Ultracool Ada35 User manual

Models

ADA35 ASA35

ADA50 ADA70

ASA50 ASA70

AUA50 AUA70

ADA50-12 ADA70-12

ASA50-12 ASA70-12

AUA50-12 AUA70-12

Circlethemodelofyourcoolerandrecord

theserialnumberbelow.

Read CarefullyAll Of This Manual Before

InstallingThe Unit

Encierrre con un circulo el modelo de su

enfriador y escribe el número de série abajo.

Lea Con Cuidado Todo Este Manual Antes De

Instalar La Unidad

Serial #

Número De Série

Safety Rules

1. Readinstructions carefully.

2. Electricalhook up should bedone by aqualifiedelectrician, so that

allelectrical wiring willconformto your localstandards.

3. AlwaysturnOFFPOWER and UNPLUGmotorandpump inside

thecooler before installingor performing anymaintenance.

4. Your cooler will run on either 120V or 240V A.C., single phase,

60 Hz (cycle) current.

5. Motor and pump have a grounded, molded plug and an automatic

thermaloverloadswitchwhichwillshutmotoroffwhenitoverheats.

Themotor willrestartautomatically when itcools down.

WARNING: To reduce the risk of fire or electric shock, do

not use this fan with any “solid-state fan speed control device.”

ReadAnd SaveTheseInstructions

Vea el Español en el interior.

110498 3-05

www.championcooler.com

Table Of Contents

SafetyInstructions....................................................................... 1

Operation..................................................................................... 2

InstallationInstructions ............................................................. 2-3

ElectricalWiringDiagram............................................................ 3

MaintenanceSection ................................................................ 3-4

Troubleshooting............................................................................ 4

Warranty ..................................................................................... 5

Specification Tables (Tablas de Especificaciones) .................... 5

Parts List (ADA35, ASA35) ................................................... 6-7

Parts List (ADA50, ADA50-12, ADA70, ADA70-12) .......... 8-9

Parts List (ASA50, ASA50-12, ASA70, ASA70-12) ..........10-11

Parts List (AUA50, AUA70, AUA50-12, AUA70-12) ...... 12-13

Instrucciones en Español ................................................... 13-16

EvaporativeCooling

Evaporative cooling is nature’s way of cooling. When air is moved

over a wet surface, water is evaporated and heat is absorbed. When

steppingoutofswimmingpoolwiththewindblowing,evaporativecooling

makes you feel cool, even though the air may be warm.

This unit works on the same principle. Air is drawn across wet filter

pads where the air is cooled by evaporation and then circulated

throughout the building. It is this combination of cooled air and the

movement of air over the skin which makes it feel cool.

Unlike refrigeration systems which recirculate the air, an evaporative

coolercontinually brings infresh air whileexhausting old air. You are

completelyreplacing the airevery 2 to4 minutesby opening windows

or doors or a combination of both. The air is always fresh, not stale,

laden with smoke and odors as happens with refrigerated air

conditioning.

Owner’s Manual

2110498

Wet

Module

Fig.1

Mounting

Bolts

Open Windows To ExhaustAir

An often misunderstood concept of evaporative cooling is the amount

of air that should be exhausted. How much should you open your

windows? The fact is that most people do not open their windows

enough. Thefollowing two methods willhelpyoudeterminetheamount

toopen your windows.

FirstMethod

You should allow an opening of at least 2 square feet (288 square

inches) for each 1000 CFM rating of your unit. Example: At 3320

CFM, model ADA 50 (1/2 hp) requires 6.6 square feet (950 square

inches) of opening (3320/1000 * 2 = 6.6). Multiply the number of

windowsby window width ininchesand divide this intothe numberof

squareinches required foryour size unit. This willgive you theheight

to open windows. In this example, four 36 inch wide windows should

be opened 6.6 inches each.

ChampionAirBalancingMethod

1. Take apiece oftissuepaper and cutit lengthwiseinto3 equal strips.

2. Turn yourcooleron high cool.

3. Open one window at least six inches wide in each room that you

want to cool.

4. Take thepiece of tissuepaper and putit up againstthe screen ofthe

openwindow furthest from thecoolerdischarge opening. Let goof

it. It will do one of three things.

IF It falls down.

