ACTIVATION AND INSTALLATION
After the activation, you can press the button and should see the data in the UnaConnect
platform
Note:
1. If you use the Plastic Nano SIM, the device will use it for network connection instead of
eSIM.
2. It might take up to 5 minutes if the device is connecting to a new network in a new
region.
3. Be sure to put the casing back.
UnaBell LTE-M User Manual 3

Here are our recommendations for installing the device:
●If the surface is flat and smooth, you can use strong double-sided tape on the bottom of
the device
●If the surface could be bolted or screwed, you can hang the device on the surface
●You can tie a string or rope around the hole on the bottom casing of the device and hang
it on other items (e.g. a doorknob)
●Please always install the device with the top facing outwards and keep it away from
metal or obstacles
UnaBell LTE-M User Manual 4

1. PRODUCT INTRODUCTION
UnaBell LTE-M is a battery-powered smart button that can be configured to
send messages and trigger actions for a variety of applications, which can last
at least 2,000 clicks. The device is also dust and water resistant.
Plug-and-play accessories such as a reed switch or temperature probe can be
purchased as add-ons to the smart button via the 3.5mm audio jack
connectors to detect the opening/closing of doors or measure the ambient
temperature of a space. Seamlessly integrated with UnaConnect, a secure and
reliable IoT Device Management Data Platform, UnaBell LTE-M and its
accessories are easy to install and configure, allowing you collect data for a
variety of use cases immediately.
UnaBell LTE-M User Manual 5

1.1. Features
●Long Battery Life: Minimum 2,000 clicks with replaceable alkaline AA batteries
●Dust & Waterproof: IP54 casing protection (Protected from limited dust
ingress.Protected from water spray from any direction.)
●Local Network: eSIM or Nano SIM can be used based on your local network provider
●Firmware Over-the-Air (FOTA) Update: via LTE-M network to update device firmware
●UnaConnect Compatible: UnaBell LTE-M sends data through the LTE network and is
natively received by the UnaConnect IoT Middleware for data parsing, configuration,
enrichment and connection to end-points
●4 Click Types: Single, double, long, extra-long clicks can be used to configure the trigger
messages from the device
●Battery Monitoring: Heartbeat messages are used to monitor device health
UnaBell LTE-M User Manual 6

1.2. Specifications
Connectivity
Battery
LTE-M Networks
Supported Bands:
2, 3, 4, 5, 8, 12, 13, 17,
20, 28
Type
Replaceable 1.5V Alkaline AA
Batteries
SIM Cards
eSIM or Plastic Nano
SIM
Battery Life
Minimum 2,000 clicks
Module
Sequans Monarch 1
GM01Q
Mechanical
Dimension
117 x 40 x 26.5mm
Weight
78g (without batteries)
Dust & Water Proof
IP54 casing protection
External Connector
3.5 mm audio jack
Casing Color
White top casing & black
Operating
Temperature
-10 to 60 degree Celsius
UnaBell LTE-M User Manual 7

Accessory: Temperature Probe
Accessory: Reed Switch
Dimension
6 mm x 50 mm
Dimension
23 mm x 14.6 mm
Wire Length
2 m
Wire Length
1 m
Operating
Temperature
-55 to 125 degree Celsius
Operating
Temperature
-40 to 125 degree Celsius
Temperature
Range &
Accuracy
± 0.5 degree Celsius between
-10 to 85 degree Celsius
Accessory: 2-Wire
Wire Length
16 cm
Optional Accessories with 3.5mm Audio Jack:
●Reed Switch to detect opening/closing of doors
●Temperature Probe to measure ambient temperature of a space
●2-Wire to connect with other sensors (e.g. pressure sensor)
Smart Modes:
●Event Mode to immediately send a message when the button is clicked. In addition,
this can be used with the reed switch accessory to send messages when a door is
opened or closed
●Timer Mode to count the number of clicks on the button at pre-configured intervals.
In addition, this can be used with the temperature probe accessory or a sensor with
the 2-wire that sends metrics, example a pressure sensor, to send temperature data
at predefined intervals
●Occupancy Mode to send a message at the start and end of a state. For example,
this can be used with the 2-wire accessory to connect to pressure sensors to detect
the state of a seat (occupied/vacant)
UnaBell LTE-M User Manual 8

