensure safe use.
Read instructions for use beforehand.
Wash hands thoroughly.
Disconnect from the mains before working on
components which conduct voltage.
Ensure air circulation.
.
Carry out work in 2-man operation.
Mandatory signs
Keep to these prohibitions.
Climbing up prohibited.
Reaching in prohibited.
Contact / touching prohibited.
Standing on surfaces prohibited.
Open ignition points prohibited,
e.g. cigar, cigarette lighter.
Spraying with water prohibited,
e.g. High-pressure cleaner.
Access prohibited for unauthorised persons.
Stepping between towing vehicle and trailer
prohibited.
Allowing trailer to run into towing machine
prohibited.

Signal words / warning signs / pictograms
1
14 Safety
Other important pictograms
Payattentiontothefollowingpictogramsforproperdisposal
as well as to provide first aid in an emergency.
Problem waste!
Disposal in household waste not permitted.
Risk of polluting the environment.
Proper disposal of old oil,
Do not dispose of old oil in the environment.
Proper disposal of old tyres,
Do not dispose of old tyres in the environment.
Immediately rinse eyes with plenty of water.
Seek medical advice.
Traffic signs regarding heights
Pay attention to the following important traffic signs on
height limits on public roads.
Max. vehicle height!
This height may not be exceeded.
Caution - Height limit at bridges / underpasses!
Tunnel - limited height!
Pay attention to the max. height stated.
m

1
General safety instructions
15Safety
Read / comply with prior to commissioning!
As the operator of a trailer, you are obliged to
comply with national and international health and
safety requirements.
– In Germany, the German Road Traffic Act (StVO) and
Product Safety Act (ProdSG) apply as well as their
regulations.
– Any additional unauthorised added structures on the
trailer can increase the potential risk.
– Only use original HUMBAUR spare parts and
accessories.
– Find out which accessories you are allowed to attach
without authorisation and what needs to be carried out
in a specialist workshop.
Furthermore, as a road user, you are obliged to
observeallnationalregulations for drivingavehicle
with trailer and to comply with your obligations as
the owner of a commercial vehicle.
– This includes carrying out regular maintenance, care
and periodically subjecting your trailer to a technical
general inspection.
Stickers on the product
Your attention is drawn to the residual risks on the trailer.
Pay attention to the instructions and comply with the
max. values / forces specified.
For people

WARNING
Children playing in the vicinity of your trailer
Trailersarenot toys!Childrenare unabletoproperlyassess
the risks associated with a trailer and could injure
themselves playing with the trailer.
Do not let children play unsupervised near your
trailer.
Keep children well away when manoeuvring with the
trailer.

WARNING
Not complying with safety / warning notices!
Ignoringsafety/warning notices andnotfollowingthe steps
of action can lead to accidents resulting in personal injury.
Incorrect operation can make you injure yourself and other
people.
Read the operating manual carefully and
completely.
Pay attention to all the safety advice and warning labels
on the product itself and warning notices throughout the
documentation.
Comply with the steps for handling.
VORSICHT
CAUTION
Nichteinhaltung der Stützlast
Unfallgefahr / Schlingergefahr!
X Verteilen Sie die Ladung so, dass keine
negative Stützlast entsteht bzw. die
max. zul. Stützlast eingehalten wird.
Noncompliance with vertical load
Risk of accident / skidding!
X When distributing the cargo, a negative
vertical load mustn’t arise and the max.
perm. vertical load has to be adhered.
620.00404_A
WARNUNG WARNING
Gefahr des Radlösens!
Lose Radmuttern führen zu Unfällen.
XRadmuttern nach 50 km
und nach jedem Radwechsel
nachziehen.
Danger of a loss wheel!
Loose wheelnuts result in accidents.
XCheck wheelnuts for thightness
after the first 50 km and after
each subsequent wheel change.
620.00037_C
WARNUNG WARNING
Unzureichende Beleuchtung
beim Be- und Entladen!
Erhöhte Unfallgefahr.
Sichern Sie den Anhänger mit
zusätzlichen Signaleinrichtungen.
Inadequate lighting during
loading and unloading!
Increased risk of accidents.
Secure the trailer with additional
signalling devices.
620.00038
WARNUNG WARNING
Hochgehobene Ladefläche!
Ladefläche kann herunterfallen.
XNicht unter gehobene Ladefläche
treten.
XLadefläche bei Wartung mit
Wartungsstütze absichern.
Elevated load area!
Load area may fall down.
XDon‘t step under elevated loading
area.
XSecure loading area with a support
during maintenance work.
620.00034
DIN Zurrpunkte
400 daN (kg)
min. 30 °
620.00031_B
Zulässige Stützlast
Permissible vertical load
max. 50 kg
620.00026_A

General safety instructions
1
16 Safety
While driving

WARNING
Excessive speed / speed not adapted!
The load could come loose and fall off - risk of snaking /
accidents!
Pay attention to the national regulations in your country
regarding permissible top speed.
Keep to the max. permissible top speed for car / trailer
combinations.

WARNING
Poor road / extreme weather conditions!
Iftheroadsurfaceisuneven, has potholes, or iftheweather
is bad, e.g. storm, snow, slipperiness, ice, hail, your trailer
could start snaking - risk of an accident!
Adapt your speed to the prevalent road and weather
conditions.

WARNING
Gusts of wind / side wind!
In the event of gusts of wind / side winds which can occur
near bridges, tunnels, cuttings through woods, sound
protection walls or when overtaking lorries, if you steer
sharplyitcouldcauseyourtrailertostartsnaking - risk of an
accident!
Slowly reduce your speed and adapt your driving to the
weather conditions.