THEN CLOSE all of the windows one inch and try step 4 again.

IF It plasters itself to the screen.

THEN OPEN all of the windows one inch and try step 4 again.

IF It stays on the screen lightly.

THEN PERFECT. You are done. Enjoy your cooler.

NOTES:

• When switchingto lowcool, youmustrebalance your home. Repeat

step 4.

• Once you balance your home you can cool some areas more than

othersby opening thosewindows more andclosingthe others bythe

same amount. Repeat step 4 to make sure your home is still air

balanced.

Motor

Clips

Yoke Adjustable

Yoke

Fig. 2

Blower

Housing

Motor

Pulley

Blower

Pulley

Fig.3

Screws

Fig. 4

Junction

Box

CAUTION: Donot screwor drillwithin

5 inches of the bottom of the wet module.

You could puncture the reservoir.

NOTE: You can separate the wet module

from the blower module by removing the 4

bolts (2 bolts in ADA35 and ASA35) from

the wet module side (Fig. 1)

MotorInstallation

•Install motor cord. For

typical 120V installation,

connect motor cord to mo-

torusing the followingcolor

code:Black -Hi,Red - Low,

White - Com., Green -

Ground.

•Mount motor. Install

blower motor in the motor

mount yokes, adjusting the yoke

if necessary. Fasten with the pro-

vided mounting clips (see Fig. 2).

NOTE: Adjustableyoke will have

to be reversed for 1 H.P. motors.

•Install pulley. Install the adjust-

able motor pulley so that it aligns

with the blower drive pulley (see

Fig. 3) and tighten set screw.

ElectricalInstallation

WARNING: Disconnect all electrical service that will be

used for this unit before you begin the installation.

•Remove junction box. The

electrical junction box is lo-

cated in the upper inside of

the left center post. Remove

the two screws and pull box

out from panel for access to

plug wiring (Fig. 4).

•Hook up electrical. Electri-

cal hook up should be done by a qualified electrician, so that all

electrical wiring will conform to your local standards. This unit is

suppled with a 120V pump. For 240V pump operation, a 240V

pump must be purchased. The fan and pump receptacles will

support both 120V and 240V installations. See the wiring dia-

grams for 120V and 240V installations on the following page.

IMPORTANT: When a single speed motor is used, do not use the

red lead on the receptacle and motor plug wiring. Tape off end of

both of the red leads.

CAUTION: Pump receptacle is for grounded evaporative

cooler pump only. Do not plug anything else into receptacle.

WARNING: Make sure that cooler cabinet is properly

grounded to a suitable ground connection for maximum safety.

Operation

To eliminate the delivery of hot air when starting the cooler, start the

pump only for the first few minutes, then turn on the blower motor.

These coolers may be used without water for ventilation purposes.

When outside air is cool (for example, at night) or when humidity is

high the water pump can be turned off.

A cooler can also be installed with a thermostat and attic exhaust

dampersto provide completelyautomaticoperation.

Cooler Installation

CAUTION: Make sure that the mounting surface is strong

enough to support the operating weight of the cooler when in

use. (For operating weight, see Specification Table.)

CAUTION: Never plug in cooler until installation is com-

plete and unit has been tested for rigidity.

WaterConnection

•Install overflow assembly. Remove nut and place nipple through

the hole in the pan, with the rubber washer between the pan and the

head of the drain nipple (Fig. 6). Screw on nut and draw up tight

against bottom of pan. Insert overflow pipe in nipple to retain

110498

Maintenance

WARNING : Before doing any maintenance be sure power

is off. At the time you remove either inspection panel be sure

to unplug motor and pump. This is for your safety.

SpringStart-Up

•Clean pads. Aclean pad is more absorbent, efficient and will give

morecool air. Annually, orwhen required, usingagarden hose with

nozzle, back wash to clean out the openings, then clean off the inlet

face any scale or other obstruction to the passages. Slight scraping

may be required to remove hardened scale.

•Change pads if necessary. The pads should be replaced after 5

years or if necessary. To change pads, remove top access panel,

remove grill, and disconnect water delivery tube. Remove water

distributorholder and liftoutmedia sections. Replace withthesame

type media. You can purchase them from your dealer.