1.3. Click Action and LED Indicators
While making short, double or long clicks, the LED green light blinks one time immediately
to indicate the button click is recognized.
Please refer to the visuals below for click action and LED feedback information:
●Click Action
Click Types
Description
Single
1 click
Double
2 clicks within 2 secs
Long
1 click and press for longer than 2 secs
Extra Long
1 click and press for longer than 6 secs
●LED Indicators
Orange
Blinking
●Power ON/Activation
●Network Scanning/Searching
SIM Card
●Firmware Upgrade (FOTA)/eSIM
OTA
Green
1 Short ON
Button click detected
Green
Slow Blinking
Network Connecting
Green
Fast Blinking
Data Transmitting
Green
1 Long ON
●Data Transmission Completed
●Communication Success
Red
1 Long ON
●Data Transmission ERROR
●Communication Failed
●Network ERROR
Red
Fast Blinking
Low Battery
UnaBell LTE-M User Manual 9

1.4. Monitor and Configure the Product
The UnaConnect platform can help you monitor all the data received and configure the
behavior of your devices
1. Login https://console.unaconnect.io/ with the credential provided by UnaBiz
2. Click on the device group containing your devices
3. Click on ‘Devices’ on the left navigation bar
4. Click on the device for data information and configuration
●Sensor Data
The Sensor Data tab is the main tab that displays all the messages containing raw data that
have been sent from the device
In the Graph section:
●Select the data types that you want to visualize in the Metrics dropdown menu
●Enter the Tick Total value to change the scale of the horizontal axis
●If you want to replace null value by other values, click on the Null Data checkbox and
enter the value to replace null
In the Device data section:
●The table displays the timestamp of each message, the data contained in each message
that have been processed or translated by UnaConnect, and the raw data in the message
sent from the device
●The data and raw messages are based on the different device types, modes and events
that triggered each of the messages to be sent from the device
●Export for a CSV file of all the sensor data messages sent from the device
UnaBell LTE-M User Manual 10

●Event Data
The Event Data tab displays all the messages containing descriptions of the events that are
device-related such as downlink messages, downlink acknowledgement messages, Sigfox
network error messages (example, a break in sequence message) along with the timestamp
of these events
UnaBell LTE-M User Manual 11

2. DEVICE OPERATION
2.1. Glossary
Uplink (UL)
An uplink message is sent from the device to the cloud platform
Downlink (DL)
A downlink message is sent from the cloud platform to the device
Timer Mode
The device counts the number of clicks detected and sends the
count in an uplink message at pre-configured intervals
Event Mode
The device immediately sends an uplink message when a click is
pressed
Heartbeat Mode
The heartbeat mode can be selected along with Event or Occupancy
modes. A heartbeat message is sent periodically by the device to
inform the user on battery life, changes in configuration etc
Occupancy Mode
The device sends an uplink message as it identifies the state has
changed between Open or Closed States
Open State
The state when the external connector is in the open state, for
example: the reed switch has the magnet away from it = open
Closed State
The state when the external connector is in the closed state, for
example: the reed switch has the magnet next to it = closed
Debounce Timer
A countdown timer used in occupancy mode which would be reset
every time the external connector detects a state change to
distinguish if a state is in open or closed states
Occupancy Duration
The period of time from which the debounce timer starts to
countdown so if no state change is detected past the occupancy
duration (and the timer countdown reaches 00:00) then the device
identifies the space as open
External I/O
External I/O (Input/Output) are the sensors or accessories that can
be plugged in to communicate with the device
Edge Mode
In edge mode, the device can detect the status change of
accessories
Pulse Mode
In pulse mode, the two-wire accessory can be used as an extension
Rising/Falling Edge
It shows the status of accessories:
Reed Switch: the magnet is away from it/next to it
Two Wire: disconnected/connected
UnaBell LTE-M User Manual 12

Full-band Scan
This command is to search the network which has better
connectivity
eSIM OTA
This command is to update the contract or information of eSIM
FOTA
This command is to update the firmware via LTE-M network
UnaBell LTE-M User Manual 13

