Ultra ULT40114 User manual

USB Display Adapter User’s Manual
1
1. Introduction
This USB Display Adapter enables you to connect one more monitor, LCD or
projector to a computer with a USB 2.0 port. For desktop users adding an extra
monitor via USB connection is easier than ever without having to open the
computer chassis to install an internal video card. Once the installation is done, the
USB-attached monitor soon wakes up. No function key hassle to swap a second
monitor.
With this handy adapter, you can enjoy many benefits brought by an add-on
monitor. The most obvious one is that you get more desktop area to have more
applications visible at one time. For example, you may work on one monitor while
your family watch video on the other. No more stacking windows within the
confines of a single display. Or you may span an application, e.g. spreadsheets,
across two displays. What’s more, the adapter is hot pluggable. If you are not using
the extra monitor, just unplug the adapter at any time; no reboot needed.
System performance is an important issue when using multiple monitors. Another
benefit of this adapter is that it uses little computer resource, ensuring users get
quality display without comprising computer performance.
VGA or DVI monitor
USB-enabled computer

USB Display Adapter User’s Manual
2
Applications
Office workstation
View your large spreadsheets across two screens with display continuity
Multitask more effectively without overlapping windows
Edit on one screen while surfing the Internet information on the other
On the road
Do multiple screen presentations without bringing another computer
Easily provide multiple screen exhibitions in a trade show
Graphics workstation
Use second display for palettes/tools
Get a panoramic view of large documents
Editing workstation
Type documents on one screen while viewing reference material on the other
Compare two documents simultaneously across two screens
Financial analysis
Have one monitor per data stream
View charts and live data at the same time
Entertainment
View videos/TV on one screen and reviews on the other
Get additional perspectives when playing games
Features
Add-on monitor, LCD or projector through a single USB 2.0 port
Supports up to 2 USB display adapters to work simultaneously
Plug & Play
Hot-plug; add or remove monitor without system reboot
Windows Vista compatible
Resumes from hibernation and suspend modes

USB Display Adapter User’s Manual
3
Package Contents
Before installation, please check the items in the package. The package should
contain the following items:
USB Display Adapter x1
Driver CD x1
USB Cable x1
Quick Installation Guide x1
DVI to VGA Adapter (Optional) x1
System Requirements
The minimum requirements for the PC are:
With CPU at 1.2GHz or higher processor clock. Intel Pentium/Celeron family,
or AMD K6/Athlon/Duron family, or compatible processor
256 MB of RAM
At least one USB2.0 port
30Mb of available disk space
Windows®2000 SP4, XP SP2 32-bit, Vista32-bit
Super VGA (800 x 600) or higher resolution monitor
To play DVD on the adapter-attached monitor, in addition to the requirements
above, the following requirements should also be met:
With dual core CPU at 2.0 GHz processor clock
The adapter screen resolution be set to 800x600 with 16bit color

USB Display Adapter User’s Manual
4
2. Installation
Follow the procedures below to install the driver and then connect the adapter:
1. Insert the provided driver CD into your CD-ROM drive. The setup program will
run automatically. If not, locate and double-click the Setup.exe file under the
Driver folder on the CD.
Notice for Windows Vista users:
Windows Vista users will encounter a User Account Control dialog box when
attempting to install a program. Enter an administrator password or click Allow
to start the installation.
When prompted with Windows Security dialog box, select Install this driver
software anyway.
Notice for Windows 2000 users:
If the following message appears, please download and install the required
patch first and then execute the Setup.exe file on the CD.
2. When the welcome screen appears, click Next.

USB Display Adapter User’s Manual
5
3. Select I accept the terms in the License Agreement and click Next.
4. Click Install to begin the installation.
5. Click Finish to complete the installation.