IMPORTANT: In order to get the best performance from your

coolingpads, they mustbeinstalled properly. If you have purchased

a pad with two equal angles, the following instructions can be disre-

garded. Pads must always be installed with the steeper flute angle

sloping down towards the

air entering side (Fig. 10).

The reason is simple. The

steeper angle puts more

wateron the hot,dry, dirty

side of the pad where it is

neededmost. Italso coun-

teracts the tendency of the

air to push the water to-

ward the back of the pad.

water. The overflow pipe may be re-

moved to drain pan when necessary. A

gardenhose may bescrewed on the drain

nipple to drain water away from your

unit.

•Connect water supply line. Install a

sillcock and water valve on faucet as

shown by figure 7. Place the nut and

ferrule on the tubing and tighten the

nut until water tight. NOTE: Do

not connect the water supply to any

soft water applications.

•Installfloat valveand fillpan. Re-

fer to Fig. 8. Remove items 1, 2, 3,

and 4. Insert float body (5) through

hole in back post panel as shown.

Install washer (1) and nut (2).

Tighten to keep float from turn-

ing. Place nut (4) and ferrule (3)

on water supply line. Connect to

float fitting and tighten until wa-

ter tight. Loosen screw (6) and

adjust rod (7) until water level is

within 1” of top of reservoir.

Tighten screw (6). Slide float

shield (8) up over float body (5)

until it snaps into place.

working inside. This should be done for

your safety. Adjust pulley to a larger

diameter and readjust belt tension, plug

motor in, install inspection panels, and

retest amperage draw. Repeat this pro-

cess until correct amperage draw is

attained. Increasing motor pulley diam-

eter increases amperage draw.

Decreasing motor pulley diameter de-

creases amperage draw (see Fig. 9).

CAUTION: Do not operate cooler with larger amperage

draw than specified on motor plate.

NOTE: No attempt should be made to completely install this unit

without the aid of an electrician or someone familiar with testing

amperage draw. Failure to comply with these instructions may void

your warranty.

AmperageDrawAndBeltTension

Thisunit is equippedwith an adjustable motordrive sheave foradjust-

ing the blower wheel speed to the proper loading on different duct

systems. It is important that the motor drive pulley is adjusted to cor-

rectsize to assuremaximum air delivery withoutdamage to themotor.

Be sure to follow these instructions carefully.

•Adjust drive pulley. After the unit is completely installed, adjust

thedrive pulley tothe least diameterand adjust belttension. See the

maintenancesection for adjustingbelt tension.

•Start cooler. Install both inspection panels, start pump, and allow

to operate until pads are wet.

•Check amperage. With pads wet and unit started, check amper-

age draw with an amperage meter.

•Adjust pulley if necessary. If amperage draw is less than motor

rating, turn off electrical power and remove inspection panels (top

pan for modelsADA35 and ASA35). Unplug motor inside cooler,

this will protect you from someone turning on unit while you are

Decrease

Amperage

Fig.9

Rubber Washer

Overflow Pipe

Nipple

Bottom Pan

Nut

Fig.6

45°

15°

Entering

Air LeavingAir

Fig.10

Faucet

Water Supply

Valve

Sillcock

Ferrule

Nut

Fig.7

1234

Fig.8

Switch

Pump

Motor

Blower Motor

Red

White

Green

Black

Ground

Com.

= Wire Nut

Ground

Com.

Pump

Black

Red

White

Orange

Green

Orange

Brown

White

Blue/Black Blue/Black

White

Brown

Orange

Green

Orange

White

Red

Black

Pump

Com.

Ground

= Wire Nut

Com.

Ground

Black

Green

Orange

Red

Blower Motor

Pump

Motor To

Switch

Wiring Diagrams

120 Volts 240 Volts

4110498

•Check belt tension. A 3 lb. force

should deflect the belt 3/4 inches

(see Fig. 11). Readjust belt if

needed.

•Oil bearings. The blower bear-

ings and cooler motor in this unit

should be oiled with a few drops of

non-detergent 20/30 weight oil once each year. The motor does not

need oil if it has no oil lines for oiling. Motors that have no oil lines

are lifetime oiled at the factory and require no further oiling for the

life of the unit.

CAUTION: Do not over oil. Over oiling can cause motor burn

out,due to excessiveoil gettingintomotor winding.

