Ultravation SOLARIS SLX-PG5T User manual

• 1SolarisairIonizer
• 162conductorpowercord
• 1Inlinefuse
• 1Returnductmountingplate
• Oneindustrialmountingmagnet
• 2selftapping3/4”hexscrews
• 31/4”Phillipsheadscrewformagnet
mountingandoptionalmountingplate
• 2circularfoamgaskets
Warranty:
SolarisIonizorsareprotectedwiththeUltravationveyearwarrantyfromthefactoryaer
dateofconsumerpurchase.
iswarrantydoesnotincludedamagetotheunitfromaccident,misuseorimproper
installation.
Ifthisproductshouldbecomedefective,Ultravationwillelecttorepairorreplacethe
productfreeofcharge.Ultravationwillreturnrepairedorreplacedwarrantedproducts
pre-paidtothecustomer,providedthattheproductwasdeliveredpre-paid.
Ultravationshallhavenoresponsibilitiesforchargesincurredbythecustomerfor
installationorremovalofwarranteditems.Liabilityislimitedonlytothereplacementor
repairofthisproduct.
iswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrights,whichvary
fromstatetostate.Allreturnsmustbeaccompaniedbyareturnauthorizationnumber,
whichmaybeobtainedbycontactingUltravation,Inc.
Whole House Air Cleaning
Right
Angle
Straight-
rough
Support
Box Style
To further enhance your indoor air quality add an
Ultravation Solaris ProgressiveMedia Air Cleaner to
your Air Ionizer. We manufacture using
U.S. origin, galvanized steel . then coated with a heavy
duty powder coat nish, we back all of our ltration
equipment with a 10 year warranty. 
Ultravation®
Ion generator for HVAC systems
ModelSLX-PG5T
Package Contents:
Safety Precautions: 
Itisrecommendedthatthisunitbeinstalledandmaintainedbyatrained
technician.
Warning
RISKOFFIRE,ELECTRICSHOCKORINJURY
THISPRODUCTMUSTBEINSTALLEDWITHIN
THEHVAC
SYSTEMORDUCTWORK.
THEREARENOUSERSERVICEABLEPARTS
DISCONNECTPOWERWHILEINSTALLINGOR
SERVICINGTHISPRODUCT.
NEVERTOUCHTHEPROBESWHENENERGIZED!
NOTINTENDEDFOROUTDOORUSE
+
-
+
+
-
+
-
-

P.O.Box165,212IdealWay,Poultney,Vermont05764
Phone:1-866-GO-UV-AIR(468-8247)•Fax:802-287-9203
www.ultravation.com•[e-mail]
Copyright©2018UltravationInc.
DC-OM-SLX-PG5T REV12-2020
Made In
USA
Determining Installation:
eSolarisAirIonizerisuniquelydesignedtobeinstalledeitherinternallyorexternallyto
mostHVACsystems.Externalmountingistypicallydonewhenmetalreturnductingispres-
ent.InstallingtheOrionpriortoanysystemltrationensuresthatanychargedparticulate
matterwillcollectintotheHVAClter.
eAirIonizersystemmayalsobeinstalledinternallyonmostfurnaceandair-conditioning
systems.
einstallingcontractorstakeallinstallationandequipmentvariablesintoconsideration
whendeterminingthenalinstallationpoint.
Preparation for external mounting only:
UsetheexternaladapterplatewheninstallingtheAirIonizertometalductwork.Firstrotate
theprobes90degrees.Usethesuppliedselftapping10-32-1/4”screw.Attachingtheplate
ensuresthattherewillbenoairleakagefromtheductworkaertheinstallation.
External plate Rotate probes 90 degrees Attach bracket
Airowshouldpassoverbothprobesatthesame
timeforoptimumperformance
Installation Procedure
1. Disconnect main power to the HVAC system(turn applicable breakers o)
2. Determine a location on the duct, use a pencil to mark the location of both probes on
the duct work.
3. Drill 2 1/4 dia. holes. 4. Mount the Orion with supplied screws
5. Attach power cord
6. Attach leads of power cord to a Solaris IAQ Module (sold seperatly) or a 24 VAC
(min 10 va)transformer (polarity is not a concern).
7. Restore power
8. e Air IonizerWW has a white power indicator on the front of the label (ensure that
the led is illuminated).
IMPORTANT:
Probes should be a minimum of
1-1/2 inches from any metal.
Electrical Requirements
isproductoperateson24VAC
Itisrecommendedtoconnecttoadedicatedtransformer.
ifconnectingtotheSolarisIAQmodule-connectonlytothedesignatedport
labled“AirIonizer”
Preparation for internal mounting only:
AttachthemagnettotheAirIonizerwiththesupplied10-32-1/4”screw.Youcanalsouse
suppliedselftappingscrewstopermanentlymounttheOrion.
Important!Notethepositionoftheprobes
Notethelocationofthe
probesforproperairow
Installation procedure:
1. Disconnect main power to the HVAC system(turn applicable breakers o).
2. Remove access door to the equipment
3. Mount the Air Ionizer either with the magnet or with supplied screws
4. Attach power cord.
5. Attach leads of power cord to a Solaris IAQ Module (sold seperatly) or a 24 VAC
(min 10 va)transformer (polarity is not a concern).
6. Restore power
7. e Air Ionizer has a white power indicator on the front of the label (ensure that the
led is illuminated).
Maintenance:
Periodicallyitisrecommendedtocleanthebrushestoensureyearsofoptimumperfor-
mance.isisacommonpracticewhenchangingtheHVAClters.
Tocleanthebrushessimply,disconnectthepower.RemovetheAirIonizerifthereisno
immediateaccesstothebrushes.ebrushescanbecleanedusingcompressedairora
cleanragtodislodgeanyaccumulateddust.
Solaris is a registered trademark of
Ultravation, Inc.