USB Display Adapter User’s Manual
6
6. If prompted to restart your computer, click Yes to restart or No to manually
restart later. Note that a reboot is always needed for a successful installation. If
the reboot prompt doesn’t appear, make sure to manually reboot your
computer.
7. Connect the adapter to your computer and monitor.
Connect the smaller end of the USB cable to the adapter. Then connect the
other end of the USB cable to an USB 2.0 port on your computer.
If your monitor is not yet connected to the adapter, make the connection and
power on your monitor.
For VGA model: Use a VGA cable (not
provided) to connect the VGA jack to a monitor
equipped with VGA input jack.
For DVI model: The equipped DVI-I (DVI-Integrated) connector transmits both
the digital and analog signals. This means it supports either of these two
connection types:

USB Display Adapter User’s Manual
7
•It can be connected to a DVI-D (digital) monitor using a DVI cable (not
provided)
•Or, it can be connected to an analog VGA monitor using the privided DVI-I
to VGA adapter and a VGA cable (not provided).
8. After you connect the adapter, Windows will automatically complete the
installation.
9. Once the installation is done, an extended screen will appear on the add-on
monitor.
For Windows Vista, if the add-on monitor is blank, please reboot your
system again.
If required, you can connect and disconnect the add-on monitor any time
without disconnecting the adapter from the USB port on your computer.
To change the display mode, see next chapter for instructions.
During the installation, it’s normal that the screen flicks black a couple of times.
Sometimes it takes time for the add-on monitor to show the video.

USB Display Adapter User’s Manual
8
3. Using the Adapter
Display Modes
There are several ways you can utilize the monitor attached on the adapter. The
add-on monitor can be configured to use either “mirror mode”, “extended mode” or
be the primary display as described in this section.
Extend Your Windows Desktop to Add-on Monitor (Default)
In this so-called “extended mode”, your display will be spread over the add-on
monitor(s). This mode allows you to perform multiple tasks more effectively without
overlapping windows.
Extended mode is the default setting. To set up the adapter to use or restore
extended mode, follow these steps:
1. Position the mouse anywhere on your computer desktop, right-click and select
Personalize > Display Settings on Vista or Properties > Settings on
XP/2000.
2. In the Display drop-down menu, select the option with the string “DisplayLink
Graphics Adapter”.
3. Check the Extend the desktop onto this monitor box on Vista or Extend my
Windows desktop onto this monitor box on XP/2000.
4. Drag the icons in the window at the top of the screen to match the physical
arrangement of your primary monitor and add-on monitor.

USB Display Adapter User’s Manual
9
The add-on monitor connected to the adapter may be identified as either "2" or
“3”, depending on your computer, although there may not be a total of 3
screens connected.
5. Click OK to close the settings screen.
Once the setting is done, to use your extended desktop, simply drag and drop
your open windows over to your second monitor. However, note that some
applications may not support display on the extended desktop.
Cursor disappeared ?
If you’re in extneded mode but the add-on monitor is not connected, the desktop
still pans to the add-on monitor and it’s possible that your cursor has moved to
the extended desktop so that you cannot find it on the primary display. To solve
the problem in such a case, connect the add-on monitor to the adapter or keep
moving your mouse to try or unplug the adapter first to restore the cursor.
Video and DVD Playback in Extened Mode
On Windows Vista with extended mode, it’s suggested that you run video or DVD
playback programs on your primary monitor instead of the add-on monitor to
ensure the playback performance.
a.
b.
c.

USB Display Adapter User’s Manual
10
Mirror Your Windows Desktop
This mode is referred to as “mirror” or “clone” mode. In this mode, your original
screen (the primary display) will be mirrored to the add-on monitor.
In mirror mode, the adapter will automatically select the settings (screen resolution,
color quality and refresh rate) for the add-on monitor. But you can manually adjust
the settings as required. However, the settings of the add-on monitor are limited by
that of the primary monitor. For example, even though your add-on monitor
supports a resolution of up to 1680x1050, you can only configure it to use
1280x1024 due to the primary monitor only supports a resolution of up to
1280x1024.
If you change the video output to extended mode and then want to switch back to
mirror mode, follow these steps:
1. Position the mouse anywhere on your computer desktop, right-click and select
Personalize > Display Settings on Vista or Properties > Settings on
XP/2000.
2. In the Display drop-down menu, select the option with the string “DisplayLink
Graphics Adapter”.
3. Uncheck the Extend the desktop onto this monitor on Vista or Extend my
Windows desktop onto this monitor on XP/2000.
4. Click OK to close the settings screen.