•Cleanpump. Cleaningthe

pump is necessary once a

year at start-up. For your

safety, turn unitoffand un-

plug motor and pump.

Removethepump from the

mount slot. Remove the

bottom cover of the pump

as shown in Fig. 12. Clean

the pump and turn the im-

peller to ensure free

operation. Remove the pump spout and check for any blockage.

After cleaning, reinstall the cover onto the pump. Reattach the

pump to the mount in the cooler using the plastic retainer to ensure

that the pump will not overturn. Do not forget to replace the spout

and water delivery tube onto the pump outlet. The pump has

automatic reset thermal protection.

•Check bleed-off valve to be sure it is not clogged.

WinterShut-Down

•Drain water. Always drain all of the water out of the cooler and

watersupply line when notinuse for prolonged periods,andparticu-

larly at the end of the season. Keep the water line disconnected

from both the unit and water supply so that it does not freeze.

•Unplug motor and pump. When cooler is not used for extended

periodsunplug the motorandpump from insidecooler.

•Cover unit. To protect the life of the finish, a cover for the unit is

suggested in extended periods of non use.

By following the operating, installation,and maintenance suggestions

as outlined, you can get many years of efficient and satisfactory ser-

vice from your cooler. In the event additional information is desired,

your dealer will be more than gladto assist you in every possible way.

Problem Possible Cause Remedy

Failureto

start or no

airdelivery

Inadequate

airdelivery

withcooler

running

Water

drainingonto

roof

Mustyor

unpleasant

odor

1. No electrical power to

unit

• Fuseblown

• Circuitbreakertripped

• Electriccorddamage

2.Belttoolooseor tight

3.Motoroverheated

• Belttoo tight

• Blowerbearingsdry

• Motorpulley diameter

toolarge

4.Motorlocked

1.Insufficientairexhaust

2.Belttooloose

3.Padsplugged

4.Motor underloaded

1.Floatarmnotadjusted

properly

2.Overflow asembly leaking

1. Stale or stagnate water in

cooler

1. Check power

• Replace fuse

• Re-set breaker

• Replace cord

2.Adjustbelttension

3. Determine cause of

overheating

• Adjustbelt tension

• Oilblower bearings

• Adjustpulleyto

correctdiameter

4.Replace motor

1. Open windows or

doors to increase air

flow

2.Adjust belt tension or

replace if needed

3. Clean pads

4.Adjustpulley

1.Adjustfloat

2.Tightennutand

overflowpipe

1. Drain pan and clean

pads

TroubleshootingGuide

Problem Possible Cause Remedy

1.Lowvoltage

2.Excessivebelttension

3. Blower shaft tight or

locked

4.Bearingsdry

5.Motorpulleydiametertoo

largecausing motor

overload

1.Bearingsdry

2.Wheel rubbing blower

housing

3. Loose parts

1. Inadequate exhaust in

house

2. Pads not wet

• Padsplugged

• Dist.tubeholesclogged

• Pumpnot working

properly

1.Insufficientairexhaust

1.Checkvoltage

2.Adjustbelttension

3. Oil or replace

bearings(Unplug unit)

4.Oil bearings

5.Adjustpulleyso full

loadampereratingof

motorisnot exceeded

1.Oil bearings

2.Inspectand realign

(Unplugunit)

3.Tightenlooseparts

1. Open windows or

doors to increase air

flow

2. Check water

distributionsystem

• Cleanpads

• Clean

• Replace or clean

pump(Unplugunit)

1. Open doors or

windows

Motor

cycleson

and off

Noisy

Inadequate

cooling

Excessive

humidityin

house

Depress Here To

Remove

Fig.12

Fig.11

3 Lb.

3/4 Inches

110498

Limited Warranty

This warranty is extended to the original purchaser of an evaporative cooler installed and used under normal conditions. It does not cover

damages incurred through accident, neglect, or abuse by the owner. We do not authorize any person or representative to assume for us any other

or different liability in connection with this product.

Terms And Conditions Of Warranty

Lifetime Limited Coverage on water reservoir against any leakage due to defects in material. From date of purchase, if any original component

part provided by Champion Cooler fails due to defect in material or factory workmanship only, we will provide the replacement part as follows:

One year on the cabinet components.

Five years on the evaporative media.

