UMLo N3 User manual

MADE IN CHINA
Please do not hesitate to contact us
whenever you want, we are always here for you!
[email protected]
MODEL:N3/N3S

Important Safety Instructions -------------------
Product Parts List ------------------------------------
Product Overview -------------------------------------
Assembly and Combination ---------------------
Charging --------------------------------------------------
Using -------------------------------------------------------
Product Parameter -----------------------------------
Maintenance and Cleaning -----------------------
Troubleshooting --------------------------------------
Warranty Policy ----------------------------------------
1
3
4
5
6
7
7
8
10
11

Do not place the vacuum cleaner close to heat sources,
radiation, or burning cigarettes.
• Do not use the appliance to remove the following objects.
1. All liquids such as water and solvents.
2. Lime, cement, ash, and other Construction dust and garbage.
3. Hot objects, such as cigarette butts.
4. Sharp debris, such as glass shards, etc.
5. No flammable and explosive articles, such as gasoline or alcohol
products.
• Do not let children play with and operate the vacuum cleaner to prevent
accidents.
• Your vacuum cleaner is an electric appliance: it must be used inappro
priately.
Do not leave the operating vacuum cleaner unattended.
• The power must be turned off during cleaning, maintenance, or when in
storage.
• Do not pull the power plug to turn off the vacuum cleaner. Hold the
plastic part of the plug to remove it from the power socket.
• The power supply voltage must correspond to that of the vacuum
cleaner charging voltage.
• Keep the power cord away from sharp objects to prevent it from being
damaged.
• To prevent fires do not immerse the vacuum cleaners in water, do not
expose them to any heating appliances;
• Do not drag the power cord when moving the charging station.
• In the case of the below situations do not use the vacuum cleaner and
send it immediately to the nearest approved maintenance facility if:
-The vacuum cleaner fell and consequently damaged
-The power cord is damaged.
• Stop operating the vacuum cleaner if the suction inlet is blocked to
prevent damages (such as overheating) to the motor or deformations to
the vacuum plastic part occasioned by overheating motor.
Battery charging signal
1. It may take you a long time for charging under the following circum
stances:
a. Room temperature is higher than 30°C;
b. Recharge immediately after the vacuum cleaner has stopped operating.
2. Always recharge the vacuum cleaner after each usage no matter how
long it has been used.
3. Unplug when not charging.
4. When not in use for more than two months the vacuum cleaner should
be disconnected from the power supply. To ensure a longer service life,
the vacuum cleaner must be charged once every two months.
5. The vacuum cleaner or adapter may become hot during charging so
take the necessary precautions to avoid contact.
1 2
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS

Retractable Metal Tube
Main Motor
Floor Brush
④ 2-in-1 Brush
Long Crevice
Filter
Wall Bracket
Adapter
User Manual
①
②
③
⑤
⑥
⑦
⑧
⑨
⑩ User Guide
3 4
PRODUCT OVERVIEWPRODUCT PARTS LIST
Suction Mode Switch Button Power Switch
Charging Port
Battery Indicator
Main Motor
Dust Box
Dust Box
Open Button
Retractable Metal Tube
Push Buttoh
Floor Brush
2
1
1
1
1
1
1
1
1
1
User Guide
1 2
3 4 5
6 7
9 10
8
MODEL:N3/N3S

* The battery must be fully charged before the first usage
as the product is delivered non fully charged for safety.
* Please use the original charger(26.5V). It takes about
4-4.5 hours to fully charge the battery.
* The vacuum cannot be turned on when charging for safety.
Insert the power plug into the charging port; connect the power adapter
with the power supply.
5 6
CHARGING

ASSEMBLY AND COMBINATION
* Attach different accessories for different tasks as illustrated.
* Install vacuum cleaner in the right direction to avoid airflow issues
or not working.
Battery Indicator
Battery Indicator
-Three blue lights flicker successively: Charging
-Three steady lights: Charging complete

7 8
Battery Indicator
Please empty the trash of the dust box
and make sure the amount of the trash
is not over the Max Line.
Rotate the dust box and take it off.
Make sure completely dry before using
again.
Rinse the dust box with cold water.
Open the dust box to empty the trash.
- Three solid green lights: Full Power
- Two solid green lights: Medium Power
- One solid green light: Low Power
- One blinking green light: Needs a Recharge
Suction Mode Switch Button
Power Switch
Model NO.
Rated Voltage
Power Adapter Output
N3
22.2V
26.5V/500mA
Net Weight
Power Adapter Input
Battery Capacity
2.4lb
100-240V,50/60Hz
2200mAh
MAINTENANCE AND CLEANINGUSING
PRODUCT PARAMETER

1 2
3
5
4

2-1 Press the power switch to turn on the vacuum, press twice to change
to the Max mode, and then press it again to turn it off.
2-2 Press the Suction Mode Switch Button to switch the power suction
mode between MAX and MIN.
Push
1. Dust Box Cleaning

2. Filters Cleaning and Installing
Rotate the primary filter and take it off.
Wash them with cold water.
Install the filter to the primary filter.
Take out the filter.
Wait until they are thoroughly dry.
Install all filters to the main motor.
TROUBLESHOOTING
9 10
* If the solutions below cannot solve the problem or the issue you met is not listed,
please contact us via [email protected].
Q1. The vacuum has no suction power
Q2. Running time shortened
Q3. No charging
A1. The dust box is full.
A2. The filters are blocked.
A3. Accessory is blocked.
A1. Battery is not fully charged.
A2. Accessory is blocked.
A3. Ambient temperature is too
high or too low.
A1. Use the wrong adapter.
A2. The outlet is not working.
A3. Ambient temperature when
charging is too high or too low.
1. Please use the original adapter to charge the
battery. It usually takes 4-4.5 hours to be fully
charged.
2. Check and remove the blockage in attachments.
Clean all filters if necessary.
3. Your vacuum should be operated at a suitable
ambient temperature.
1. Please use the original adapter to charge the
battery. The original adapter is 26.5V.
2. Please try another outlet to charge.
3. Charge the battery under the right temperature
environment(5℃-40℃)
Q4. Abnormal noise
A1. The dust box is full.
A2. Accessory is blocked.
1. Clean the dust box after use to prevent build-ups.
2. Check and remove the blockage in attachments.
You could get more operation guidance and maintenance tips on UMLo YouTube:
https://bit.ly/umlo-n3-y2b
1. Clean the dust box after use to prevent build-ups.
2. Clean all filters with cold water and install them
until they are thoroughly dry. Please replace the
white filter if it couldn't filter out dust anymore.
3. Check and remove the blockage in attachments.
1 2
3 4
5 6
Rotate the dust box, then fix it in place.
7
Please Note:
* Never operate the vacuum without all filters.
* Wash filters with cold water when they
are dirty.
* Replace the white filter according to your
use frequency.

11
WARRANTY POLICY
NOTE: THIS WARRANTY TERM GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
Only apply to eligible purchases made directly from the UMLo authorized distributors.
Warranty coverage applies to the original owner and to the original product only and
is not transferable.
If your appliance operates improperly while in use under normal household conditions
within the warranty period, please contact our customer support
[[email protected]] to fill out the warranty form to initiate a warranty claim.
12-month Warranty & Lifetime Customer Support
How to initiate a warranty claim
All rights are reserved by UMLo.
