UNI MAX User manual

T82ALERT02-R

2
02
43
03
For best performance, please insert the alerting device as shown below.
The position as picture 2- picture 8 are not suggested.
1

65
04
87
05

Tone Alert and Ring Tone Amplifier
06 07
Thank you for purchasing Unication’s product, UNI MAX.
UNI MAX will always alert you that your pager has been paged. Its high volume audible alert will
always catch your attention. We hope you enjoy using it.
Two retaining screws are for
installing the dock adaptor.
Other supported products:

Tone Alert and Ring Tone Amplifier
08
1. Operation with you Unication Pager:
UNI MAX can be used with pagers or other alerting devices such as cell phones.
For best operation. make sure to place the alerting device into its audible tone alert mode.
or the alert may not be detected.
For best operation, select the correct dock adapter to match your Unication pager.
Then simply set the pager into UNI MAX as shown in the illustrations below.
Before inserting the right
pager type dock adapter,
please be sure to remove
the screws which are fitted
inside the socket.
After inserting the correct
dock adapter, please
remember Using the
provided screws to secure it.
09
2. Operation with your Cell Phone:
Your Uni Max is also designed to work with most of the popular models of cellular phones.
Please turn the cell phone to any audible alert mode and then place into the Uni Max.
3. Feature and Function Locations
Phone
Alert time setting
Alert tone selector
Reset button and
visual alert
Volume control
For better performance,
ensure that the cell phone is properly
positioned to detect the alert.
This may require the cell phone to be set
upside-down.

10
Your Uni MAX can use three separate power sources. Using the wall transformer supplied with the unit,
installing the optional rechargeable battery pack, or standard AA alkaline batteries only.
The Uni MAX will operate normally from the wall transformer, but if the main power is interrupted, the Uni
MAX will automatically switch over to the rechargeable batteries.
NOTE:
(1) The Uni MAX will only recharge the optional Unication rechargeable battery pack.
You can use rechargeable batteries and still leave the wall transformer connected.
(2) Do not use standard AA batteries with the wall transformer connected.
Charging Uni MAX
Tone Alert and Ring Tone Amplifier
11
1. Connecting to the Wall Transformer
2. Installing the Rechargeable Battery Pack
You can use rechargeable battery pack by itself. You can also connect the wall
transformer, so the rechargeable battery pack is used as a backup power source. Before
installing the rechargeable battery pack, you can remove the wall transformer if needed.
Connect the power cable to the Uni MAX and then plug the AC transformer into the
electrical outlet (90-240VAC).
When the Uni MAX is powered, the GREEN power LED will illuminate.

12
Tone Alert and Ring Tone Amplifier
Step1: Remove the retaining screws in the battery door and then lift off the battery compartment cover.
Step2: Then simply insert the pin connector from Battery Pack into the mating connector inside
the battery compartment of the Uni MAX unit.
Step3: Reinstall the battery cover and screws, and then plug the wall transformer in to an AC receptacle
if needed. After the batteries are inserted, the GREEN Power LED will automatically light.
NOTE:
To avoid the risk of electrical shock, DO NOT alter the charging or use batteries other than
the battery pack intended for this unit.
Socket
Step3: Reinstall the battery cover and screws. After the batteries are inserted,
the GREEN Power LED will automatically light and flash.
NOTE:
For proper operation, please unplug the wall transformer before using the alkaline batteries. 13
3. Installing the Alkaline Batteries
You can use 3 standard AA alkaline batteries To power the device.
Step1: Remove the retaining screws in the battery door and then lift off the battery
compartment cover.
Step2: Observing the correct polarities, insert the AA batteries into
the Uni MAX battery compartment as shown below.

Tone Alert and Ring Tone Amplifier
14
3. LED Indicator
Action With wall transformer Meaning
Green Yes The main power status is normal.
Orange Yes Rechargeable batteries are low and charging.
Red Yes Rechargeable batteries have problem,and can’t
be charged.
Flashing Green No The batteries are normal.
Flashing Red No The batteries are low.
None No No power
The LED indicator will help you to identify the status of Uni MAX.
15
Operation
1. Alert Tone Selection
There are ten alert tone types to choose from. Follow the directions below to sample and then to
select an alert.
(1) Listening to current tone alert setting:
Depress then release the Alert Tone Setting Button to listen to the current alert type.
(2) Listen to the next alert tone type:
Depress then release the alert selector switch again and the next alert type will sound.
(3) Selecting your alert tone:
When sampling through through the alert tones, press and hold the Alert Tone Setting Button
once again until a short beep is heard. The current alert type has now been selected.
press

16 17
2. Volume Setting
1.press 2.press & turn
Press and turn the volume knob to set an appropriate alerting volume level.
When an alert has been detected, the UniMax will begin the alerting cycle at a low volume and
increase to your setting over the time period selected in the following step.

18
4. Reminder Visual Alert
The Reset Button will keep flashing after an after an alert until it is pressed.
5. Stopping the Alert
The alert stops automatically when the selected alert time (1 or 3 minutes) has expired
You may also press the reset button to stop the alert.
6. Operation of the Optional Battery Pack
Battery pack charging time : 10 hours maximum from a completely discharged condition.
19
(Ordering part #: T65AMP001 )
9.6 X 7.8 X 5.1 cm
(Ordering part #: T65AMP001 )
(Not including battery)