Two years on the original blower motor if furnished by Champion Cooler.

Exclusions From The Warranty

We are not responsible for any incidental or consequential damage resulting from any malfunction.

We are not responsible for any damage received from the use of water softeners, chemicals, descale material, plastic wrap, or if a motor of a

higher horsepower than what is shown on the serial plate is used in the unit.

We are not responsible for the cost of service calls to diagnose cause of trouble, or labor charge to repair and/or replace parts.

How To Obtain Service Under This Warranty

Contact the Dealer where you purchased the evaporative cooler. If for any reason you are not satisfied with the response from the dealer,

contact the Customer Service Department: Champion Cooler, 5800 Murray Street, Little Rock, Arkansas 72209. 1-800-643-8341. E-mail:

info@championcooler.com.

This limited warranty applies to original purchaser only.

Motor Specifications / Especificaciones Del Motor

General Specifications / Especificaciones Generales

Models

Modelos

Weight (lbs.)

Peso (libras) Cabinet Dimensions (in.)

Dimensiones De La Caja (pulgadas) Duct Opening (in.)

Abertura De Ducto (pulgadas)

*Dry

Seco *Operating

Lleno Height

Altura Width

Anchura Depth

Profundidad Width

Anchura Height

Altura

ADA35, ASA35 120 169 22 9/16 34 40 13 5/8 13 5/8

ADA50, ASA50, AUA50 165 230 28 42 45 17 3/4 17 3/4

ADA50-12, ASA50-12 175 250 28 42 49 17 3/4 17 3/4

ADA70, AS70, AUA70 198 265 34 5/8 42 48 19 3/4 19 3/4

ADA70-12, ASA70-12 217 292 34 5/8 42 52 19 3/4 19 3/4

* Does not include motor weight. / No incluye el peso del motor.

Models

Modelos HP

C.V. Motor#

Motor-N° Speed

Velocidad Volts

Voltios *Amps

Amperaje Weight (lbs .)

Peso (libras) MotorPulley #

Polea Del Motor-N° Model

Modelo Drive Belt Part #

Correa - N°

ADA35 &

ASA35

1/3

1/2

110445

110447

110475

115

230

7.2

9.8

4.9

15 110279-001 ADA35 110209 (4L-430)

ASA35 110207 (4L-460)

ADA50,

ASA50,

AUA50,

ADA50-12 &

ASA50-12

1/3

1/2

3/4

110445

110447

110475

110449

110480

115

230

115

230

7.2

9.8

4.9

13.8

6.9

110279-002

110279-004

ADA50 110208 (4L-520)

110229 (4L-530) - 3/4 hp

ASA50 110212 (4L-570)

AUA50 110222 (4L-510)

ADA50-12 110208 (4L-520)

110229 (4L-530) - 3/4 hp

ASA50-12 110212 (4L-570)

ADA70,

ASA70,

AUA70,

ADA70-12 &

ASA70-12

1/2

3/4

110447

110475

110449

110480

110471

110458

115

230

115

230

115

230

9.8

4.9

13.8

6.9

110279-002

110279-004

110279-003

ADA70 110230 (4L-640)

ASA70 110213 (4L-670)

AUA70 110213 (4L-670)

ADA70-12 110230 (4L-640)

ASA70-12 110213 (4L-670)

* Amperage shown is from Nataional Electrical Code for high speed. / Amperaje listado es del código eléctrico nacional para la velocidad alta.

6110498

No.

N° Description / Descripción ADA35 ASA35

1. Top, Blower Section / Tapa De La Sección De La Rueda ................................................................... 222130-028 222130-028

2. Top, Wet Section / Tapa De la Sección De Agua ................................................................................. 222130-029 222130-029

3. Cabinet Wrapper, Blower Section / Envoltura De Caja De La Sección De La Rueda ....................... 322130-230 322130-130

4. Cabinet Wrapper, Wet Section / Envoltura De Caja De La Sección De Agua.................................... 222130-032 222130-032

5. Blower Housing / Caja De La Rueda ................................................................................................... 324106-104 324106-204

6. Cut-Off Plate / Placa Externa .............................................................................................................. 224002-003 224011-001

7. Blower Wheel / Rueda .......................................................................................................................... 12BW 12BW