USB Display Adapter User’s Manual
11
Be the Primary Monitor
To make the add-on monitor the primary display:
1. Position the mouse anywhere on your computer desktop, right-click and select
Personalize > Display Settings on Vista or Properties > Settings on
XP/2000.
2. In the Display drop-down menu, select the option ends with DisplayLink
Graphics Adapter.
3. Check the This is my main monitor box on Vista or Use this device as the
primary monitor box on XP/2000.
On some PCs and laptops it is necessary to disable the main display (i.e.
uncheck the Extend the desktop onto this monitor or Extend my Windows
desktop onto this monitor box for the main display) as part of the same
settings change.
4. Click OK to close the settings screen.
The add-on monitor stays primary if the PC enters hibernate or suspend mode or is
rebooted. If the add-on monitor is unplugged, the main display becomes primary
again.
Adjusting Resolution, Color Depth and Refresh Rate
There are three components that make up the screen mode:
Resolution: In common usage, this refers to the number of pixels displayed on
screen horizontally and vertically.
Color Depth: This defines the number of different colors that can be shown on the
screen at the same time.
Refresh rate: Measures the speed that the entire screen is rescanned. Higher
frequencies reduce flicker.
Some monitors advertise the supported modes through the video connector. If this
is the case, the adapter identifies the supported modes from the monitor. If the
monitor does not advertise the supported modes, the adapter software chooses a
set of common screen modes for the monitor.

USB Display Adapter User’s Manual
12
The software supports the modes listed below.
Color
Depth
Resolution
Refresh rates available
at 16 bit color quality
Refresh rates available at
32 bit color quality
640x480
60 72 75
60 72 75
800x600
56 60 72 75 85
56 60 72 75 85
1024x768
60 75 85
60 75 85
1280x960
60 85
60 85
1280x1024
60 75 85
60 75
1360x768
60
60
1366x768
60
60
1368x768
60
60
1400x1050
60 75 85
60 75 85
1440x900**
60
60
1600x1200**
60
60
1680x1050**
59 60
59 60
*Note that interlaced modes are not supported.
**Only supported by 1600x1200 model.
About the resolutions and refresh rates available to users
The resolutions and refresh rates available to the user through Windows are a
comprise of the support from the following elements:
■ The USB display adapter
■ The primary monitor and the add-on monitor
■ The primary video card on your computer and installed drivers
Therefore, for example, if your monitor doesn’t support a resolution of
1600x1200, then 1600x1200 is not possible even you are using a USB display
adapter with 1600x1200 support. This ensures that the monitor cannot be put
into an unsupported mode, which might damage it.

USB Display Adapter User’s Manual
13
If cloning the primary display, the video component will try to use the preferred
monitor mode. In some cases, this may not be the most appropriate mode for the
cloned desktop. It is recommended that the primary display resolution be changed
to closer match the default resolution of the add-on monitor.
To configure the three components (resolution, color depth and refresh rate) of a
screen mode, follow these steps:
1. Position the mouse anywhere on your computer desktop, right-click and select
Personalize > Display Settings on Vista or Properties > Settings on
XP/2000.
2. In the Display drop-down menu, select the option ends with DisplayLink
Graphics Adapter.
3. To change the screen resolution or color quality, select those options on the
screen. Be sure to select one of the supported resolutions and color quality
numbers in the table above. For an add-on monitor, you can also select any
resolution or color quality supported by that monitor.
4. To change the refresh rate, click Advanced… and then click Monitor.
5. Select a refresh rate from the Screen refresh rate drop-down list and then click
Apply.
6. Click OK to close the settings screen.

USB Display Adapter User’s Manual
14
Effects on Vista Aero Interface
On Windows Vista, after you install the USB display adapter the original Vista Aero
interface (if enabled) will be disabled. You will be warned that that color scheme
has been changed when finishing the adapter installation. But if you unplug or
uninstall the adapter, the system will automatically resume the Aero Glass look.