2.2. Message Type
2.2.1. Downlink Messages
A downlink message is sent from the UnaConnect platform to UnaBell LTE-M; the device
initiates the downlink process by sending an uplink message with current device information
to the cloud platform for downlink request, when the cloud platform receives the downlink
request, it will send a downlink message to update the latest configuration set in
UnaConnect to the device.
All the configurations for UnaBell LTE-M can be defined on the UnaConnect platform. The
Downlink Interval (DI) defines how often the device performs a downlink process with the
cloud platform to update the configurations. An immediate downlink message can also be
manually triggered by the user by applying an extra long click to the button (1 click and
press for longer than 6 secs).
Parameter
Default Configuration
Description
Operation mode
Event
There are 6 modes available:
●Timer
●Event
●Event + Timer
●Event + Heartbeat
●Occupancy
●Occupancy + Heartbeat
Uplink Frequency
24 messages per day
This defines the frequency of messaging in
24 hours and is only utilized in Timer and
Heartbeat modes.
The ranges are:
●1 timer message in one day (periodic
24 hours)
●2 timer messages in one day (periodic
12 hours)
●3 timer messages in one day (periodic
8 hours)
●4 timer messages in one day (periodic
6 hours)…
●144 messages in one day (periodic 10
minutes)
Downlink Interval
24 hours
This defines the time interval for the device
to initiate the downlink process.
Minimum = 6 hours
Maximum = 336 hours (2 weeks)
UnaBell LTE-M User Manual 14

Parameter
Default Configuration
Description
Occupancy
Duration
0 second
In Occupancy Modes, this sets the period of
time from which the debounce timer starts
to countdown so if no state change is
detected past the occupancy duration (and
the timer countdown reaches 00:00) then
the device identifies the state that has
changed. For example, if this is set at 10
secs, then the device will only change state
after it detects the same state for longer
than 10 secs.
Command
No command
There are 4 commands available:
●No command
●Full-band scan
●eSIM OTA
●FOTA
Config external
I/O detection
mode
Disable, no external I/O
There are 4 external I/O detection modes
available:
●Disable, no external I/O
●Edge
●Pulse
●Temperature Sensor
Detection Delay
Time
0 second
Delay on the detection of the triggers in
edge detection mode.
Unit: seconds
Minimum = 0 (disable detection delay)
Maximum = 7200 seconds
Event mask
All event triggers enabled
This defines the detection types
(rising/falling edge) and click types that can
trigger the device to send messages. The
options are:
●Rising edge or occupied
●Falling edge or vacant
●Short click
●Long click
●Double short click
●Extra-long click
UnaBell LTE-M User Manual 15

2.2.2. Uplink Messages
UnaBell LTE-M supports 6 operation modes, each with its corresponding uplink message
type, that could be configured by the user on the UnaConnect platform:
●Event
●Timer
●Event + Timer
●Event + Heartbeat
●Occupancy
●Occupancy + Heartbeat
Click Types
Description
Single
1 click
Double
2 clicks within 2 secs
Long
1 click and press for longer than 2 secs
Extra Long
1 click and press for longer than 6 secs
UnaBell LTE-M User Manual 16

2.3. Operation Modes
2.3.1. Event Mode and Messages
In event mode, the device sends an uplink message immediately each time a click type is
applied on the button.
For example, this mode can be used as a maintenance call to repair equipment on a
production line, an emergency button to call for assistance in an elderly home or a service
call for cleaning in a bathroom.
The uplink message for Event mode contains the following data:
●Message type: Event
●Sequence number: counter from 0 to 4095
●Enabled detection type: Rising edge, Falling edge, Single, Double, Long, Extra Long
Note: If the Temperature Sensor is connected as the external connector, then the current
temperature will be sent in event messages when the button is pressed
2.3.2. Timer Mode and Messages
In timer mode, the device logs a count of the number of clicks for each click type over a
period of time and sends an uplink message at an uplink frequency configured on the
UnaConnect platform.
For example, this mode can be used to count the number of maintenance or service calls
sent from the buttons installed at various points of a facility during a period of time to help
with resource allocations and operations.
The uplink message for Timer mode contains the following data:
●Message type: Timer
●Sequence number: counter from 0 to 4095
●Uplink frequency: from 1 to 144 messages per 24 hours
●Summary of number of clicks detected: Edge, Single, Double, Long, Extra Long
Note: If the Temperature Sensor is connected as the external connector, then the
temperature values will be sent in timer messages
UnaBell LTE-M User Manual 17