8. Shaft, Blower Wheel / Eje De La Rueda .............................................................................................. 110182 110182

9. Pulley, Blower Wheel / Polea De La Rueda ......................................................................................... 110274 110274

10. Drive Belt / Correa................................................................................................................................ 110209 110207

11. Pulley, Motor / Polea Del Motor ........................................................................................................... 110279-001 110279-001

12. Motor / Motor........................................................................................................................................ **

13. Motor Mount Clips / Seguros Para Montar Motor .............................................................................. 314005-001 314005-001

14. Motor Mount / Montura Del Motor ...................................................................................................... 314003-021 314003-020

15. Electrical Cord, Motor (115V) / Cable Eléctrico Del Motor (115V) ...................................................... 110364 110364

15. Electrical Cord, Motor (230V) / Cable Eléctrico Del Motor (230V) ..................................................... 110372-2 110372-2

16. Bearings, Blower Wheel Shaft / Cojinetes Del Eje De La Rueda ........................................................... 110351 110351

17. Electrical Junction Box / Caja De Empalme .......................................................................................... 322009-001 322009-001

18. Receptacle, Motor / Toma De Corriente Del Motor ............................................................................. 110393 110393

19. Receptacle, Pump / Toma De Corriente De La Bomba......................................................................... 110361 110361

20. Retainer, Bearing Mount / Soporte Para La Montura De Los Cojinetes ............................................ 218002-008 218002-008

21. Water Distributor Housing / Caja Del Distribuidor De Agua .............................................................. 281035 281035

22. Media Shield / Pantalla Protectora Para El Medio Evaporativo ....................................................... 281025-005 281025-005

23. Water Distributor Assembly / Sistema Del Distribuidor De Agua ....................................................... 3D-26 3D-26

24. Water Distributor Bracket, Right / Soporte Para El Distribuidor De Agua, Derecha ........................ 222004-005 222004-005

24A. Water Distributor Bracket, Left / Soporte Para El Distribuidor De Agua, Izquierda ........................ 222004-003 222004-003

25. Evaporative Media / Medio Evaporativo .............................................................................................. 110103 110103

26. Support, Media / Soporte Para El Medio Evaporativo........................................................................ 222130-027 222130-027

27. Water Reservoir / Bandeja Acumuladora De Agua............................................................................. 281030 281030

28. Pump Mount / Montura De La Bomba ................................................................................................. 216003-008 216003-008

29. Pump Assembly / Bomba ....................................................................................................................... C60P-120 C60P-120

30. Pump Screen / Malla Para La Bomba.................................................................................................. 281001-001 281001-001

31. Pump Retainer / Sujetador De La Bomba ............................................................................................ 110866N 110866N

32. Float Valve / Flotador ........................................................................................................................... FL-BK FL-BK

33. Float Shield / Pantalla Protectora Del Flotador .................................................................................. 281005-001 281005-001

34. Over Flow Assembly / Montaje De Desagüe ....................................................................................... 3OA-3 3OA-3

35. Tube, Water Delivery / Tubo De Agua .................................................................................................. 110716 110716

37. Anti-Flattening Coil / Espiral Protectora .............................................................................................. 110847 110847

38. Grill / Parrilla ........................................................................................................................................ 224115-001 224115-001

39. Hobbs Polyester Pad / Filtro De Poliester ............................................................................................ 110119-1 110119-1

40. Support Bracket / Soporte Del Distribuidor......................................................................................... 220101-008 220101-008

* See the motor specification table on page 5. / Vea la tabla de especificaciones del motor en la página 5.

NOTE: Standard hardware items may be purchased from your local hardware store.

NOTA: Artículos de uso corriente pueden comprarse en la ferretería de su localidad.

Replacement Parts List / Lista De Piezas De Repuesto

When ordering parts, please be sure to furnish the following information on all orders. Failure to do so may delay your order. /

Al pedir piezas, incluya toda la información siquiente con su pedido. El no proporcionar toda esta información resultará en una demora.

1. Cooler model number / El modelo de su enfriador

2. Cooler serial number / Número de serie de la unidad

3. Motor HP / C.V. del motor

4. Description and part number / Descripción y número de pieza

5. Date of purchase / Fecha de compra

110498

Replacement Parts / Piezas De Repuesto

ADA35, ASA35

28 30

31 32

27 16

6 (ADA35)

24A

3 (ASA35)

6 (ASA35)

5 (ADA35)

3 (ADA35)

5 (ASA35)

8110498

No.