WARNING
Unsecured / poorly secured load!
The load can shift during the trip and could unbalance the
trailer or could be directly thrown off the trailer.
Tie down the load before driving off.
Ensure that the load is adequately secured when taking
a break.
Pay attention to national regulations on load securing.

WARNING
Structure too high on the trailer!
Loading the trailer too high (load, accessories)
could be ripped off when driving through tunnels,
underbridges,throughunderpassesetc.-riskofan
accident!
Before driving off, make sure that the max. total height is
not exceeded.
Before driving into a tunnel, an underpass or towards a
bridge, pay attention to the traffic signs with the max.
permissible vehicle height.

WARNING
Objects on the trailer body!
Objects such as branches, ice, snow, etc. can be thrown on
the road during the journey – accident risk!
Remove all objects, such as branches, ice, snow, water
loads etc. from the body of the trailer.

WARNING
Worn tyre profile / incorrect tyre pressure!
The tyres can burst when driving along and the trailer will
start to break away. Breaking distances get longer - risk of
snaking / an accident!
Regularly check the tyres.
Check the tyre pressure, profile depth and condition of
the tyres.

WARNING
Loose wheel nuts / wheel bolts!
The wheel nuts / wheel bolts could come loose.
The trailer could lose a wheel - risk of snaking / an accident!
After the first 50 km, after the first drive with a load, and
every time after changing the tyres, tighten the wheel
nuts / wheel bolts.
Check that the wheel nuts / wheel bolts are tight at
regular intervals.
m
WARNUNG WARNING
Gefahr des Radlösens!
Lose Radmuttern führen zu Unfällen.
XRadmuttern nach 50 km
und nach jedem Radwechsel
nachziehen.
Danger of a loss wheel!
Loose wheelnuts result in accidents.
XCheck wheelnuts for thightness
after the first 50 km and after
each subsequent wheel change.
620.00037_C

General safety instructions
17Safety
1
CAUTION
Non-compliance with the drawbar load!
Exceedingthemax.permissibledrawbarload/notreaching
the min. drawbar load can cause accidents - risk of snaking!
Distribute the load so that no negative drawbar load is
created or respectively, that the max. permissible
drawbar load is complied with.
Do not exceed the max. permissible drawbar load of the
towing vehicle and the trailer coupling.
Observe the information on the maximum permis-
sible drawbar load in your vehicle papers and the trailer
coupling.
Observe the information on the maximum permissible
drawbar load in the COC papers, Section 19.
CAUTION
Worn trailer coupling!
A worn trailer coupling leads to poor road handling of the
trailer - risk of snaking!
Make sure that the coupling is not worn / deformed
before driving off.
Carry out regular maintenance of the coupling to prevent
wear.
CAUTION
Inadequate / faulty lighting!
It is difficult to see the trailer or it will not be seen in time by
other road users - risk of accident!
Before setting off, check that the lighting on the trailer is
working and is not covered by the load.
Remedy any defects to the lighting.
CAUTION
Driving without the safety cable / arrester cable
attached!
In the event of the trailer becoming detached or if the
coupling fails, the trailer will not be braked / caught.
Connect the safety cable / arrester cable to the towing
vehicle.
Pay attention to the national regulations on this.
During loading / unloading

WARNING
Inadequate lighting!
Whenloading/ unloading,thelightingon thetrailercouldbe
covered up - meaning the trailer is difficult for road users to
see (at dusk /in the dark) - risk of accident!
Make sure that road traffic safety is not impaired when
loading / unloading the trailer.
If necessary, use additional signalling devices, e.g.
signs, barriers.
VORSICHT
CAUTION
Nichteinhaltung der Stützlast
Unfallgefahr / Schlingergefahr!
XVerteilen Sie die Ladung so, dass keine
negative Stützlast entsteht bzw. die
max. zul. Stützlast eingehalten wird.
Noncompliance with vertical load
Risk of accident / skidding!
XWhen distributing the cargo, a negative
vertical load mustn’t arise and the max.
perm. vertical load has to be adhered.
620.00404_A
WARNUNG WARNING
Unzureichende Beleuchtung
beim Be- und Entladen!
Erhöhte Unfallgefahr.
Sichern Sie den Anhänger mit
zusätzlichen Signaleinrichtungen.
Inadequate lighting during
loading and unloading!
Increased risk of accidents.
Secure the trailer with additional
signalling devices.
620.00038

General safety instructions
1
18 Safety
When parking

WARNING
Unsecured trailer!
Thetrailercanstartmovingoutofcontroland could
injure people - risk of accident!
Secure the trailer against rolling away.
Place the wheel chocks under the wheels.
Apply the parking brake.
Park the trailer on ground which is as level as possible
(not on a slope).
Park the trailer so that it does not pose any further risks.
Secure the trailer against being used by unauthorised
third parties (anti-theft device).

WARNING
Standing / hanging trailer on its end!
The trailer could tip up and fall down.
People could be knocked / crushed.
Secure the trailer against falling over.
Tie the trailer to a solid wall.

WARNING
Trapped in the box body!
Risk of suffocation due to lack of oxygen.
Before locking closed bodies, make sure that no people
/ animals are inside them.
Open windows / hoods when spending time inside.
Where applicable, check that cooling units, heaters etc.
are switched off.
Pay attention to the sticky label on the inside.
620.00484
WARNUNG
Im geschlossenem Koeraufbau können Sie
wegen Sauerstomangel ersticken.
Sorgen Sie bei Aufenthalt im Innen-
raum für ausreichende Luftversorgung.
Erstickungsgefahr!
WARNING
Lack of oxygen can lead to suocation if
you are inside the box body.
Ensure adequate air supply when you
are inside the box body.
Risk of suocation!