USB Display Adapter User’s Manual
15
Standby and Hibernate, Shut Down and Restart
When the adapter is connected to a computer and an external monitor, if the
computer goes into standby or hibernate mode, the external monitor display goes
blank.
When the computer returns to an active state, the external monitor display keeps
the same settings it had before the computer went into standby or hibernate mode.
However, if the add-on monitor was set for extended mode, windows that were
previously on the external monitor will not move back to that secondary monitor.
Also, if the add-on monitor is in extended mode and the computer requires a login
after standby or hibernate mode, the login screen appears on the primary computer
monitor, not the external monitor.
If the computer is shut down, restarted and logged in, again the add-on monitor
returns to the same mode as it was before shutdown.
Disconnecting the Adapter
If the adapter is unplugged from the computer, the add-on monitor goes blank. All
windows and icons move to the primary screen.
On reconnection of the adapter, the adapter returns to the same mode as it was
before disconnection. However, windows and icons that were previously on the
screen will not be moved back.
Using Dual Adapters
Up to two adapters can be simultaneously attached to one computer. To use two
adapters:
1. Install the driver as described in the “2. Installation” section and connect the
first adapter to your computer.
The flip 3D effect will be
automatically disabled when the
adapter is in service. But if you
unplug or uninstall the adapter,
the system will automatically
resume the 3D effect.

USB Display Adapter User’s Manual
16
2. Then connect the second adapter to your computer. The system will
automatically complete the installation.
While two adapters are connected to a computer, in most cases both adapters
supports extended and mirror modes. The only exception is on Windows Vista
XDDM mode as described below.
Limitation for dual adapters on Windows Vista in XDDM mode: In this mode
one extended screen and one mirrored screen is supported. Only the first
connected adapter can be configured to use extended mode; the second adapter is
forced to use mirror mode. When you bring out the Windows display settings dialog
box, you will find that only one …DisplayLink Graphics Adapter (representing
your first attached adapter) is configurable.
What is Vista XDDM mode?
XDDM refers to Windows XP Driver Mode. It is a video card driver mode used in
some legacy computers that running the new generation Vista OS. It provides an
interface similar to Windows XP user Interface on Vista and one of its
characteristics is that it doesn’t support Windows Aero interface. To see current
display video driver mode, right-click Computer on the desktop and select
Device Manager. Then expand the Display adapters item.

USB Display Adapter User’s Manual
17
Uninstall the Adapter and Driver
If for any reason you want to uninstall the video adapter and its driver, please take
these steps:
1. Open the Control Panel and double-click Programs and Features on Vista or
Add or Remove Programs on XP/2000.
2. Select AN24X0 and click Uninstall or Remove.
3. Click Yes to confirm the removal. During the removal process a couple of DOS
windows will pop up.
4. Click Yes to restart your computer and then unplug the adapter now.

USB Display Adapter User’s Manual
18
4. Troubleshooting
Q1: The display on the add-on monitor is blank.
A: If the monitor power LED is green (in most cases), wait a moment for the
monitor to show the video as sometimes it takes time for the add-on monitor to
show the video. You can also reboot your system to try again. Also make sure the
computer is not in standby or hibernation mode, which will lead the add-on monitor
to be blank.
If the monitor power LED is red (in most cases), check if the connection is properly
made. If problem still exists, uninstall the driver, unplug the adapter and reinstall
the driver to try again.
Q2: The add-on monitor is flickering.
A: This is usually caused by a low refresh rate. To solve this problem:
In mirror mode, increase the refresh rate of the main monitor. This will in turn
increase the refresh rate of the add-on monitor.
In extended mode, increase the refresh rate of the add-on monitor.
Q3: When I play MPEG file by Windows Media Player on the extended monitor,
how come the display becomes abnormal when I switch it to full screen mode?
A: If your system is Windows XP SP1, we suggest you upgrade it to SP2 to solve
this problem.
Q4: When playing the video in full screen mode, the motion is not smooth.
A: Try the following tips to improve the smoothness of the movie playback:
•Reduce the resolution of the display to 640x480 or 800x600.
•Use the adapter in extended mode.
•Terminate any other CPU intensive applications running on the computer.