N° Description / Descripción ADA50 ADA50-12 ADA70 ADA70-12

1. Top, Cabinet / Tapa De La Caja .................................................................... 222130-035 222130-035 222140-018 222140-018

2. Top Access Panel / Panel Superior De Acceso ............................................... 222130-034 222130-045 222130-034 222130-045

3. Bottom, Blower Section / Base De La Sección De La Rueda......................... 322130-044 322130-044 322140-024 322140-024

4. Bottom, Wet Module / Base De La Sección De Agua .................................... 222130-037 222130-047 222130-037 222130-047

5. Front Panel / Panel Del Frente ....................................................................... 222130-011 222130-011 222140-008 222140-008

6. Inspection Panel / Panel De Inspección.......................................................... 222130-042 222130-042 222140-023 222140-023

7. Center Post, Right / Poste Central, Derecho .................................................. 222130-040 222130-040 222140-021 222140-021

8. Center Post, Left / Poste Central, Izquierdo .................................................. 222130-054 222130-054 222140-028 222140-028

9. Back Post, Right / Poste Trasero, Derecho .................................................... 222130-039 222130-048 222140-022 222140-025

10. Back Post, Left / Poste Trasero, Izquierdo .................................................... 222130-053 222130-056 222140-029 222140-030

11. Blower Housing / Caja De La Rueda ............................................................. 324130-201 324130-201 324140-201 324140-201

12. Cut-Off Plate / Placa Externa......................................................................... 224003-015 224003-015 224004-003 224004-003

13. Motor Mount / Montura Del Motor .............................................................. 314003-011 314003-011 314003-012 314003-012

14. Retainer, Blower Housing / Soporte Para La Caja De La Rueda .................. 318002-104 318002-104 318002-104 318002-104

15. Support, Media / Soporte Para El Medio Evaporativo .................................. 222130-008 222130-049 222130-008 222130-049

16. Grill / Parrilla ................................................................................................. 222130-060 222130-060 222140-044 222140-044

17. Electrical Junction Box / Caja De Empalme ................................................... 322009-001 322009-001 322009-001 322009-001

18. Motor Mount Clips / Seguros Para Montar Motor ...................................... 314005-001 314005-001 314005-001 314005-001

19. Float Shield / Pantalla Protectora Del Flotador ............................................. 281005-001 281005-001 281005-001 281005-001

20. Pump Screen / Malla Para La Bomba ............................................................ 281001-001 281001-001 281001-001 281001-001

22. Media Shield / Pantalla Protectora Para El Medio Evaporativo ................... 281025-001 281025-003 281025-002 281025-004

23. Water Distributor Housing / Caja Del Distribuidor De Agua ........................ 281038 281033 281038 281033

24. Water Reservoir / Bandeja Acumuladora De Agua ......................................... 281031 281032-001 281031 281032-001

25. Water Distributor Tube / Tubo Del Distribuidor De Agua............................. 3D-23 3D-23 3D-23 3D-23

26. Evaporative Media / Medio Evaporativo ....................................................... 110099 110108 110104 110109

27. Over Flow Assembly / Montaje De Desagüe ................................................. 3OA-1 3OA-1 3OA-1 3OA-1

28. Float Valve / Flotador ..................................................................................... FL-BK FL-BK FL-BK FL-BK

29. Pump Assembly / Bomba ............................................................................... C60P-120 C60P-120 C60P-120 C60P-120

30. Tube, Water Delivery / Tubo De Agua ........................................................... 310716 310716 310716 310716

31. Bleed-Off Kit / Equipo De La Válvula De Desahogo .................................... 310586 310586 310586 310586

32. Receptacle, Motor / Toma De Corriente Del Motor ...................................... 110393 110393 110393 110393

33. Receptacle, Pump / Toma De Corriente De La Bomba.................................. 110361 110361 110361 110361

34. Blower Wheel / Rueda .................................................................................... 16BW 16BW 20BW 20BW

35. Shaft, Blower Wheel / Eje De La Rueda ......................................................... 110183 110183 110183 110183