2.3.3. Event + Timer Mode and Messages
The event + timer mode combines the two modes so that it sends an uplink message
immediately each time a click type is applied on the button, and logs a count of the number
of clicks for each click type over a period of time and sends an uplink message at an uplink
frequency configured on the UnaConnect platform.
The uplink message for Event + Timer mode contains the following data:
●Message type: Event + Timer
●Sequence number: counter from 0 to 4095
●Uplink frequency: from 1 to 144 messages per 24 hours
●Summary of number of clicks detected: Edge, Single, Double, Long, Extra Long
2.3.4. Event + Heartbeat Mode and Messages
In event + heartbeat mode, the device sends an uplink message immediately each time any
of the click type is applied on the button, and sends a heartbeat message at an interval
configured on the UnaConnect platform.
The heartbeat message contains battery voltage data to help monitor the batteries and
manage the device lifecycle in your operations.
The uplink message for Event + Heartbeat mode contains the following data:
●Message type: Event + Heartbeat
●Sequence number: counter from 0 to 4095
●Battery voltage: remaining voltage measured in mV
●Enabled detection type: Rising edge, Falling edge, Single, Double, Long, Extra Long
UnaBell LTE-M User Manual 18

2.3.5. Occupancy Mode and Messages
The occupancy mode sends an uplink message at the start and end of a state. In
Occupancy Modes, a debounce timer counts down from a preconfigured occupancy
duration and if no state change is detected past the occupancy duration, then the device
identifies the state that has changed.
For example, if the occupancy duration is set at 10 secs, then the device will only change
state after it detects the same state for longer than 10 secs. This mode can be used with
the 2 wire accessory to connect to pressure sensors to detect the state of a seat
(occupied/vacant).
The uplink message for Occupancy mode contains the following data:
●Message type: Occupancy
●Sequence number: counter from 0 to 4095
●Sensor status: status of external I/O connector configured as Pulse or Edge mode
2.3.6. Occupancy + Heartbeat Mode and Messages
The Occupancy + Heartbeat mode sends an uplink message at the start and end of a state,
and sends a heartbeat message at an interval configured on the UnaConnect platform.
The uplink message for Occupancy + Heartbeat mode contains the following data:
●Message type: Occupancy + Heartbeat
●Sequence number: counter from 0 to 4095
●Battery voltage: remaining voltage measured in mV
●Sensor status: status of external I/O connector configured as Pulse or Edge mode
UnaBell LTE-M User Manual 19

2.4. External I/O
To fulfill an even wider range of applications and use cases, UnaBell LTE-M may also act as a
battery-powered gateway when used with its corresponding plug-and-play accessories in
addition to the embedded button on the device. The configuration in UC should be updated
to the accessory that is plugged into the device.
The accessories can be plugged to UnaBell LTE-M via 3.5mm audio jack connectors and their
main use cases are:
●Reed Switch Accessory: detect opening/closing of doors
●Temperature Probe Accessory: measure ambient temperature of the surrounding space
●2 Wire Accessory: connect with other sensors (e.g. pressure sensor)
*You can put the rubber plug inside the device casing.
2.4.1. Reed Switch Accessory
When the reed switch accessory is connected to UnaBell LTE-M, the same operation mode
and configurations for the embedded button is applied to the reed switch external I/O
connector, and the recommended detection mode for the external I/O is edge detection.
An example scenario is that the reed switch sensor is connected to UnaBell LTE-M to detect
the opening and closing of a door. The edge detection in event mode detects the instance
that the magnets are closed or separated and sends a message immediately when the door
is opened and closed.
UnaBell LTE-M User Manual 20