36. Pulley, Blower Wheel / Polea De La Rueda ................................................... 110275 110275 110276 110276

37. Drive Belt / Correa......................................................................................... ****

38. Bearings, Blower Wheel Shaft / Cojinetes Del Eje De La Rueda .................... 110351 110351 110351 110351

39. Motor / Motor ................................................................................................ ****

40. Pulley, Motor / Polea Del Motor .................................................................... ****

41. Electrical Cord, Motor (115V) / Cable Eléctrico Del Motor (115V) ............... 110372 110372 110372 110372

41. Electrical Cord, Motor (230V) / Cable Eléctrico Del Motor (230V) .............. 110372-2 110372-2 110372-2 110372-2

42. Water Distributor Bracket, Right / Soporte Del Distribuidor De Agua, Derecha... 222004-004 222004-006 222004-004 222004-006

42A. Water Distributor Bracket, Left / Soporte Del Distribuidor De Agua, Izquierda ... 222004-001 222004-002 222004-001 222004-002

43. Anti-Flattening Coil / Espiral Protectora ....................................................... 110847 110847 110847 110847

44. Pump Mount / Montura De La Bomba .......................................................... 216003-008 216003-008 216003-008 216003-008

45. Pump Retainer / Sujetador De La Bomba ...................................................... 110866N 110866N 110866N 110866N

46. Support Bracket / Soporte Del Distribuidor .................................................. 220101-007 220101-007 220101-007 220101-007

47. Hobbs Polyester Pad / Filtro De Poliester ..................................................... 110119 110119 110119 110119

* See the motor specification table on page 5. / Vea la tabla de especificaciones del motor en la página 5.

NOTE: Standard hardware items may be purchased from your local hardware store.

NOTA: Artículos de uso corriente pueden comprarse en la ferretería de su localidad.

Replacement Parts List / Lista De Piezas De Repuesto

When ordering parts, please be sure to furnish the following information on all orders. Failure to do so may delay your order. /

Al pedir piezas, incluya toda la información siquiente con su pedido. El no proporcionar toda esta información resultará en una demora.

1. Cooler model number / El modelo de su enfriador

2. Cooler serial number / Número de serie de la unidad

3. Motor HP / C.V. del motor

4. Description and part number / Descripción y número de pieza

5. Date of purchase / Fecha de compra

110498

Replacement Parts / Piezas De Repuesto

ADA50, ADA50-12, ADA70, ADA70-12

42A

10 110498

No.

N° Description / Descripción ASA50 ASA50-12 ASA70 ASA70-12

1. Top, Cabinet / Tapa De La Caja .................................................................... 222130-035 222130-035 222140-018 222140-018

2. Top Access Panel / Panel Superior De Acceso ............................................... 222130-034 222130-045 222130-034 222130-045

3. Bottom, Blower Section / Base De La Sección De La Rueda......................... 222130-038 222130-038 222140-020 222140-020

4. Bottom, Wet Module / Base De La Sección De Agua .................................... 222130-037 222130-047 222130-037 222130-047

5. Front Panel / Panel Del Frente ....................................................................... 322130-012 322130-012 322140-007 322140-007

6. Inspection Panel / Panel De Inspección.......................................................... 222130-042 222130-042 222140-023 222140-023

7. Center Post, Right / Poste Central, Derecho .................................................. 222130-040 222130-040 222140-021 222140-021

8. Center Post, Left / Poste Central, Izquierdo .................................................. 222130-054 222130-054 222140-028 222140-028

9. Back Post, Right / Poste Trasero, Derecho .................................................... 222130-039 222130-048 222140-022 222140-025

10. Back Post, Left / Poste Trasero, Izquierdo .................................................... 222130-053 222130-056 222140-029 222140-030

11. Blower Housing / Caja De La Rueda ............................................................. 324130-210 324130-210 324140-210 324140-210

12. Cut-Off Plate / Placa Externa ......................................................................... 224003-015 224003-015 224004-003 224004-003

13. Motor Mount / Montura Del Motor .............................................................. 314003-011 314003-011 314003-012 314003-012

14. Retainer, Bearing Mount / Soporte Para La Montura De Los Cojinetes ........... 218002-004 218002-004 218002-009 218002-009
